Joyor A1 User manual

Joyor A/F, X, Y
USER MANUAL
GUÍA DEL USUARIO
MODE D’EMPLOI

Joyor User Manual
CONTENTS
1 The Main Parts & Technical Specifications
1.1 The Main Parts Series A/F
1.2 Technical Specifications Series A/F
1.3 The Main Parts Series X
1.4 Technical Specifications Series X
1.5 The Main Parts Series Y
1.6 Technical Specifications Series Y
2. Important Safety Instructions
3. Operational Instructions
3.1 Folding & Unfolding
3.2 Display
3.3 Riding Operations Instructions
3.3.1 Before Riding
3.3.2 Riding
3.3.3 Braking
4. Maintenance
4.1 Tires
4.2 Battery
4.3 Charger
5. Warranty Policy
5.1 Warranty Scope
5.2 Warranty Limitations
5.3 Warranty Application Process
6. Contact Us

Joyor User Manual
1 THE MAIN PARTS & TECHNICAL SPECIFICATIONS
1.1 The Main Parts Series A/F
1) LCD display
2) Lever lock for handlebar height
adjustment
3) Handlebar folding sleeve
4) Brake wire
5) Front suspension
6) Front light
7) Front mudguard
8) Folding system
9) Rear light
10) Parking stand
11) Brake handle
12) Front air tire
13) Rear solid tire
14) Rear mudguard
15) Rear drum brake

Joyor User Manual
1.2 Technical Specifications Series A/F
Model
A1
F3
F5
F5S
Motor Power
250W
350W
350W
500W
Motor Type
DC brushless motor
Maximum Load
120kg
Material
Aluminum alloy
Speed
25km/h
35km/h
Dimensions When
Unfolded
980x540x1140mm
Dimensions When
Folded
880x180x360mm
Weight
11.5kg
13kg
15.5kg
Distance Range
25km
40km
55-60km
50km
Brake
Rear drum brake
Frame Width
16cm
Battery Voltage
24V
36V
36V
48V
Battery Capacity
8.0Ah
13.0Ah
18.0Ah
13.0Ah
Battery Type
Environmental lithium battery
Input Voltage
AC100-240V
Output Current
2A
Charging Time
4-5h
6-7h
9-10h
6-7h
Color
Black/White/Pink/Green
Gradeability
15°
Tires Size
8 inches
Tire Type
Front air tire, rear solid tire
Display
Multifunctional color LCD display with USB charging port
Cruise Control Mode
Available

Joyor User Manual
1.1 The Main Parts Series X
1) LCD display
2) Lever lock for handlebar
height adjustment
3) Handlebar folding sleeve
4) Brake wire
5) Front suspension
6) Front light
7) Front mudguard
8) Folding system
9) Rear light
10) Parking stand
11) Brake handle
12) Front air tire
13) Rear air tire
14) Rear mudguard
15) Rear disk brake

Joyor User Manual
1.2 Especificaciones técnicas serie X
Model
X1
X5S
Motor Power
400W
500W
Motor Type
DC brushless motor
Maximum Load
120kg
Material
Magnesium alloy
Speed
35km/h
Dimensions When
Unfolded
1150x540x1180mm
Dimensions When
Folded
1060x190x380mm
Weight
13kg
15kg
Distance Range
30-35km
40-50km
Brake
Rear disk brake
Frame Width
19cm
Battery Voltage
36V
48V
Battery Capacity
10Ah
13Ah
Battery Type
Environmental lithium battery
Input Voltage
AC100-240V
Output Current
2A
Charging Time
5h
7h
Color
Black/White
Gradeability
15°
Tires Size
10 inches
Tire Type
Front and rear air tires
Display
Multifunctional color LCD display with USB charging port
Cruise Control Mode
Available

Joyor User Manual
1.3 The Main Parts Series Y
1) LCD display
2) Lever lock for handlebar
height adjustment
3) Handlebar folding sleeve
4) Brake wire
5) Double front suspension
6) Front light
7) Front mudguard
8) Folding system
9) Rear light
10) Parking stand
11) Brake handle
12) Seat (optional)
13) Lever lock for the seat
tube height adjustment
14) Seat folding system
15) Front air tire
16) Rear air tire
17) Double rear suspension
18) Rear mudguard
19) Front turning signal
20) Rear turning signal
21) Front and rear disk
brake

