Kaixin DCU12 User manual

KAIXIN
DCU12
Full Digital Color Doppler Ultrasonic
Diagnostic Instrument (Vet)
User’s Manual
XUZHOU KAIXIN Electronic Instrument Co., Ltd.

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
Introduction
Thank ou for purchasing DCU12 Full Digital Color Doppler Ultrasonic Diagnostic Instrument.
Users shall carefull read through this manual and full understand the text before operating the
equipment.
Please keep this manual after reading so that ou can access at an time when needed.
The user’s manual issue date: September 1st, 2014 Version: V1.00
For the changes of appearance, this manual is subject to change without further notice!
Intellectual Pro erty Information
The user’s manual and the corresponding intellectual propert rights belonging to Xuzhou Kaixin
Electronic Instrument Compan Ltd. (hereinafter referred to as Kaixin).
Individual or organization ma not cop , modif or translate an part of this user’s manual, without
the express written permission of Kaixin.
Statement
Kaixin has the final explanation right of this user’s manual.
Kaixin was considered responsible for the safet , reliabilit and performance in case of meeting all
the following requirements:
1. Assembl , expansion, readjustment, improve and repair are all performed b professionals
recognized b Kaixin;
2. All replacement parts and accessories, consumables involved repairs are Kaixin compan
(original) or approved b Kaixin;
3. Related electrical equipment complies with national standards and the requirements of the user’s
manual;
4. Operate the product in accordance with the user’s manual.
Warranty and re air service
Purchased the product warrant , sees the compan 's service policies.
The qualified service personnel can repair the instrument out of warrant b themselves. But this
should be agreed b Xuhou Kaixin Electronic Instrument Co., Ltd. We will provide circuit diagrams,
component part lists or other information to assist service personnel to repair those parts of our equipment
that are designated b our compan .
Manufacturer’s Information
Xuzhou Kaixin Electronic Instrument Co., Ltd.
Kaixin Mansion, C-01, Economic Development Zone, Xuzhou, Jiangsu, China.
Post Code: 221004
Tel: [phone] 87733758
Fax: [phone] 87792848
Website: http://www.kxele.com
E-mail: [e-mail]
F-1

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
Im ortant Statement
1. User shall be full responsible for the maintenance and management of this product after
purchasing this product.
2. Even in the warrant period, warrant does not include the following:
a) Damage or loss caused b error or rough using.
b) Damage or loss caused b force majeure (such as fires, earthquakes, floods, or lightning etc.).
c) Damage or loss caused b not meeting the conditions of use specified b the s stem, such as
inadequate power suppl , incorrect installation or environmental conditions do not meeting
the requirements.
d) Damage or loss caused b not used the s stem in the initial bu region.
e) Damage or loss caused b the s stem purchased not b Kaixin or its authorized dealer or
agents.
3. Medical personnel qualified with professional qualifications onl to use this s stem.
4. Do not modif the software or hardware of the equipment without authorization of the
manufacturer.
5. In an case, Kaixin shall not be liable for the problems, damages or losses due to re-installation,
alteration or repair the s stem b non-Kaixin designated personnel.
6. This product is intended to provide clinical diagnostic data for the doctor.
The doctor shall be responsible for the diagnostic process. Kaixin shall not be liable for an
problems arising out of the process.
7. Be sure to back up important data to external storage media, such as notebooks.
8. Due to operator’s error or abnormal condition causing the data stored in the internal s stem is lost,
Kaixin is not responsible.
9. This user’s manual contains warnings for predictable dangers. Users shall also exercise care at an
time to be aware of the dangers unforeseen in this manual. Kaixin shall not be liable for the
damages and losses arising out of neglecting to follow the operation instructions herein described.
10. This user’s manual shall be furnished with the machine so that managerial and operating
personnel can refer to it an time as necessar . Once the managerial personnel of the s stem
changes, it shall hand over this user’s manual.
11. Deal with the exhausted product according to the local statute.
12. The maintenance and servicing of product shall be performed b professional engineer or b
Kaixin Electronic Instrument Compan Ltd.
13. Professional engineer mentioned in the user’s manual is the person who has been trained and
authorized b KAIXIN Compan .
F-2

