JVC RM-LP100U User manual

For Customer Use:
Model No.
Serial No.
Enter below the Serial No. which is located on the
body.
Retain this information for future reference.
RM-LP100U
Thank you for purchasing this JVC product.
Before operating this unit, please read the instruc-
tions carefully to ensure the best possible perfor-
mance.
In this manual, each model number is described
without the last letter (U/E) which means the shipping
destination.
(U: for USA and Canada, E: for Europe)
Only “U” models (RM-LP100U) have been evaluated
by UL.
Please read the following before getting started:
B5A-1723-00
RM-LP100U/RM-LP100E
Details
INSTRUCTIONS
(BASIC)
REMOTE CAMERA CONTROLLER
Specifications and appearance of this unit are subject to change for further improvement without prior notice.
For details on settings and operation, refer to “INSTRUCTIONS” on the website.
Please check the latest INSTRUCTIONS, tools, etc. from the URL below.
North America:
http://pro.jvc.com/prof/main.jsp
Europe:
http://www.service.jvcpro.eu/public/
China:
http://www.jvc.com.cn/service/download/index.html

Safety Precautions
.
Cautions
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
CAUTION:
A UNIT IS A CLASS 1 LASER PRODUCT. HOWEVER THIS
UNIT USES A VISIBLE LASER BEAM WHICH COULD CAUSE
HAZARDOUS RADIATION EXPOSURE IF DIRECTED. BE SURE
TO OPERATE THE UNIT CORRECTLY AS INSTRUCTED.
WHEN THIS UNIT IS PLUGGED INTO THE WALL OUTLET, DO
NOT PLACE YOUR EYES CLOSE TO THE OPENING OF THE
DISC TRAY AND OTHER OPENINGS TO LOOK INTO
THE INSIDE OF THIS UNIT.
USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
MISE EN GARDE:
CET APPAREIL EST UN PRODUIT LASER DE CLASSE 1.
CEPENDANT, CET APPAREIL UTILISE UN FAISCEAU LASER
VISIBLE QUI PEUT ENTRAÎNER UNE EXPOSITON
DANGEREUSE AUX RAYONNEMENTS. S’ASSURER DE
FAIRE FONCTIONNER L’APPAREIL CORRECTEMENT, EN
RESPECTANT LES INSTRUCTIONS.
LORSQUE CET APPAREIL EST BRANCHÉ À UNE PRISE
MURALE, NE PAS PLACER SES YEUX PRÈS DE
L’OUVERTURE DU TIROIR POUR DISQUE OU D’AUTRES
OUVERTURES DANS LE BUT D’OBSERVER L’INTÉRIEUR
DE L’APPAREIL.
L’UTILISATION DES COMMANDES, RÉGLAGES OU
PROCÉDURES DE PERFORMANCE AUTRE QUE CELLE
SPÉCIFIÉE DANS CE DOCUMENT RISQUE D’ENTRAÎNER
UNE EXPOSITION DANGEREUSE AUX RAYONNEMENTS.
L’UTILISATEUR NE DOIT PAS OUVRIR NI RÉPARER
L’APPAREIL DE LUI-MÊME. FAIRE APPEL À UN PERSONNEL
QUALIFIÉ POUR L’ENTRETIEN.
AVIS
RISQUE DE CHOC ELECTRIQUE
- NE PAS OUVRIR.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
CAUTION:
This unit should be used withAC 120VH, 60Hz.
To prevent electric shocks and fire hazards, DO NOT use any
other power source.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION:
POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA
LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU
FOND.
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s
attention to Article 820-40 of the NEC that provides guidelines
for proper grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.
“WARNING” and the following or equivalent. “To reduce the risk
of fire or electric shock, do not expose this apparatus to rain or
moisture.”
“ATTENTION” et suivant ou équivalent. “Pour limiter les risques
d’incendie ou d’électrocution, n’exposez pas cet appareil à la
pluie ou à l’humidité.”
A warning that an apparatus with CLASS I construction shall be
connected to a MAINS socket outlet with protective earthing
connection.
Avertissement: un appareil de CLASSE I doit être branché à une
prise SECTEUR comprenant une mise à la terre de protection.
WARNING
Batteries shall not be exposed to excessive heat such as
sunshine, fire or the like.
When the main plug or appliance coupler shall remain readily
operable.
CAN ICES-3 A / NMB-3 A
2Safety Precautions
Getting Started