Joyor User Manual
1.4 Technical Specifications Series Y
Model
Y5S
Y10
Motor Power
500W
Motor Type
DC brushless motor
Maximum Load
120kg
Material
Aluminum alloy
Speed
35km/h
Dimensions When
Unfolded
1200x570x1190mm
Dimensions When
Folded
1150x210x430mm
Weight
20.5kg
23kg
Distance Range
40-50km
90-100km
Brake
Front and rear disk brake
Frame Width
21cm
Battery Voltage
48V
Battery Capacity
13Ah
26Ah
Battery Type
Environmental lithium battery
Input Voltage
AC100-240V
Output Current
2A
Charging Time
5-8h
10-15h
Color
Black/White
Gradeability
15°
Tires Size
10 inches
Tire Type
Front and rear air tires
Display
Multifunctional color LCD display with USB charging port
Cruise Control Mode
Available

Joyor User Manual
2 IMPORTANT SAFETY INSTRUCTIONS
• Joyor electric scooter is a personal transport vehicle and it is designed for one person use only. Please do not carry a
passenger on this electric scooter.
• Joyor electric scooter is designed for adult use only. Persons under the age of 16 should not use this vehicle.
• Please wear the safety helmet when riding the electric scooter.
• Do not ride the electric scooter on the unsafe surface or off road.
• Please practice on an open traffic-free space on gear level 1 before riding on the bicycle lane.
• Please during the riding operations always keep both hands on the handlebar and both feet on the standing board. Please
do not jump on the standing board.
• Do not turn off the motor power while riding the scooter.
• Do not try to ride over a gap of more than 3 cm. This may cause injury to the rider or damage the vehicle.
• When riding on the rough or bumpy road, please slow down the electric scooter or stop riding the vehicle
• A user must adjust the height of the handlebar tube according to their height to ensure a safe, stable and comfortable ride.
• Do not ride Joyor electric scooter on slippery surfaces such as oil or ice.
• Do not use Joyor electric scooter in the weather conditions with the temperature below -5.
• Do not leave the product immersed in a water depth of more than 3 cm to avoid damage to the electrical parts of the
vehicle.
• Avoid riding the Joyor electric scooter in adverse weather conditions like rain, snow or wind storm to prevent an accident. If
riding in these conditions, never exceed the speed of 10 km/h.
• If the electric scooter is not used for a period of longer than 30 days, regularly charge it at least every 30 days.
• When unfolding the vehicle, please press the folding system handle till it clicks and make sure that it is in place

Joyor User Manual
3 OPERATIONAL INSTRUCTIONS
3.1 Folding/Unfolding

Joyor User Manual
3.2 Display
1) On/Off Switch
2) Gear switch
3) Acceleration handle
4) Gear indicator
5) Speed indicator
6) Multi-indication area/mileage indicator
7) Battery charge level indicator
8) USB charging port
Model: 882
Working Voltage: DC24V/36Vcompatible, 36V/48Vcompatible
Communication protocol: UART
Wire Connections
1. Red Wire (D+): Positive pole input
2. Black Wire (GND): Negative pole
3. Blue Wire (DS): Controller electric door lock
4. Green Wire (RX): Communication reception
5. White Wire (TX): Communication launch

Joyor User Manual
The Buttons
• Long press the ON/OFF button to turn on the display, short press the ON/OFF to switch between ODO, TRIP, V, A, E, TM in
the multi-indicator
• Long press the ON/OFF to turn off the display
• Long press the M and ON/OFF at the same time to enter into the parameter settings mode. Short press the ON/OFF button
to switch between parameters. Short press M to change the settings. Long press the M and ON/OFF at the same time to
save and exit
• Long press M to turn on the lights
Display Functions
Speed indication, power indication, error code indication, lights control, cruise control, gear level switch and gear indicator, total
mileage, single mileage, real-time voltage, running time, acceleration control
Multi-indicator Area
Total mileage ODO, single mileage TRIP, real-time voltage V, running time TIME, error code E
Error Code Indicator
When the symbol ! is flashing, short press ON / OFF switch button to enter into the error analysis mode. Each number of the error
code corresponds to a specific problem as follows:
ERRO 1: Motor fault
ERRO 2: Throttle fault
ERRO 3: Controller fault
ERRO 4: Brake lever power off
ERRO 5: Under voltage protection
ERRO 6: Communication fault, the display unable to get the output from the controller
ERRO 7: Communication fault, the controller unable to get the output from the display

