Iluminar IL-iLOGIC6-UVIR User manual

USER
MANUAL
iLogic6 UV + Far-Red
330W
1-877-540-5588
iluminarlighting.com
[email protected]
IL-iLOGIC6-UVIR

3
2
CONTENTS
Please read this manual thoroughly prior to installing or
operating the ILUMINAR iLOGIC6 + Far-Red
1-877-540-5588
iluminarlighting.com
[email protected]
• Observe all safety precautions (see page 10), seek the services of a
qualified electrician, installation professional, or call ILUMINAR Lighting
technicians for assistance.
• DO NOT handle or touch the fixture while in use.
• Connect the fixture only to the power sources of the appropriate voltage
using the correct AC plug type. Protect power cables from being pinched,
walked on, or otherwise damaged. Be especially careful where the power
cable enters the power outlet to the unit. Only connect the fixture to an
electrical outlet or extension cord of comparable standard and level
rating. Connect the fixture ONLY to the power sources of the correct
voltage using the plug received.
• The fixture should only be cleaned as directed. Always seek service for
your system by qualified service personnel if any of the following occur:
1. The fixture shows a noticeable change in performance.
2. The powersupply cord or plug is damaged.
3. The fixture has been dropped, or the exterior is damaged.
Pre-Install Information ........................................
Technical & Physical Specifications ......................
Hardware & Accessories ....................................
Connection Instructions .......................................
Hanging Installation ..........................................
Cable Logic Instructions .....................................
Important Cautions & Warranty ..........................
2
3
4
5
6-7
8-9
10
© Copyright 2022, ILUMINAR Lighting
Subject to change without notice.
TECHNICAL SPECS
UV + Far-Red LED SPECTRUM
MOUNTING & COVERAGE
LED Lighting Solution
MODEL:
VOLTAGE:
SKU:WATTS: 330W
iLogic6 UV + Far-Red
100-277V
IL-iLOGIC6-UVIR
1002mm / 39.4”
124mm / 4.9”
1.2m / 4’
1.2m / 4’
25cm / 8-12”
1064mm / 41.9”
Voltage Range (+/-10%)
Rated Voltage
100-277V
120-277V AC
ePAR 925 µmol/s
ePAR Efficacy 2.85 µmol/J
3300k
120º
Min Power Factor
Color Rendering Index
Waterproof Rating
0.95
THD
Minimum Mounting Height
LED Lifespan (90% of Life)
< 20%
85
IP66 for Damp/Wet Conditions
Crest Factor 1.5
BTU
8-12” to top of Canopy
50,000+ hours
Frequency
1126
Dimmable
50 / 60Hz
Ambient Temperature
0-10V Controllable
Relative Humidity
Emitter Cooling
0 - 35°C / 32-95°F
Color Temperature
Light Distribution
85%
Passive / Extruded Case
PHYSICAL SPECIFICATIONS
Length 1064 mm 41.9”
39.4”
4.9”
45.6lbs
Width 1002 mm
Height 124.3 mm
Weight 20.7kg
VOLTAGE AND AMPERAGE
3.1A 350W
208V
120V
1.53A 302W
240V 1.32A 301W
277V 1.25A 330W

1-877-540-5588
iluminarlighting.com
[e-mail]
4
HARDWARE AND ACCESSORIES
The iLogic6 UV + Far-Red can be
hung from rope ratchets or can be
mounted to a rack.
Before you begin installation,
check that you have all the
necessary parts to begin.
1 iLogic6 UV + Far-Red Fixture
IN THE BOX
4 Rope Ratchets
© Copyright 2022, ILUMINAR Lighting
Subject to change without notice.
5
1-877-540-5588
iluminarlighting.com
[email protected]
Lay the central mast on a flat table top or surface with
the attachment brackets facing UP. Attach each LED Bar
by aligning the plastic clips and carefully sliding them into
place until you hear a soft click.
CONNECTION INSTRUCTIONS
Once the plastic clips are all snapped in place, attach the A/C
cables coming from the mast to each LED bar by aligning the
connector pins and pressing the ends together. Lock by twisting
in opposite directions.
Once all the LED bars are fastened into place and A/C cables
are attached to the mast, turn the fixture over (this may require
more than one person). Ensure the flat surface is clear of
anything that could damage the delicate diodes.
2
1
3
! CAUTION when handling your ILUMINAR Fixture. The
LED array should NOT come in contact with sharp objects.
DO NOT touch diodes or apply direct force to the diodes
as this can/will cause permanent damage.

