• Be sure that the speaker is switched o with the POWER button (10) in OFF
position and that the power cord (11) is not plugged into the mains socket. All
operations should be carried out without power.
• Place your speaker in a suitable place, keeping it away from moisture and direct
sun rays. Use the side handles to carry the xture.
• Check that the selected (9) voltage is correct. A wrong voltage could seriosly
damage the xture and cause dangerous short-circuits.
• You can plug a microphone with XLR connector in the MIC socket (3). If you have
a microphone with 6,3 mono jack connector, you can use the socket (2).
• The input signal, coming from a mixer, a CD player or another “line” device, can
be connected to the RCA (6), XLR (5) “line input” sockets or Jack 3,5mm ST (6A).
• A further output for another powered speaker is available as an audio line signal,
on the “line output” XLR socket (7), while if you want to connect at 8 Ohms a
passive speaker (We suggest mod. BX 6822) you can use the speakon (8) socket.
The powered speaker will amplify also the passive one.
• If you wish to place your speaker on a tripod stand, please use the mount hole on
the bottom. It has a standard 35 mm diameter.
• Once made the connections, please put all the amplier volumes at their minimum
position (completely turned anti-clockwise). Connect the power cord to the socket
(11) and then to the mains (230V)
• Turn on the amplier through the POWER button (10). The power led (14) will light
up to indicate that the speaker is on. If with the button (10) in ON position the led
(14) remains oo and the speaker doesn’t work, before contacting the technical
service, disconnect the power cord and check if the protection fuse of the power
socket (11) is ok. If it is blown replace it with one of the same amperage. During
use, the cooling wings could get very hot. Don’t touch them to avoid the risk of
burning yourself.
• Turn on the xture providing the audio signal. The signal will be amplied. The
volume of each amplied signal can be adjusted through the specic control: for
the microphone use the rotating knob (1), for the line signal use the rotating knob
(4). The rotating knob Master (15) controls the general lever of the output signal.
The led CLIP(13) can ash to indicate signal peaks. If it remains on for more than
2 or 3 seconds, you must immediately turn down the volumes of input signals to
avoid to damage the xture.
• The useful 5 bands equalizer (17) allows to adjust with precision the incidence of
the tones reproduced, with increased performance in quality and power.
MP3 PLAYER AND RADIO
Your new speaker is provided with USB sticks and SD cards reader to play MP3 les.
It is enough to plug your mobile device into the specic socket (B/C) and use the PLAY
button to play, pause or change track. The display (A) shows main information of the