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
Safety Cautions
1. Warning Symbols and Definitions
The following warning s mbols are used in this manual to indicate safet level and other important items.
Please remember these s mbols and understand the meaning as ou read this user’s manual. These
s mbols conve specific meanings as detailed in the table below:
Symbols & Words Connotation
Danger Indicates an imminent danger that ma result in personal death or
serious injur if not avoided.
Warning Indicates a potential danger that ma result in personal injur if not
avoided.
Attention Indicates a potential danger or unexpected use condition that ma
result in light injur or propert loss or affecting the use if not avoided.
2. Safety Symbols
Symbols Meaning Symbols Meaning
T pe BF applied part Up
Stand-b
Keep dr
Power suppl indication Fragile
Adapter connection indication Stacking limit b number
Batter charge indicator (reserved)
Temperature limits (Storage and
transport)
Marking for the separate collection of
electrical and electronic equipment
Humidit limitation (Storage
and transport)
Follow instructions for use
Atmospheric pressure limitation
(Storage and transport)
F-3

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
3. Labels
Label Descri tion
Danger:
1. It ma have explosion hazard if used
with flammable gas.
2. Operate the probe with care. Read
the probe information in the relevant
manual for proper probe use.
Attention:
Do not place object on the machine. Do
not appl external force on the machine.
Close the ke board before moving the
machine.
Attention:
It is prohibited to scratch or squeeze the
LCD/LED.
Warning:
The device should be used onl with
external AC/DC adapter provided b
manufacturer. Use of other AC/DC
adapter ma cause damaged to the
device or cause fire and electric shock
hazards.
Symbol for the marking of electrical and electronics devices according to
Directive 2002/96/EC. The device, accessories and the ackaging have to be
dis osed of waste correctly at the end of the usage. Please follow Local
Ordinances or Regulations for dis osal.
F-4

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
Contents
Cha ter One Technical S ecifications……………………………………………………………1
Cha ter Two System Outline………………………………………………………………………3
2.1 Structure composition of the instrument ………………………………………………3
2.2 Components name…………………………………………………………………………3
2.3 Parts of the probe…………………………………………………………………….. 3
2.4 Rear panel instruction…………………………………………………………………….4
2.5 Function ke s instruction…………………………………………………………………4
2.6 Trackball……………………………………………………………………………………..…6
Cha ter Three System Configuration………………………………………………………………7
Cha ter Four O eration Condition………………………………………………………………7
Cha ter Five System Installation and Check……………………………………….……………8
5.1 S stem placement………………………………………………………………………………9
5.2 Probe brackets installation……………………………………………………………………9
5.3 Ultrasonic probe installation………………………………………………………………….9
5.4 Connect to power……………………………………………………………………………9
5.5 Install foot switch…………………………………………………………………………10
5.6 Video recorder installation……………………………………………………………………10
5.7 Ultrasonic probe check before and after operation…………………………………………10
5.8 Main unit check before and after operation…………………………………………………10
5.9 S stem reset…………………………………………………………………………………11
Cha ter Six Work Main Interface………………………………………………………………12
6.1 Startup and Shutdown…………………………………………………………………………12
6.2 Work main interface……………………………………………………………………………12
6.3 Title information region………………………………………………………………………12
6.4 Menu adjustment region……………………………………………………………………13
6.5 Image region…………………………………………………………………………………13
6.6 Image parameters displa region………………………………………………………13
6.7 Measured result displa region…………………………………………………………13
6.8 Status prompt region…………………………………………………………………………13
Cha ter Seven System Preset………………………………………………………………………14
7.1 S stem preset interface…………………………………………………………………14
7.2 Basic preset………………………………………………………………………………14
7.3 Probe Information………………………………………………………………………15
7.4 Parameter Displa ………………………………………………………………………15
7.5 Formula preset……………………………………………………………………………15
7.6 Net Setting………………………………………………………………………………15
7.7 Comment preset……………………………………………………………………………15
7.8 Store preset………………………………………………………………………………16
7.9 Password preset………………………………………………………………………………16
7.10 About…………………………………………………………………………………………16
7.11 Restore the factor setting…………………………………………………………………16
Cha ter Eight Patient Information In ut………………………………………………………17
8.1 Enter/exit New Patient interface……………………………………………………………17
8.2 Input patient information……………………………………………………………………..17
Cha ter Nine Select robe and a lication mode………………………………………………18

