Iluminar iLogic6 User manual

USER
MANUAL
iLogic6 Full Spectrum
330W
1-877-540-5588
iluminarlighting.com
[email protected]
IL-iLOGIC6

3
2
CONTENTS
Please read this manual thoroughly prior to installing or
operating the ILUMINAR iLOGIC6
1-877-540-5588
iluminarlighting.com
[email protected]
• Observe all safety precautions (see page 10), seek the services of a
qualified electrician, installation professional, or call ILUMINAR Lighting
technicians for assistance.
• DO NOT handle or touch the fixture while in use.
• Connect the fixture only to the power sources of the appropriate voltage
using the correct AC plug type. Protect power cables from being pinched,
walked on, or otherwise damaged. Be especially careful where the power
cable enters the power outlet to the unit. Only connect the fixture to an
electrical outlet or extension cord of comparable standard and level
rating. Connect the fixture ONLY to the power sources of the correct
voltage using the plug received.
• The fixture should only be cleaned as directed. Always seek service for
your system by qualified service personnel if any of the following occur:
1. The fixture shows a noticeable change in performance.
2. The powersupply cord or plug is damaged.
3. The fixture has been dropped, or the exterior is damaged.
Pre-Install Information ........................................
Technical & Physical Specifications ......................
Hardware & Accessories ....................................
Connection Instructions .......................................
Hanging Installation ..........................................
Cable Logic Instructions .....................................
Important Cautions & Warranty ..........................
2
3
4
5
6-7
8-9
10
© Copyright 2021, ILUMINAR Lighting
Subject to change without notice.
LED Lighting Solution
© Copyright 2021 ILUMINAR Lighting
Subject to change without notice.
iluminarlighting.com
Toll Free: 1-877-540-5588
MOUNTING & COVERAGE
1.2m / 4'
1.2m / 4'
20-30cm / 8-12"
124.3mm / 4.9”
PHYSICAL SPECIFICATIONS
Length
Width
Height
Weight
1064mm
1002mm
124.3mm
20.7kg
41.9"
39.4"
4.9"
45.6lbs
Rated Voltage
Voltage Range (+/-10%)
PPF
Efficacy
Min Power Factor
THD
Crest Factor
BTU
Frequency
Dimmable
Ambient Temperature
Relative Humidity
Color Temperature
Color Rendering Index
Minimum Mounting Height
Emitter Cooling
Light Distribution
Waterproof Rating
LED Lifespan (90% of Life)
924 µmol/s
2.8 µmol/J
0.95
< 20%
1.5
625
50 / 60Hz
0 - 10V Controllable
0 - 35°C / 32-95°F
85%
4000k
90
8-12” to top of Canopy
Passive / Extruded Case
120º
IP66 for Damp/Wet Conditions
50,000+ hours
TECHNICAL SPECS
120-277V
100-277V
MODEL:
WATTS: 330W
iLogic6
VOLTAGE:
SKU: IL-iLOGIC6
iLOGIC6 LED SPECTRUM
100-277V
VOLTAGE AND AMPERAGE
120V
208V
240V
277V
347V
480V
1.0A
0.72A
3.1A
1.53A
1.32A
1.25A
325W
330W
350W
302W
301W
330W
1064mm / 41.9”
1002mm / 39.4”
W
A
VELENGTH NM






    

1-877-540-5588
iluminarlighting.com
[e-mail]
4
HARDWARE AND ACCESSORIES
The iLogic6 can be hung from
rope ratchets or can be mounted
to a rack.
Before you begin installation,
check that you have all the
necessary parts to begin.
1 iLogic6 Fixture
IN THE BOX
4 Rope Ratchets
© Copyright 2021, ILUMINAR Lighting
Subject to change without notice.
5
1-877-540-5588
iluminarlighting.com
[email protected]
Lay the central mast on a flat table top or surface with
the attachment brackets facing UP. Attach each LED Bar
by aligning the plastic clips and carefully sliding them into
place until you hear a soft click.
CONNECTION INSTRUCTIONS
Once the plastic clips are all snapped in place, attach the A/C
cables coming from the mast to each LED bar by aligning the
connector pins and pressing the ends together. Lock by twisting
in opposite directions.
Once all the LED bars are fastened into place and A/C cables
are attached to the mast, turn the fixture over (this may require
more than one person). Ensure the flat surface is clear of
anything that could damage the delicate diodes.
2
1
3
! CAUTION when handling your ILUMINAR Fixture. The
LED array should NOT come in contact with sharp objects.
DO NOT touch diodes or apply direct force to the diodes
as this can/will cause permanent damage.

