Hunter Products D8010 User manual

Styles and colours may vary.
SUITABLE FOR AGES 3 YEARS +
MAXIMUM USER WEIGHT 30KG
ONLY 1 RIDER AT A TIME
For after sales service, replacement parts or
general enquiries please contact:
Web: www.electricrideon.com.au
Toll Free Service Phone: [phone]
Email: [email protected]
Item No.: 8453
Model No.: D8010
INSTRUCTION MANUAL
Minnie Mouse 6 volt Car

Contents
Before First Use: .................................................................................... 2.
Product Specifications: ........................................................................ 3.
Safety Precautions & Warnings: ....................................................... 4-7.
Parts Description: ...................................................................................8.
Assembly Instructions:..................................................................... 9-10.
Direction of use:....................................................................................11.
Charging Instructions: ....................................................................... 12 .
Reset Fuse: .......................................................................................... 13.
Maintenance: ....................................................................................... 14.
General Care: ........................................................................................15.
Troubleshooting: ............................................................................16- 17.
Customer Service Information: .......................................................... 18.
Warranty: .............................................................................................. 19.

This Instruction Manual contains important safety information as well as assembly,
use and maintenance instructions. This car must be assembled by an adult who
has read and understands the instructions in this manual. Keep the packaging
away from children and dispose of properly before use.
Keep this manual for future reference.
Before First Use: 2

3 Product Specifications:
For after sales service, replacement parts or general enquiries please contact:
Web: www.electricrideon.com.au
Toll Free Service Phone: [phone]
Email: [email protected]
SPEED
BATTERY
SPEC.
CHARGING SPEC
30 kg
3 km/hr
6V 7AH SLA
AC100-240V, 50Hz(input)
DC8V 800mA(output)
POWER MODE
CHARGING TIME
FUSE SPEC
Rechargeable
8-12 hours(charge)
1-2 hours (use)
EXTERNAL
DIMENSIONS
MAX WEIGHT
LIMIT
7 amp Thermal FuseAGES
1070 x 651 x 525 mm
3+ years

Safety Precautions & Warnings 4
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
WARNING!
The following safety hazards may result in serious injury or death to the user of the
vehicle Minnie Mouse 6v Car Ride-on:
This product contains small parts that are for adult assembly only. Keep small
children away when assembling. Remove and dispose of all protective material and
poly bags before assembly. Be sure to remove all packaging materials and parts
from underneath the car body.
complies with Australian Standard AS/NZS 2063:2008.
Battery posts, terminals and related accessories contain lead and lead compounds
(acid) chemicals that are toxic and corrosive. Never open the battery.
Body parts such as hands, legs, hair and clothing can get caught in moving parts.
Never place a body part near a moving part or wear loose clothing while using the
vehicle. Always wear shoes when using the vehicle.
Using the vehicle near streets, motor vehicles, drop-offs such as: steps, water
(swimming pools) or other bodies of water, sloped surfaces, hills, wet areas,
accident.
Always use the vehicle in a safe, secure environment with continuous adult
supervision. Never leave the child unattended.
Using the vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand or
Using the vehicle in an unsafe manner. Examples include but are not limited to:
Pulling the vehicle with another vehicle or similar device
Allowing more than one rider
Pushing the user from the back
Traveling at an unsafe speed
Always use common sense and safe practices when using the vehicle. Different type
of batteries or new and old batteries are not to be mixed.
This toy is unsuitable for children under 3 years due to its maximum speed.
Battery charger, electric wire plug enclosure and other parts should be periodically.
•There are additional hazards of using the toy in areas other than private grounds.
check for damage, if have damage, need to repair before use.
Not to be used in trafc
•

