Infortrend EonStor GSe Pro 2000 Series User manual

Version 1.0
Infortrend EonStor GSe Pro 2000 Series
Hardware Manual

Legal Information
Legal Information
All Infortrend products, including the product customers have purchased from
Infortrend, shall be subject to the latest Standard Warranty Policy available on the
Infortrend website: http://www.infortrend.com/global/Support/Warranty
Infortrend may from time to time modify, update or upgrade the software, firmware or
any accompanying user documentation without any prior notice. Infortrend will
provide access to these new software, firmware or documentation releases from
certain download sections of our website or through our service partners. Customer
shall be responsible for maintaining updated version of the software, firmware or
other documentation by downloading or obtaining from Infortrend, and installing
designated updated code, including but not limited to firmware, microcode, basic
input/out system code, utility programs, device drivers, and diagnostics delivered
with Infortrend product.
Before installing any software, applications or components provided by a third party,
customer should ensure that they are compatible and interoperable with Infortrend
product by checking in advance with Infortrend. Customer is solely responsible for
ensuring the compatibility and interoperability of the third party’s products with
Infortrend product. Customer is further solely responsible for ensuring its systems,
software, and data are adequately backed up as a precaution against possible
failures, alternation, or loss.
For any questions of hardware/ software compatibility, and the update/ upgrade code,
customer should contact Infortrend sales representative or technical support for
assistance.
To the extent permitted by applicable laws, Infortrend shall NOT be responsible for
any interoperability or compatibility issues that may arise when (1) products, software,
or options not certified and supported by Infortrend are used; (2) configurations not
certified and supported by Infortrend are used; (3) parts intended for one system are
installed in another system of different make or model.

Contact Information
3
Contact Information
Headquarters
(Taiwan)
Infortrend Technology, Inc.
8F, No. 102, Sec. 3, Jhongshan Rd., Jhonghe Dist., New Taipei City 235, Taiwan
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Japan
Infortrend Japan, Inc.
6F Okayasu Bldg., 1-7-14 Shibaura, Minato-Ku, Tokyo, 105-0023 Japan
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Americas
Infortrend Corporation
435 Lakeside Dr. Sunnyvale, CA. 94085, USA
Tel: [phone] Fax: [phone] Email, Technical Support, Website
China
Infortrend Technology, Ltd.
上海市浦建路 146 号强生大厦 1906 室
Tel: [phone] Fax: [phone] Email, Technical Support, Website
Europe (EMEA)
Infortrend Europe LTD.
5 Ringway Centre, Edison Road, Basingstoke, Hampshire, RG21 6YH, UK
Tel: [phone] Fax: [phone] Email, Technical Support, Website

Copyright Notice
4
Copyright Notice
All rights reserved. This publication may not be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical,
magnetic, optical, chemical, manual or otherwise, without the prior written
consent of Infortrend Technology, Inc.
Disclaimer
Infortrend Technology makes no representations or warranties with respect to
the contents hereof and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Furthermore, Infortrend
Technology reserves the right to revise this publication and to make changes
from time to time in the content hereof without obligation to notify any person of
such revisions or changes. Product specifications are also subject to change
without prior notice.
Trademarks
Infortrend, the Infortrend logo, SANWatch, ESVA, EonStor, EonStor DS,
EonNAS, and EonPath are registered trademarks of Infortrend Technology, Inc.
Other names prefixed with “IFT” and “ES” are trademarks of Infortrend
Technology, Inc.
Windows is a registered trademark of Microsoft Corporation.
Mac OS X is a registered trademark of Apple Computer, Inc.
Linux is a trademark of Linus Torvalds.
All other names, brands, products or services are trademarks or
registered trademarks of their respective owners.

Safety Precautions
Safety Precautions
Read these instructions before you install, operate, or transport EonStor GSe Pro system.
Setup the EonStor GSe Pro system at a site where the ambient temperature stays lower than
40C.
Install the power source socket outlet near the enclosure where it is easily accessible.
Secure airflow clearance around the enclosure:
- Secure an 18 to 20cm clearance around the enclosure.
- Do not cover the enclosure openings.
- Do not leave the drive bays empty as it will affect the airflow efficiency.
NEVER remove more than one hard disk drive tray out of the enclosure at the same time!
Secure each hard disk drive using its retaining screws.
Put the power cords and other cables away from foot traffic. Do not place things over the
power cords and make sure they do not rest against data cables.
Ensure that the correct power range is being used before powering the device.
If the enclosure is not used for a long time, disconnect it from mains to avoid transient
over-voltage.
Important Notice
The use of Infortrend certified components is strongly recommended to ensure compatibility,
quality and normal operation with your Infortrend products. Please contact your distributor for a
list of Infortrend certified components (eg. SFP, SFP+, HBA card, iSCSI cable, FC cable,
memory module, etc.).

