JUMO TDA-3000 User manual

JUMO TDA-300(0)
Handheld Thermometer
with data logger
B 702540.0
Operating Manual
2013-12-03/00448127

Contents
1Introduction 7
1.1 Preface .......................................................................................................... 7
1.2 Typographical conventions ......................................................................... 8
1.3 Instrument features ...................................................................................... 9
1.4 Checking the delivery ................................................................................ 10
1.5 Instrument description .............................................................................. 10
1.5.1 LCD display .................................................................................................. 11
1.5.2 Operating keys ............................................................................................. 12
1.6 Function menu ............................................................................................ 14
2Preparation 17
2.1 Inserting the battery ................................................................................... 17
2.2 Setting the date and time .......................................................................... 18
2.3 Connecting the temperature sensor ........................................................ 19
3Operation&normaldisplay 21
3.1 Switching on the instrument ..................................................................... 21
4 Temperature measurement 23
4.1 Registering TAG names ............................................................................. 24
4.1.1 Character entry ............................................................................................ 24
4.1.2 Character entry with selection list ................................................................ 25
4.1.3 Character entry without selection list ........................................................... 27
4.2 Setting limits ............................................................................................... 27
4.3 Evaluating measured temperatures ......................................................... 29
5Datalogger 31
5.1 Manual logging ........................................................................................... 32

Contents
5.2 Automatic logging ...................................................................................... 33
5.2.1 Activating the interval ................................................................................... 33
5.2.2 Starting data logging .................................................................................... 34
5.2.3 Canceling data logging ................................................................................ 34
5.2.4 Checking data .............................................................................................. 35
5.3 Searching recorded data ........................................................................... 35
5.3.1 Searching data with a specific TAG name (TAG filter) .................................. 35
5.3.2 Searching data with a specific LOG No. (LOG jump) ................................... 37
5.4 Deleting recorded data .............................................................................. 38
5.4.1 Deleting individual data only (delete?) ......................................................... 38
5.4.2 Deleting all data (Clear all?) .......................................................................... 39
5.5 Optimizing recorded data (defragmenting) .............................................. 40
6Peak/Bottomvaluestorage 43
6.1 Displaying the peak/bottom value ............................................................ 43
6.2 Resetting the peak value ........................................................................... 44
6.3 Resetting the bottom value ....................................................................... 44
7Usernames 45
8Configuration 47
8.1 Language .................................................................................................... 47
8.2 Date format ................................................................................................. 47
8.3 Sensor type ................................................................................................. 48
8.4 Temperature unit ........................................................................................ 48
8.5 Decimal point (decimal place) ................................................................... 49
8.6 Temperature correction ............................................................................. 49
8.7 Digital filter .................................................................................................. 50
8.8 Automatic switch-off ................................................................................. 50
8.9 Locking ........................................................................................................ 51
9EvaluatingdatawithaPC 53
9.1 Connection between the TDA-3000 and the PC ...................................... 53
9.2 Stored data ................................................................................................. 54

Contents
9.3 Disconnecting ............................................................................................. 58
9.4 Opening CSV data on the PC .................................................................... 59
10 Appendix 61
10.1 Replacing the battery ................................................................................. 61
10.2 Cleaning ...................................................................................................... 63
10.3 Fault finding ................................................................................................ 64
10.3.1Error messages ............................................................................................ 64
10.3.2Problems and solutions ............................................................................... 66
10.4 Technical data ............................................................................................. 66

Contents

7
1 Introduction
1.1 Preface
Please read this Operating Manual before commissioning the instrument.
Keep the manual in a place that is accessible to all users at all times.
Please assist us to improve this operating manual, where necessary.
Your comments will be appreciated.
H
If any difficulties should arise during commissioning, you are asked
not to carry out any manipulations that could endanger your rights
under the instrument warranty!
Please contact the nearest subsidiary or the head office in such a
case.
E
When returning modules, assemblies or components, the
regulations of EN 61340-5-1 and EN 61340-5-2 “Protection of
electronic devices from electrostatic phenomena” must be
observed. Use only the appropriate ESD packaging for transport.
Please note that we cannot accept any liability for damage caused
by ESD.
ESD=electrostatic discharge

1 Introduction
8
1.2 Typographical conventions
Warning signs
A
Caution
This symbol is used when there may be damage to equipment or data if the
instructions are ignored or not followed accurately!
Note signs
H
Note
This symbol is used when your special attention is drawn to a remark.
v
Reference
This symbol refers to further information in other manuals, chapters or
sections.
abc1Footnote
Footnotes are remarks that refer to specific points in the text. Footnotes
consist of two parts:
A marker in the text, and the footnote text.
The markers in the text are arranged as continuous superscript numbers.
h
Action instruction
This symbol indicates that an action to be performed is described.
The individual steps are marked by this asterisk, e.g.
hPress the hkey
hConfirm with E
Disposal
Do not put this device into the garbage bin after use!
Please ensure a proper and environmentally-friendly disposal.

