IHP CDFBBK-35 User manual

IHP.US.com 506019-40 A
1
P/N 506019-40 Rev. A 05/2015
P506019-40 HEARTH PRODUCTS
KITS AND ACCESSORIES
CONTEMPORARY FAÇADE KITS
INSTALLATION INSTRUCTIONS FOR CONTEMPORARY FAÇADE KITS
FOR USE WITH MERIT™ SERIES MLDVTCD-35 GAS FIREPLACES
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 1
GENERAL INFORMATION
CONTEMPORARY
FAÇADE KITS
The Contemporary Façade Kit is composed of three separate elements
that are purchased separately. Refer to Table 1.
NOTE: To complete one Façade a selection of one Base, one Frame and
one Façade Trim must be made.
The frame must be installed on a properly positioned MLDVTCD fireplace.
Refer to manual number 506015-03 for detailed instructions. Refer to
Figure 1 for façade significant dimensions.
NOTE: The fireplace must be positioned at least 18” up the wall to use
the co ntemporary façade
INSTALLATION INSTRUCTIONS FOR CONTEMPORARY FAÇADE KITS
FOR USE WITH MERIT™ SERIES MLDVTCD-35 GAS FIREPLACES
HEARTH PRODUCTS
KITS AND ACCESSORIES
506019-40
REV. N/C 04/2009
Figure 1
44-3/4”
33”
24”
35-1/2”
29”
18” Min. Required
> 28” Recommended
Floor Fireplace
16”
32”
35”
Contemporary Façade Kits
Choose One Base (Largest Piece Immediately Against The Finish Wall)
Cat. No. Model No. Description
H7732 CDFBBK-35 Façade Base, Black
H7733 CDFBSS-35 Façade Base, Stainless
Choose One Frame (Inner Façade Frame Piece Surrounding The Opening)
H7730 CDFFBK-35 Façade Frame, Black
H7731 CDFFSS-35 Façade Frame, Stainless
Choose One Trim (Finishes The Inner Frame Opening)
H7727 CDTKBK-35 Façade Trim, Black
H7728 CDTKSS-35 Façade Trim, Stainless
H7729 CDTKBR-35 Façade Trim, Polished Brass
Table 1
Base
Trim
Frame
TOOLS REQUIRED
1 - Phillips Screwdriver, 1 - 5/16” Nut Driver
fire-parts.com

IHP.US.com 506019-40 A
2
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
2
Figure 3
Step 2. Locate two screws (one left and one right) in the fireplace
support structure (see Figure 3 ) and (using a 5/16” nut driver) remove
them. Position the exhaust ramp and install it by replacing the screws
that were removed.
Step 3. Locate and loosen (using a Phillips screwdriver) two screws
attaching the base adjustment bracket to the façade base. Hold the façade
base in front of the fireplace and engage the base tabs in the slots on the
fireplace (see Figure 4 ). Press the façade base back against the wall/fin-
ish materials as far as it will go and tighten the screws (see Figure 5 ).
IMPORTANT: Ensure that the façade base upper flange is above the
exhaust ramp. The exhaust ramp must be unobstructed and properly
engaged with the façade base to allow the exhaust to escape from the
fireplace (See Figure 6 ).
Figure 4
Figure 5
Attaching The Exhaust Ramp
Fireplace Slots
Tighten Screws On Base Adjustment Bracket
Figure 2
INSTALLATION INSTRUCTIONS
Step 1. Install the exhaust ramp in the opening above the fire place front
glass enclosure panel (see Figure 2 ).
Exhaust Ramp
Engage Base Tab
Base Adjustment Bracket
Frame Base
Facade Base
Fireplace
Exhaust
Ramp
Facade Base
Upper Flange
Side View
Figure 6
fire-parts.com

IHP.US.com
506019-40 A 3
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 3
Figure 7 Figure 8
Insert Trim Piece Engage Frame Tabs
Step 4. Insert Selected trim pieces on the façade frame as indicated in
Figure 7.
Step 5. Hold the façade frame in front of the façade base and align the
tabs on the frame with the slots on the base (see Figure 8 ). Insert the
tabs into the slots, taking care not to scratch the face of the base and
engage the tabs by dropping the frame downwards. A slight amount of
force may be necessary to snap the frame into pace.
fire-parts.com

IHP.US.com 506019-40 A
4
P/N 506019-40 Rev. A 05/2015
1508 Elm Hill Pike, Suite 108
Nashville, TN 37210
IHP.US.com
P506019-40
The manufacturer reserves the right to make
changes at any time, without notice, in design,
materials, specifications, prices and also to
discontinue colors, styles and products. Consult
your local distributor for fireplace code informa-
tion.
Printed in U.S.A. © 2015 by Innovative Hearth
Products
