IHP F1762 User manual

FM100 FLOOR MEDIA KIT
[FOR USE WITH APPLIANCE MODELS BLAZE&GLOW18/24, MAGNIFLAME24/30, MULTISIDED27, DUAL-FLAME EOS18, MONTEBELLO18/24, SHERIDAN18/24, MNF24/30/36
LMF24/30/36, GLOWRAMP LBG18/24/30/36, MULTI-SIDED FVFM27, VF18/24, DUAL-BURNER VD1824, SINGLE-BURNER VS1824, SOMERSET27 FVFM27]
FM100 FLOOR MEDIA KIT
P/N 115579-01
Rev. B, 04/2017
HEARTH PRODUCTS
KITS AND ACCESSORIES
Cat. No. Model Description
F1762 FM100 Floor Media Kit
REQUIRED TOOLS AND SUPPLIES
None
GENERAL INFORMATION
The floor media kit is used to give a more natural appearance to the
fireplace floor where the gas log set is installed.
READ ALL THE STEPS BEFORE STARTING THE INSTALLATION
THE APPLIANCE MUST BE OFF AND COLD BEFORE BEGINNING.
ALL WARNINGS, PRECAUTIONS AND INSTRUCTIONS IN THE
INSTALLATION AND OPERATION MANUAL PROVIDED WITH THE
APPLIANCE APPLY TO THESE INSTRUCTIONS.
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local
distributor or dealer.
If any of these parts are missing or damaged, contact your dealer or
IHP.us.com for referral information.
KIT CONTENTS
9 ea. Fiber Log Pieces
1 ea. Volcanic Stone
1 ea. Ember Material
1 ea. Instruction Sheet
WARNING
•Make sure the unit is turned off and cool before
adding floor media material to fireplace floor.
•Do not add extra logs or ornaments such as pine
cones, vermiculite or glowing embers (rockwool).
Using these added items can cause sooting. Use
only the material included in this kit.
•Do not place volcanic stone, embers or fiber log
pieces on logs or burners. This may cause sooting.
Placefloormediamaterialonlyonthefireplacefloor.
Figure 1 - FM100 Floor Media Kit
Figure 2 - Placing Volcanic Stone
IHP.us.com 1
INSTALLING FLOOR MEDIA KIT
1. Place decorative log pieces randomly as desired on fireplace hearth.
Place volcanic stone around base of unit making sure the burner
ports and valve access are not blocked (see Figure 2). Retain a
small amount of volcanic stone to be used in step 4.
fire-parts.com

2IHP.us.com
Printed in U.S.A. © 2004 Innovative Hearth Products
P/N 115579-01 Rev. B 04/2017
IHP reserves the right to make changes at any time, without notice, in design, materials, specifica-
tions, prices and also to discontinue colors, styles and products. Consult your local distributor
for fireplace code information.
IHP
1508 Elm Hill Pike, Suite 108 • Nashville, TN 37210
Figure 5 - Floor Media Kit Installed
Figure 3 - Placing Ember Material
Figure 4 - Placing Fiber Log Pieces
3. Place fiber log pieces randomly on volcanic stone and ember mate-
rial around unit (see Figure 4).
2. Place ember material around front and sides of unit close to (but
NOT on) he burner (see Figure 3). Embers will "glow" when heated
to enhance the realistic look of your log set.
4. Use remaining volcanic stone to blend the floor media together.
Your finished effect should resemble Figure 5.
