Keys Fitness Functional Trainer KF-FT User manual

Functional trainer
Owner’s Manual
KF-FT
215-00216
03/07 Rev A

2
Table Of Contents
Before You Start 3
Important Safety Information 4
Assembly 5-11
Weight Stack Sticker Placement 12
Parts List 13
Exploded View 14
Warranty Information 15

KEYS FITNESS SERIES
MODEL: KF-FT
QUESTIONS?
CALL
1-888-340-0482
Monday-Friday
8:30-5:30 Central Time
When calling please have the following product information available:
3
Model Name :
Date Mfg.:
PO # :
Serial #:
This information can be found on
the serial tag located on the unit.
THANK YOU for making this unit a part of your exercise program.
Keys Fitness assures the very best in value, appearance, durability
and biomechanics.
This manual will guide you through the assembly process. If at any time you are
having trouble with the assembly or use of this product, then please contact us
at our Keys Fitness Help line. We have trained service technicians on site to take
care of you, our valued customer.
REGISTRATION CARD
To avoid unnecessary delays in warranty parts and to insure that a permanent
record of your purchase is on file with our company, be sure to send in the war-
ranty registration card or register on-line at www.keysfitness.com within 10 days
of purchase.
Before You Start

4
Important Safety Information
Prior to assembly, remove components from the box and verify that all the listed parts were
supplied.
WARNING!
Before using this unit or starting any exercise program, consult your
physician. This is especially important for persons over the age of
35 and/or persons with pre-existing health problems. Keys Fitness
Products LP assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
It is the owner’s responsibility to ensure that all users of this unit have
read the Owner’s Manual and are familiar with safety information and
precautions.
SAFETY PRECAUTIONS
• This unit should only be used on a level surface and is intended for
indoor use only. Keys Fitness recommends an equipment mat be
placed under the unit to protect the floor or carpet and for easier
cleaning.
• Wear comfortable, good-quality walking or running shoes and appro-
priate clothing. Do not use this unit with bare feet, sandals, socks or
stockings!
• Always examine your unit before using to ensure all parts are in
working order.
• Do not leave children unsupervised near or on the unit.
• Service to your unit should only be performed by an authorized
service representative, unless authorized and/or instructed by a
Keys Fitness technician. Failure to follow these instructions will void
the warranty.
Read all precautions and instructions in this manual before using this equipment.

STEP 1 Connect Left Frame (1) and Right Frame (2) with the two Rear
Beams (4) using Bolts M10X80 (55), Washers M10 (60), and Nylon
Nuts M10 (64).
5
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

STEP 2 Attach Main Beam (3) to Left and Right Frames (1 & 2) using Bolts
M10X105 (52), Washers M10 (60), and Nylon Nuts M10 (64).
6
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

7
STEP 3 Slide the Guide Rods (19) into the holes located on the Left and Right
Frames (1 & 2). Now apply the Lithium Grease included with your bolt
pack onto the Guide Rods (19).
Next, slide a Weight Bumper (37) onto each Guide Rod (19). Slide the
Weight Plates according to the appropriate configuration as shown on
Page 12. Last, slide the Top Plate (34) onto the guide rods. Note: Be
sure the weight pin holes face towards the inside of the unit. Screw
the Pulley Bracket (30) into the Top Plate (34).
Secure the Guide Rods (19) to the top of the Left and Right Frames
(1 & 2) using Allen Bolts M10X50 (57), Spring Washers M10 (61), and
Washers M10 (60).
7
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

STEP 4 Slide Left Frame Slip (5) onto Left Slip Tube (13).
Install Left Slip Tube (13) into the Left Frame (1). Note: Make sure
the numbers on the slip tube face to the front of the unit. Secure the
assembly using Bolt M10X80 (55), Washers M10 (60), Nylon Nut M10
(64) on the bottom and Bolt M10X95 (54), Washers M10 (60), Nylon
Nut M10 (64) on the top connection.
Repeat this step to complete the right side.
8
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

9
End
Start
5
STEP 5 Start by threading one end of the Pulley Cable (8) into Left Slip
Frame (5). Remove hardware and ball from the other end of the
cable. Follow the diagram above to complete the cable installation.
Note: When installing the cable, make sure the cable is centered on
the pulley and is not rubbing against any part of the frame or any
hardware.
Repeat this step to complete the right side.
9
Assembly

10
STEP 6 Slide Weight Shrouds (11) in between the Frame and the Weight
Stack as shown above.
Loosely attach Shroud Brackets (12) onto the Weight Shrouds (11)
and Left Frame (1) using Bolts M8X15 (58), Bolt M10X100 (53),
Spring Washers M8 (63), Washers 9X16X1.6 (62), Washers M10 (60),
and Nylon Nut M10 (64).
Repeat this step to complete the right side.
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly
10