.
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the
obsolete outlet.
10)Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11)Only use attachments/accessories specified by the
manufacturer.
12)Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-
over.
13)Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14)Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Failure to heed the following precautions may result in
damage to the unit, remote control or disc/cassette.
1. DO NOT
place the unit^
^in an environment prone to extreme temperatures or
humidity.
^in direct sunlight.
^in a dusty environment.
^in an environment where strong magnetic fields are
generated.
^on a surface that is unstable or subject to vibration.
2. DO NOT
block the unit’s ventilation openings or holes.
(If the ventilation openings or holes are blocked by a newspaper
or cloth, etc., the heat may not be able to get out.)
3. DO NOT place heavy objects on the unit or remote control.
4. DO NOT
place anything which might spill on top of the unit
or remote control.
(If water or liquid is allowed to enter this equipment, fire or
electric shock may be caused.)
5. DO NOT
expose the apparatus to dripping or splashing.
6. DO NOT
use this equipment in a bathroom or places with
water. Also DO NOT place any containers filled with water or
liquids (such as cosmetics or medicines, flower vases, potted
plants, cups, etc.) on top of this unit.
7. DO NOT
place any naked flame sources, such as lighted
candles, on the apparatus.
8. AVOID violent shocks to the unit during transport.
When the equipment is installed in a cabinet or a shelf, make sure
that it has sufficient space on all sides to allow for ventilation
(10cm or more on both sides, on top and at the rear).
When discarding batteries, environmental problems must be
considered and the local rules or laws governing the disposal of
these batteries must be followed strictly.
Use the supplied power cord.
(If not, fire or electric shock may be caused.)
DON'T continue to operate the equipment if you are in any doubt
about it working normally, or if it is damaged in any way^switch
off, withdraw the mains plug and consult your dealer.
DO be careful with glass panels or doors on equipment.
DO consult you dealer if you are ever in doubt about the
installation, operation or safety of your equipment.
NEVER let anyone especially children push anything into holes,
slots or any other opening in the case^this could result in a fatal
electrical shock.
MOISTURE CONDENSATION
Moisture in the air will condense on the unit when you move it from
a cold place to a warm place, or under extremely humid
conditions^just as water droplets form on the surface of a glass
filled with cold liquid. In conditions where condensation may occur,
disconnect the unit’s power plug from the wall and keep it
disconnected for a few hours to let the moisture dry, then turn on
the unit.
CAUTION:
Changes or modifications not approved by JVC could void user’s
authority to operate the equipment.
Declaration of Conformity
Model Number: RM-LP100U
Trade Name: JVC
Responsible Party: JVCKENWOOD USA Corporation
Address: 1700 Valley Road Wayne, N.J. 07470
Telephone Number: 973-317-5000
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
"This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to
correct the interference at his own expense."
Safety Precautions 3
Getting Started

.
DISCLAIMER OF LIABILITY
JVC shall not be liable for any loss relating to the unit’s failure to
properly record, store or playback any content (video, audio or
otherwise) for any reason whatsoever. Any applicable warranties
shall only cover replacement or repair of the effected unit, and shall
not apply to recovery or replacement of lost content.
HOW TO USE THIS INSTRUCTION MANUAL
●All major sections and subsections are listed in the Table Of
Contents on page 5. Use this when searching for information on
a specific procedure or feature.
●The Amark signals a reference to another page for instructions
or related information.
●Operation buttons necessary for the various procedures are
clearly indicated through the use of illustrations at the beginning
of each major section.
Batteries^Incorrect use of batteries may cause the batteries
to burst or ignite. A leaky battery may corrode the equipment,
dirty your hands or spoil your clothing. In order to avoid these
problems, make sure to observe the precautions below:
●Use the specified batteries only.
●Install the batteries with due attention to the plus (+) and
minus (-) sides of the batteries according to the instructions in
the compartment.
●Do not mix old and new batteries.
●Do not mix batteries of different types. Voltage specifications
of batteries of the same shape may vary.
●Replace an exhausted battery with a new one promptly.
●If you will not use the remote control for a long time, remove
the batteries.
●If leaked battery fluid gets on your skin or clothing, rinse
immediately and thoroughly. If it gets into you eye, bathe your
eye well rather than rubbing and seek medical treatment
immediately. Leaked battery fluid that gets into your eye or
your clothing may cause a skin
●Do not put the batteries in a place where young children can
reach.
irritation or damage your eye.
ATTENTION:
Using a mobile phone in the vicinity of the unit may cause
picture vibration on the TV screen or change the screen to a
black back display.
Some TVs or other appliances generate strong magnetic
fields. Do not place such appliances on top of the unit as it
may cause picture disturbance.
When moving the product, pressAto turn off the power,
and wait at least 30 seconds before unplugging the power
cord. Then, wait at least 2 minutes before moving the
product.
If there is a power outage when using the unit, the recorded
data may be erased.
It is recommended to back up discs which contain important
recordings periodically (every few years). As digital signals
do not deteriorate, failure to play back or record might arise
due to the effects of the disc aging through the years
depending on the storage environment.
Recorded programs and data cannot be restored once the
disc or tape is damaged.
If this symbol is shown, it is only valid in the European
Union.
4Safety Precautions
Getting Started