5 Safety Precautions & Warnings (cont.)
WARNING!
Age Range 3 to 7 years
Weight Range No more than 30kg
Before using the vehicle the child should understand the vehicle controls and safety
issues. They must also demonstrate the capability to handle the vehicle and
operate its controls. It is the responsibility of the adult to educate the child and
supervise use of the vehicle.
Read the following safety warnings to any child using the vehicle:
•
•
•
•
•
•
•
•
Only use the vehicle when an adult is present to watch (supervise).
Adult assembly requited.
•Always sit in the seat when using the vehicle.
•Keep your hands, hair and clothes away from moving parts.
•Always wear shoes when using the vehicle.
•Only one rider is allowed at a time on the vehicle.
•Children under three years old cannot use the vehicle.
•Only drive on level ground.
•Do not go near water, drop-offs or up and down steep slopes.
• gravel.
•Do not drive the vehicle on streets or near cars.
PREVENT INJURIES AND DEATHS:
NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when
child is in vehicle. Direct adult supervision is REQUIRED.
NEVER use in roadways, near cars, on or near steep inclines or steps,
swimming pools or other bodies of water.
ALWAYS wear shoes.
ALWAYS sit on the seat.
RISK OF FIRE. Do not bypass.
NEVER allow more than one (1) rider in the vehicle.

Safety Precautions & Warnings (cont.) 6
• Contact or exposure to battery leakage (lead acid) may cause serious injury.
If contact or exposure occurs immediately call your physician. If the chemical is
on the skin or in the eyes, flush with cool water for 15 minutes. If the chemical
was swallowed, immediately give the person water or milk. Do not give water or
milk if the patient is vomiting or has a decreased level of alertness. Do not induce
vomiting.
The following safety hazards may result in serious injury or death to the user of the
vehicle:
WARNING!
•
•
• Explosive gases are created during charging. Charge the battery in a well
ventilated area. Do not charge the battery near heat or flammable materials.
• Contact between the positive and negative terminals may result in fire or explosion.
vehicle direct contact between the terminals. Picking up the battery by the wires or
charger can cause damage to the battery and may result in a fire. Always pick up
the battery by its case or handles.
• Liquids on the battery may cause fire or electric shock. Always keep all liquids
away from the battery and keep the battery dry.
Use of a battery or charger other than the supplied 6v rechargeable battery and
charger may cause a fire or explosion. Only use the supplied 6v rechargeable
battery and charger with the vehicle.
Using the 6v rechargeable battery and charger for any other product may result in
over heating, fire or explosion. Never use the 6v rechargeable battery and charger
with another product.

7 Safety Precautions & Warnings (cont.)
WARNING!
WARNING!
•
Important! Before using the vehicle for the first time the battery needs to be charged for
a full 16 hours. Only an adult who has read and understands the following safety
warnings should handle, charge or recharge of the battery (see Maintenance).
• Tampering or modifying the electric circuit system may cause
or explosion and permanently damage the system. Exposed wiring, circuitry
in the charger may cause electric shock. Always keep the charger housing
closed.
Battery posts, terminals and related accessories contain lead and lead
compounds (acid), chemicals and are toxic and corrosive. Never open the
battery.
• Non-rechargeable batteries are not to be recharged;
• Batteries are to be inserted with the correct polarity;
• Exhausted batteries are to be removed from the toy;
• The supply terminals are not to be short-circuited.
• Rechargeable batteries are only to be charged under adult supervision;

Parts Description 8
Parts
descrip on
Quan ty Parts
descrip on
Quan ty Parts
descrip on
Quan ty
Front
wheel
2 1 1
Rear
wheel
2
Steering
wheel
1
3
1 1
2
Seat
Windshield
Washer Rearview
mirror
Instrucon
Manual
Charger
4
2
7
1
3
3
7
6
3
5
8
9
Styles and colours may vary.
SUITABLE FOR AGES 3 YEARS +
MAXIMUM USER WEIGHT 30KG
ONLY 1 RIDER AT A TIME
FORWARD GEAR ONLY
For after sales service, replacement parts or
general enquiries please contact:
Web: www.electricrideon.com.au
Toll Free Service Phone: [phone]
Email: [email protected]
Item No.: 55180
Model No.: ZP3999B
INSTRUCTION MANUAL
Minnie Mouse 6 volt Car