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
9.1 Select probe and application mode…………………………………………………………..18
9.2 User Settings………………………………………………………………………………..18
Cha ter Ten Image o eration modes…………………………………………………………19
10.1 Operation modes……………………………………………………………………………..19
10.2 Switch operation modes……………………………………………………………………..19
10.3 Image parameter adjustment……………………………………………………………..19
10.3.1 Image brightness adjustment……………………………………………………………..19
10.3.2 B/2B mode………………………………………………………………………………..20
10.3.3 B/M mode………………………………………………………………………………..21
10.3.4 M mode…………………………………………………………………………………..23
10.3.5 CFM mode………………………………………………………………………………..23
10.3.6 PDI mode…………………………………………………………………………………..26
10.3.7 PW mode…………………………………………………………………………………..26
Cha ter Eleven Cine layback…………………………………………………………………30
11.1 Enter/exit cine pla back…………………………………………………………………..30
11.2 Operation of cine pla back………………………………………………………………..30
Cha ter Twelve Syno sis of Measurement Menu……………………………………………31
12.1 Measurement menu categories……………………………………………………..31
12.2 Measurement menu composition…………………………………………………..32
12.3 Basic operation………………………………………………………………………..32
Cha ter Thirteen B mode measurement and calculation………………………………34
13.1 B general measurements……………………………………………………………………34
13.2 B abdominal measurements…………………………………………………………………37
13.3 B obstetric measurements……………………………………………………………………39
13.4 B cardiac measurements……………………………………………………………………41
13.5 B urolog measurements……………………………………………………………………45
13.6 B superficial organs measurements…………………………………………………………47
Cha ter Fourteen M mode measurement and calculation………………………………………50
14.1 M general measurements……………………………………………………………………50
14.2 M cardiac measurements……………………………………………………………………51
Cha ter Fifteen CFM/PDI mode measurement and calculation……………………………55
15.1 CFM/PDI mode measurement and calculation parameters are the same as B-mode…………55
15.2 CFM/PDI mode measurement and calculation methods are the same as B-mode……………55
Cha ter Sixteen PW mode measurement and calculation……………………………………56
16.1 PW mode measurements………………………………………………………………56
16.2 PW measurement report…………………………………………………………………59
Cha ter Seventeen Text comment and arrow mark……………………………………………60
17.1 Enter/exit text comment……………………………………………………………………..60
17.2 Add text comment…………………………………………………………………………..60
17.3 Delete text comment………………………………………………………………………..61
17.4 Enter/exit arrow mark……………………………………………………………………..61
Cha ter Eighteen Body mark, Puncture guide and Lithotri sy………………………………62
18.1 Enter/exit bod mark………………………………………………………………………..62
18.2 Enter/exit puncture guide…………………………………………………………………..62
18.3 Operation of Lithotrips …………………………………………………………………..62
Cha ter Nineteen Image management……………………………………………………………63
19.1 Work interface of image management………………………………………………………..63
19.2 Enter/exit image manage…………………………………………………………………..63

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
19.3 Formats of image files……………………………………………………………………..64
19.4 Review, demo image/video/report………………………………………………………..64
19.5 Dicom archive……………………………………………………………………………..64
Cha ter Twenty Edit and rint re ort…………………………………………………………65
20.1 Enter/exit report editing module…………………………………………………………..65
20.2 Work interface of report editing…………………………………………………………….. 65
Cha ter Twenty-one Print and Transfer files…………………………………………………67
21.1 Print…………………………………………………………………………………………..67
21.1.1 Network print……………………………………………………………………………..67
21.1.2 USB Print………………………………………………………………………………..72
21.2 Transfer BMP files…………………………………………………………………………..72
21.3 DICOM parameter setting………………………………………………………………..72
21.4 Transfer DICOM files……………………………………………………………………..72
Cha ter Twenty-two System Maintenance……………………………………………………73
22.1 Maintenance b users…………………………………………………………………..73
22.1.1 S stem cleaning and disinfection………………………………………………………..73
22.1.2 Clean the probe cable and its connector………………………………………………..74
22.1.3 Clean the LED screen…………………………………………………………………..74
22.1.4 Clean the trackball………………………………………………………………………..75
22.1.5 Clean the video recorder, printer………………………………………………………..75
22.1.6 Clean the control panel, shell and probe bracket………………………………………..75
22.2 Replace the fuse………………………………………………………………………..75
22.3 Data maintenance…………………………………………………………………………..75
22.4 Troubleshooting……………………………………………………………………………..76
22.5 Maintenance b service personnel………………………………………………………..76
Cha ter Twenty-three Storage and Trans ortation………………………………………………77
Cha ter Twenty-four Safety Classification………………………………………………………77
A endix B System Block Diagram………………………………………………………………78