.
WARNING :
WARNING :
DO NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
The rating plate and the safety caution are on the rear of
the unit.
IMPORTANT:
Please read the various precautions on pages 5 to 6 before
installing or operating the unit.
It should be noted that it may be unlawful to re-record pre-
recorded tapes,DVDs, or discs without the consent of the owner
of copyright in the sound or video recording, broadcast or cable
programme and in any literary, dramatic, musical, or artistic
work embodied therein.
CAUTION:
When you are not using the unit for a long period of time, it is
recommended that you disconnect the power cord from the
mains outlet.
Dangerous voltage inside. Refer internal servicing to qualified
service personnel. To prevent electric shock or fire hazard,
remove the power cord from the mains outlet prior to connecting
or disconnecting any signal lead or aerial.
The mains plug shall remain readily operable.
The STANDBY/ON Abutton does not completely shut off mains
power from the unit, but switches operating current on and off.
ABBshows electrical power standby and ACBshows ON.
A warning that an apparatus with CLASS I construction shall be
connected to a MAINS socket outlet with protective earthing
connection.
Main Plug
The Main Plug is used as the disconnect device, the disconnect
device shall remain readily operable
Even if the display window of the unit is unlit, the main power
supply is not cut off unless the power cord is unplugged.
The main power supply for this unit is controlled by inserting or
removing the power plug.
Dear Customer, [European Union]
This apparatus is in conformance with the valid European
directives and standards regarding electromagnetic compatibility
and electrical safety.
DANGEROUS VOLTAGE INSIDE
TO PREVENT FIRE OR SHOCK HAZARD,
European representative of JVC KENWOOD Corporation is:
JVC Technical Services Europe GmbH
Konrad-Adenauer-Allee 1-11
61118 Bad Vilbel
GERMANY
WARNING
This is a Class A product. In a domestic environment this product
may cause radio interference in which case the user may be
required to take adequate measures.
Sehr geehrter Kunde, [Europäische Union]
sehr geehrte Kundin,
dieses Gerät stimmt mit den gültigen europäischen Richtlinien
und Normen bezüglich elektromagnetischer Verträglichkeit und
elektrischer Sicherheit überein.
Die europäische Vertretung für die
JVC KENWOOD Corporation ist:
JVC Technical Services Europe GmbH
Konrad-Adenauer-Allee 1-11
61118 Bad Vilbel
DEUTSCHLAND
Safety Precautions 5
Getting Started