9 Assembly Instructions
Steering wheel
1: Install the steering wheel:
Remove the bolt and nut from the steering wheel
and t over the steering rod.
Place bolt and nut back through steering wheel
and rod to x in place.
2: Installing the windshield and rear view mirrors.
Clip the wind shield into the recess holes on the dash.
Clip the rear view mirrors into the recess holes.
4: Install the rear right wheel:
Make sure at washer is tted to rear axle
Slide the rear wheel onto the axle & click into place.
3: Install the rear left wheel:
Slide the rear wheel onto the rear axle ensuring
it is aligned with gearbox and click both rear wheels
into place.

Assembly Instructions 10
5: Install the front left wheel:
Make sure at washer is tted to front axle
Slide the front wheel onto the axle ensuring
it is clicked into place.
6: Install the front right wheel:
Make sure at washer is tted to front axle
Slide the front wheel onto the axle ensuring
it is clicked into place.
7: Connect the Fuse & Install Seat
Connect the loose cable to the small thermal fuse
as per image 7.
Insert the clip of the seat into the recess hole.
Turn the locking knob on the seat to lock into position.
7
6
Fuse
connector

11 Directions of use
Forward & Back Switch
pedal switch
power switch
Opening & Closing Doors
Pull the door handle inside the door to open.
Reverse this step to close the door.
Driving the Vehicle
Turn the car on via the power button.
Select forward or back from the gear switch.
Step on the foot pedal to operate the car.
Release your foot to stop the car.

Charging Instructions 12
To Charge the Battery:
1: Ensure the car is stopped and turned off.
2: Plug the round charge pin into the charge port located below the front of the driver seat.
As per image below.
3: Plug transformer into a 240 V outlet.
NOTE: First time charge should be for 16 hours
Subsequent charges should be 8-12 hours.
Do not charge for more than 18 hours.
Charging Port
Please note car will not work while charger is connected.
Disconnect charger from car before attempting to operate.

13 Reset Fuse
Thermal Overload Fuse:
This car is fitted with a thermal overload fuse. If the car is overloaded the fuse will cut off
power to the car for 10-20 seconds before resetting itself.
To avoid the fuse activating please
follow the below guidelines.
1: Maximum user weight is 30kg
2: Do not tow or overload car with weight.
3: Do not get the car or its electric components wet.
4: Do not alter the cars circuitry or construction.

Maintenance 14
Important Battery and Charger Information
Only an adult who has read and understands the safety warnings may
handle and operate the battery and battery charger. Keep away from
children.
Charge the battery for 16 hours before using the vehicle for the first
time.
Charge the battery immediately after each use. Charge for at least 8-12
hours, but no more than 18 hours.
Charge the battery at least once a month, even if the vehicle is not used
or stored.
Never leave the battery in a discharged condition.
Connect the terminal of the battery and charger, then plug the charger
into a 240V AC outlet.
It is normal for the charger to heat slightly. If the charger rises above
71°C / 160°F, disconnect the charger and call Customer Service for
assistance.
Keep the charger away from water or excessive moisture to prevent
short-circuiting.
Only use the charger speci ed with the original item. Do not charge the
battery with any other charger.
Do not attempt to recharge non-rechargeable batteries with the original
charger.
Do not replace the battery with any other battery, or the warranty
will be voided.
Remove damaged batteries from the car immediately. Recycle or
dispose of the used batteries responsibly.
Do not short circuit the supply terminals.
Do not leave the battery connected in the vehicle for extended periods
of time when the vehicle is not being used. Disconnect the battery
connector from the engine connector before storing.
The vehicle is equipped with a thermal fuse to protect the electric
circuit. If the vehicle cuts out, turn the vehicle off and on to reset.

