JTS GM-5200L Series User manual

INSTRUCTION MANUAL
Dimension:
GM-5218 GM-5212 GM-5206
GM-5218C GM-5212C GM-5206C
Ø13.0
Ø13.0
Ø13.0
Ø7.0
51.7
51.7
51.7
60.0
60.0
287
135 110.0
456
303
152.0
608
105
105
105
36.3
36.3
36.3
110.0
2851(L)
2851(L)
2851(L)
Ø6.0
Ø6.0
Ø7.0
Ø8.0
Ø8.0
Ø18.9
Ø18.9
Ø18.9
Ø18.9
Ø18.9
Ø18.9
Ø21.0
Ø21.0
Ø21.0
Ø21.0
Ø21.0
Ø21.0
Ø20 Ø20 Ø20
GM-5225
GM-5225C
Ø13.0
Ø7.0
51.7 60.0 415
736
105
36.3
110.0
2851(L)
Ø6.0
Ø8.0
Ø18.9
Ø18.9
Ø21.0
Ø21.0
Ø20
Ø13.0
Ø7.0
Ø6.0
Ø8.0
Ø18.9
Ø21.0
Ø21.0
Ø20 Ø18.9
59.4 60.0 415 110.0
736
36.3
105
2851(L)
GM-5225L
GM-5225CL
Ø13.0
Ø7.0
Ø6.0
Ø8.0
Ø18.9
Ø21.0
Ø21.0
Ø20 Ø18.9
59.4 60.0 287 110.0
608
36.3
105
2851(L)
GM-5218L
GM-5218CL
Ø21.0
Ø21.0
Ø20 Ø18.9
Ø8.0
Ø7.0
Ø6.0
Ø13.0
Ø18.9
36.3
105
456
110.013560.059.4
2851(L)
GM-5212L
GM-5212CL
Ø21.0
Ø21.0
Ø20
Ø18.9
Ø18.9
Ø13.0
36.3
105
59.4
303
152.0
2851(L)
GM-5206L
GM-5206CL
59512-004-02

Features:
■ The series are wide-range condenser microphones with uni-direction polar pattern, that they are optimal
for speech and other demands in sound pickup situation.
■ Screw-in type gooseneck microphones feature an additional 3m cable, offering extended length for greater
positioning range.
■ Plug-in type gooseneck microphones feature a 3P XLR connector Insert, allowing it to be plugged directly
into a matching panel jack or cable connector.
■ The small diameter gooseneck permits high flexibility in proper position, and multiple gooseneck length is
able to match different requirement.
Installation:
GM-5206C/GM-5212C/GM-5218C/GM-5225C
GM-5206CL/GM-5212CL/GM-5218CL/GM-5225CL
1. Equipped with built-in power module, that acn external 9V ~ 52V DC source is required to power the unit.
2. Screw microphone flange tightly onto a mounting stud of floor stand or conference table and make suitable
cable length. (figure 1)
3. Adjust gooseneck for aiming the microphone toward the proper sound source. (figure 3)
4. Slip on windscreen over the microphone head to control breath and popping noise. (figure 4)
GM-5206/GM-5212/GM-5218/GM-5225
GM-5206L/GM-5212L/GM-5218L/GM-5225L
1. Equipped with built-in power module, that an external 9V ~ 52V DC source is required to power the unit.
2. Plug connector insert directly into a 3P panel jack on floor stand or conference table. (Figure 2)
3. Adjust gooseneck for aiming the microphone toward the proper sound source. (Figure 3)
4. Slip on windscreen over the microphone head to control breath and popping noise. (Figure 4)
GM Series Gooseneck Microphones
(Figure 3) (Figure 4)
(Figure 2)
Dynamic Frequency response
Condenser Frequency response
(Figure 1)
mixer
Type..............................
Frequency Response..
Polar Pattern................
Output Connector........
Sensitivity (at 1,000Hz)
Impedance....................
Max. SPL for 1% THD...
Back Electret Condenser
80 ~ 18,000Hz
Supercardioid
XLR(M) type (power module) :
GM-5206L/GM-5212L/GM-5218L/GM-5225L
Screw 5/8" *27 :
GM-5206CL/GM-5212CL/GM-5218CL/GM-5225CL
-58dB(1mV)
220Ω
125dB
Type..............................
Frequency Response..
Polar Pattern................
Output Connector........
Sensitivity (at 1,000Hz)
Impedance....................
Max. SPL for 1% THD..
Back Electret Condenser
80 ~ 18,000Hz
Supercardioid
XLR(M) type (power module) :
GM-5206/GM-5212/GM-5218/GM-5225
Screw 5/8" *27 :
GM-5206C/GM-5212C/GM-5218C/GM-5225C
-60dB(1mV)
220Ω
125dB
Specification:
Capsule type: Electret Condenser
(for GM-5200L/GM-5200CL series)
Capsule type: Electret Condenser
(for GM-5200 Condenser/GM-5200C series)
Accessories:
Windscreen
Model Variations:
6" (152mm) GM-5206/GM-5206C/GM-5206L/GM-5206CL
12" (305mm) GM-5212/GM-5212C/GM-5212L/GM-5212CL
18" (457mm) GM-5218/GM-5218C/GM-5218L/GM-5218CL
25" (635mm) GM-5225/GM-5225C/GM-5225L/GM-5225CL
