JTS US-8216D Series User manual

Instruction Manual
us-8002d(DB)
US-8216D Series
US-8001D(DB)

ank you for choosing the JTS wireless system. In order to obtain the best eciency from the system,
you are recommended to take a few minutes to read this instruction manual carefully.

1. Important Caution
2. Features
3. Specication
3-1 Receiver// US-8001D(DB)/ US-8002D(DB)/US-8216D
3-2 Handheld Transmitter // Mh-750 / Mh-850 / Mh-8016
3-3 Miniature Head Worn Transmitter/UT-16HW
3-4 Body-pack Transmitter // PT-850B(mi)
3-5 Optional Condenser Microphone
4. Part Identication & Accessories
4-1 Receiver// US-8001D(DB)/ US-8002D(DB)/US-8216D
4-2 Handheld Transmitter // Mh-750 / Mh-850 / Mh-8016
4-3 Miniature Head Worn Transmitter/UT-16HW
4-4 Body-pack Transmitter // PT-850B(mi)
4-5 Optional Condenser Microphone
4-6 Accessories
5. Preparing Procedures & Basic Operation
5-1 Receiver// US-8001D(DB)/ US-8002D(DB)/US-8216D
5-2 Rack Mounting
5-3 Battery Insertion of the transmitter
5-4 Body-pack Transmitter // PT-850B(mi)
6. System operation
7. Recommendation
8. Important notice
1
1
2
2
2
3
3
4
6
6
6
7
7
7
11
12
12
13
14
15
16
19
20
INDEX

WIRELESS MICROPHONE SYSTEM
1
1. Important Caution
2. Features
• Always makes all connections before plugging the unit into an AC power outlet.
• Do not leave the device in a place neither with high temperature nor high humidity.
• Always do not handle the power cord with wet hands!
• Keep the devices away from re and heat sources.
• Operated in UHF band where there is less RF interference than the VHF band.
• Due to the PLL synthesized technology, the system oer 16 selectable channel.
• e true diversity reception with 2 independent RF receivers ensure the stable transmission and
reception.
• Adjustable squelch control can eectively reduce the noise.
• Tuned antennas can benet the stable RF reception.
• Built-in Tone key Squelch & Noise Mute detection are available to restrain the interference
signal.
• Rugged metal housing can pass through the dicult environment.
• Equipped with balanced XLR and unbalanced output allows great convenience.
• Body-pack transmier provides phantom powering for condenser lavaliere and headset
microphones.

2
3. Specication
3-1 Receiver
3-2 Handheld Transmitter
Model No .........................................
Frequency Preparation..............
Carrier Frequency Range.......
S/N Ratio...........................................
T.H.D.................................
Display..............................
Display Contents...........................
Controls............................
Audio Output Level....................
AF Output Impedance..............
Squelch.............................
OperationVoltage.........................
Output Connector.......................
Dimension(m/m)...............
US-8001D(DB)/US-8002D(DB)/US-8216D
PLL Synthesized Control
502~960 MHz
> 105dB
<0.6%@1KHz
LED
Antenna A/B, RF/AF Status
Power On/O, Channel Selecting, Audio Level
-12dB
600Ω
Pilot Tone, Noise and Mute
US-8002D(DB)/US-8216D: 12-18 VDC, 200mA
US-8001D(DB): 12-18 VDC, 150mA
1 Balanced XLR socket
(2 for US-8002D(DB)/US-8216D)
1 Unbalanced Ø6.3mm phone jack
221mm (W)* 40mm (H)* 152mm (D)
Model No......................................
Frequency Preparation.........
Carrier FrequencyRange....
RF Outputs..................................
Stability............................................
Frequency Deviaion..............
LED Display................................
Controls..........................................
Spurious Emissions................
Audio Frequency Resonse
Baery..............................................
Mh-750 / Mh-850
PLL Synthesized Control
502~960 MHz
10mW
±10KHz
±48KHz
Low Baery, Power On/O
Power On/O,
Channel Selecting
<-50 dBC
50~16,000 Hz
UM3, AA 1.5V*2
Mh-8016( i )
PLL Synthesized Control
502~960 MHz
10mW
±10KHz
±48KHz
Power On/O,
Channel Up/Down
<-60 dBC
50~16,000 Hz
UM3, AA 1.5V*2

