Keys Fitness KF-HC User manual

HALF CAGE
Owner’s Manual
Read all precautions and
instructions in this manual before
using this equipment.
KF-HC
215-00096
09/06 Rev A

2
Important Safety Information 3
Before You Start 4
Assembly 5-9
Parts List 10
Exploded View 11
Warranty Information 12
Table of Contents

3
THANK YOU for making this unit a part of your exercise program.
Keys Fitness assures the very best in value, appearance, durability
and biomechanics.
This manual will guide you through the assembly process. If at any
time you are having trouble with the assembly or use of this product, then
please contact us at our Keys Fitness Helpline. We have trained service techni-
cians on site to take care of you, our valued customer.
KEYS FITNESS SERIES
MODEL: KF-HC
QUESTIONS?
CALL
1-800-683-1236
Monday-Friday
8:30-5:30 Central Time
When calling please have the following product information available:
REGISTRATION CARD
To avoid unnecessary delays in warranty parts and to insure that a permanent
record of your purchase is on file with our company, be sure to send in the war-
ranty registration card or register on-line at www.keysfitness.com within 10 days
of purchase.
Important Safety Information

4
Prior to assembly, remove components from the box and verify that all the listed parts
were supplied.
Before using this unit or starting any exercise program, consult your physician.
This is especially important for persons over the age of 35 and/or persons with pre-
existing health problems. Keys Fitness Products LP assumes no responsibility for
personal injury or property damage sustained by or through the use of this prod-
uct.
It is the owner’s responsibility to ensure that all users of this unit have read the
Owner’s Manual and are familiar with safety information and precautions.
SAFETY INFORMATION WARNING!
SAFETY PRECAUTIONS
• This unit should only be used on a level surface and is intended for indoor use
only. Keys Fitness recommends an equipment mat be placed under the unit to
protect the floor or carpet and for easier cleaning.
• Wear comfortable, good-quality walking or running shoes and appropriate cloth-
ing. Do not use this unit with bare feet, sandals, socks or stockings!
• Always examine your unit before using to ensure all parts are in working order.
• Do not leave children unsupervised near or on the unit.
• Service to your unit should only be performed by an authorized service represen-
tative, unless authorized and/or instructed by a Keys Fitness technician. Failure
to follow these instructions will void the warranty.
Before You Start
NOTE: Hand tighten bolts and nylon nuts until machine is fully
assembled.

Assembly
5

6
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly
STEP 1
Connect Right Front Support (8) to Base Frame (3) using
Bolts (15) and Washers (16). Make sure that the printed
numbers on the Front Supports (8) are facing inward for
proper viewing.
Left and Right Safety Bars (6,7) should be set at desirable
height in order to catch straight bar at lowest position if
needed.

STEP 2
Secure Right Rear Support (1) to Base Frame (3) with
Bolts (10), Washers (11) and Nylon Lock Nuts (12).
Secure Right Rear Support to Right Front Support with
Bolt (15) and Washer (16).
Repeat using Left Rear Support (2), Left Front Support (8)
and Base Frame (3).
7
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

STEP 3
Connect Lower Cross Frame (4) and Upper Cross Frame
(5) to Left and Right Rear Supports from using Bolts (13),
Washers (11) and Nylon Lock Nuts (12). NOTE: TWO PEO-
PLE WILL BE NEEDED TO SAFELY COMPLETE THIS STEP.
8
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

STEP 4
Connect Gun Racks (9) to the outside of both Front
Supports (8) using Bolts (14), Washers (16) and Nylon
Lock Nuts (17).
Connect Weight Holders (20) to Left and Right Rear
Supports (1,2) with Bolts (15) and Washers (16).
9
NOTE: Hand tighten bolts and nylon nuts until machine is fully assembled.
Assembly

Parts List
10
Ref # Part # Description Qty
1 223-00885 RIGHT REAR SUPPORT, KF-HC 1
2 223-00886 LEFT REAR SUPPORT, KF-HC 1
3 223-00887 BASE FRAME, KF-HC 2
4 223-00888 LOWER CROSS FRAME, KF-HC 1
5 223-00889 UPPER CROSS FRAME, KF-HC 1
6 223-00890 RIGHT SAFETY BAR, KF-HC 1
7 223-00891 LEFT SAFETY BAR, KF-HC 1
8 223-00892 LEFT FRONT SUPPORT, KF-HC 1
9 223-00893 GUN RACK, KF-HC 2
10 202-00641 ALLEN BOLT M12X100 4
11 202-00223 WASHER 12 24
12 202-00092 NYLON LOCK NUT M12 12
13 202-00642 ALLEN BOLT M12X75 8
14 202-00643 ALLEN BOLT M10X72 8
15 202-00644 ALLEN BOLT M10X20 16
16 202-00645 WASHER 10 32
17 202-00091 NYLON LOCK NUT M10 8
18 206-00394 PLUG 50.8X76.2 2
19 223-00894 RIGHT FRONT SUPPORT, KF-HC 1
20 223-00895 WEIGHT HOLDER, KF-HC 8
21 206-00016 ROUND PLUG 8
KF-HC Parts List Rev A
