ENGLISH
1
We appreciate the confidence you have placed in JBC in purchasing this station.
It is manufactured to the most stringent quality standards in order to give you the
best possible service. Before turning on your station, we recommend you to read
these instructions carefully.
Control Unit
Indication LCD
multifunction
Temperature
selection
Air flow
regulation
Hot air
ON/OFF
Vacuum pump
selection
Vacuum inlet
Heater stand JT 8700
Ref. 0828700
Heater
Extractor stand
Ref. 0932845
Heater inlet
Tripod 20
Ref. 0932050
Tripod 40
Ref. 0932250
Suction tube
with connectors
Ref. 0932330
JT 7000
Hot-air flow
repair station

2
ENGLISH
OPERATION
Turning on
Turn on using the switch on the rear of the
control unit. The screen shows OFF.
Descriptionofcontrols
-PEDAL:
Hot air is produced when it is held down.
Releasing it returns the system to OFF,
though the turbine continues to operate until
the air temperature falls below 100°C.
-BUTTONS:
Activates or desactivates the hot-air flow. After a
function-time of one minute the hot-air flow
switches automatically off.
On/off switch for the suction pump.
- CONTROLS:
TEMPERATURE
This enables temperatures from 150 to 450°C
to be selected.
The display shows the actual air temperature
when the unit is working.
AIR FLOW
This enables the air flow to be set on a scale
from 1 (corresponding to the lowest setting
of 6 l/min) to 10 (corresponding to the
highest of 45 l/min).
HEAT
VACUUM
SPECIFICATIONS
The JT7000is a hot air generating station intended
for repair work involving electronic circuits with
SMDs of any size.
-JT 7000 230V 50Hz EU: Ref. 7000200
-JT 7000 230V 50Hz UK: Ref. 7000201
-JT 7000 120V 60Hz US: Ref. 7000100
Thestation’scomponents
- Control Unit with 900 W heater
- JT 8700 heater stand Ref.0828700
- Extractor stand Ref.0932845
- Set of 5 protectors (Fig. 1, page 36)
- Set of 5 extractors (Fig. 2, page 36)
- 2 tripods for the protectors (Fig. 1, page 36)
- Set of 4 suction cups Ref.0930110
- 3 nozzles
In order to make the nozzles removal easier, the
stand has a special bushing. (Fig. 3, page 36).
- Suction tube with connectors Ref.0932330
- Pedal with cable and connector Ref. 0964551
- Spare filters Ref.0786620
- Instructionmanual Ref.0825400
ControlUnittechnicalspecifications
- Temperature selection from 150 to 450°C
- Accuracy of selected temperature: ± 5%
- Air flow regulation: 6-45 l/min
- Station's maximum power: 1000W
- ESD protected housing.
Typical surface resistance: 105-1011Ohms/square
- Complies with EC standards on electrical safety,
electromagnetical compatibility and antistatic
protection.
- Weight of complete unit: 6.2 kg

ENGLISH
3
- Use the pedal or the HEAT button to start the
hot-air generator, directing it with a circular
movement at the component terminals and
taking care to distribute the heat evenly.
- When the soldering flux turns liquid the extractor
will automatically lift the component.
B) Extractor:
- Select extractor size in function of the IC to be
desoldered. Use the VACUUM button to start
the suction pump.
DESOLDERING PROCEDURE
We would also recommend the use of the nozzles of
largerdiameter,reservingthesmallestone(diam.4
mm) for desoldering small components such as
resistors, condensers and the like, bearing in mind
that with this small nozzle the concentration of heat
is greater and care must be taken to avoid burning
the printed circuit; we recommend keeping below a
temperature of 350 °C and air flow of 6.
Depending on the size of the integrated circuit to be
desoldered, you will have to use:
A) Protector + tripod
B) Extractor
C) Tripod
A) Protector + tripod:
- Select protector and tripod size in function of
the IC to be desoldered and place it over the
component.
- Use the VACUUM button to start the suction
pump and then fit the tripod. Press the sucker
down until it sticks onto the component.

4
ENGLISH
There are different models of protectors and
extractors as accessories.
The measurements of all the extractors and
protectors are given on page 34 of instructions
manual.
C)Tripod:
For small components for which an extractor
cannot be used, we recommend use of tripod 20
Ref. 0932050, as shown in the figure.
Use the tripod 40 Ref. 0932250 for larger integrated
circuits.
SOLDERING PROCEDURE
1 After desoldering the component, any solder
left on the printed circuit should be removed
using a desoldering station. We recommend
our station, the AR 5500 station.
- Fit the extractor and press the sucker down until
it sticks onto the component.
- Use the pedal or the HEAT button to start the
hot-air generator, directing it with a circular
movement at the component terminals and taking
care to distribute the heat evenly.
- When the soldering flux turns liquid the extractor
will automatically lift the component.