7
6
HANGING INSTALLATION
Lift the LED and attach the carabiners
to pre-installed hooks from ceiling or
mounting beam. The Ratchets should
be installed closest to the LED (and not
the ceiling).
A: Remove slack to raise fixture.
B: Give slack to lower fixture.
To suspend mount, attach the 4 rope ratchets that come packaged with
this fixture to the LED.
1
2
A
B
© Copyright 2022, ILUMINAR Lighting
Subject to change without notice.
1-877-540-5588
iluminarlighting.com
[email protected]
Once fixture is hanging with all LED bars installed, connect the power cable
(blue tip) from the outlet to one side of the fixture.
3
Power SupplyAC INPUT
Controller
Cable
Led Bar´s

8© Copyright 2022, ILUMINAR Lighting
Subject to change without notice.
CABLE LOGIC CONNECTIONS
1-877-540-5588
iluminarlighting.com
[email protected]
3
3
Cable Logic
RJ9 to RJ14 (Included with Touch+ Controller)
Dimming Cable
Cable Logic Secondary AC
Extension Cables
Hard Wired
Power Cable
2Cable Logic Single Joint
4
Cable Logic 110V-480V
Panel Mount
Plug Options:
Cable Logic 120V AC Power
Cable Logic 240V AC Power
Cable Logic 277V AC Power
Main or Sub Panel
Touch+ Controller
Electrician Wire to Panel
Junction Box
2.4 m / 8 ft
1.5 m / 5 ft
Cable Logic Main-Line AC
Extension Cable
1
Available Options
0.9 m / 3 ft
1.8 m / 6 ft
4.5 m / 15 ft
Available Options
0.9 m / 3 ft
1.8 m / 6 ft
Available Options
0.3 m / 1.3 ft
1.8 m / 6 ft
3 m / 10 ft
6 m / 20 ft
3m / 10 ft
0.15 m / 0.5 ft
0.25m / 0.85 ft
Hash Controller
Scale legend
1.6 ft (0.5 m)
With our ILUMINAR Lighting Professional Systems, our new LED lighting fixtures allow
growers to connect multiple fixtures using a single power cable.
This cabling solution forms a fixture-to-fixture connection to the power source. Our grow
light cables and grow light accessories eliminate the need for the typical mess of LED
lighting cables, which have various fixtures with multiple cables running to several power
sockets.
Please consult with our lighting layout designers to ensure proper spacing of outlets for
your unique setup.

10
CAUTION
1. Leave at least one inch of space between the fixture and the mounting area
for maximum performance and lifespan.
2. ALWAYS wear protective eye wear when looking directly at the diodes to
prevent eye damage.
3. Only handle, clean or move fixture when it’s unplugged and completely
cool.
4. Keep the fixture free of dust, debris, deposits to ensure the maximum
potential of the fixture.
5. NEVER use cloth to clean the diodes. This will scratch the diodes and could
potentially break or dislodge them.
6. DO NOT use chemicals to clean the fixture. Use ONLY low pressure air or
low pressure water to remove dust and debris.
7. Do NOT exceed 70% max load for breakers due to Inrush current in LED
fixtures.
8. Do NOT use sulfur vaporizers
Please read the following list carefully prior to beginning installation.
At ILUMINAR, we stand behind our products and our technology
as well as our customers. All ILUMINAR LED fixtures are backed
by our 5-Year Guarantee. Please visit our website iluminarlighting.
com/warranty for more information.
1-877-540-5588
iluminarlighting.com
[email protected]
GUARANTEE
