JTS CX-500F User manual

CX-500F / MA-500 CX-500F / MA-500
User Manual
Open the rotational button on the xing clip.
Place the xing clip into the ute and fasten the rotational button.
Place the CX-500F into the xing clip.
Adjust the position of CX-500F gooseneck microphone, and it is then ready.
1
2
3
4
MA-500
MIC Input..................
Output......................
Phantom Power........
PAD...........................
Low Cut.....................
Frequency Response
Impedance................
T.H.D.........................
S/N............................
Weight......................
Dimensions(mm)......
4P Mini XLR(Male)
XLR(Male)
12~48V
-10dB
100Hz -6dB
400Hz -4dB
30~20,000Hz
220Ω
<0.045%@1KHz -50dB
>95 dB
40g
Ø20mm*94.5mm(H)
CX-500F MA-500
/
Condenser Instrument Microphone / Phantom power Adapter
Condenser Instrument Microphone / Phantom power Adapter Condenser Instrument Microphone / Phantom power Adapter
Please maintain the temperature in proper status it helps the Submin-
iature Condenser Instrument Microphone to lengthen its life.
Using the part and adapter made from JTS to ensure the unit quality
and lifetime. Do not attempt to employ non-standard adapters or
connectors as you might damage the unit
59010-091-01
Specication
CX-500F
Type.............................
Frequency Response....
Sensitivity (at 1,000Hz)
Impedance..................
Max.SPL for 1% T.H.D.
Signal-To-Noise Ratio
Output Connector.......
Power Supply.............
Current Consumption
Weight......................
Dimensions(mm)......
Omni-directional Condenser
20~20,000 Hz
-58±3dB*(1.25mV)*0dB=1V/μbar
1.5kΩ
130 dB
68 dB
4P Mini XLR
1-5 VDC
≤0.05mA
8 grams (including cable)
Ø6mm(W)*171mm(H)
}}
}
125Hz
250Hz
500Hz
1000Hz
2000Hz
4000Hz
8000Hz
16000Hz
+10
0
-10
20 100 200 500 1k 2k 5k 10k 20kHz
The CX-500F is built with full range omni directional capsule with golden plating in and
outside.The at frequency response reproduces all types of utes. Dynamic design of mic
holder can rmly mount CX-500F to utes with dierent sizes while the dual injection
design prevent the ute from scratch.The exible mini gooseneck renders a desirable
miking position while minimizes air stream noises and blasts.
Omni directional pick up pattern
Flat frequency response
Versatile mount clip
Terminated with 4 pin mini XLR for easy wireless application
Phantom power adapter with low cut and pad provided for wired application
Parts ldentication
CX-500F Miniature microphone: 1 piece
MA-500 Adapter: 1 piece
Windscreen (reticular foam cover): 4 pieces
1
2
3
1 2
3PIN2 OUT(+)
PIN3 OUT(−)
TUPTUO
1
2
3
4MIC IN
V+
NICIM
(Phantom Power Supply)
Output: XLR (Male)
Pin 1: GND
Pin 2,3: Audio signal
Input: 4P Mini XLR (Male)
Pin 1: GND
Pin 2: V+
Pin 3,4: Audio signal
4
2
3
1