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 1 -
Cha ter One Technical S ecifications
1.1 Technical arameters
1. Gra scale: 256
2. Monitor: 10.4” LED
3. Adapter rating: 100-240V~, 1.2-0.6A, 50-60Hz
4. Output of Adapter: DC12.8V 3.0A
5. Main device rating: DC12V 3.0A
6. Main Unit Size: approx. 256 * 150 * 326 (L * M * H, mm)
7. Weight of main unit: approx. 5 kg (excluding accessories)
1.2 Primary Functions
1. S stem preset function;
2. Exam part preset function;
3. Probe switching function;
4. Mode conversion function;
5. Magnification/depth range selection function;
6. Frequenc conversion function;
7. Frame average adjustment function;
8. Edge enhancement function;
9. Compress curve adjustment function;
10. Image post-process adjustment function;
11. Focus position adjustment function;
12. Image up/down, left/right reversal;
13. Image freeze/unfreeze function;
14. Man segments adjustable TGC, adjustment of total gain and d namic range;
15. Image optimization function;
16. Adjustable Dopple frequenc , PRF, wall filter function;
17. Sensitivit , color persistence, color threshold, color balance, color smooth and artif remove
function;
18. Adjustable corrected angle, sample volume, linear color steering, velocit scale, baseline function;
19. Adjustable harmonics function;
20. B mode general measurement function;
21. M mode general measurement function;
22. CFM mode general measurement function;
23. PDI mode general measurement function;
24. PW mode measurement function;
25. Abdomen application measurement function;
26. Obstetric application measurement function;
27. Cardiolog application measurement function;
28. Urolog application measurement function;
29. Superficial organs application measurement function;
30. Adjustable acoustic power;
31. Puncture guide function;
32. Lithotrips positioning function;
33. Image, video and report storage function;
34. Image management function;

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 2 -
35. Cine pla back function;
36. Bod marks function;
37. Information annotation function;
38. User defined function;
39. Input patient information function;
40. Automaticall general report function;
41. Recall report b one-ke ;
42. Transmit image to Network Printer b one-ke ;
43. Network print function;
44. LED brightness adjustment function;
45. Energ -saving function;
46. Chinese-English menu switch function.

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 3 -
Cha ter Two System Outline
2.1 Structure com osition of the instrument
DCU12 full digital color Doppler ultrasonic diagnostic instrument (Vet) is composed of main unit and
probe and etc.
2.2 Com onents name
Fig. DCU12 main unit sketch map
2.3 Parts of the robe (Take 3.5MHz convex array robe for exam le)
Fig. Parts name of 3.5MHz R60 convex arra probe
Name Function
(1) Acoustic lens
To convert electric signal to ultrasonic signal based on principle of converse
piezoelectric effect. The ultrasonic signal, after entering the human bod , is
reflected as echo wave and converted to electric signal again. The acoustic
lens is on the probe surface. Suppl ultrasonic coupling gel to the acoustic
lens surface when performing ultrasonic diagnosis.
(2) Puncture anchor To fix the puncture bracket
(3) Cable To connect the probe to the probe connector
(4) Probe connector To connect the probe to ultrasonic diagnostic s stem.
(5) Lock/loosen knob To lock/loosen the connection of probe to ultrasonic diagnostic s stem.
Displa
Ke board
Probe
Main unit
BATTERY
(Reserved)

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 4 -
2.4 Rear anel instruction
Color SVGA Out
Fig. Real panel A sketch map
12V
Fig. Real panel B sketch map
2.5 Function keys instruction
SN Key symbol Key name Key function
1 Exit Exit dialog, menu or measurement;
2 LED setting Adjust the brightness of LED;
3 Acoustic power In real-time scanning mode, press the ke to adjust the acoustic
power parameters of s stem;
4 Image post-process Press ke to adjust the image post-process;
5 Menu switch In real-time scanning mode, press the ke to switch the
“Parameters” menu and “Displa ”menu;
6 Volume
Displa or hide the control bar of volume; when displa the
control bar, press up/down direction ke to adjust the volume;
7
Chinese input
editing method Press this ke to input Chinese (use in the Chinese version);
8
One-ke transfer
Press the ke to transfer images to the software
, the specific use of Network Printer sees its
instructions for use;
9 Puncture guide Displa or switch the puncture guide line;
10 Store
In frozen status, the current displa image or video is saved to D
disk or U disk;
11 One-ke store
In frozen status, press this ke , the current displa image is saved
to D disk or U disk;
12 S stem Preset Enter/exit s stem preset interface;
13 Probe selection
Select the probe model and select the s stem defaults or
user-defined values;
14
management
·In frozen status, enter the image management module;
·Review the saved patient images, reports and videos;
Network
interface
Color SVGA output
Video output interface
int
erface
USB port
Power input interface
USB port
Foot
switch

