Infortrend EonStor GS 1000 Gen2 User manual

Version 1.0
Infortrend EonStor DS 1000 Gen2 Series
Hardware Manual

Legal Information
2
Legal Information
All Infortrend products, including the product customers have purchased from
Infortrend, shall be subject to the latest Standard Warranty Policy available on the
Infortrend website: http://www.infortrend.com/global/Support/Warranty
Infortrend may from time to time modify, update or upgrade the software, firmware or
any accompanying user documentation without any prior notice. Infortrend will
provide access to these new software, firmware or documentation releases from
certain download sections of our website or through our service partners. Customer
shall be responsible for maintaining updated version of the software, firmware or
other documentation by downloading or obtaining from Infortrend, and installing
designated updated code, including but not limited to firmware, microcode, basic
input/out system code, utility programs, device drivers, and diagnostics delivered
with Infortrend product.
Before installing any software, applications or components provided by a third party,
customer should ensure that they are compatible and interoperable with Infortrend
product by checking in advance with Infortrend. Customer is solely responsible for
ensuring the compatibility and interoperability of the third party’s products with
Infortrend product. Customer is further solely responsible for ensuring its systems,
software, and data are adequately backed up as a precaution against possible
failures, alternation, or loss.
For any questions of hardware/ software compatibility, and the update/ upgrade code,
customer should contact Infortrend sales representative or technical support for
assistance.
To the extent permitted by applicable laws, Infortrend shall NOT be responsible for
any interoperability or compatibility issues that may arise when (1) products, software,
or options not certified and supported by Infortrend are used; (2) configurations not
certified and supported by Infortrend are used; (3) parts intended for one system are
installed in another system of different make or model.

Contact Information
3
Contact Information
Customer Support
Contact your system vendor or visit the following support sites.
EonStorDS Support
Headquarters
(Taiwan)
Infortrend Technology, Inc.
8F, No. 102, Sec. 3, Jhongshan Rd., Jhonghe Dist., New Taipei City 235, Taiwan
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Japan
Infortrend Japan, Inc.
6F Okayasu Bldg., 1-7-14 Shibaura, Minato-Ku, Tokyo, 105-0023 Japan
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Americas
Infortrend Corporation
435 Lakeside Dr. Sunnyvale, CA. 94085, USA
Tel: [phone] Fax: [phone] Email, Technical Support, Website
China
Infortrend Technology, Ltd.
北京市朝阳区东四环中路远洋国际中心 D座403 室
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Europe (EMEA)
Infortrend Europe LTD.
5 Ringway Centre, Edison Road, Basingstoke, Hampshire, RG21 6YH, UK
Tel: [phone] Fax: [phone] Email, Technical Support, Website

Copyright Notice
4
Copyright Notice
All rights reserved. This publication may not be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior written
consent of Infortrend Technology, Inc.
Disclaimer
Infortrend Technology makes no representations or warranties with respect to
the contents hereof and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Furthermore, Infortrend
Technology reserves the right to revise this publication and to make changes
from time to time in the content hereof without obligation to notify any person of
such revisions or changes. Product specifications are also subject to change
without prior notice.
Trademarks
Infortrend, the Infortrend logo, SANWatch, ESVA, EonStor DS, EonNAS, and
EonPath are registered trademarks of Infortrend Technology, Inc. Other names
prefixed with “IFT” and “ES” are trademarks of Infortrend Technology, Inc.
Windows is a registered trademark of Microsoft Corporation.
Mac OS X is a registered trademark of Apple Computer, Inc.
Linux is a trademark of Linus Torvalds.
All other names, brands, products or services are trademarks or registered
trademarks of their respective owners.

