jbc CS-F Series User manual

INSTRUCTION MANUAL
www.jbctools.com
Compact Desoldering Station
with Electric Pump
Ref. CS-F

Packing List
The following items are included:
Brass Wool ...................1 unit
Ref. CL6210
Sponge ........................ 1 unit
Ref. S0354
Micro Desoldering
Iron ................................... 1 unit
Ref. DS360-A
C360004 already inserted
CSV Control Unit ......... 1 unit
Ref. CSV-1F (120V)
CSV-2F (230V)
CSV-9F (100V)
Power Cord .....................1 unit
Ref. 0023715 (120V)
0023714 (230V)
0024092 (100V)
2

Manual ......................... 1 unit
Ref. 0026123
Electric Desoldering
Module ............................ 1 unit
Ref. MS-A
DS360-A Accessories
Ref. 0010259
Filter Box ........................ 1 unit
Ref. 0005966
It contains 50 filters
Suction Filter ................ 1 unit
Ref. 0821830
Module Cable ............. 1 unit
Ref. 0010207
Cotton Filter ................... 1 unit
Ref. 0781046
It contains 10 filters
Cleaning Rods .............. 1 unit
Ref. 0008466
Tips .......................... 10 units
Ref. C360002 (x5)
C360004 (x5)
Cleaning Brush ......... 1 unit
Ref. 0008297
Union Flanges ......... 2 units
R ef. 0 0113 5 6
Solder Collector ..... 2 units
Ref. 0008467
Filter ........................... 2 units
Ref. 0008473
www.jbctools.com
3

Features and Connections
Micro
Desoldering Iron
Ref. DS360-A
Suction Filter
Ref. 0821830
Module Cable
Ref. 0010207
Cable Collector
Process
Screen
Adjustable Stand:
Intelligent Heat Management
Tip Cleaner Brass Wool
with Antisplash Membrane
and Wiper
Earth Fuse
Equipotential Connection
USB-B Connector
Fume Extractor Connector
Power Socket
Main switch
Fuse
4