WIRELESS MICROPHONE SYSTEM
3
3-4 Body-pack Transmitter
3-3 Miniature Head Worn Transmitter
Model No........................................
Frequency Preparation.........
Carrier Frequency Range......
RF Outputs.....................................
Stability...................................
Frequency Deviation................
LED Display....................................
Controls..................................
Spurious Emissions...................
Audio Frequency Response
Battery....................................
PT-850B(mi)
PLL Synthesized Control
502~960 MHz
10mW
±10KHz
±48KHz
Power On/O, Low baery
Power On/O, AF Level,
Channel Selecting
<-50 dBC
40~18,000 Hz
UM3, AA 1.5V*2
Model No........................................
Frequency Preparation........
Carrier Frequency Range.....
RF Outputs............................
Stability..................................
Frequency Deviation............
LED Display...........................
Controls.................................
Spurious Emissions.............
Audio Frequency Response
Baery....................................
UT-16HW
PLL Synthesized Control
502~960 MHz
Maximum 10mW
±10KHz
±48KHz
Power On/O, Low baery
Power On/O, AF Level, Channel
Selecting, Mute
<-50 dBC
40~18,000 Hz
LR03, AAA 1.5V

4
3-5 Optional Condenser Microphone
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-501
4P Mini XLR
100~15,000 Hz
Cardioid
-60±3 dB
2.2kΩ
130dB
Ø10.1mm(W)
* 26.4mm(H)
21.5g
CM-201
4P Mini XLR
60~15,000 Hz
Omni-directional
-60±3 dB
2.2kΩ
130dB
Ø5mm(W)
* 9mm(H)
20.7g
CM-125
4P Mini XLR
50~18,000 Hz
Omni-directional
-53±3 dB
4.4kΩ
130dB
Ø4mm(W)
* 11mm(H)
7g (cable excluded)
Lavaliere Microphone
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-225
4P Mini XLR
50~18,000 Hz
Omni-directional
-53±3 dB
4.4kΩ
130dB
155mm(W)
* 134mm(H)
* 157mm(D)
17g (cable excluded)
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-204
4P Mini XLR
60~15,000 Hz
Omni-directional
-60±3 dB
2.2kΩ
130dB
125mm(W)
* 134mm(H)
* 157mm(D)
32.9g
CM-204U
4P Mini XLR
30~18,000 Hz
Cardioid
-68±3 dB
680Ω
130dB
205mm(W)
* 134mm(H)
* 157mm(D)
38.4g
CM-204UL
801C3 (3 pin mini XLR)
801C4 (4 pin mini XLR)
801CS (3.5 stereo plug)
100 ~ 18,000Hz
Cardioid
-75±3 dB
1.5kΩ
120dB
125mm(W)
* 134mm(H)
* 157mm(D)
18g (cable excluded)
Headset Microphone
CX-504
4P Mini XLR
30~18,000 Hz
Cardioid
-68±3 dB
680Ω
130dB
285mm(W)
* 55mm(H)
* 111.3mm(D)
56.3g

WIRELESS MICROPHONE SYSTEM
5
Model No...............................
Connector..............................
Option Connector...........
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
CM-801/CM-804i
801C4 (4 pin mini XLR)
801C3 (3 pin mini XLR)
801CS (3.5 stereo plug)
60~15,000 Hz
Omni-directional
-64±3 dB
1.8kΩ
130dB
CM-8015/CM-825i
801C4 (4 pin mini XLR)
801C3 (3 pin mini XLR)
801CS (3.5 stereo plug)
50~18,000 Hz
Omni-directional
-53±3 dB
1.2kΩ
130dB
Ear-hook Microphone
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Good For.................................
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Good For.................................
CX-500
4P Mini XLR
20~20,000 Hz
Omni-directional
-58±3dB
1.5kΩ
130 dB
Violin
CX-508W
4P Mini XLR
50~18,000 Hz
Cardioid
-67±3 dB
220Ω
130 dB
Winds
CX-500F
4P Mini XLR
50~18,000 Hz
Omni-directional
-58±3dB
1.5kΩ
130 dB
Flutes
CX-520
4P Mini XLR
50~18,000 Hz
Supercardioid
-78±3dB
600Ω
148 dB
Harmonica
CX-516W
4P Mini XLR
50~18,000 Hz
Cardioid
-67±3 dB
220Ω
130 dB
Accordion
Compatible Instrument Microphone