Safety Precautions
5
Safety Precautions
Read these instructions carefully before you install, operate, or transport the EonStor
DS storage system and expansion enclosures.
Installation and Operation
Install the rack cabinet and the associated equipment at a site where the ambient
temperature (special room cooling equipment may be required) stays lower than:
a. 35C ~ if your system have a BBU (all dual controller systems come with
BBU by default)
b. 40C ~ if your system does not have a BBU
Install the power source socket outlet near the enclosure where it is easily
accessible and ground the rack cabinet.
Secure airflow clearance inside and around the rack cabinet.
- Secure an 18 to 20cm clearance on the rear side.
- Do not cover the enclosure openings.
- Route the cables inside the rack cabinet.
- Do not leave drive bays empty as it will affect airflow efficiency.
Secure each enclosure module using its retaining screws.
Place power cords and other cables away from foot traffic. Do not place items on
top of power cords and make sure they do not rest against data cables.
Install all modules to the enclosure before powering-on systems.
Ensure that the correct power range is being used before powering-on.
DO NOT remove covers or replaceable modules if they are not faulty.
If the system is not going to be used for a long period of time, disconnect it from the
power mains to avoid transient over-voltage.
For power source redundancy, please make sure that the two PSUs are plugged
into two different power sources (ie. different circuit breakers).

Service and Maintenance
Service and Maintenance
Keep the faulty module in place until you have a replacement unit; an empty
module greatly affects the airflow efficiency within the enclosure.
During service operation, place the enclosure on soft and clean surface to prevent
exterior damage. Do not place tools or other items on top.
When transporting the enclosure, repackage all disk drives separately in the
original package foam blocks. Replaceable modules can stay in the enclosure if
you are using the original package; if not, repackage them separately as well.
Disconnect the power cords before servicing or cleaning the enclosure.
Use a slightly moistened paper sheet or cloth for cleaning. Avoid using liquid or
sprayed detergent.
When replacing components, insert them as gently as possible while assuring full
engagement. Vibration and shock can easily damage hard drives.
Only qualified service personnel should open the enclosure.
Contact service personnel if any of the following situations occurs:
- The power cord or plug is damaged.
- The enclosure has been exposed to moisture.
- The system has not been working properly.
- The enclosure was dropped against a hard surface.
- The enclosure shows obvious signs of breakage.
To move the enclosure, more than one person might be necessary due to its weight.
Drives should be removed from the enclosure beforehand.
Important Notice
The use of Infortrend certified components is strongly recommended to ensure
compatibility, quality and normal operation with your Infortrend products. Please
contact your distributor for a list of Infortrend certified components (eg. SFP, SFP+,
HBA card, iSCSI cable, FC cable, memory module, etc.).

ESD Precautions
ESD Precautions
Handle the modules by their retention screws, ejector levers, or the module’s metal
frame/faceplate only. Avoid touching the PCB boards or connector pins.
Use a grounded wrist strap and an anti-static work pad to discharge static electricity
when installing or operating the enclosure.
Avoid dust, debris, carpets, plastic, vinyl, and styrofoam in your work area.
Do not remove any module or component from its anti-static bag before installation
takes place.
Drives must not be stacked on top of each other without their protective drive trays.
Even when drives are fixed in the drive trays, contacting the exposed PCB or
rear-side interface may damage the drives.

8
About This Manual
The manual introduces hardware components of EonStor DS 1000 Gen2 series storage
systems and expansion enclosures. It also describes how to install, monitor, and maintain
them.
For non-serviceable components, please contact our support site.
Firmware operation: Consult the Firmware User Manual on the CD-ROM.
SANWatch software: Consult the SANWatch User Manual on the CD-ROM.
Revision History
Version
Date
Description
1.0
July 2017
Initial release

EonStor DS 1000 Gen2 Series
9
Table of Contents
Legal Information................................................................................................2
Contact Information............................................................................................3
Copyright Notice.................................................................................................4
Safety Precautions..............................................................................................5
Installation and Operation....................................................................................... 5
Service and Maintenance ........................................................................................ 6
Important Notice....................................................................................................... 6
ESD Precautions ...................................................................................................... 7
About This Manual..............................................................................................8
Revision History....................................................................................................... 8
Introduction.......................................................................................................13
Product Overview................................................................................................... 13
Model Naming Conventions..................................................................................... 13
Model Variations..................................................................................................... 14
Major Components................................................................................................. 15
Controller and Interface............................................................................................ 15
Expansion Enclosure Controller and Interface......................................................... 15
Power Supply Unit with Built-in Cooling Module...................................................... 16
The Rear Panel ....................................................................................................... 17
Dual Controller Models............................................................................................. 17
Single-Controller Models.......................................................................................... 18
Connection between Storage Systems and Expansion Enclosures ........................ 18
Chassis.................................................................................................................... 19
Front Panel............................................................................................................... 19
Rear Panel ............................................................................................................... 21
Internal Backplane.................................................................................................... 22
Front Panel Components....................................................................................... 23
LED Panel................................................................................................................ 23
Drive Tray Bezel....................................................................................................... 24
Rear Panel Components........................................................................................ 25
Cache Backup Module (CBM).................................................................................. 26
Super Capacitor & Flash Backup Module................................................................ 27
PSU & Cooling Module ............................................................................................ 28
System Monitoring Features................................................................................. 29
Expansion Enclosure Support.................................................................................. 29
I2C bus..................................................................................................................... 30
Firmware (FW) and SANWatch................................................................................ 30
Audible Alarms ......................................................................................................... 30
Hot-swapping.......................................................................................................... 31

