Jacuzzi 67662-X5127H2 User manual

TUB FILLER FAUCET
Jacuzzi®Item # NW50827 (CP) / NW50826 (BN) / NW50845 (ORB)
NW50817 (MB) / NW50818 (BB)
MODEL # 67662-X5101 / 67662-X5104 / 67662-X5127H2
67662-X517001 / 67662-X518204
1
Questions, problems, missing parts? Before
returning to your retailer, call our customer service
department at 1-800-288-4002, 6 a.m. - 5 p.m.,PT
and 9 a.m. - 8 p.m.,ET, Monday - Friday
ATTACH YOUR RECEIPT HERE
Purchase Date ___________________
2019/04/08 V2
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate, or install the product.
WARNING:
• Follow the installation instructions carefully. Proper installation is the installer’s responsibility.
• Failure to follow correct installation procedures can result in the faucet being loose, which can result in serious injury.
• Not suitable for installation in concrete floors.
CAUTION:
• Check local building codes before beginning installation to ensure compliance.
PREPARATION
Before beginning the assembly of this product, make sure all parts are present. Compare parts with the package
contents and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 90 minutes (including removal of old faucet)
Tools Required for Assembly (not included): Adjustable Wrench, Silicone Sealant, Phillips Screwdriver, Pencil, Electric Drill
ITEM / ARTICLE / ARTÍCULO # 0577330 (CP)

2
PACKAGE CONTENTS
PART DESCRIPTION
A Faucet
B Plastic Wrench
C Standpipe
D Escutcheon
E Screw (ST6.3x1.8)
F Anchor
G
H
Hand Shower
I
Shower Hose
2.5mm Hex Wrench
1
1
1
1
3
3
1
1
1
A
B
C
D
E
F
G
H
I
QUANTITY

3
ASSEMBLY INSTRUCTIONS
Loosen the set screw (1) pre-assembled to the
spout (2), rotate the spout (2) about 90° to align
handle (3), then tighten the screw.
Place the escutcheon (1) over the standpipe (2)
and then push it to the base.
Place the assembly with the flexible supply lines (1)
through the prepared hole. Then holding the
escutcheon (2), secure the standpipe (3).
Note: If mounting into wooden floor, secure the
standpipe (3) using screws (4) only (wall plugs are
not needed). If mounting into solid floor, mark the
position of holes first and then secure the standpipe
(3) using anchors (5) and screws (4). Where requried
ensure correct anchors for your floor type are used.
Connect one end of the shower hose (1) to the mixer
(2) and the other end to the hand shower (3). Ensure
the washer (4) is in each end for seal.
23
1
2
1
1
2
1
2
2
3
Floor
Floor
Screw the standpipe (1) onto the mixer (2) by hand.
Turn in a clockwise direction until it is tight.
Note 1: Do not to reverse the cold and hot supply lines.
Note 2: After installing the standpipe (1), the inlet supply
lines will be exposed 12 in. below the standpipe. Please
pay attention to set aside enough space to connect the
water supply lines and prevent the water inlet supply
lines from twisting.
4
2
1
5
1
2
5
3
4
6
1
2
4
3
4
Front
Hot inlet supply lineCold inlet supply line
1/4 in. dia.
Drill a hole 2 1/4 in. diameter min. - 2 9/16 in. diameter
max. in the floor with an electric drill (1). Mark the
locations for the screws with a pencil (2). Then drill
three holes 1/4 in. diameter for the screws in the floor
with an electric drill (1).
305.0mm
[ 12 " ]

