Ingenico iCT220, iCT250 User manual

RESTAURANT
Quick
Reference
Guide
TERMINAL MESSAGES
AMOUNT DUE/BALANCE DUE: A partial
authorization has occurred. Ask
customer for another form of payment
for the remaining balance of the sale.
Press ENTER to print the receipt.
Pressing CANCEL will not void the
transaction.
AVS (ADDRESS VERIFICATION SERVICE): Checks if
the street address and ZIP code entered
match the customer’s billing address.
CALL: Call Voice Authorization Center. If
approved, proceed with Offline Entry.
HOLD/CALL OR PICK UP CARD: Hold the card.
Call the Voice Authorization Center.
CARD READ ERROR: Magnetic stripe did not
read. Swipe card again or manually key-
in account number.
LOST COMM WITH HOST: A communication
error has occurred. Check line
connections, call Help Desk.
GB (NUMBER): Good batch. Batch
transmission accepted.
MANUAL ENTRY NOT ALLOWED: Current
transaction will not allow manual entry.
Debit cards may not be manually keyed-
in.
QD (NUMBER) OR RB (NUMBER): Quit
Duplicating or Rejected Batch. Call Help
Desk.
RECORD NOT FOUND: Invoice number is not
found in terminal batch.
SETTLEMENT UNSUCCESSFUL: Settlement failed,
call help desk.
V-CODE: Verification Code. A 3-4 digit
non embossed number found on card
signature panel or near embossed
account number on front. V-code may
be prompted for on a manually-entered
transaction.
EBT DEFINITIONS
ELECTRONIC VOUCHER: Form which is
completed by a merchant when a Food
Stamp transaction authorization cannot
be received through the terminal.
FCSID (FOOD AND CONSUMER SERVICES
IDENTIFIER): Identifies a merchant as
approved to accept Food Stamps.
VOUCHER AP (VOUCHER APPROVAL CODE):
A Voice Authorized Approval Code
received when a Food Stamp transaction
authorization through the terminal is
not possible. To obtain, call the Voice
Authorization Center.
VOUCHER S/N (VOUCHER SERIAL NUMBER):
A pre-printed number found on an
Electronic Voucher form.
0300010
V081314
© 2014 Total System Services, Inc. All rights reserved worldwide. TSYS is a federally registered service mark of Total System Services, Inc. Other marks are trademarks
or registered trademarks of their respective owner.
www.tsysacquiring.com
Bank Name ______________________
Bank Phone ______________________
Help Desk Phone __________________
V Number _______________________
Voice Authorization Phone ____________
Merchant Number ID _______________
Other __________________________
_______________________________
QUICK REFERENCE
INGENICO®
iCT220, iCT250, iWL220, iWL250
IMGEMV2
CREDIT SALE
• Press 1
• Choose CREDIT
• Enter sale amount and press ENTER
• Enter tip amount and press ENTER
• Swipe or insert customer card
- Select the desired language
- Have customer enter PIN on PIN pad
and press ENTER
• Terminal dials out, and receipt prints
- Remove the card
MAIL/PHONE SALE
• Press 1
• Choose CREDIT
• Enter sale amount and press ENTER
• Enter card number and press ENTER
• Enter expiration date (MMYY) and press
ENTER
• Enter tip amount and press ENTER
• Press Enter to accept transaction
• Card present? Choose YES or NO
- Enter V-Code/CID Code and press
Enter, or press Enter to bypass
- If bypassed, Choose V-Code option:
1(Unreadable), 2(Not Present), 3(Not
Provided)
- Enter street address number and press
ENTER, or press ENTER to bypass
• Enter Zip Code and press ENTER, or press
ENTER to bypass
• Terminal dials out, and receipt prints
DEBIT SALE
• Press 1
• Choose DEBIT
• Enter sale amount and press ENTER
• Enter tip amount and press ENTER
• Swipe or insert customer card
- Select the desired language
- Enter cash back amount and press
ENTER, or press ENTER to bypass
• Press ENTER to accept total
• Have customer enter PIN on PIN pad
and press ENTER
• Terminal dials out, and receipt prints
- Remove the card
CREDIT REFUND
• Press 2
• Choose CREDIT
• Enter refund amount and press ENTER
• Swipe customer card, insert customer
card, or enter card number and press
ENTER
- Enter expiration date (MMYY)
and press ENTER
- Select the desired language
• Terminal displays Captured,
and receipt prints
- Remove the card
DEBIT REFUND
• Press 2
• Choose DEBIT
• Enter refund amount and press ENTER
• Enter original transaction date
(MMDDYY) and press ENTER
• Enter original transaction time
(HHMMSS) and press ENTER
• Swipe or insert customer card
- Select the desired language
• Have customer enter PIN on PIN pad
and press ENTER
• Terminal dials out, and receipt prints
- Remove the card
REVERSAL
• Press 4
• Choose a search option
• Enter retrieval information and
press ENTER
• Choose SELECT
• Press ENTER to accept transaction
• Terminal dials out, and receipt prints
CREDIT OFFLINE ENTRY
• Press 5
• Choose CREDIT
• Enter amount and press ENTER
• Swipe customer card, insert customer
card, or enter card number and press
ENTER
- Enter expiration date (MMYY) and press
ENTER
- Card present? Choose YES or NO