10
Hardware Installation........................................................................................32
Installation Prerequisites....................................................................................... 32
Installation Procedures Overview ........................................................................ 33
Unpacking the System........................................................................................... 34
Box Contents............................................................................................................ 34
Preinstalled Components......................................................................................... 34
Components to be Installed...................................................................................... 34
Installing Hard Drive .............................................................................................. 35
Hard Drive Installation Prerequisites........................................................................ 35
SAS Interface........................................................................................................... 37
Hard Drive Designation............................................................................................ 38
Installing the Hard Drive into Drive Tray................................................................... 39
Installing the Hard Drive Tray into the Enclosure..................................................... 40
Installing CBM ........................................................................................................ 41
Removing the Controller .......................................................................................... 41
Flash Backup Module & Battery Backup Unit .......................................................... 42
Flash Backup Module Installation ............................................................................ 42
Battery Backup Unit (BBU) Installation .................................................................... 44
Super Capacitor & Flash Backup Module Installation.............................................. 46
Flash Backup Module Installation ............................................................................ 46
Installing the Super Capacitor.................................................................................. 48
Installing the Controller............................................................................................. 50
System Connection ..........................................................................................51
General Considerations on Making Connections............................................... 51
Host-Side Topologies ............................................................................................... 52
Host-Side Parameters.............................................................................................. 52
Maximum Concurrent Host LUN Connection (“Nexus” in SCSI) ............................. 53
Maximum Queued I/O Count ................................................................................... 54
Fibre-Host RAID Connections............................................................................... 55
Fibre-Host Components (including 10GB iSCSI)..................................................... 55
Fibre-Host Topologies .............................................................................................. 57
Fibre Cabling............................................................................................................ 58
Simple End-to-End Connection................................................................................ 59
DAS (Direct-Attached) Connection .......................................................................... 61
Switched Fabric Connection (Dual-Controller)......................................................... 63
Switched Fabric Connection (Single-Controller)...................................................... 66
SAS-Host Connections.......................................................................................... 69
DAS (Direct-Attached Storage) Connection with Redundant Host Path.................. 70
DAS (Direct-Attached Storage) Connection to Two Servers.................................... 72
iSCSI-Host Connections........................................................................................ 73
Network & Host Connection Topologies................................................................... 74
High Availability IP SAN with Redundant Controller ................................................ 75
Single-Controller with Fault-Tolerant Path ............................................................... 77
High Availability IP SAN (Recommended Cabling Method for Remote Replication)78
High Availability IP SAN with Port Trunk (Remote Replication Enabled)................. 80
Hybrid Host Connections...................................................................................... 82
Single Hybrid Unit Connected to FC/iSCSI Hosts.................................................... 82
Utilizing Hybrid iSCSI ports for Data Replication ..................................................... 83
Expansion Enclosure Connections...................................................................... 84
SAS Expansion Enclosure Configuration................................................................. 85
Configuration Rules.................................................................................................. 86
Dual Controller Expansion Connection.................................................................... 88
Single Controller Expansion Connections................................................................ 89
Management Console Connections..................................................................... 90