6
4. Parts Identication & Accessories
4-1 Receiver // US-8001D(DB) / US-8002D(DB)/US-8216D
Power On
Channel Selector
RF indicator
AF indicator
Volume control
Antenna(BNC Antenna for US-8001DB , US-8002DB)
DCV Input (US-8002D(DB)/US-8216D 12-18V DC/200mA)
(US-8001D(DB) 12-18V DC/150mA)
Unbalanced 6.3mm jack socket
Balanced XLR socket
4-2 Handheld Transmitter // Mh-850/Mh-750/Mh-8016( i )
1
4
7
Interchangeable capsule module
Baery tray release knobs
Baery tray
Channel selector
Power On/O switch
LED Indicator
ID housing
Gain control
10
13
11
14
16
17
12
15
2
5
8
3
6
9
MH-850 MH-750 MH-8016
1
1
1
1
2
2
2
2
3
3
3 3
4
4
4
4
7
7
6
6
6 6
5
5
5
9
9
8
8
POWER Low Batt.
POWER Low Batt.
CH
10
12
13
15 16 16
11
14
POWER Low Batt.
POWER Low Batt.
CH
10 10
12
14
17
13
15
11
14
13
12
(US-8002D/US-8216D)
(US-8001D)
(US-8001DB)(US-8002DB)
7
79
98
8
US-8002D

WIRELESS MICROPHONE SYSTEM
7
Mic. input (4 pin mini XLR socket)
Power On/O switch
Antenna
LED indiccator for power and baery status
Baery tray
AF leavel control
Belt-loop
Carry case
Channel selector
Gooseneck
Headband
Baery Lid(Color ID):Orang/White/Gray
Adjustable elastic headband
Input gain
Channel selector
Power On/Mute/O switch
LED indicator for power On/O, beery
status and mute
Sweat Shield
4-4 Body-pack Transmitter // PT-850B(mi)
4-3 Miniature Head Worn Transmitter/UT-16HW
27
18
29
20
33
24
25
26
28
19
30
21
35
32
23
31
22
34 27
29
31
32
28
30
35
33
18
22
24
25
19
20
26
21
34
Clip
4 Pin Mini XLR
Windscreen
4-5 Optional Condenser Microphone
38
38 38 38
37
37
Lavaliere Microphone // CM-501 / CM-201 / CM-125
CM-501 CM-201 CM-125
36
36
36 36
Gain adjust
(for PT-850Bmi only)
23

8
CM-204 CM-204U
CM-225 CX-504
40 40
40
40
40
42 42
42
42
42
39
39
39
39
39
Gooseneck
Headband
4 Pin Mini XLR
Windscreen
40
42
39
41
41
CM-204UL
Standard :
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
Headset Microphone // CM-204 / CM-204U / CM-204UL / CM-225 /
CX-504

WIRELESS MICROPHONE SYSTEM
9
Boom
Adjustable Headband
Adjustable ear hook
Detchable Cable
Cable Clip
Windscreen
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
Ear-hook Microphone // CM-801 / CM-804i / CM-8015 / CM-825i
48
50
50
49
51
51
45
47
49
46
43
44
CM-825i 47
48
43
45
46
44
Option
Option
CM-801
47
48
43
45
46
CM-804i 47
48
43
45
46
44
CM-8015
47
48
43
45
46

10
57
Gooseneck
Clip
Bracket
Volume Control
Windscreen
4 Pin Mini XLR
55
56
57
54
53
56
56
52
CX-508WCX-520
CX-500F
CX-500
CX-516W
53
52
52
56 56
52
54
Compatible Instrument Microphone // CX-500 / CX-500F / CX-520 /
CX-508W / CX-516W
53
55

WIRELESS MICROPHONE SYSTEM
11
4-6 Accessories
AC/DC adaptor
Switching Power Supply(100V~240V , 50~60Hz)
Linear Power Supply (220V , 50Hz)
Linear Power Supply (220V , 60Hz)
Screwdriver
DR-900 Dual Rack Adaptor
RP-900 Panel Cover
AF output cable (with Ø6.3 plug at both ends)
GC-80/GC-100 Guitar Cable
GC-80L/GC-100L Guitar Cable
62
63
63
64
64
61
62
Option
Option
Option
Option
Option
Option
A
B
C
59
59
60
60
58
58
A
B C
61