7
6
HANGING INSTALLATION
Lift the LED and attach the carabiners
to pre-installed hooks from ceiling or
mounting beam. The Ratchets should
be installed closest to the LED (and not
the ceiling).
A: Remove slack to raise fixture.
B: Give slack to lower fixture.
To suspend mount, attach the 4 rope ratchets that come packaged with
this fixture to the LED.
1
2
A
B
© Copyright 2021, ILUMINAR Lighting
Subject to change without notice.
1-877-540-5588
iluminarlighting.com
[email protected]
Once fixture is hanging with all LED bars installed, connect the power cable
(blue tip) from the outlet to one side of the fixture.
3
Power SupplyAC INPUT
Controller
Cable
Led Bar´s

8© Copyright 2021, ILUMINAR Lighting
Subject to change without notice.
CABLE LOGIC CONNECTIONS
If you’re planning to utilize several LEDs in your room or facility, one of the many benefits
of the ILUMINAR LED is that you can “daisy chain” one fixture to another to save space
and use only one outlet to run several lamps thus minimizing the amount of cords used in
your space.
If you plan to utilize the ILUMINAR HASH Controller, you can connect the
yellow connections from the controller to the fixture and then connect the Daisy
Chain Controller Cable from fixture to fixture. Please consult with our lighting
layout designers to ensure proper spacing of outlets for your unique setup.
1
1-877-540-5588
iluminarlighting.com
[email protected]
3
3
Cable Logic
RJ9 to RJ14 (Included with Touch+ Controller)
Dimming Cable
Cable Logic Secondary AC
Extension Cables
Hard Wired
Power Cable
2Cable Logic Single Joint
4
Cable Logic 110V-480V
Panel Mount
Plug Options:
Cable Logic 120V AC Power
Cable Logic 240V AC Power
Cable Logic 277V AC Power
Main or Sub Panel
Touch+ Controller
Electrician Wire to Panel
Junction Box
2.4 m / 8 ft
1.5 m / 5 ft
Cable Logic Main-Line AC
Extension Cable
1
Available Options
0.9 m / 3 ft
1.8 m / 6 ft
4.5 m / 15 ft
Available Options
0.9 m / 3 ft
1.8 m / 6 ft
Available Options
0.3 m / 1.3 ft
1.8 m / 6 ft
3 m / 10 ft
6 m / 20 ft
3m / 10 ft
0.15 m / 0.5 ft
0.25m / 0.85 ft
Hash Controller
Scale legend
1.6 ft (0.5 m)

10
CAUTION
1. Leave at least one inch of space between the fixture and the mounting area
for maximum performance and lifespan.
2. ALWAYS wear protective eye wear when looking directly at the diodes to
prevent eye damage.
3. Only handle, clean or move fixture when it’s unplugged and completely
cool.
4. Keep the fixture free of dust, debris, deposits to ensure the maximum
potential of the fixture.
5. NEVER use cloth to clean the diodes. This will scratch the diodes and could
potentially break or dislodge them.
6. DO NOT use chemicals to clean the fixture. Use ONLY low pressure air or
low pressure water to remove dust and debris.
7. Do NOT exceed 70% max load for breakers due to Inrush current in LED
fixtures.
Please read the following list carefully prior to beginning installation.
At ILUMINAR, we stand behind our products and our technology
as well as our customers. All ILUMINAR LED fixtures are backed
by our 5-Year Guarantee. Please visit our website iluminarlighting.
com/warranty for more information.
1-877-540-5588
iluminarlighting.com
[email protected]
GUARANTEE
