iPECS LDP-9240D Specification sheet

LDP-9240D Button Layout
15. Speaker
14. Volume
Ericsson-LG iPECS
LDP-9240D Handset Key Features Guide
1. LCD Screen: Displays your phones status, dialing
directories, and text message information.
2. Soft keys: Soft keys are interactive, changing function
based on the phones status.
3. Flexible Button (‘ex key’): a line or feature can be
assigned to these 24 exible buttons - ask your system
administrator for help.
4. Flash button: use the ash button to dial straight out to
another line once you have nished a call.
5. Speed: assign or use assigned speed dial numbers.
6. Trans/PGM: transfer the current active call or access
the Program menu while the phone is idle.
7. Directory: Accesses your private or public directory for
speed dialing.
8. DND (Do-Not-Disturb): blocks incoming calls. You can
also activate Do-Not-Disturb while the phone is ringing.
Use to allow you to forward all calls to another number
9. Call Back: when a light shows on the call back button
this indicates you have a message, use to access your
Voice Mailbox.
10. Mute: mute the call so that the caller cannot hear your
voice.
11. Hold/Save: Use to place a call on Hold. Also, use to
access a held call. In menu mode, it saves your inputs.
12. Headset: when a headset is connected, toggle call
between headset and speaker.
13. Flash button: use the ash button to dial straight out to
another line once you have nished a call.
14. Volume control: adjust the ring, headset, handset, and
speaker volume.
15. Speakerphone: toggle the speakerphone on and o󰀨
during a call. The button will automatically illuminate
when the phone is in menu mode.
16. Navigation key: use to navigation through the soft
keys and menu options.
Button Guide
2. Three soft keys
1. LCD Display
Answering an Incoming Call
Lift the handset or press the ashing Flex button (as needed), the call will be connected.
You may also use pick up codes assigned by your installer engineer to answer other ringing handsets
from your desk phone.
To answer a call on another extension that is programmed to one of the phones 12 ex keys, press
the ashing ex key before lifting the handset.
Making an External Call Lift the handset and press a free ex key allocated to a line, or dial 9 to pick up an outside line.
Once you have the outside line, dial your number.
Making an Internal Call Lift the handset. Dial the extension number or press the ex key assigned to the contact.
Rejecting a Call Press the DND button when a call comes in - the caller will get a busy tone.
Placing a call on hold During a call, press the Hold/Save button.
To reconnect the call, press the ashing line key.
Dealing with calls
4.
3. 24 exible
buttons (ex keys)
across 2 pages
5. 6.
7. 8. 9.
10. 11. 12.
16. Navigation

Do-Not-Disturb
Makes your extension
unavailable for calls
Press the DND button to activate.
Press the DND button again to deactivate.
Conference Calls
3 way calling
Establish a call with one of the desired conference parties,
Select the conf soft button
Establish call with the other conference party,
Press the conf soft button to establish the conference.
To place a conference call on hold, press the Hold/Save button. Press again to retrieve the
conference.
Transferring a Call
During an active call, press the Transfer button
Press TRANS/PGM
Call the required recipients number
For unscreened Call Transfer simply hang-up
For screened Call Transfer, when the call is answered, announce the call and hang-up
Transferring a call
Features
Call waiting
Speed Dial
Lift the handset
Press the Speed button
Dial the desired System or Station Speed Dial number
Quick access call tools
The last number dialed on an external call is automatically saved in the Last Number Redial
(LNR) bu󰀨er. Register redial to a ex button.
Lift the handset.
Press the speed button
Dial *
or
Select the Redial ex key
Use the Volume keys to select from the last numbers dialed or received
Press the OK soft button or Hold/Save button
Last Number Redial (LNR)
When dialing an extension that is engaged, the Camp On feature allows the station to be notied
that there is a call waiting. If the called party is busy, you may activate Camp-On which allows you to
wait o󰀨-hook for the called station to answer.
Press * and await an answer.
Camp on
Press the ashing line key or press trans/PGM.
Returning to Caller from a Transfer
Features and operations are based on number plan 1. Please consult your installer engineer for further details.