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 5 -
15 Value adjustment Rotate this knob to adjust the corresponding parameters;
16
Menu-item
selection Rotate this knob to select the menu-item;
17 Depth
Press the ke and then rotate【Value】knob, adjust the scanning
depth;
18 Frequenc
Press the ke and then rotate【Value】knob, adjust the conversion
frequenc ;
19 Focus
Press the ke and then rotate【Value】knob, adjust the position of
focus;
20 Velocit scale
Rotate this knob to adjust the pulse repetition frequenc of
CFM/PDI/PW;
21 Wall filter Rotate this knob to adjust the wall filter of CFM/PDI/PW;
22 D namic range Rotate this knob to adjust the d namic range of image;
23 Sample volume
·Operate in PW mode;
·Rotate this knob to adjust the size of sample volume;
24 Angle
·Operate in PW mode;
·Rotate this knob to adjust the deflection angle of sample
volume;
25 Baseline
·Operate in PW mode;
·Rotate this knob to move the position of baseline in PW
spectrum image;
26
Linear color
steering
·Operate in CFM, PDI and PW mode;
·The function onl be used with linear arra probe;
·Press the ke to adjust the deflection direction of color sampling
box;
27 Harmonics Press the ke to enter tissue harmonics function;
28 B mode Press the ke to enter B mode; press again to enter dual B mode;
29 B/M mode Press the ke to enter B/M mode; press again to enter M mode;
30
Color flow
mapping Doppler Press the ke to enter CFM mode;
31
Color Power
Doppler Press the ke to enter PDI mode;
32
Pulse-wave
Doppler Press the ke to enter B/PW mode;
33
Color Continuous
Doppler Reserved ke , to be upgraded;
34 New patient ·Access to new patient module;
·Input the information and data for new patient;
35 Annotations Press the ke to enter the annotation module;
36 Bod marks Press the ke to enter bod mark module;
37 Clear
Press the ke to clear annotations, arrow marks, markers of
measurement and calculation, measured results and bod mark
on the image;

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 6 -
38 Cine pla back In frozen status, press the ke to enter the cine pla back status;
39
Measurement and
calculation
Press the ke to enter general measurement menu and
application measurement menu;
40 Update
·In B/B mode, realize the switching of dual B mode;
·In PW mode, realize the switching among B/PW mode (sample
reference mode of previous PW and PW mode);
·Switch the quad screen.
41 Obstetric Press the ke to enter obstetric measurement menu;
42 Ultrasound report Press the ke to enter the ultrasound report interface;
43 Freeze Press the ke to freeze or unfreeze the image;
44 Set ·Select or confirm;
·Press the ke to increase the values;
45 Back
·Press the ke , in reverse order revoked the measured results and
measured reference lines;
·Press the ke to decrease the values;
46 Case conversion Switch the input between capital letters and small letters;
47 Shift Shift ke with the standard ke board;
48 Arrow
·In annotation status, press the ke to enter the function of arrow
mark;
·Now, through rotate【Value】knob to adjust the direction of
arrow mark;
49 Backspace Delete the character before the cursor while the cursor move left;
50 Enter Accept the input data;
51 Space Input space character;
52 Omit Numbers, letters,
s mbols
·Main characters: characters on the ke board, next-row
letters/numbers/s mbols of the multiplex ke s;
·Superscript characters: up-row letters and s mbols of the
multiplex ke s.
53
『TGC』 TGC Through the segments to adjust the gain at different depths;
54 B-Gain
Rotate【Gain】knob, adjust the gain of black/white image;
55 C-Gain
Rotate【Function】knob, adjust the gain of color image;
56 Power switch Open/close the main unit;
57 Ke board light Open/close the ke board light.
58 Function options
·Choose menu-item;
·Adjust the start-end positon of punction guide lines;
59 Increase/decrease
·Adjust parameters or values;
·Adjust the angle of punction guide lines;
2.6 Trackball
1. If has color sampling box when displa images, move the color sampling box;
2. When performing cine pla back b manual, view the images frame b frame;
3. Move the cursor when measurement;
4. Move the sample line;
5. In other work interface, move the cursor, etc.

