CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manu-
al for future reference.
Model No. NTBE1076.0
Serial No.
Write the serial number in the
space above for future reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT THE
STORE; please contact
Customer Care.
IMPORTANT:You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-888-825-2588
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.nordictrackservice.com
USER’S MANUAL
Serial Number Decal
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
V

2
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PART IDENTIFICATION CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
EXPLODED DRAWING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
TABLE OF CONTENTS
WARNING DECAL PLACEMENT
The decals shown here have been applied in
the locations shown. If a decal is missing
or illegible, call the telephone number on
the front cover of this manual and
request a free replacement decal. Apply
the decal in the location shown. Note: The
decals may not be shown at actual size.
NordicTrack is a registered trademark of ICON IP, Inc.

3
1. Before beginning any exercise program, con-
sult your physician. This is especially impor-
tant for persons over the age of 35 or per-
sons with pre-existing health problems.
2. Read all instructions in this manual and all
warnings on the weight bench before using
the weight bench. Use the weight bench only
as described in this manual.
3. It is the responsibility of the owner to ensure
that all users of the weight bench are ade-
quately informed of all precautions.
4. The weight bench is intended for home use
only.Do not use the weight bench in any
commercial, rental, or institutional setting.
5.
Keep the weight bench indoors, away from
moisture and dust. Place the weight bench on
alevel surface, with a mat beneath it to pro-
tect the floor or carpet. Make sure that there
is enough clearance around the weight bench
to mount, dismount, and use the weight
bench .
6. Keep children under age 12 and pets away
from the weight bench at all times.
7.
Inspect and properly tighten all parts regular-
ly. Replace any worn parts immediately.
8. Always make sure that the adjustment knob is
fully engaged before you use the backrest.
9. Wear appropriate clothes while exercising.
Always wear athletic shoes for foot protec-
tion while exercising.
10.
The weight bench is designed to support a
maximum user weight of 300 lbs. (136 kg)
and a maximum total weight of 510 lbs. (231
kg). Do not use the weight bench with more
than 210 lbs. (95 kg) of weight. Note: The
weight bench does not include weights.
11. If you feel pain or dizziness at any time while
exercising, stop immediately and begin cool-
ing down.
WARNING: Toreduce the risk of serious injury, read all important precautions and
instructions in this manual and all warnings on the weight bench before using the weight bench.
ICON assumes no responsibility for personal injury or property damage sustained by or through
the use of the weight bench.
IMPORTANT PRECAUTIONS

4
Adjustment Knob
Frame
Backrest Bracket
Seat
Backrest
Seat Pin
BEFORE YOU BEGIN
Thank you for selecting the versatile NordicTrack®
E125 weight bench. The weight bench is designed to
be used with your own weights to develop the major
muscles of your upper body.
For your benefit, read this manual carefully before
using the weight bench. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please review the drawing below
and familiarize yourself with the parts that are labeled.
ASSEMBLED DIMENSIONS:
Height: 48 in. (122 cm)
Width: 24 in. (61 cm)
Depth: 49 in. (124 cm)

5
M6 Washer (3)
M10 Nylon
Locknut (12)
M10 x 180mm Bolt (23)
M8 x 40mm Bolt (25)
M10 Washer (10)
M8 Nylon
Locknut (28)
M4 x 15mm
Screw (20)
M8 Washer (27)
M6 x 15mm
Screw (21)
M6 x 35mm Screw (22)
M8 x 15mm
Screw (19)
M6 x 55mm Screw (24)
M8 x 70mm Carriage Bolt (26)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts may
have been preattached. If a part is not in the hardware kit, check to see if it has been preattached.

6
ASSEMBLY
1.
Attach the two Rear Stabilizers (5) to the Base
(4) with four M4 x 15mm Screws (20).
Insert two M8 x 70mm Carriage Bolts (26) up
through the Base (4). Note: It may be helpful
to place a piece of tape over the Carriage
Bolts to hold them in place.
5
5
20
20
4
1
26
Before beginning assembly, make sure
that you have read and understand the
information in the box above.
Before beginning assembly, carefully read the fol-
lowing information and instructions:
• Assembly requires two persons.
• Because of its size, the weight bench should be
assembled in the location where it will be used.
Make sure that there is enough clearance to walk
around the weight bench as you assemble it.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until assembly is completed.
•For help identifying small parts, use the PART
IDENTIFICATION CHART on page 5.
• As you assemble the weight bench, make sure all
parts are oriented as shown in the drawings.
• Tighten all parts as you assemble them, unless
instructed to do otherwise.
• Assembly requires the following tools (not
included):
two adjustable wrenches
one rubber mallet
one standard screwdriver
one Phillips screwdriver
Assembly may be more convenient if you have a
socket set, a set of open-end or closed-end
wrenches, or a set of ratchet wrenches.
Make Assembly Easier
Everything in this manual is designed to ensure
that the weight bench can be assembled suc-
cessfully by almost anyone. By setting aside
plenty of time, assembly will go smoothly