ENGLISH
5
Soldering Iron 2210 ref. 2210000 for great
precision tasks, like SMD solders, etc.
Soldering Iron 2245 ref.2245000 for general
soldering tasks in professional electronics.
These soldering irons have a wide range of
cartridges with different models of tips. The
cartridge 2245-009 and 2245-010 are specially
designed for soldering SMD circuits of the
QFP and PLCC types.
Solder wire with a diameter of between 0.5 and
0.7 mm should be used.
6 Depending on the nature of the component to
be soldered, use soldering paste together
with our hot air station TE 5000, which gives
very accurate air-flow regulation, between
2 and 11 l/min.
OPERATING INCIDENTS
The suction cup does not adhere to the
component.
Deficient aspiration, Vacuum.
1 Verify if the suction cup is well placed and in
perfect condition.
2 Check the incoming air filter in the interior of
the station and replace it if dirty or obstructed.
2 Place the component or printed circuit.
3 When the component is correctly placed,
solder its pins.In the case of integrated circuits
of the Flat Pack type, first solder one pin of
every IC angle to fix it in place in the circuits.
4 Apply Flux FL 9582 in pads and leads.
5 Solder the remaining pins. For that, we
recommend you use our soldering station,
the Advanced Series, which has 2 models
of irons.

6
ENGLISH
JBC reserves the right to make technical changes without
prior notification.
Error messages
Whenever the ERR message appears, the
equipment turns itself off completely.
The following messages are displayed:
- BLANKSCREEN
Power failure.
Check for blown fuses.
- ERR 1
The temperature will not rise.
Possible causes: heating element open or blown
fuse.
- ERR 3
No reading from the thermocouple.
Possible cause: open thermocouple.
- ERR 6
Insufficient air flow which causes an excesive
rise of the heating temperature.
Before recuperating this type of error you must
wait until the temperature goes down.
Possiblecauses:leaking or blocked air conducts
or faulty air pump.
- ERR 8
Faultyreadingoftherotationsmeter oftheairpump.
Possible causes: airpump damaged or faulty
function of the optical sensor circuit.
To recuperate any of these errors actuate the
general switch at the back of the station, the
pedal should not be pushed at this moment.
Filter
Ref. 0861800

TE5000
Hot-air flow repair station designed for soldering
and desoldering small and medium-sized SMDs.
AD2200
Soldering stations for specialized use with SMD
components assemblies.
AR5500
Desoldering station which enable the rapid
desoldering of all kinds of insertion components.
AM6000
Station for rework and repair of through-hole and
SMT boards.

ITALIANO
32
ELECTRIC WIRING DIAGRAM
JT 7000 230V 50Hz

ITALIANO
33
ELECTRIC WIRING DIAGRAM
JT 7000 120V 60Hz

ITALIANO
34
JT 7000 230V 50Hz

JT 7000 120V 60Hz

Fig. 1
PROTECTOR
Fig. 2
EXTRACTOR
PART Nº A/mm B/mm
*00 / 0934035 9.0 13.0
*00 / 0934040 9.5 19.0
0*0 / 0934080 9.5 21.0
*32 / 0932220 10.0 10.0
*00 / 0934045 10.5 21.0
*00 / 0934090 11.0 16.0
*24 / 0932235 12.0 17.0
*44 / 0934000 12.5 12.5
*00 / 0934025 13.5 21.5
*48 / 0932230 15.0 15.0
*60 / 0934010 17.0 17.0
*00 / 0934030 18.5 18.5
PART Nº A/mm B/mm
*52 / 0932052 20.0 20.0
*64 / 0932064 20.0 26.0
*80 / 0932184 24.0 24.0
*68 / 0932068 27.0 27.0
0934020 28.5 28.5
0934015 31.5 31.5
*84 / 0932084 33.0 33.0
100 / 0932100 38.0 38.0
124 / 0932124 45.0 45
MANUAL EXTRACTOR
.0 0932190 ø D/mm= 7
* Supplied with the station
Fig. 3
TRIPOD øC/mm
*20 / 0932050 39
*40 / 0932250 85 øDD
DD
D09321900932190
09321900932190
0932190

WARRANTY ENGLISH
The JBC 2 years warranty, guarantees
thisequipmentagainstall manufacturing
defects, covering the replacement of
defectiveparts and all necessary labour.
Malfunctions caused by misuse are not
covered.
In order for the warranty to be valid,
equipment must be returned, postage
paid,tothedealerwhereitwaspurchased
enclosing this, fully filled in, sheet.
GARANTIA ESPAÑOL
JBC garantiza este aparato durante 2
años, contra todo defecto de fabrica-
ción, cubriendo la reparación con susti-
tuciónde las piezas defectuosase inclu-
yendo la mano de obra necesaria.
Quedan excluidas de esta garantía las
averías provocadas por mal uso del
aparato.
Es indispensable para acogerse a esta
garantía el envio del aparato al distribui-
dordondeseadquirió,aportespagados,
adjuntandoestahojadebidamente cum-
plimentada.
GARANTIE FRANÇAIS
JBC garantit cet appareil 2 ans contre
toutdéfautdefabrication.Celacomprend
laréparation,leremplacementdespièces
défectueuses et la main d'oeuvre
nécessaire.
Sontexcluesdecettegarantielespannes
provoquéesparunemauvaiseutilisation
de l'appareil.
Pour bénéficier de cette garantie il est
indispensable d'envoyer l'appareil chez
le distributeur où il a été acquis, en ports
payés, en joignant cette fiche dûment
remplie.
✂
Other manuals for advanced Series
4
This manual suits for next models
4
Table of contents
Other jbc Power Tools manuals
Popular Power Tools manuals by other brands

Baileigh Industrial
Baileigh Industrial DP-1000VS Operator's manual

Ronix
Ronix 3401 instruction manual

NSI Solutions
NSI Solutions SinkBULLIT SB-KIT2 instruction manual

Precision matthews
Precision matthews PM-932M manual

Promac
Promac 378VB operating instructions

VIBRA FER
VIBRA FER EPS Series Installation and operating instructions