Joyor User Manual
Speed Indicator
Unit: MPH, KM/H
Speed signal comes from the motor via controller to the display.
The indicated speed depends on the motor signal and the wheel diameter.
Gear Switch
Short press the MODE button to switch the gear: 1 - slow, 2 - medium, 3 - fast. The higher the gear, the faster the speed. Gear 0
means the motor is not powered.
Lights Control
Long press the MODE key to switch on/off the front and rear lights. Rear lights are also lit automatically when braking.
Cruise Control Function
When riding the scooter, keep the acceleration handle pressed with the same pressure for 5 seconds to activate the cruise control
mode. Use the brake handle to deactivate the cruise control mode.
Start mode selection
For safety purposes all Joyor models except Mbike model are set by default to non-zero start mode which means the motor will
not get started until you start kick the scooter first so that the speed is above zero:
NON - Non-zero start mode
ZERO - zero start mode

Joyor User Manual
USB Charging Indicator
The display is equipped with a USB port for you to be able to charge your electronic devices. When the device is connected, the
USB indicator is lit. In cae of problem the indicator starts to flash, and a safety mode will be automatically activated.
Parameter Settings
Long press the M and ON/OFF at the same time to enter into the parameter settings mode. Short press the ON/OFF button to
switch between parameters. Short press M to change the settings. Long press the M and ON/OFF at the same time to save and
exit
P01: rear light brightness: 1 - the darkest, 3 - the lightest;
P02: mileage unit, 0: km; 1: mile;
P04: sleep mode time: 0 - no sleep mode; 1-60 - sleep mode, minutes;
P06: wheel diameter: unit - inch; precision: 0.1;
P07: number of measuring magnets: range 1-100;
P09: zero start, non-zero start setting: 0 - zero start; 1 - nonzero start;
P12: starting torque: range 0-5, 0 - the weakest, 5 - strongest;
P15: motor drive signal percentage settings: (connected to PO8 speed limit function) full speed is set to 100
P16: cruise control function: 1 - activated, 0 - deactivated
P17: light settings: the lights are not lit automatically when the vehicle is on, 0 - the lights are lit automatically when the vehicle is
on
P99: settings reset (when in P99 settings, press and hold the MODE button for 5-6 seconds to reset all the parameters back to the
initial settings)

Joyor User Manual
3 OPERATIONAL INSTRUCTIONS
3.3 Riding Operations Instructions
3.3.1 Before Riding
• Choose a suitable venue for riding.
• Unfold the electric scooter according to the instructions.
• Adjust the height of the handlebar tube according to your height.
3.3.2 Riding
• Press the power button to turn on the power. The speed is set by default to gear level 1.
• For safety purposes, Joyor electric scooter has a safe start design which means the motor can start only when the speed of
the vehicle is above 0. It prevents motor start when the acceleration handle is pressed by mistake. To start the riding
operations, put one foot on the standing board and the other foot on the ground and kick scoot it like a classic kick scooter.
When the scooter is in motion and its speed is above 0, smoothly use the acceleration handle to start the motor. Once the
motor starts, put the other foot on the standing board and continue riding.
• When riding, adjust the gear level from 1 to 3, use lights and horn according to the road conditions and according to the
situation.
• Be aware of the cruise control function. Cruise control function is activated when the acceleration handle is pressed with the
same pressure for 3 seconds.
• Be aware of the possibility of unpredictable sudden obstacles on your way and control the speed level.
3.3.3 Braking
• Use the rear brakes handle for braking under normal circumstances. Use front brake handle (for models series Y and M) for
braking in emergency situations.
• The greater pressure you put, the greater braking force will be applied. Be aware that hard braking may result in an
accident due to slipping of the wheels, lost of balance and fall of the vehicle. Hard braking might also cause damage to the
tire.