7
2
1
28
4
26
3
4
2
1
9
Holes
9
825
27
27
27
27
28
28
25
19
19
2. Attach the Frame (1) to the Base (4) with the two
M8 x 70mm Carriage Bolts (26) and two M8
Nylon Locknuts (28). Donot tighten the Nylon
Locknuts yet.
3. Attach the Front Leg (2) to the Frame (1) with
four M8 x 15mm Screws (19).
See step 2. Tighten the M8 Nylon Locknuts
(28).
4. Orient the Backrest Tubes (9) so that the indicat-
ed holes are in the positions shown.
Attach the Backrest Bracket (8) to the Backrest
Tubes (9) with four M8 x 40mm Bolts (25), four
M8 Washers (27), and four M8 Nylon
Locknuts (28). Do not tighten the Nylon
Locknuts yet.

8
5
11
9
24
3
6
3
21
7
3
22
6
13
Wide
End
Wide End
24
5. Attach the Backrest (11) to the Backrest Tubes
(9) with four M6 x 55mm Screws (24) and four
M6Washers (3). Donot tighten the Screws
yet.
6. Attach the Seat (13) and the Seat Plate (7) to
the Seat Frame (6) with two M6 x 15mm
Screws (21), two M6 x 35mm Screws (22), and
two M6 Washers (3).

9
8
9. Make sure that all parts are properly tightened before you use the weight bench. The use of the remaining
parts will be explained in ADJUSTMENT, beginning on page 10.
7
12 9
7
1
10
10
7. Insert the Backrest Bracket (8) into the slot in
the Frame (1) as shown. Next, grease an M10 x
180mm Bolt (23). Attach the Seat Plate (7) and
the Backrest Tubes (9) to the Frame with the
Bolt, two M10 Washers (10), and an M10 Nylon
Locknut (12). Do not overtighten the Nylon
Locknut; the Seat Bracket and the Backrest
Tubes must pivot easily.
See step 4. Tighten the M8 Nylon Locknuts
(28).
See step 5. Tighten the M6 x 55mm Screws
(24). Grease
Slot
8. Note: For clarity, the seat is not shown in this
step.
Tighten the Adjustment Knob (15) into the
Frame (1); make sure that the Adjustment
Knob is engaged in a hole in the Backrest
Bracket (8).
Attach the Seat Pin (14) to the Seat Frame (6)
with an M4 x 15mm Screw (20). Then, insert the
Seat Pin into a hole in the Seat Frame and the
Frame (1).
20
1
15
8
14
6
8
23

10
This section explains how to adjust the weight bench. See the EXERCISE GUIDELINES on page 11 for impor-
tant information about how to get the most benefit from your exercise program. Also, refer to the accompanying
exercise guide to see the correct form for several exercises.
Make sure all parts are properly tightened each time you use the weight bench. Replace any worn parts immediate-
ly. The weight bench can be cleaned with a damp cloth and a mild, non-abrasive detergent; donot use solvents.
ADJUSTING THE BACKREST
To adjust the position of the Backrest (11), first pull
the Adjustment Knob (15). Then, raise or lower the
Backrest to the desired position, and reengage the
Adjustment Knob into the Backrest Bracket (8).
Make sure that the Adjustment Knob is inserted
into one of the holes in the Backrest Bracket.
15
8
11
ADJUSTMENT
ADJUSTING THE SEAT
Toadjust the Seat (13), first remove the Seat
Pin (14). Then, raise or lower the Seat to the
desired position, and reengage the Seat Pin into the
Seat Frame (6) and the Frame (1).
13
14 6
1