- Select the desired language
• Enter approval code (six digits), and
press ENTER
• Enter transaction ID (15 digits), and
press ENTER
• Terminal displays Captured and receipt
prints
- Remove the card

DEBIT RE-ENTER
• Press 5
• Choose REENTER
• Choose DEBIT
• Choose transaction type
• Swipe customer card, insert customer
card, or enter card number and press
ENTER
- Select the desired language
• Enter original transaction date
(MMDDYY) and press ENTER
• Enter original transaction time
(HHMMSS) and press ENTER
• Enter reference retrieval number
(12 digits), and press ENTER
• Enter trance number (six digits),
and press ENTER
• Enter Network ID (one character),
and press ENTER
• Enter settlement date (MMDD),
and press ENTER
• Enter approval code (six digits),
and press ENTER
• Enter amount and press ENTER
• Enter tip amount and press ENTER
- Enter cash back amount and press
ENTER, or press ENTER to bypass
• Press ENTER to accept amount
• Terminal displays Captured,
and receipt prints
• Press CANCEL
AUTHORIZATION ONLY
• Press 9
• Choose AUTH ONLY
• Choose AMT AUTH
• Swipe customer card, insert customer
card, or enter card number and
press ENTER
- Enter expiration date (MMYY)
and press ENTER
- Card present? Choose YES or NO
- Enter Zip Code and press ENTER,
or press ENTER to bypass
- Select the desired language
- Have customer enter PIN on PIN pad
and press ENTER
• Terminal dials out, and receipt prints
- Remove the card
BALANCE INQUIRY
• Press 7
• Choose card type
• Swipe customer card, insert customer
card, or enter card number and
press ENTER
- Enter expiration date (MMYY)
and press ENTER
- Select the desired language
- Have customer enter PIN on PIN pad
and press ENTER
• Terminal dials out, and receipt prints
- Remove the card
TIP ADJUST
NOTE: Adjustments are not allowed on
Smart Card/Chip Card sales. Tip must be
added at time of sale.
• Press 6
• Choose a search option
• Enter retrieval information and
press ENTER
• Choose SELECT
• Enter new tip amount and press ENTER
• Terminal displays Captured,
and receipt prints
• Add Another? Choose YES or NO
- If Yes, repeat steps to add
another tip
OPEN TAB
• Press 3
• Choose OPEN
- Tab Amount: Choose Accept or Change
• Enter tab amount and press ENTER
• Swipe customer card, insert customer
card, or enter card number and
press ENTER
- Enter expiration date (MMYY)
and press ENTER
- Card present? Choose YES or NO
- Enter Zip Code and press ENTER, or
press ENTER to bypass
- Select the desired language
- Have customer enter PIN on PIN pad
and press ENTER
• Terminal dials out, and receipt prints
- Remove the card
CLOSE TAB
• Press 3
• Choose CLOSE
• Enter retrieval information and press
ENTER
• Choose SELECT
• Press ENTER to accept transaction
• Enter tip amount and press ENTER
• Terminal displays Captured, and receipt
prints
DELETE TAB
• Press 3
• Choose DELETE
• Enter retrieval information and press
ENTER
• Choose SELECT
• Choose YES
• Terminal displays Tab Deleted, and
receipt prints
ADD SERVER
• Press #
• Choose CLERK MENU
• Choose ADD ID
• Enter server ID and press ENTER
• Add Another? Choose YES or NO
- If Yes, repeat steps to add
another server
REPRINT A RECEIPT
• Press 9
• Choose REPRINT
• Choose a search option
• Enter retrieval information and press
ENTER
• Choose SELECT
• Choose a receipt type
• Receipt prints
TRANSACTION ADJUST
NOTE: Adjustments are not allowed on
Smart Card/Chip Card sales.
• Press 9
• Choose TRANS ADJUST
• Choose a search option
• Enter retrieval information and press
ENTER
• Choose SELECT
• Enter new sale amount and press ENTER
• Terminal displays Captured, and receipt
prints
REPORTS
• Press #
• Choose REPORTS MENU
• Choose report: Summary (total amount)
or Detail (each transaction)
• Choose PRINT
• Report prints
• Press CANCEL
VIEW TOTALS
• Press #
• Choose BATCH MENU
• Choose BATCH TOTALS
• Terminal displays totals
• Press ENTER
• Press CANCEL
MANUAL BATCH SETTLEMENT
• Press 8
• Choose YES
- Print Reports? Choose YES or NO
- Report prints
FAILED SETTLEMENT
• Terminal will display QDXXXXX or
RBXXXXX
• DO NOT DELETE BATCH OR CONTINUE
WITHOUT HELP DESK VERIFICATION
• Call Help Desk
AUTHENTICATE THE TERMINAL
• Press #
• Choose MAINTENANCE
• Choose AUTHENTICATE
• Enter authentication code and press
ENTER
• Enter zip code and press ENTER
• Terminal dials out, and receipt prints
DEACTIVATE THE TERMINAL
• Press #
• Choose MAINTENANCE
• Choose DEACTIVATE
• Choose YES
• Terminal dials out, and receipt prints
ALPHA CHARACTERS
• Press key corresponding with desired
letter
• Press Fkey until desired letter appears
[Number + F key = Letter]
CARD TYPES ACCEPTED
• Visa
• MasterCard
• American Express
• Discover
• JCB
• Diners Club
• Carte Blanche
• PayPal
• ATM/Debit Cards
NOTE: Italicized steps are optional and may not be prompted for.
NOTE: Printing the customer copy is an option on all transactions.