.
Note for United Kingdom power cord only
The plug of United Kingdom power cord has a built-in fuse.
When replacing the fuse, be sure to use only a correctly rated
approved type, re-fit the fuse cover. (Consult your dealer or
qualified personnel.)
How to replace the fuse
Open the fuse compartment with the
blade screwdriver, and replace the
fuse.
POWER CONNECTION
The power supply voltage rating of this product is AC 220 – 240 V
(For European countries, Asian countries, and United Kingdom).
The power cord attached conforms to the following power supply
voltage and countries. Use only the power cord designated to
ensure safety and EMC regulations of each country.
This plug will fit only into a grounded power outlet. If you are unable
to insert the plug into the outlet, contact your electrician to install the
proper outlet. Do not defeat the safety purpose of the grounded plug.
●This product should be operated only with the type of power
source indicated on the label. If you are not sure of the type of
power supply of your home, consult your product dealer or local
electric power company.
Warning:
●Do not use the same power cord for AC 120 V as for AC 220 –
240 V. Doing so may cause malfunction, electric shock or fire.
For European and Asian
countries: AC 220 – 240 V
For United Kingdom:
AC 220 – 240 V
Fuse
This equipment has been designed and manufactured to meet
international safety standards but, like any electrical
equipment, care must be taken if you are to obtain the best
results and safety is to be assured.
DO read the operating instructions before you attempt to use the
equipment.
DO ensure that all electrical connections (including the mains plug,
extension leads and interconnections between pieces of
equipment) are properly made and in accordance with the
manufacturer’s instructions. Switch off and withdraw the mains
plug when making or changing connections.
DO consult your dealer if you are ever in doubt about the installation,
operation or safety of your equipment.
DO be careful with glass panels or doors on equipment.
DON’T continue to operate the equipment if you are in any doubt
about it working normally, or if it is damaged in any way^
switch off, withdraw the mains plug and consult your dealer.
DON’T remove any fixed cover as this may expose dangerous
voltages.
DON’T leave equipment switched on when it is unattended unless
it is specifically stated that it is designed for unattended
operation or has a standby mode. Switch off using the switch
on the equipment and make sure that your family knows how
to do this. Special arrangements may need to be made for
infirm or handicapped people.
DON’T use equipment such as personal stereos or radios so that
you are distracted from the requirements of road safety. It is
illegal to watch television whilst driving.
DON’T listen to headphones at high volume, as such use can
permanently damage your hearing.
DON’T obstruct the ventilation of the equipment, for example with
curtains or soft furnishings. Overheating will cause damage
and shorten the life of the equipment.
DON’T use make shift stands and NEVER fix legs with wood screws
^to ensure complete safety always fit the manufacturer’s
approved stand or legs with the fixings provided according to
the instructions.
DON’T allow electrical equipment to be exposed to rain or moisture.
ABOVE ALL...
^NEVER let anyone especially children push anything into holes,
slots or any other opening in the case^this could result in a fatal
electrical shock;
^NEVER guess or take chances with electrical equipment of any
kind^it is better to be safe than sorry!
.
Importer (EU only)
12 Priestley Way, London NW2 7BA,
UNITED KINGDOM
Importeur (Nur EU)
Konrad-Adenauer-Allee 1-11, 61118 Bad Vilbel,
DEUTSCHLAND
Importateur (EU uniquement)
7 Allee des Barbanniers, CS20034
92632 Gennevilliers Cédex, FRANCE
Importatore (Solo EU)
Via G. Sirtori 7/9, 20129 Milano, ITALIA
Importador (Solamente EU)
Ctra. Rubi, 88 Edificio Can Castanyer,
08174 Sant Cugat del Valles,
Barcelona,
ESPAÑA
Importeur (Alleen EU)
Leuvensesteenweg 248J, 1800 Vilvoorde,
BELGIQUE
Importeur (Alleen EU)
Amsterdamseweg 37, 1422 AC Uithoorn,
NEDERLAND
.
Manufacturer
3-12,Moriya-cho, Kanagawa-ku,Yokohama-shi,
Kanagawa, 221-0022, JAPAN
6Safety Precautions
Getting Started

.
󱂕ḏ䌰὞ἀ䒩㚠旑
󱂕ḏḨ⑂ᶮ䘅㚊⬴䇪岩
恩ṷ⎎䥱
㚊⬴䇪岩
摆
澐Qc澑
㯟
澐Ih澑
擊
澐De澑
󱂏Ṹ摭
澐Ds)WJ*澑
⢛㸵俕剰
)QCC*
⢛㸵ḍ剰愛
澐QCEF澑
乀嵰㜀久ṷ ȵȵ  ȵ ȵ
㚻䬲 ȵȵ  ȵ ȵ
㴳㗷㖿䢻⯐㦢⛘
ḥ㳂廭㋣◩
󱂘ṗ旅ṷ
ȵȵ  ȵ ȵ
ȵȵ  ȵ ȵ
ȵȵ  ȵ ȵ