EonStor DS 1000 Gen2 Series
11
Power Connections................................................................................................ 92
Checklist................................................................................................................... 92
Connecting Power Cords ......................................................................................... 93
Power On Procedure................................................................................................ 93
Power On Status Check........................................................................................... 94
Power Off Procedure................................................................................................ 95
System Monitoring............................................................................................96
Monitoring Features............................................................................................... 96
LED Panel LEDs ...................................................................................................... 97
Drive Tray LED......................................................................................................... 99
Controller LED...................................................................................................... 100
Controller LED for Storage Systems...................................................................... 100
iSCSI / Ethernet Management Port LEDs.............................................................. 102
10Gb iSCSI Host Port LEDs (Fibre)....................................................................... 103
10Gb iSCSI Host Port LEDs (RJ45)....................................................................... 103
8Gb Fibre-Host Port LEDs ..................................................................................... 104
16Gb Fibre Channel Host Port LEDs..................................................................... 105
12G SAS-Host Port LEDs ...................................................................................... 106
PSU / Cooling Module LEDs................................................................................ 107
Alarms and I2C Bus ............................................................................................. 108
Audible Alarms ....................................................................................................... 108
I2C........................................................................................................................... 108
Restoring Default System Settings .................................................................... 109
Restoring Default Settings ..................................................................................... 109
System Maintenance ......................................................................................111
Replacing the Controller Module(s): Single / Dual / Simultaneous Upgrade..112
Replacing the Controller Host Board..................................................................115
Replacing the Memory Module on Storage Systems ........................................116
Replacing the CBM for Storage Systems ...........................................................118
BBU Fault Conditions and Precautions...................................................................119
Replacing the Battery Backup Unit (BBU) ............................................................. 120
Replacing the Flash Backup Module (FBM) .......................................................... 121
Replacing Super Capacitor and Flash Backup Module.................................... 122
Super Capacitor Fault Conditions and Precautions............................................... 123
Replacing the Super Capacitor .............................................................................. 124
Replacing Flash Backup Module (coupled with SuperCap)................................... 125
Replacing the Power Supply Module / Cooling Module................................... 126
Detecting a Failed PSU.......................................................................................... 126
Replacing the Power Supply Unit (PSU)................................................................ 127
Replacing a Hard Drive........................................................................................ 129
Appendix..........................................................................................................132
Technical Specifications...................................................................................... 132
Host/Drive Interface................................................................................................ 132
Power Supply......................................................................................................... 133
Dimensions............................................................................................................. 134
Environment........................................................................................................... 135
Certifications...................................................................................................136
Summary............................................................................................................... 136

12
Slide Rail Kit Installation Guide.....................................................................138
Slide Rail Kits ....................................................................................................... 138
Enclosure Installation Prerequisites.................................................................. 138
Unpacking the System......................................................................................... 139
Component Installation Procedure .................................................................... 139
Tools Required ..................................................................................................... 139
Rack Ear Mount Kit .............................................................................................. 140
Kit Contents............................................................................................................ 140
Installation Procedure............................................................................................. 141
Slide Rail Kit ......................................................................................................... 143
Kit Contents............................................................................................................ 143
Once Mounted.................................................................................................146

EonStor DS 1000 Gen2 Series
13
Introduction
Product Overview
This manual introduces EonStor DS 1000 Gen2 systems that support 6Gbps,
12Gbps SAS or 6Gbps (SATA-III) drive interfaces. The 2U / 3U / 4U enclosure is
designed to utilize 2.5”or 3.5” hard drives. Drive capacity can be expanded by
attaching hard drive expansion enclosures.
Model Naming Conventions
The naming rules for storage systems and expansion enclosure models are
explained in the example below:
DS1024R2B DS(A) + 10(B) + 24(C) + R(D) + 2(E) + L(F) + B(G)
Designation
Description
(A)
DS = EonStorDS systems
JB = Expansion enclosures
(B)
10 where 0 indicates first generation, 1 indicates second generation and so on
(C)
12 = 2U system, 12 hard drives capable
16 = 3U system, 16 hard drives capable
24 = 2U / 4U systems, 24 hard drives capable
(D)
R= Redundant (dual) controllers
G= Single and NOT upgradeable to dual controllers
(E)
2 = Gen2 Models
(F)
L= Models with BBU
C= Models with super capacitor
Without any CBM if not mentioned
(G)
B= 2.5”hard drive form factor system
3.5”hard drive form factor system if not mentioned