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 7 -
Cha ter Three System Configuration
3.1 Ty ical configuration
1 Main unit 1 unit
2 Power adapter 1 PC
3 3.5MHz convex arra probe 1 PC
4
6.5MHz micro convex arra probe
7.5 MHz high frequenc linear arra probe
6.5MHz animal transrectal linear arra probe
Choose one
3.2 O tional arts
1. Video recorder
2. Foot switch
Cha ter Four O eration Condition
4.1 Power su ly
Adapter rating: 100-240V~, 1.2-0.6A, 50-60Hz
Adapter model: BJE01-40-001M
Output of Adapter: DC12.8V 3.0A
Main device rating: DC12V 3.0A
4.2 O eration Environment
Ambient temperature: 10℃-40℃
Relative humidit : 30%-75% (without condensation)
Atmospheric pressure: 800hPa-1060hPa
Altitude: < 2000 m
Overvoltage: Overvoltage Categor Ⅱ
Pollution degree: 2
4.3 Storage and Trans ort
Ambient temperature: -20℃-55℃
Relative humidit : 30%-93% (without condensation)
Atmospheric pressure: 700hPa-1060hPa
Attention
:
The main voltage is varies with different countries or regions.
Attention: System should be avoided using in following environments:
1. S lash 2. Moist 3. Rain
4. Thunderstorm weather 5. No ventilation 6. Dust
7. Close to heat source 8. Direct sunlight 9. Dramatic tem erature change
10. Chemical medicines 11.Poisonous gas 12. Corrosive gas
13. Strong shock 14. Strong electromagnetic field (e.g. MRI)
15. Radiation (e.g. X-ray, CT) 16. Defibrillators or short wave thera y equi ment
Danger: Do not use this equi ment where flammable gas (such as anesthetic gas, oxygen
or hydrogen) or flammable liquid (such as alcohol) are resent. Failure to do so may
result in ex losion.
Warning: Avoid using this equi ment with high-frequency electric knife,
high-frequency thera y equi ment or defibrillators and other electronic devices, or may
an electric shock occur to the atient.
Attention: Using radio transmitting equi ment nearby the system may interfere with
the normal o eration of the system. Prohibited carry or use of devices that can generate
radio waves within the room installed this system, such as cell hones, radio transceivers
and wireless remote control toys.

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 8 -
Cha ter Five System Installation and Check
Warning:
1. All lugs of instruments of this system shall be connected into the ower socket with
rotectively earth on the wall and the socket must meet the requirement of ower rating of
instrument. Use of multi le ortable socket-outlets may affect rotective earth to make
leakage currents exceed the safety requirements.
2. Please follow the correct electrical connections method to connect the ower su ly and
earth, otherwise there will be danger of electric shock. Do not connect the grounding wire to
any gas i e or water i e, or it may cause bad grounding and danger of ex losion.
3. This equi ment is not water roof, not use this equi ment in lace where liquid may into the
interior of the equi ment. Never our any liquid on the equi ment; otherwise there will be
danger of electric shock or cause equi ment damage. If accidentally s ill liquid on the
equi ment, turn off the ower immediately and contact your local re resentative.
4. Prohibit the live arts of the equi ment or other devices (such as various signal in ut and
out ut orts, etc.) contact with the atient, if this equi ment or other equi ment has failure,
the atient will have danger of electric shock.
5. Additional equi ment connected to the medical electrical equi ment must com ly with the
res ective IEC or ISO standards (e.g. IEC60950 for data rocessing equi ment).
Furthermore all configurations shall com ly with the requirements for medical electrical
systems (see IEC 60601-1-1 or clause 16 of IEC60601-1 3rd, res ectively). Anybody
connecting additional equi ment to medical electrical equi ment configures a medical
system and is therefore res onsible that the system com lies with the requirements for
medical electrical systems. Attention is drawn to the fact that local laws take riority over
the above mentioned requirements. When more than one device is connected to use, the
accumulation of leakage current may cause the danger of security.If in doubt, consult your
local re resentative or the technical service de artment.
Warning:
1. When instrument works abnormally, do sto working, turn off the ower and check the
reason, then contacts the KAIXIN Com any about it.
2. Turn off ower and ull out of the lug from socket after each ultrasonic diagnostic
o eration.
3. It is forbidden to drag and ress the ower and robe cables em hatically; regularly
ins ect whether there is ull-a art and bareness, if there is the henomena like this, turn off
ower su ly immediately, sto using it and change it for new one.
4. It is forbidden to load and unload the robe or move the instrument in galvanic to avoid
danger of safety.
5. Pull out of the lug from socket after o eration in thunderstorm weather to avoid the
instrument being damaged by lightening.
6. If the tem erature changes greatly in short time will cause va or recovery inside of
instrument, the case may damage the instrument.
7. The equi ment is switched com letely only by disconnecting the ower su ly from the
wall socket.
Warning: To avoid the risk of electric shock, this equi ment must only be connected to a
su ly mains wi
th rotective earth.
Warning: The ower ada ter, robes, foot switch as described in this section may be
re laced by o erator. To re lace according to the method of this section, does not result in
an unacce table risk.