ESD Precautions
ESD Precautions
Avoid touching the PCB boards or connector pins on the hard disk drives.
Avoid dust, debris, carpets, plastic, vinyl, and styrofoam in your work area.
Do not remove the hard disk drive from its anti-static bag before installation takes place.
Drives must not be stacked on top of each other without their protective drive trays. Even when
drives are fixed in the drive trays, contacting the exposed PCB or rear-side interface may
damage the drives.

Service and Maintenance
Service and Maintenance
Keep the faulty hard disk drive in place until you have a replacement unit in hand; removing a
hard disk drive tray will affect airflow within the enclosure.
When transporting the enclosure, repackage all disk drives separately in the original package
foam blocks.
Disconnect the power cords before servicing or cleaning the enclosure.
Use a slightly moistened paper sheet or cloth for cleaning. Avoid using liquid or sprayed
detergent.
When replacing hard drives, insert the hard drive cage as gently as possible while assuring full
engagement. Vibration and shock can easily damage hard drives.
Contact service personnel if any of the following situations occurs:
- The power cord or plug is damaged.
- The enclosure has been exposed to moisture.
- The system has not been working properly.
- The enclosure was dropped against a hard surface.
- The enclosure shows obvious signs of breakage.
When relocating the enclosure, hard disk drives should be removed from the enclosure
beforehand. Please remember the installation order of the hard disk drive and their
corresponding slots.

About This Manual
Table of Contents
Legal Information ..................................................................................................... 2
Contact Information ................................................................................................. 3
Copyright Notice ...................................................................................................... 4
Safety Precautions................................................................................................... 5
Important Notice.....................................................................................................................5
ESD Precautions....................................................................................................................6
Service and Maintenance ......................................................................................................7
Revision History..................................................................................................... 10
1Introduction...................................................................................................11
1.1 Product Overview.....................................................................................................11
1.1.1 Model Naming Conventions..............................................................................11
1.2 Front panel................................................................................................................13
1.3 Rear panel.................................................................................................................14
1.4 Side and Bottom Panel ............................................................................................15
1.5 Hard Drive Designation............................................................................................16
1.6 LED Definitions.........................................................................................................18
1.6.1 Front Panel LEDs..............................................................................................18
1.6.2 Drive Tray LEDs................................................................................................19
1.6.3 Rear Panel Ethernet LEDs................................................................................20
2Hardware Installation .................................................................................. 22
2.1 Before You Start........................................................................................................22
2.1.1 Hot-swappable components..............................................................................22
2.2 Installing Hard Drives...............................................................................................23
2.2.1 Hard Disk Drive Prerequisites...........................................................................23
2.2.2 Inserting the Drive into the Drive Tray...............................................................23
2.2.3 Drive Tray Numbering Sequence......................................................................26
2.2.4 Inserting the Drive Tray into the Enclosure .......................................................27
2.3 Memory Installation..................................................................................................27
2.4 Host Board Installation............................................................................................29
3Powering EonStor GSe Pro ........................................................................ 31
3.1 Powering EonStor GSe Pro for the First Time .......................................................31
3.1.1 To power on and off EonStor GSe Pro..............................................................32
4Connections................................................................................................. 33
4.1 Connection Concept ................................................................................................33

9
5Maintenance................................................................................................. 34
5.1 Replacing the Hard Disk Drive ................................................................................34
5.2 Restore Default Settings..........................................................................................37
Appendix................................................................................................................. 38
Technical Specifications......................................................................................................38
Certifications........................................................................................................................39

Revision History
10
Revision History
Version
Date
Description
1.0
March 2017
Initial release