4
ASSEMBLY INSTRUCTIONS
CARE AND MAINTENANCE
•
and void your warranty.
Connect the flexible supply lines (1) to the water
supplies (2).
7
1
2
8
1
3
There is a leak from aerator when the
faucet is on.
1. Remove and reinstall the aerator.
2. Call customer service for a new
aerator and replace it after you receive
the new aerator assembly.
The aerator does not fit correctly on
the faucet.
Hand shower leaks or has a low flow
pattern.
Hand shower is dirty or damaged. Remove the hand shower and check
for any debris clogged at the shower
connection, check the hand shower’s
spray nozzle for any build up or debris.
The aerator has an irregular or
reduced water flow.
Remove the aerator and clear the
debris.
The aerator is dirty.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
There is a leak from under the handle
or there is a leak from aerator when
the faucet is off.
The cartridge is damaged. Remove the handle and replace the
cartridge.
3
2
Flushing debris and checking for water leaks:
Important: After installation is complete, remove the
aerator (2) with the plastic wrench to flush debris from
the water lines. Do not lose the o-ring(1) in the
aerator(2).Turn on the water supply and allow both hot
and cold water to run for at least one minute each.
Remove hand shower and push the diverter pin
button (3) to the bottom position. This will divert water to
the hand shower. Run for at least one minute. This
flushes away any debris that could cause damage or
blockage to internal parts. Check for water leaks. After
flushing, completely shut off water, and reinstall the
aerator (2). The diverter pin button (3) should
auto-reset back into the outward position.
Retighten any water/hose connections if necessary,
but be careful to not overtighten to prevent damage.
Diverter Instructions : To divert water from the faucet spout to the hand shower, push in the diverter pin (3) to the
bottom position.To divert water back to faucet spout, turn the water completely off, and then on again.
The diverter pin (3) will auto-reset back into the outward position. If the diverter pin (3) does not auto-reset back into the
outward position, then gently rotate the diverter pin (3) button left or right while the water is shut off, and it should easily reset
back to the outward position.
CAUTION: While water is running through the hand shower, the diverter will not pull outward to reset to the faucet spout unless
the water is shut off and turned on again. DO NOT FORCIBLY PULL THE DIVERTER PIN (3) OUTWARD WHILE WATER IS
RUNNING. This can cause damage to the diverter pin (3) assembly.

5
The manufacturer warrants this faucet to be free from defects in workmanship and material present at time of shipment
from the factory for a limited lifetime from the date of purchase. This warranty applies only to the original purchaser. The
manufacturer agrees to correct such defects at no charge or, at our option, replace the faucet with a comparable or
superior model. To obtain warranty service, call our customer service department at 1-800-288-4002 for return
authorization and shipping instructions. You may be required to present a copy of your sales receipt as proof of purchase.
All cost of removal and reinstallation are the expressed responsibility of the purchaser. Any damage to the faucet by ac-
, are the purchaser’s
responsibility. The manufacturer assumes no responsibility whatsoever for faucet installation during the warranty period.
There is no further expressed warranty. The manufacturer disclaims any and all implied warranties. The manufacturer shall
not be liable for incidental, consequential or special damages arising at or in connection with product use or performance
rights which vary from state to state. This warranty supersedes all prior warranties.
WARRANTY
For replacement parts, call our customer service department at
1-800-288-4002, 6 a.m. - 5 p.m., PT and 9 a.m.-8 p.m., ET,
REPLACEMENT PARTS LIST
Printed in China
2
1
3
467
5
8
910 11 12
14
13
15
18
PART DESCRIPTION PART#
1 Hand Shower RP38356*
2 Shower Hose RP38236*
3 Aerator RP30185
6O-Ring RP60107
7 Set Screw (M5x0.8-6g) RP50002
8 Cartridge RP20063
9 Bonnet RP70015
10 Cap RP80008*
11 Screw RP50049
12 Handle RP13381*
14 Index RP10067*
16 Screw RP50037
15 Escutcheon RP80502*
17 Anchor RP50036
18 Supply Line RP70661
4Plastic wrench RP30186
13 Set Screw RP50113
5 Spout assembly RP80501*
Monday - Friday
16
17
*=Color Options: 01=Chrome, 04=Brushed Nickel,
2707=Oil Rubbed Bronze, 7001= Matte Black,
8204= Brushed Bronze.