15 General Care
Regularly inspect all vehicle parts to ensure they are in good working
condition.
Regularly inspect the charger, cord, plug, and other related parts for
damage.
Remove any damaged parts and immediately contact Customer Service
for replacement parts.
DO NOT operate the vehicle if there are any damaged parts.
Carefully clean the vehicle with a damp cloth and mild soap. Do not
get water in or near any electrical parts. Do not wash the vehicle with a
hose.
Store the vehicle indoors or use a tarp to cover it. Keep away from
stoves, heaters, or other sources of heat.

16 Troubleshooting Guide
Problem Potential Cause Solution
Vehicle does not run Battery is low Recharge the battery
Thermal fuse tripped Reset fuse
Snap pins are loose Tighten snap pins
Loose wires or loose
connectors
Ensure the battery connectors
are securely attached. If wires
are loose, contact Consumer
Service for repairs
Battery is dead Call Customer Service for
replacement battery
Electrical system is
damaged
Call Customer Service for
repairs
Motor is damaged Call Customer Service for
repairs
Vehicle only runs for a
short time
Undercharged battery Ensure a secure connection
when the battery is
recharging. Recharge for at
least 8-12 hours
Overcharged battery Never charge the battery for
more than 18 hours
Battery is old Replace battery
Vehicle runs slowly Battery is not fully
charged
Ensure a secure connection
when the battery is recharging
Battery is old Call Customer Service to
order replacement battery
Too much weight on
vehicle
Reduce weight on vehicle
(30kg max)
Harsh conditions Operate the vehicle on level
ground and safe surfaces
Completely read through the manual and troubleshooting guide before
contacting Customer Service.

17 Troubleshooting Guide
Problem Potential Cause Solution
Vehicle needs a push to
start
Loose wires or loose
connectors
Ensure the battery connectors
are securely attached. If wires
are loose, contact Consumer
Service for repairs
“Dead spot” on motor A “dead spot” means
electricity is not being
delivered to the terminal.
Contact Consumer Service for
repairs
Dif culty shifting Attempting to shift while
vehicle is moving
Stop the vehicle before
shifting
Motor or gear box
making grinding noises
Motor or gear damage Contact Consumer Service for
repairs
Battery will not recharge Charger is not plugged in Plug in the charger to a
functional wall outlet
Charger is not working Call Consumer Service for a
replacement
Loose connector or loose
adapter
Check that the connectors are
securely plugged in to each
other
Battery makes bubbling
noise while recharging
This is normal No action required
Charger is warm This is normal No action required

Service and Repairs 18
If your product requires service, repairs or replacement parts, please visit
us online at www.electricrideon.com.au
Or contact us at:
Toll Free Service Phone: [phone]
emall: [email protected]
Hours: 9.00 AM - 5.00 PM (AEST), Monday - Friday

19 Warranty
One-Year Limited Warranty
Hunter Products warrants that your Minnie Mouse 6v Car will be free from defects in
materials and workmanship for the vehicle (except for the 6-volt battery) for a
period of 12 months, from the date of purchase. This warranty only applies where
the product is completely and correctly assembled and used in accordance with all
accompanying recommendations and users instructions. This warranty is in addition
to your rights under the Australia Consumer Law.
Hunter Products , at its option will provide you with a refund or replacement parts for
this product if the
Minnie Mouse6v Car becomes defective within the warranty
period. Hunter Products will bear the reasonable expense of claiming the warranty.
This warranty will no longer apply where the defect is a result of an accident, misuse,
abuse, neglect or other causes not arising out of defects in materials or
workmanship, nor does it cover damages arising out of damages arising out of
service by other than an authorised service person.
Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and
compensation for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Please retain your receipt as proof of purchase and contact Hunter Products for
further assistance on how to process any warranty claims.
Business name: Hunter Products Pty Ltd
Business address: Level 2, 424 Warrigal Road, Moorabbin VIC 3189, Australia
Toll Free Phone: [phone] (Monday to Friday 9.00 to 5.00pm AEST)
Email address: [email protected]
Edition: 20170817