12
5. Preparing Procedures & Basic Operation
5-1 Receiver // US-8001D(DB) / US-8002D(DB)/US-8216D
MIXER
AC/DC ADAPTOR
AC POWER SOCKET
AUDIO OUTPUT
DC INPUT
2
1
(1) Audio Output Connector
e receiver equipped with both balanced XLR output and unbalanced φ 6.3mm jack output;
you can choose the proper way for using.
Connect one end of the Audio cable to the AF output socket in the rear panel of the receiver and
plug another end to the “MIC IN” input socket of a mixer or amplier. (Step 1 of Figure 1)
(2) Power connection
Connect one end of AC/DC adaptor cable to DC input socket in the rear panel of the receiver,
and plug another end into an AC outlet. (Step 2 of Figure 1)

WIRELESS MICROPHONE SYSTEM
13
5-2 Rack Mounting
(1) Before mount receivers onto DR-900 rack adaptor, please release any cables from the rear of
the receiver.
(2) Turn over receiver and DR-900 rack adaptor simultaneously, there are 4 threaded holes each
in the boom of receiver and rack adaptor for inserting screws.
(3) Single receiver
Insert in a receiver through the front of DR-900 until it is rmly aached to the rack, then
screw on a RP-900 to another side of the rack. (Figure 4)
(4) Dual receivers
e same way as above, put one receiver to each rack space.
(Figure 4)

14
5-3 Battery Insertion of the transmitter
(1) Mh-850 & Mh-750 Handheld Transmier
1. Turn the microphone ball grille counter-clockwise
( Figure 1), press both release knobs to remove the
baery tray from the mic. housing ( Figure 2).
2. Insert two 1.5V baeries according to the correct polarity
(Step 1 of Figure 3) and return the baery tray back to
housing (Step 2 of Figure 3).
Aim the connecting pins exactly toward the cavities on the
boom side of detachable mic. capsule module ( Figure 4)
and tighten it clockwise!
(2) Mh-8016 Series Handheld Transmier
1. Insert 2 pcs 1.5V AA baeries into the baery tray.
2. Aer puing into the baery, switch on the power switch.
2
1
Figure 1 Figure 2 Figure 3 Figure 4

WIRELESS MICROPHONE SYSTEM
15
5-4 Body-pack Transmitter // PT-850B(mi)
(1) Slide the baery tray cover in the direction of the arrow to open it. Insert two 1.5V baeries
according to the correct polarity , and return the cover.
(2) Lavaliere microphone
Aach lavaliere microphone to a tie, lapel, where is suitable for sound pick-up.
Plug the connector into input socket on the body-pack transmier.
(3) Headset microphone
Put the headband behind your head, and x the temples on your ears as shows, then
adjust the gooseneck to have best miking. Plug the connector into input socket on the
body-pack transmier.
MIC IN
I.5V
ORUM-3X2
SIZE “AA“OREQUIV.
(4) Instrument Microphones
e system is compatible with JTS various instrument microphones.
For detail please refer to user’s manuals of these microphones.

16
Be sure to mute the audio signal of a mixer or amplier before turning on the receiver and
transmier.
(1)Power on
Turn AF level on the receiver completely counter-clockwise to the minimum level, and switch
on the receiver. As soon as you turn power of the receiver on, the power LED lights red,
meanwhile the RF signal and AF LED light up to indicate the receiver is ready for operating.
Always it’s a good idea to keep “open space” between transmier and receiver, that will improve
RF reception.
(2) Selecting channel for the receiver and transmier
1. Use the supplied screwdriver to select a desired channel for the receiver and transmiers.
Both receiver and transmiers are preprogrammed with 16 channels.
2. Make sure the channel of receiver matches that of the transmier.
3. When 2 or more transmiers and receivers are being used in the same location, they must
be set up to use dierent channels. If existing channel is being interfered, please change to
another non-interference channel.
6. System operation
US-8002D
CH
US-8002D

WIRELESS MICROPHONE SYSTEM
17
(3) Using the PT-850B / PT-850Bmi Body-pack transmier
1. Use the supplied screwdriver to adjust the gain control on the rear panel of PT-850B /
PT-850Bmi body-pack transmier to a proper level.
2. e carry case allows the PT-850B to be aached on performer’s belt, place the antenna
towards the back of his body. e Velcro tag ensures tight xing and less hindrance
during performance.
Wing the Velcro tag around the belt and x it.