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 9 -
5.1 System lacement
Please carefull read through and full understand the safet cautions before moving and placing the
s stem.
1. Unpack the instrument case and check the goods for its completeness according to the packing list
furnished.
2. Place the instrument on a stable and leveled position.
3. Leave adequate space of 20 centimeters as minimum from rear, left and right side of the instrument.
5.2 Probe brackets installation
The probe bracket should be mounted behind the main unit.
5.3 Ultrasonic robe installation
5.3.1 Probe connection
1. Shutdown the s stem; open the probe locking knob, and insert the probe connector into the probe
socket at the back of the main unit until the metal spring plates is evenl contacted. Tightl press the
connector.
2. Rotate the probe locking knob 90 degree clockwise and lock it, shown as the figure .
5.3.2 Probe disconnection
Shutdown the s stem; rotate the locking knob 90 degree counterclockwise, pull out the probe connector
verticall .
5.4 Connect to ower
1. Connect to the ower ada ter
Insert the output plug of adapter into DC input interface, which is at the back of main unit.
Attention: Adequate s ace from rear, left and right side of the machine shall be reserved,
or the machine may malfunction under excessive heat inside the enclosure.
Attention:
1. Turn off the ultrasonic system before disconnecting the robe. Disconnecting the robe
with system ower on may damage the system or robe.
2. Before disconnecting the robe, lace the robe on the robe bracket so that the robe
may not be damaged or injury erson by unex ected fall.
3. Freeze the instrument when instrument is start-u without o eration to increase of service
life of robe.
4. Re eat available machine time should be more than 5 minutes to avoid turn on/off ower
su ly in short time.
Warning:
1. Do not use the robe not rovided by our com any, otherwise the equi ment and the robe
will cause damage, and may cause fire in extreme cases.
2. Check the ultrasonic robe and connecting cable after diagnostic o eration. Use of
defective robe may cause electric shock to the atient.
3. Do not strike the robe; using the damaged robe may cause electric shock to the atient.
4. Unauthorized disassembly of the robe shall be rohibited as it may cause electric shock.
Warning: Before connecting or using the robe, make sure that the robe, connecting
cable and connector are in normal condition (free of cracks or dro ). Use of defective
robe may cause electric shock.

