JCROffroad LPRLC2 Configuration guide

Thank you for purchasing from JcrOroad! Checkout our website, www.jcroroad.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-353-1184!
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.
UNIVERSAL
LICENSE PLATE AND
CAMERA RELOCATION
BRACKET
INSTALL INSTRUCTIONS

INCLUDED HARDWARE
6x 1x
1/4”-20 X 3/4”
Button Head
3/8”-16 X 3/4”
Carriage Bolt
1/4”-20
Serr. Flange Nut
8-32 X 1”
Button Head
8-32
Locknut
3/8”-16
Wing Nut
6x 1x
6x 6x

INCLUDED PARTS
1x 1x
1x 1x
1x 1x

1Assemble the brackets together as shown below using the 1/4”-20 X 3/4”
button head bolts and 1/4”-20 serr. flange nuts. If you are choosing not to
use our third break light, leave that bracket out.
ASSEMBLY
Third Break Light Bracket

2Place the whole assembly onto the carrier-side bracket that is installed
behind your spare and bolt them together using the 3/8”-16 X 3/4”
carriage bolt and 3/8”-16 wing nut. It is up to you whether you want to put
the carriage bolt through the top or bottom. When placing the assembly
onto the bracket, make sure the small rectangular tab of the bracket is
sticking up through the slot.
ASSEMBLY

3With everything assembled, take the backing o of the small white LED
light and stick it to the bottom of the tab on the top of the license plate
bracket in the area shown below. It can go anywhere on the tab but it
works best if you place it as far out as possible.
ASSEMBLY
4Once everything is in place, all there is le to do is attach your license plate
using the 1/4”-20 X 3/4” button head bolts and 1/4”-20 serr. flange nuts.

5If you are choosing to use our third break light, mount it to the bracket
using the 8-32 X 1” button head bolts and 8-32 lock-nuts in the provided
holes.
ASSEMBLY