䌰὞ἀ䒩㚠旑
㫥♿㞈埩䢻ḇᶮ⋏ḻ㮒󱂓␍♾䘅㱖⼌㇁奅⬛䘅䌰὞ἀ䒩㚠旑ɝ⍫夂䒩ㆸ⚩ἀ䒩㚭Ḩ⑂㕷忶
⬉㱩ゐḌ柺ᶮ䘅⎅柺奅⬛澔ṏ↷御㕦㚠⺁⥌↱㫥♿㞈㞈ⅻ䘅㚠旑ᶻ㫣澐䌰὞ἀ䒩㚠旑澑㕣
ᶎẛ㯢㝔䌰⠄󰶁ᶎẛḨ䒠⭺ḻỔ㚊⬴䘅䇪岩ɝ
旅ṷ␍㴉侘⾨晷ṷ䘅䌰὞ἀ䒩㚠旑⤃ᶌ㇁䢻澢
澐ᶎ⎍Ḩ⑂ᶮ⊆⎬䘅旅ṷ␍㴉侘⾨晷ṷ󰶁ᶎ䙹⎍ɝ澑
忦㌨◩ɜḥ㳂廭㋣◩ɜ䒶亇䯼澢21ⷵ
㚭埩㞽἞㋯ ! TK0U22475 ! 䘅奅⬛亗↷ɝ
ȵ澢埩䢻学㚊⬴䇪岩⚩学恩ṷ㇁㚊⛈岩㛑㔚ᶮ䘅⎬慐⛈⚩ ! HC0U37683 ! 奅⬛䘅旑慐夂㯃Ṧᶌɝ
澢埩䢻学㚊⬴䇪岩兴⮒⚩学恩ṷ䘅㝑ᶁ⛈岩㛑㔚ᶮ䘅⎬慐崆ⅻ ! HC0U37683奅⬛䘅旑慐夂㯃ɝ
For RM-LP100E
GB4943.1-2011
GB9254-2008
GB17625.1-2012
Safety Precautions 7
Getting Started

Contents
Getting Started
Safety Precautions ................................................................ 2
Contents ................................................................................ 8
Precautions ........................................................................... 8
Name of Parts ........................................................................ 9
Basic Operations ................................................................... 9
Others
Troubleshooting ................................................................... 10
Connection Diagram ............................................................ 10
Specifications ...................................................................... 11
.
Content of this manual
Symbols used
Caution :Describes precautions concerning the operation
of this product.
Memo : Describes reference information, such as
functions and usage restrictions of this product.
Content of this manual
0All rights reserved by JVC KENWOOD Corporation.
Unauthorized duplication or reprinting of this manual, in
whole or in part, is strictly prohibited.
0Illustrated designs, specifications and other contents of this
manual are subject to change for improvement without prior
notice.
0Other product and company names included in this
instruction manual are trademarks and/or registered
trademarks of their respective companies. Marks such as
™ and ® have been omitted in this manual.
Precautions
Storage and Usage Locations
Avoid using or placing this unit in the following
places.
It might result in malfunctions or failure.
0Hot or cold places that are beyond the allowable operating
temperature range (0 °C to 40 °C).
0Locations beyond or below the allowable operating
humidity range of 20 %RH to 90 %RH. (Condensation is
not allowed)
0Near equipment that emits strong magnetic fields, such as
transformers or motors.
0Near equipment that emits radio waves, such as
transceivers and mobile phones.
0Locations with excessive dust and sand.
0Locations prone to moisture such as window side.
0Locations that are subjected to radiation, X-rays, salt attack
or corrosive gases.
0Places subject to smoke or vapor such as near a cooking
stove
0Places subject to strong vibrations or unstable surfaces
In a parked car under direct sunlight or near a
heater for long hours
Protect this unit against penetration of dust
when using it in a place subject to sandy dust.
Handling Precautions
Do not rub against or press the surface of the
touch panel with a knife or a sharp object.
Do not apply excessive force to this unit; do not
lift this unit while holding the control lever.
Maintenance
Turn off the power before performing any
maintenance.
Wipe using a soft cloth. Wiping with thinner or
benzene may melt or tarnish its surface.
For tough stains, wipe using a cloth that is
dipped into a neutral detergent diluted with
water, followed by wiping with a dry cloth.
Cautions on Installing this Unit on a
Desktop
Install this unit such that it does not fall from the
desktop due to vibrations.
Energy Saving
When this unit is not in use, set the Power
switch to “OFF” to reduce power consumption.
8Contents
Getting Started