9
1 Introduction
1.3 Instrument features
Temperature
ranges - Resistance thermometer (RTD) type Pt100: -200 to +850 °C (-328 to +1562 °F) or
-199.9 to +850.0 °C (-199.9 to +999.9 °F)
- Thermocouple K
-200 to +1372 °C (-328 to +2501 °F) or
-199.9 to +999.9 °C (°F)
-ThermocoupleJ
-200 to +1200 °C (-328 to +2192 °F) or
-199.9 to +999.9 °C (°F)
- Thermocouple T
-50 to +400 °C (-58 to +752 °F) or
-50.0 to +400.0 °C (-58.0 to +752.0 °F)
TAG numbers
TAG names You can enter designations for the measurement points (TAG names) with up to 11 characters. The instrument itself will automatically assign a sequential
TAG number to each name.
(TDA-300: max. 5 names; TDA-3000: max. 99 names)
User names With the TDA-3000, you can enter 99 user names with up to 11 characters.
The instrument itself will automatically assign a sequential number to each
name.
The TDA-300 does not have a user management – there is only one user.
Limit function With this function, you can immediately detect whether the measured
temperature is above, below, or within the limits (the upper and lower limits
must be set up).
Data logger Measurement point designation (TAG name), measured temperature, date and
user name can be entered manually, or automatically detected and saved.
(TDA-300: max. 99 measurements, TDA-3000: max. 9999 measurements)
MIN and MAX
memory The minimum and maximum temperatures (Peak and Bottom) can be saved in the instrument.
Service life The handheld thermometer can acquire data continuously for up to 400 hours
– using an alkaline LR6 battery (based on IEC and JIS).
PC evaluation With the TDA-3000, data can be checked and evaluated by a PC.
Measurement data can be copied to a PC via the USB interface, in CSV format
(Comma Separated Values). This data can then be processed by the PC.

1 Introduction
10
1.4 Checking the delivery
Before using the handheld thermometer, check the following:
-Orderdetails
- Check that the housing is undamaged
- Check that all the accessories are present (see Accessories)
Order details
Accessories - Operating Manual
- Alkaline battery, type LR6 (IEC and JIS)
- Carrying strap
- USB interface instructions (with TDA-3000)
1.5 Instrument description
Order details Instrument description
702540/... TDA-300
no USB interface, 99 data sets
702541/... TDA-3000
incl. USB interface, 9999 data sets
REC
SET
ESC
MENU
/POWER
LCD display
Operating keys
Battery compartment
USB interface (with TDA-3000)
Sensor connection

11
1 Introduction
1.5.1 LCD display
The following details are shown in the LCD display.
(1)
Number While data is being recorded, or during standby for data recording, the number of the measurement point or the user is shown here.
If stored data are displayed, the memory number for the measurement being
displayed appears in front of the “/” symbol and the total quantity of stored
data appears after the “/”.
(2)
Data logging During manual data logging (manual recording) the REC display will only light up when the REC key is pressed. During automatic data logging (automatic
recording) the REC display will light up continuously during recording, and will
blink during an interruption.
(3)
Input
interruption
This indicates that the input is open (probe break), short-circuited, or not
properly connected.
(4)
Battery
charge status
Indicates the charge in the battery.
(5)
Temperature Indicates the measured temperature and the error number, if an error occurs.
(6)
°C or °F Displays the temperature unit that is set at the moment.
C
(1) (2) (3) (4)
(5)
(6)
(7)
(8)
(9)
Battery is full.
Battery is half full.
Battery near end of life; insert new battery.
Battery empty; insert new battery immediately.

1 Introduction
12
(7)
Limit value Indicates whether the measured temperature is within the selected range limits.
Caution: The limit values (upper and lower limits) must be set up.
(8)
Message line This shows the name in the function menu, the date1, the name of the
measurement point3, the user name2,3 etc.
1. Set the date, so that it can be recorded
(see Chapter 2.2 “Setting the date and time”).
2. Will not be displayed if no user name has been defined.
3. Maximum 11 characters.
(9)
Message
selection
Shows that the information in the LCD display changed, by using the (,)
keys.
1.5.2 Operating keys
MENU/POWER
key You can use this key to switch the instrument on and off. If you press the key for longer than 2 seconds, when the instrument is switched on, it will switch
off.
When the instrument is switched on, you can use this key to call up the
function menu and to change between the individual functions.
SET key You can use this key to make settings.
ESC key You can use this key to cancel the alteration of a settings. If the setting
procedure is canceled, the instrument will retain the original value.
UP and DOWN
keys You can use these keys (, )to select the measurement points or the user
names that are stored in the instrument, and are shown in the LCD display.
You can select the setting during configuration.
Temperature above the limit temperature.
Temperature within the limits.
Temperature below the limit temperature.