14
Model Variations
Comprised of storage system and expansion enclosure models, the storage systems
store hard drives and control the entire storage system while expansion enclosures
connect to a master storage system and can expand storage capacities by adding more
hard drives. All systems are compatible with SAS-3 and SATA-III hard drives. However
hard drive limitation(s) may vary model to model.
2U systems
3U systems
4U systems

15
Major Components
NOTE
Upon receiving your system, check the package contents against the included
Unpacking List. If module(s) are missing, contact your system vendor immediately.
The Cache Backup Module (CBM) is an optional feature in single controller systems.
Controller and Interface
Each controller comes with a pre-installed DIMM module.
The traditional battery backup is replaced by an innovative Cache Backup Module
methodology (CBM) which consists of a battery backup unit (BBU) and flash backup
module (FBM). Cached data is quickly distributed to a flash backup module with the
support of a BBU in the event of a power outage. With a super capacitor and flash
backup module combination cached data will be quickly distributed to a flash backup
module for permanent storage in the event of a power outage. The advantage of a
super capacitor is its very fast charging time. The super capacitor is charged within a
few minutes and available to distribute power to the controller. So the cached data
can be saved immediately and permanently in flash backup module (FBM).
The embedded firmware features intelligent algorithms, such as power-saving
modes, variable fan speeds and exiled drive handling.
Expansion Enclosure Controller and Interface
The enclosure is managed by expander controllers that distribute data flow to
individual disk drives and report operating status through a proprietary enclosure
service via in-band protocols. The enclosure, along with other expansion enclosures,
connects to a storage system and serves as a building block of a scalable
configuration.
Expansion enclosures feature SAS interfaces that provide ease of cabling Mini-SAS
HD connectors. With a backplane adapting SAS connectors, the system is ideal for
adding large storage capacities to a storage pool.

16
Power Supply Unit with Built-in Cooling Module
Two cooling modules built into the power supply unit (PSU) protect the system from
overheating, and two hot-swappable PSUs provide constant power to the system.
The modular nature of the system and the easy accessibility to all major components
ensure ease of maintenance.

17
The Rear Panel
Dual Controller Models
Dual controller systems are indicated by an “R”in their model number (please refer
to Model Naming Conventions). Controller A is located on top and controller B at the
bottom for dual controller models. In dual controller configuration, if one controller
fails, the second controller module will take over in a manner that is transparent to
application servers.
The top controller (Controller A) is the primary controller. The bottom controller
(Controller B) is the secondary (= redundant) controller which is idle during normal
operation and takes over the management role when Controller A cannot function
properly due to hardware error, controller module removal, etc.
If the failed Controller A restarts or a replacement is installed, Controller A will
temporarily assume the role of the secondary controller.
When the storage system is rebooted, all system configurations will revert back to
the default state and Controller B returns the primary role back to Controller A.

18
Single-Controller Models
Single-controller models are designated by a “G”in their model number. The second
controller slot is filled with a dummy cage (D).
Connection between Storage Systems and Expansion Enclosures
The following rule applies when connecting storage systems and expansion
enclosure(s):
Dual-controller storage system connects to dual-controller expansion
enclosure.
Single-controller storage system connects to single-controller
expansion enclosure.

19
Chassis
The storage system chassis is a rugged storage chassis divided into front and rear
sections. The chassis is designed to be installed into a rack or cabinet.
Front Panel
Ex. 1: 3U / 16-bay
Ex. 2: 2U / 24-bay, SFF
Hard drive trays (1): Each drive tray is hot-swappable and holds a 2.5 /
3.5-inch hard drive.
LED Panel (2): It contains Service / Power / Cooling Fan / Thermal /
System LED
Mute button / service LED (3): The mute button is to mute an alarm when
sound or to indicate that the system requires service.
Rotary ID switch in expansion enclosure systems (4): The rotary ID
switch is for users to set a unique ID to each expansion enclosure when
connected in a multi-array environment.

20
Handles (5): There are handles on both sides of the enclosure for users to
pull / push the enclosure out and into the cabinet when the enclosure is
installed on a slide rail rackmount system.
Rackmount holes (6): There are two rackmount holes (one on each side
of the enclosure) for users to secure the enclosure onto the cabinet.
Hard drive status LED (7): There is a set of hard drive status LEDs on
each hard drive tray or right hand side or below of it to indicate operation
status.