EonStor GSe Pro 2000 Series Hardware Manual
11
1 Introduction
1.1 Product Overview
The EonStor GSe Pro 2005 and 2008 are ruggedly built and come with five (5) and
eight (8) hard drive bays, respectively. The hard drive bay can support a single 3.5
inch hard disk drive up to 3TB. The hard disk drives can be configured in RAID 0,1,5
and 6, offering users with performance or data backup functionalities. The EonStor
GSe Pro 2005 and 2008 are the perfect NAS storage solution for SMBs, media
services, education and medical institutes.
Features
Rugged construction
Single hard disk support up to 3TB
Hot swappable hard disk drives
Versatile miniaturized NAS storage for ease of placement or portability
Easy to setup and operate
1.1.1 Model Naming Conventions
The naming rules for systems are explained in the example below:
GSeP 2008T GSeP(A) + 2(B) + 0(C) + 08(D) + T(E)
Designation
Description
(A)
GSeP = EonStor GSe Pro systems
(B)
The number that indicates family series.
1 = entry-level SMB
2 = mid-level SMB
(C)
The number that indicates generation
0 = first generation
(D)
The number that indicates bay count.
05 = 5-bay

EonStor GSe Pro 2000 Series Hardware Manual
12
08 = 8-bay
(E)
The letter that indicates CPU performance.
Null = standard performance
T = advanced performance

EonStor GSe Pro 2000 Series Hardware Manual
13
1.2 Front panel
The EonStor GSe Pro 2005 has 5 hard drive slots while the EonStor GSe Pro 2008 has 8 hard
drive slots. In the front of the panel, they both have a power button and three (3) LED
indicators.
Shown below is an illustration of EonStor GSe Pro 2005. The difference between EonStor GSe
Pro 2005 and 2008 externally is that the 2008 has three extra hard disk drive bays.
1
Power button
2
System status LED
3
Fan LED
4
Temperature LED

EonStor GSe Pro 2000 Series Hardware Manual
14
1.3 Rear panel
At the rear of the system, the main difference between EonStor GSe Pro 2005 and 2008 is that
there is only one fan for 2005.
EonStor GSe Pro 2005
EonStor GSe Pro 2008

EonStor GSe Pro 2000 Series Hardware Manual
15
Rear panel components
1
Kensington lock slot
2
Power socket
3
Host board slots (HB 1 on the right, HB 2 on the left)
4
10 GbE(SFP+) ports
5
1 GbE(RJ-45) ports
6
USB 3.1 Gen2 ports
7
USB 3.0 ports
8
Restore default button
NOTE
Always insert the host board to slot 1 (which is on the right) first.
1.4 Side and Bottom Panel
Slide the side case outward; there are two (2) memory slots (shown in red).
One (1) UART mini port locates at the bottom for firmware debug.

EonStor GSe Pro 2000 Series Hardware Manual
16
1.5 Hard Drive Designation
The hard disk drives are located from left to right in numeric order.
EonStor GSe Pro 2005

EonStor GSe Pro 2000 Series Hardware Manual
17
EonStor GSe Pro 2008

EonStor GSe Pro 2000 Series Hardware Manual
18
1.6 LED Definitions
1.6.1 Front Panel LEDs
Name
Icon
Color
Status
1. System status
LED
Blue / Amber
Blue indicates the device is ready.
Flashing Blue indicates the device is
booting up or shutting down.
Amber indicates the device has
critical errors or errors occur.
2. Fan LED
Blue / Amber
Blue indicates the system FAN
module is in normal condition.
Amber indicates the system FAN
module is in abnormal condition.
3 .Temperature
LED
Blue / Amber
Blue indicates the system
temperature is normal.
Amber indicates the system
temperature is abnormal.

EonStor GSe Pro 2000 Series Hardware Manual
19
1.6.2 Drive Tray LEDs
Two (2) LED indicators are located on the bottom of each drive tray. When notified by a drive
failure message, you should check the drive tray indicators to find the correct location of the
failed drive.
LED
Color
Status
1. Drive Busy
LED
Blue
Flashing Blue indicates data is being written
to or read from the drive. The drive is busy.
OFF indicates that there is no activity on the
disk drive.
2. Power Status
LED
Green/
Red
Green indicates that the drive bay is
populated and is working normally.
Red indicates that the disk drive has failed, or
a connection problem occurred.

EonStor GSe Pro 2000 Series Hardware Manual
20
1.6.3 Rear Panel Ethernet LEDs
10 GbE(SFP+):
LED
Color
Status
1. Link status
LED
Green
Green indicates a connection has been
established.
Flashing green indicates data I/O.
Off indicates connection not established.
2. Speed
LED
Green
Green indicates 10Gb connection established.
Off indicates 1G/100Mb connection
established.