13
1 Introduction
LEFT and
RIGHT keys You can use the (,)keys to select details on the screen when it is in the normal display mode.
You can move to the next or previous function, while a function menu (Fn0 to
Fn9) is displayed.
You can move the cursor in front of and behind every character, when you are
altering a setting (editing names).
REC key During manual data logging (manual recording) you can use this key to store
the temperature and the date.
During automatic data logging (automatic recording) you can use this key as
an ON/OFF key for the data logging function.

1 Introduction
14
1.6 Function menu
The TDA-300(0) has a function menu for running the functions that are required
for temperature measurement and recording (data logger). First select the
required function. Additional details about the individual menus can be found
on later pages in the operating instructions.
vSee Chapter 5
“Data logger” vSee Chapter 4
“Temperature
measurement”
vSee Chapter 5
“Data logger” vSee Chapter 6
“Peak/Bottom
value storage”
vSee Chapter 2
“Preparation” vSee Chapter 8
“Configuration” vSee Chapter 7
“User names”

15
1 Introduction
Fn1 Memory
vSee Chapter 5 “Data logger”
Fn2 TAG Setup
vSee Chapter 4 “Temperature measurement”
Fn 3 Logging
vSee Chapter 5 “Data logger”
Fn4 Peak/Bottom
vSee Chapter 6 “Peak/Bottom value storage”
Fn8 User Name
vSee Chapter 7 “User names”
Fn9 Setup
vSee Chapter 8 “Configuration”
Fn0 Date/Time
vSee Chapter 2 “Preparation”

1 Introduction
16

17
2 Preparation
This section describes the preparation that is required for operation of the
instrument.
2.1 Inserting the battery
hUndo the screw for the battery cover
hTurn the screw with a suitable screwdriver or coin.
hTake off the battery cover.
hCarefully insert a type LR6 (AA) battery.
Please observe the correct polarity.
hPut the battery cover back in position and tighten up the screw.
vChapter 2.2 “Setting the date and time”
Unscrew, e.g. with a coin.
Alkaline battery (LR6)
+
-
H
After the battery has been fitted, the instrument will make a fresh
start (reset).
The function menu “Date/Time (Fn0)”, for setting the year, will be
shown in the LCD display.
hSet up the year, date and time.
H
The instrument will automatically switch itself off if no keys are
pressed within the auto-switch-off time that has been configured
(factory setting: 3 minutes).
vChapter 8.8 “Automatic switch-off”

2 Preparation
18
2.2 Setting the date and time
Year setup hPress the LEFT or RIGHT key to move the position where the digit is
blinking.
hPress the UP or DOWN key to set the “Year”.
hPress the SET key to save the new value.
Range of values: 0000 (only after RESET)
2003 to 9999
Setting as delivered: 0000
Month and day
setup hPress the UP or DOWN key to set the “Day (Month)”.
hPress the LEFT key to move the blinking cursor to “Month (Day)”.
hPress the UP or DOWN key to set the “Month (Day)”.
hPress the SET key to save the new value.
Range of values: Month: 01 to 12
Day: 01 to 31
Setting as delivered: 01/01 (Day/Month format)
Time setup hPress the UP or DOWN key to set the “Minute”.
hPress the LEFT key to move the blinking cursor to “Hour”.
hPress the UP or DOWN key to set the “Hour”.
hPress the SET key to save the new value.
Range of values: Hour: 00 to 23
Minute: 00 to 59
Setting as delivered: 00:00
Version number The version number of the device software is shown in the LCD display.
Setting
end hPress the ESC key twice: this brings you back to the normal display. Or press the MENU/POWER key for longer than two seconds: this will switch
off the instrument.
Month/Day format Day/Month format
Month Day (cursor blinks) Day Month (cursor blinks)

19
2 Preparation
2.3 Connecting the temperature sensor
hAttach the temperature sensor to the instrument.
vAn overview of the available temperature sensors
can be found in the Data Sheet 702540.
ESC
SET

2 Preparation
20
