hygena 503/7968 Configuration guide

HYGENA LIDO GLASS TABLE AND 4 CHAIRS
Assembly Instructions - Please keep for future reference
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Issue 1 - 13/10/15
Dimensions
Width - 42cm
Depth - 49.5cm
Height - 96cm
503/7968
487/6821
hygena

Care and maintenance
Handy Hints
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• Do not stand on the chair.
• Do not use this chair as step
ladder.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the
bolts.
• Regularly check and ensure
that all bolts and fittings are
tightend properly.
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product, this
could cause damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Unit weight: 4.4 kgs.
• Maximum safe weight of user:
110kgs.
1
Safety and Care Advice
Important - Please read these instructions fully before starting assembly

2
Front leg
(41 x 44.5 x 1.5cm)
1Left leg
(43 x 39.5 x 4cm)
2Right leg
(43 x 39.5 x 4cm)
3
Back rest
(35.5 x 67 x 7cm)
4Seat
(42 x 42 x 2cm)
5
Components - Parts
Please check you have all the parts listed below
If you have damaged or missing components, call the
Customer Helpline: Argos = 0345 640 0800
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
Components - Fittings
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly of 1 chair. In some cases more
fittings may be supplied than are required.
M6 x 22mm Bolt x 4 M6 x 12mm Bolt x 8
A
Allen Key x 1
CB

Attach the left leg and
right leg onto the front
leg as shown using
bolts . Then tighten
bolts using allen key .
3
Assembly Instructions
Step 1
Step 2
Attach back rest onto
left leg and right leg
as shown using bolts .
Then tighten bolts
using allen key as
shown.
B
B
B
B
B
B
2
2
2 3
4
3
1
3
2
4
3
3
1
1
3
A
A
A
A
A
A
C
B
A
C

4
Assembly Instructions
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
A
A
A
A
A
5
2
2
3
Step 3
Place the seat face
down on a raised
protected surface.
Position the chair frame
on the seat as shown
and attach through holes
on the left and right
legs using bolts . Then
tighten bolts using allen
key .
Carefully turn the chair
upright.
Assembly is complete.
5
5
2 3
A
C

HYGENA LIDO GLASS TABLE AND 4 CHAIRS
Assembly Instructions - Please keep for future reference
Issue 1 - 13/10/15
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
503/7968
487/6821
Dimensions
Width - 120cm
Depth - 80cm
Height - 75cm
hygena

1
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product, this
could cause damage.
• Assemble the item as close to
its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
• Unit weight: 24 kgs.
Safety and Care Advice
Important - Please read these instructions fully before starting assembly
Care and maintenance
Handy Hints
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• Do not stand on the product.
• Always lift the product when
moving it around. Never drag.
• Please note wood is a natural
material, some slightly colour
and grain variation and natural
marks will be present.
• This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
• Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the
bolts.
• Regularly check and ensure
that all bolts and fittings are
tightened properly.
Glass Safety
• Keep these instruction for future reference.
• Imported by:
• If the glass is chipped or broken,stop using the
product and consult the Manufacturer or Supplier.
• Batch No:
Arogs ltd
489-499 Avebury Boulevard.
Saxon Gate West.
Central Milton Keynes.
Mk92nw
• Date of Manufre:
• Type of glass used: 7mm toughened glass
Warnings
(a) Do not place very hot or very cold items on the glass surface(s) unless adequately thick mats are
used to prevent such items from coming into contact with the glass.
(b) Do not sit or stand upon the glass surface.
(c) Do not use the glass as a chopping surface. Do not strike the glass with hard or pointed items.
(d) When cleaning glass panels use a damp cloth or leather with washing up liquid or soft soap if
necessary, do not us washing powders or any other substance containning abrasives since these
substances cscratch glass.

2
Components - Parts
Components - Fittings
Please check you have all the parts listed below
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
M8 x 45mm Bolt x 8 M6 x 8mm Bolt x 4
A
Flat washer x 8
CB
Ruler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
If you have damaged or missing components, call the
Customer Helpline: Argos = 0345 640 0800
Spring washer x 8 Allen Key x 1
D E
Adhesive pad x 4
F
Table frame
(118.5 x 78.5 x 4cm)
1Table leg x 4
(74 x 3.8 x 3.8cm)
2Glass top panel
(120 x 80 x 1.7cm)
3

Carefully turn the table
frame upright.
Remove backing from
adhesive pads F and
carefully paste on the
table frame as shown.
Then attach the glass top
panel using bolts .
Tighten bolts using allen
key .
Note:
Take extra care
when handling
and securing the
glass table top. At
least 2 people
required are
required to carry
the glass top.
Assembly is complete.
3
Assembly Instructions
Step 1
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Place the table frame
upside down on a flat
protected surface.
Attach the legs onto
the table frame as
shown using bolts ,
spring washers and
flat washers . Tighten
bolts using allen key .
Step 2
3B
E
D
C
E
A
1
1
2
2
2
2
3
1
1
2
A
D
C
A
D
C
A
D
C
ADC
ADC
A
D
C
A
D
C
B
B
B
B
F
F
F
F
A
A
D
D
C
C
A
D
C
2
1
1
1
F
3
F