Name of Parts
Front panel
.
A
B
C
D
E
F
G
H
I
J
AUSER1 button
For switching the settings menu.
BF1 knob
Used for the multi-function settings.
CF2 knob
Used for the multi-function settings.
DUSER2 button
For switching the settings menu.
EZoom lever
For performing the zoom operation of the remote camera.
FALARM lamp
Red : Lights up when the alarm is activated.
GPOWER lamp
Green : Lights up while the power is on.
HControl lever (F3)
0For operating pan/tilt of the remote camera.
0Used for the multi-function settings.
IFocus knob/Push auto button
0For performing the focus operation of the remote camera.
0Used for the one-push auto focus function.
JOperation panel
Used as a touch panel.
Rear panel
.
A B C D E F G
I
H
APower switch
For turning the power on or off.
BCable clamp
For preventing the AC adapter cable from falling out.
CDC 12V terminal
For connecting the supplied AC adapter.
DLAN terminal
For connecting a LAN cable.
ESERVICE terminal
For use during servicing.
FTALLY terminal
Used for TALLY connection.
GSETTING switch
1 to 4 : For switching TALLY IN and OUT.
5 to 8 : Used for servicing only.
HSERIAL terminal
Not used.
IRating label
Basic Operations
For details, refer to the instruction manual.
1Turn on the power.
0Set the power switch at the rear of this unit to “On”. The
LED lamp lights up in green.
2Configure the settings of this unit.
0Set the IP address of this unit as follows.
ASelect [SETTINGS] on the top screen of the control
panel.
0If the top screen doesn’t appear, select [HOME].
BSelect [Network].
CSelect [CONTROLLER].
0The IP address setting screen appears.
DEnter the IP address and press [ENTER].
3Configure the camera setting.
0Set the camera to be operated as follows.
ASelect [SETTINGS] on the top screen of the control
panel.
0If the top screen doesn’t appear, select [HOME].
BSelect [Network].
CSelect [CAMERA REGISTRATION].
DSelect [AUTO] to register the camera.
Memo :
0For details on the [MANUAL] settings, please refer
to the “INSTRUCTIONS” on the website.
0To change the camera to be operated, perform the above
operations again.
Name of Parts 9
Getting Started

Troubleshooting
Problem Symptom Action
Power does
not turn on.
No response after
pressing the control
panel on the unit.
Turn off the power switch at
the back of the unit and
power on again. If it still
does not start up, stop using
the unit, disconnect the
power cord from the power
outlet and consult a dealer
or our service center.
Connection Diagram
.
RM-LP100
KY-PZ100 KY-PZ100 KY-PZ100
LAN cable
HUB
* Up to 100 cameras can be connected concurrently.
10 Troubleshooting
Others

Specifications
General
Item Description
Power DC 12 V
Current consumption 0.6 A
Mass Approx. 2.1 kg
Surrounding
temperature
0 °C to 40 °C (operation)
Allowable operating
humidity
20 %RH to 90 %RH (No condensation)
Terminal Section
Item Description
TALLY terminal D-sub 9-pin
LAN terminal 10BASE-T/100BASE-TX
[DC] terminal DC jack (for the supplied AC adapter)
Accessories
Accessories
Warranty Card (U model only) 1
INSTRUCTIONS (BASIC) 1
AC Adapter 1
Power Cord (U model: 1, E model: 2)
Wire Clamp 1
Screw (M3) 1
Dimensional Outline Drawing (Unit: mm)
.
350 182
110
62
177
* The specifications and appearance of this product are subject to changes for further improvement without prior notice.
Specifications 11
Others

RM-LP100U/RM-LP100E REMOTE CAMERA CONTROLLER
© 2016 JVC KENWOOD Corporation B5A-1723-00
