CUSA EXcel

CUSA EXcel
Console Testing to IT0032 Issue 2
Remove the rear and
left side panels
DANGER
Live mains voltages will be exposed
Only remove the
right side panel if required
Console Full Function Testing

CUSA EXcel
3.1. Visual checks
Console Testing to IT0032 Issue 2
Visually inspect the console for
damage which would effect the
normal function of the system
including:
All covers and panels
Casters (including locks)
Membrane panels
Switches
Moving parts
Footswitch
All cables
Console Full Function Testing

CUSA EXcel
3.2 Visual checks
Console Testing to IT0032 Issue 2
Visually inspect the console
wiring looms and connectors
to ensure:
Firm connections
Undamaged
Console Full Function Testing

CUSA EXcel
3.3 Visual checks
Console Testing to IT0032 Issue 2
Visually inspect the PCB
potentiometers to ensure:
All are paint lock and
undamaged
The only exceptions are
potentiometers used for
adjust when carrying out
these tests
Console Full Function Testing

CUSA EXcel
4.1 Alarm tests
Console Testing to IT0032 Issue 2
With the console set up and operating
in the STANDBY state press the TEST
button on the display and check:
All amplitude indicators illuminate for
approximately 4 seconds
Check no Alarms have been activated
Console Full Function Testing

CUSA EXcel
4.1 Alarm tests (Continued)
Console Testing to IT0032 Issue 2
With the console set up and operating
in the RUN state set the amplitude to
100% and tissue select to STD check:
All amplitude indicators illuminate
while the amplitude pedal on the
footswitch is pressed
Check no Alarms have been activated
Console Full Function Testing

CUSA EXcel
4.2 Alarm tests
Console Testing to IT0032 Issue 2
With the console set up and operating
in the STANDBY or RUN state
disconnect the footswitch Plug from
the console and check:
The warning triangle and the footswitch
alarm indicator is active and the alarm
tone can he heard
Reconnect the footswitch and check:
The warning alarms visual and audio
cancel and the console footswitch
functions are normal
Console Full Function Testing

CUSA EXcel
4.2 Alarm tests (continued)
Console Testing to IT0032 Issue 2
With the console set up and operating
in the RUN state loosen the hand piece
tip and set the amplitude to 10% then
press the amplitude pedal on the
footswitch and check:
The warning triangle and the tip alarm
indicator is active and the alarm tone
can he heard
Retighten the tip and check:
The warning alarms visual and audio
cancel and the hand piece functions
normally
Console Full Function Testing

CUSA EXcel
4.2 Alarm tests (continued)
Console Testing to IT0032 Issue 2
With the console set up and operating in
the RUN state disconnect the cooling
reservoir from the console and check:
The warning triangle and cooling alarm
indicator and the alarm tone can he heard
after approximately 30 seconds
Reconnect the reservoir and check:
The warning alarms visual and audio
cancel after approximately 30 seconds and
the console functions normally
Paper towels will be required to mop up
cooling water returning to the reservoir
Console Full Function Testing

CUSA EXcel
4.2 Alarm tests (continued)
Console Testing to IT0032 Issue 2
With the console set up and operating
in the RUN or STASNDBY states
disconnect the hand piece plug from
the console and check:
The warning triangle and hand piece
alarm indicator and the alarm tone can
he heard
Reconnect the reservoir and check:
The warning alarms visual and audio
cancel
Note the console will restart and run
through the pre-set start up sequence
Console Full Function Testing

CUSA EXcel
Console Testing to IT0032 Issue 2
5.1 Vacuum pump speed mesurements
Cooling Prime =
Stopped
Standby state =
≥1520 RPM
Run state =
3200 RPM ±100
Console Full Function Testing

CUSA EXcel
Console Testing to IT0032 Issue 2
On the suction pump motor controller
adjust potentiometer R18 (R12 on older
PCB’s) For the correct speed with the
console in the RUN state
DO NOT adjust the other potentiometers
5.1 Vacuum pump speed adjustment
Console Full Function Testing

CUSA EXcel
5.1 Cooling pump speed Measurements
Console Testing to IT0032 Issue 2
With a tachometer measure the speed
of the following motors
Cooling Prime =
138±2 RPM
Standby State =
61-68 RPM
Run State =
61-68 RPM
Console Full Function Testing

CUSA EXcel
Console Testing to IT0032 Issue 2
5.1 Cooling pump speed adjustment
On the cooling pump motor
controller
Adjust potentiometer R2 for the
correct motor speed
DO NOT adjust the other
potentiometers
Console Full Function Testing

CUSA EXcel
Console Testing to IT0032 Issue 2
5.2 DC Power supply Measurements
ALL VOLTAGE ADJUSTMENTS
ARE MADE WITH THE
CONSOLE IN THE RUN STATE
ALL MESUREMENTS ARE
TAKEN DIRECTLY FROM THE
ULTRASONIC BOARD
‘C’ Type Ultrasonic assemblies
Console Full Function Testing

CUSA EXcel
Console Testing to IT0032 Issue 2
5.2 DC Power supply Measurements
‘C’ Type Ultrasonic PCB ‘A’ & ‘B’ Type Ultrasonic PCB
Establish what type of ultrasonic assembly is fitted to the console
Console Full Function Testing

CUSA EXcel
Console Testing to IT0032 Issue 2
5.2 Bias 5v DC power supply
DC Bias power supply output
Measure between TP86 and TP87
Set to 5.00Volts
Tolerances 4.95v to 5.05v
‘C’ Type Ultrasonic PCB
Console Full Function Testing

CUSA EXcel
Console Testing to IT0032 Issue 2
5.2 Bias 5v DC power supply adjustments
Lambda DC Bias Power Supply
Console Full Function Testing

CUSA EXcel
Console Testing to IT0032 Issue 2
5.2 Bias 5v DC power supply
DC Bias power supply output
Measure between TP6 and JMP16
Set to 4.50Volts
Tolerances 4.45v to 4.55v
‘B’ Type Ultrasonic PCB
On obsolete ‘A’ Type Ultrasonic PCB’s set 4.75v, tolerance 4.70 to 4.80
Console Full Function Testing