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 10 -
2. Connect to the main ower su ly
Insert the power plug (jack) furnished with the machine into power input socket of the power adapter,
the other end to the mains socket-outlet. The instrument uses three-core power suppl . It connects with
the protective earth line when power plug inserts into its socket.
5.5 Install foot switch
Shutdown the s stem; insert the plug of foot-switch into the “ ” socket at the back of the main unit.
5.6 Video recorder installation
1. Connect the equipotential terminal ( ) of the video recorder to the earthing;
2. Connect one end of the video connection line to the video recorder and the other end to the video output
interface ( ) on the real panel of main unit;
3. Insert one end of power plug (jack) of the video recorder to the power input socket of the video recorder,
the other end to the power suppl socket.
5.7 Ultrasonic robe check before and after o eration
Check if there are an exceptionall on the surface of the probe or cable jacket, such as peeling, cracks,
bulge, or if the acoustic lens is reliable, disinfected or cleaned.
5.8 Main unit check before and after o eration
5.8.1 Ins ection before start-u
Check the following items before starting the machine:
1. The temperature, humidit and atmospheric pressure shall meet the requirements of operation
condition.
2. No condensation occurs.
3. No distortion, damage or contamination on s stem and peripheral. Clean the parts as specified in
relevant sections, if the contaminant is present.
4. Check the control panel, LED screen and enclosure to ensure the are in good working condition and
free of abnormit (such as cracks and loosened screws).
5. No damage on cable (power cable, etc.), and hard up on its connection.
6. Check probe and its connections to ensure the are free of abnormit (such as scuffing, drop-off or
contamination). If the contaminant is present, clean, disinfect the contaminated objects as specified in
relevant sections.
7. See to it that there are no foreign objects on the control panel (Remove the object if an ).
8. No barriers around the intake of equipment.
9. See to it that probe has been cleaned, disinfected; else dispose it as specified in relevant sections.
10. Check all the ports of the machine for possible damage or blockage.
11. Clean the field and environment.
Warning:
1. Ada ter has no switch. APPLIANCE COUPLER or MAINS PLUG is used as the isolation
means from the SUPPLY MAINS. Not to osition the EQUIPMENT so that it is difficult to
o erate the disconnection device.
2. The device should be used only with ower ada ter rovided by Kaixin Com any.
3. To avoid damaging ower ada ter or harming eo le by unex ected fallen, make sure the
ower ada ter is laced on the leveled lane.
4. The o erator must not touch signal in ut/signal out ut and atient simultaneously.
Attention: The water roof grade of foot switch is IPX1.

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 11 -
5.8.2 Ins ection after start-u
Check the following items after starting the machine:
1. No abnormal voice, strange smell and overheating appear.
2. Check the machine to ensure a normal start-up: The power indication light is on and startup picture is
shown on the screen. Then the machine will automaticall enter B mode.
3. Check the acoustic lens for abnormal heat when the probe is in use. This can be done b hand touching
the probe to feel the temperature of the lens.
4. Check the image to ensure trouble-free displa (no excessive noise or flicker).
5. Check the control panel to ensure normal operation condition.
6. Check the instrument to ensure that the phenomenon of local high temperature will not appear.
5.9 System reset
In case of abnormal screen displa or not work for s stem operation, tr to restart the s stem b turning
on/off the power.
Attention: If the overheat acoustic lens is laced on the atient’s skin, heat injury may
occur.
Attention : Thoroughly clean the cou ling gel on the robe surface each time after
ultrasonic o eration, or the cou ling gel may become hardened on the acoustic lens of the
robe, deteriorating quality of image.

Full Digital Color Doppler Ultrasonic Diagnostic Instrument (Vet) User’s Manual V1.00
- 12 -
Cha ter Six Work Main Interface
6.1 Startu and Shutdown
First connect the power suppl , and then press the button on the bottom of screen to start the
machine, it will displa the B-mode image on the screen.
If ou want to turn off the machine, please press the button again, then pull out mains plug from
the suppl mains.
Note: Please do not directly un lug the ower ada ter when the machine is running. Turn off
ower and wait at least 5 minutes, then turn on the ower to reboot.
6.2 Work main interface
Work interface shows the ultrasonic images, various parameters and the corresponding operation
menus, etc. Menus and parameters in various scanning modes are slightl different.
The main regional distribution map of work interface is as follows.
②Menu
adjustment
region
⑥Status prompt region
③Image region
①Title information region
④Image
parameter
displa
region
⑤
Measured
result
displa
region
6.3 Title information region
It displa s the compan logo, hospital name, s stem date and time, patient information, MI/TI values,
acoustic power values, probe model, the current application mode and freeze icon, etc.
1. Compan logo
The compan logo is shown on the top left of screen.
2. Hospital name
Displa hospital name. Hospital name can be edited and modified in the “S stem Preset/Basic”.
3. S stem date and time
Displa the current s stem date and time. The adjustment of date and time, as well as the format of
date can be edited and modified in the “S stem Preset/Basic”.
4. Patient information
Displa the patient’s name and ID. In the module of “New Patient”, input or edit the name and ID for
the current patient.
5. MI/TI value
Displa the values of mechanical index (MI) and thermal index (TI) in the current s stem. According
to the different real-time scanning condition, it will displa different index values.
6. Acoustic power value
Displa the acoustic power in the current s stem. According to the different real-time scanning
condition, the acoustic power is different.
7. Probe model
Displa the probe model using in the current s stem, switching the probe can be realized b pressing