11
EXERCISE GUIDELINES
THE FOUR BASIC TYPES OF WORKOUTS
Muscle Building
Toincrease the size and strength of your muscles,
push them close to their maximum capacity. Your mus-
cles will continually adapt and grow as you progres-
sively increase the intensity of your exercise. You can
adjust the intensity level of an individual exercise in
two ways:
•by changing the amount of resistance used
•by changing the number of repetitions or sets per-
formed. (A “repetition” is one complete cycle of an
exercise, such as one sit-up. A “set” is a series of
repetitions.)
The proper amount of resistance for each exercise
depends upon the individual user. You must gauge
your limits and select the amount of resistance that is
right for you. Begin with 3 sets of 8 repetitions for each
exercise you perform. Rest for 3 minutes after each
set. When you can complete 3 sets of 12 repetitions
without difficulty, increase the amount of resistance.
Toning
You can tone your muscles by pushing them to a mod-
erate percentage of their capacity. Select a moderate
amount of resistance and increase the number of rep-
etitions in each set. Complete as many sets of 15 to
20 repetitions as possible without discomfort. Rest for
1minute after each set. Work your muscles by com-
pleting more sets rather than by using high amounts of
resistance.
Weight Loss
To lose weight, use a low amount of resistance and
increase the number of repetitions in each set.
Exercise for 20 to 30 minutes, resting for a maximum
of 30 seconds between sets.
Cross Training
Cross training is an efficient way to get a complete and
well-balanced fitness program. An example of a bal-
anced program follows:
•Plan strength training workouts on Monday,
Wednesday, and Friday.
•Plan 20 to 30 minutes of aerobic exercise, such as
running on a treadmill or riding on an elliptical exer-
ciser or exercise cycle, on Tuesday and Thursday.
•Rest from both strength training and aerobic exercise
for at least one full day each week to give your body
time to regenerate.
The combination of strength training and aerobic exer-
cise will reshape and strengthen your body, plus devel-
op your heart and lungs.
PERSONALIZING YOUR EXERCISE PROGRAM
Determining the appropriate length of time for each
workout, and the numbers of repetitions and sets to
complete, is an individual matter. Avoid overdoing it
during the first few months of your exercise program.
Progress at your own pace and be sensitive to your
body’s signals. If you experience pain or dizziness
while exercising, stop immediately and cool down.
Find out what is wrong before continuing. Remember
that adequate rest and a proper diet are important fac-
tors in any exercise program.
WARMING UP
Begin each workout with 5 to 10 minutes of stretching
and light exercise to warm up. Warming up prepares
your body for more strenuous exercise by increasing
circulation, raising your body temperature and deliver-
ing more oxygen to your muscles.
WORKING OUT
Each workout should include 6 to 10 different exercis-
es. Select exercises for every major muscle group,
emphasizing areas that you want to develop most. To
give balance and variety to your workouts, vary the
exercises from workout to workout.
Schedule your workouts for the time of day when your
energy level is the highest. Each workout should be
followed by at least one day of rest. Once you find the
schedule that is right for you, stick with it.
EXERCISE FORM
Maintaining proper form is an essential part of an
effective exercise program. This requires moving
through the full range of motion for each exercise, and
moving only the appropriate parts of the body.
Exercising in an uncontrolled manner will leave you
feeling exhausted. On the exercise guide accompany-
ing this manual you will find photographs showing the
correct form for several exercises, and a list of the
muscles affected. See the muscle chart on the next
page to find the names of the muscles.
Perform the repetitions in each set smoothly and with-
out pausing. The exertion stage of each repetition
should last about half as long as the return stage.
Proper breathing is important; exhale during the exer-
tion stage of each repetition and inhale during the
return stroke. Never hold your breath.

12
Rest for a short period of time after each set as fol-
lows:
•Rest for three minutes after each set for a muscle-
building workout.
•Rest for one minute after each set for a toning work-
out.
•Rest for 30 seconds after each set for a weight loss
workout.
Plan to spend the first couple of weeks familiarizing
yourself with the equipment and learning the proper
form for each exercise.
COOLING DOWN
End each workout with 5 to 10 minutes of stretching.
Include stretches for both your arms and legs. Move
slowly as you stretch and do not bounce. Ease into
each stretch gradually and go only as far as you can
without strain. Stretching at the end of each workout
is an effective way to increase flexibility.
STAYING MOTIVATED
For motivation, keep a record of each workout. List the
date, the exercises performed, the resistance used,
and the numbers of sets and repetitions completed.
Record your weight and key body measurements at
the end of every month. Remember, the key to achiev-
ing the greatest results is to make exercise a regular
and enjoyable part of your everyday life.
O
P
Q
R
S
T
U
V
X
W
N
M
J
G
F
H
I
K
E
C
D
B
A
L
MUSCLE CHART
A. Sternomastoid (neck)
B. Pectoralis Major (chest)
C. Biceps (front of arm)
D. Obliques (waist)
E. Brachioradials (forearm)
F. Hip Flexors (upper thigh)
G. Abductor (outer thigh)
H. Quadriceps (front of thigh)
I. Sartorius (front of thigh)
J. Tibialis Anterior (front of calf)
K. Soleus (front of calf)
L. Anterior Deltoid (shoulder)
M. Rectus Abdominus (stomach)
N. Adductor (inner thigh)
O. Trapezius (upper back)
P. Rhomboideus (upper back)
Q. Posterior Deltoid (shoulder)
R. Triceps (back of arm)
S. Latissimus Dorsi (mid back)
T. Spinae Erectors (lower back)
U. Gluteus Medius (hip)
V. Gluteus Maximus (buttocks)
W. Hamstring (back of leg)
X. Gastrocnemius (back of calf)