Joyor User Manual
4 MAINTENANCE
4.1 Tires
• Joyor electric scooter uses rubber elastic tires. When the tires are worn out or have a puncture, they need to be replaced
timely.
• Contact the official distributor to replace the original tires.
• Inspect your scooter and its tires every month, check if the screws are tightened enough. If they are loose, tighten them.
4.3 Battery
• Joyor electric scooter is equipped with a lithium polymer battery. The average lifespan of the battery is 1000 cycles. Under
normal use and maintenance, the battery lifespan can generally reach more than 1000 cycles.
• Before using the scooter for the first time, please charge the battery to the full charge.
• Avoid totally depleting your scooter’s battery before charging. Always make sure it is minimum 10 % charged. For
satisfactory vehicle performance, the battery has to be charged minimum 50 %
• Do not leave your electric scooter with a significantly discharged battery for a few hours. Charge it promptly.
• When storing the electric scooter for a long period, make sure the battery is at least 40-50 % charged. It is advisable to
charge your scooter minimum once per 30 days.
• Always use only the original Joyor charger that corresponds to the model of the scooter.
• Do not leave your electric scooter in the cold temperature below 0 or under the direct sun. Keep the battery dry. Negative
environmental conditions can damage the battery.
• Polymer lithium batteries have to be treated with extreme caution. Unappropriated charging, damage or overheating can
result in a fire. Do not leave your electric scooter to charge without supervision. Do not leave the electric scooter to charge
overnight. Always supervise the electric scooter while it is charging and avoid battery over-charge. Do not use, charge or
leave a damaged battery unattended and follow the disposal protocols immediately.
4.4 Charger
The dedicated charger provided by Joyor has a charging protection timing function.

Joyor User Manual
Charging instructions
• Open the charging port cover on the electric scooter and insert the charger output connector into the charging port.
• Insert the charger input power plug into the power socket (AC110V-220V)
• Charger light is red to indicate that charging is in progress; when the charger light turns green, it indicates that the battery
is fully charged.
• When charging the battery, place it in a dry, ventilated environment.
5 WARRANTY POLICY
5.1 Warranty Scope
• This limited warranty covers any defects in material or workmanship in the new Joyor devices accompanied by this limited
warranty statement for a period of 24 months after the first retail purchase for the non-electric parts and for the electric
scooter and for a period of 12 months for the battery, under normal installation, use, service and maintenance
• Only consumers purchasing this device from an authorized Joyor retailer or reseller may obtain coverage under this limited
warranty.
• This warranty extends to the original purchaser only and is non-transferable.
5.2 Warranty Limitations
This limited warranty does not cover any problem that is caused by:
• Commercial use, accident, abuse, neglect, shock, heat or humidity beyond product specifications, improper installation,
operation, maintenance or modification
• Any misuse contrary to the instructions in the User Manual
• Malfunctions caused by other equipment
• This limited warranty is void if a product is returned with removed, damaged or tampered labels of any alterations
(including the unauthorized removal of any component or external cover)
• Joyor does not cover the cost of nationa/international warranty shipping at any time

Joyor User Manual
5.3 Warranty Application Process
• Joyor will not provide any warranty coverage unless your claim it in compliance with all terms of this limited warranty
statement and you follow the proper return procedure.
• To request warranty service, you may contact us or contact an authorized Joyor distributor.

Joyor User Manual
6 CONTACT US
Joyor E-Moving S.L.
Address
Carrer d'Enric Prat de la Riba, 100, 08301
Mataró, Barcelona, Spain
Email
[email protected]
Technical Support
Please contact the official Joyor distributor where you purchased your electric scooter
Website
https://www.joyorscooter.com

Joyor Guía del Usuario
CONTENIDO
1. Piezas principales y especificaciones técnicas
1.1 Piezas principales serie A/F
1.2 Especificaciones técnicas serie A/F
1.3 Piezas principales serie X
1.4 Especificaciones técnicas serie X
1.5 Piezas principales serie Y
1.6 Especificaciones técnicas serie Y
2. Instrucciones de seguridad
3. Instrucciones de operación
3.1 Plegar/desplegar
3.2 Pantalla
3.3 Instrucciones de operaciones de montaje
3.3.1 Antes de montar
3.3.2 Montaje
3.3.3 Frenado
4. Mantenimiento
4.1 Neumáticos
4.2 Batería
4.3 Cargador
5. Política de garantía
5.1 Alcance de la garantía
5.2 Limitaciones de la garantía
5.3 Proceso de solicitud de garantía
6. Contáctanos