13
MONDAY
Date:
//
EXERCISE WEIGHT SETS REPS
EXERCISE WEIGHT SETS REPS
EXERCISE WEIGHT SETS REPS
AEROBIC EXERCISE
AEROBIC EXERCISE
TUESDAY
Date:
/ /
WEDNESDAY
Date:
/ /
THURSDAY
Date:
/ /
FRIDAY
Date:
/ /
Make photocopies of this page for scheduling and recording your workouts.

14
Key No. Qty. Description Key No. Qty. Description
1 1 Frame
2 1 Front Leg
36 M6 Washer
4 1 Base
5 2 Rear Stabilizer
6 1 Seat Frame
7 1 Seat Plate
8 1 Backrest Bracket
9 2 Backrest Tube
10 2 M10 Washer
11 1 Backrest
12 1 M10 Nylon Locknut
13 1 Seat
14 1 Seat Pin
15 1 Adjustment Knob
16 4 60mm Square Cap
17 4 40mm x 25mm Cap
18 1 40mm x 20mm Cap
19 4 M8 x 15mm Screw
20 5 M4 x 15mm Screw
21 2 M6 x 15mm Screw
22 2 M6 x 35mm Screw
23 1 M10 x 180mm Bolt
24 4 M6 x 55mm Screw
25 4 M8 x 40mm Bolt
26 2 M8 x 70mm Carriage Bolt
27 4 M8 Washer
28 6 M8 Nylon Locknut
* – User’s Manual
* – Exercise Guide
* – Grease Packet
* – Hex Key
PART LIST—Model No. NTBE1076.0 R1207A
Note: Specifications are subject to change without notice. See the back cover of this manual for information
about ordering replacement parts. *These parts are not illustrated.

15
1
2
4
5
5
6
7
8
9
9
11
13
14
15
16
16
16
16
17
17
18
19 26
20
20
21 22
23
24
24
25
25
20
10
27
27
3
3
10
3
28
28
28
12
19
EXPLODED DRAWING—Model No. NTBE1076.0 R1207A

Part No. 248112 R1207A Printed in China © 2007 ICON IP, Inc.
To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro-
vide the following information when contacting us:
•the model number and serial number of the product (see the front cover of the manual)
•the name of the product (see the front cover of this manual)
•the key number and description of the part(s) (see the PART LIST and the EXPLODED DRAWING near the
end of this manual)
ORDERING REPLACEMENT PARTS
LIMITED WARRANTY
ICON Health & Fitness, Inc. (ICON) warrants this product to be free from defects in workmanship and
material, under normal use and service conditions, for a period of ninety (90) days from the date of pur-
chase. This warranty extends only to the original purchaser. ICON's obligation under this warranty is lim-
ited to replacing or repairing, at ICON's option, the product through one of its authorized service centers.
All repairs for which warranty claims are made must be preauthorized by ICON. If the product is shipped
to a service center, freight charges to and from the service center will be the customer’s responsibility. For
in-home service, the customer will be responsible for a minimal trip charge. This warranty does not extend
to any product or damage to a product caused by or attributable to freight damage, abuse, misuse,
improper or abnormal usage or repairs not provided by an ICON authorized service center; products used
for commercial or rental purposes; or products used as store display models. No other warranty beyond
that specifically set forth above is authorized by ICON.
ICON is not responsible or liable for indirect, special or consequential damages arising out of or in con-
nection with the use or performance of the product or damages with respect to any economic loss, loss
of property, loss of revenues or profits, loss of enjoyment or use, costs of removal or installation or other
consequential damages of whatsoever nature. Some states do not allow the exclusion or limitation of inci-
dental or consequential damages. Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of
merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth
herein. Some states do not allow limitations on how long an implied warranty lasts. Accordingly,the above
limitation may not apply to you.
This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
ICON HEALTH & FITNESS, INC., 1500 S. 1000 W., LOGAN, UT 84321-9813
