Instruction Manual
RIDE ON BUMPER CAR 360 ROTATION (12V)
Item number: 060-ROT-06V2
This vehicle is packed with the battery disconnected.
Connect the battery before use.
This manual contains important safety, performance
and maintenance information. Read the manual before
allowing your child to ride your new electric ride-on toy.
Keep this manual properly for future reference.
Note: Product appearance and colors may vary from the photo.

Read all Instructions before operating this product
WARNING:
WARNING:
PREVENT FIRE
also ruin the electrical system.
Use of the wrong type of battery or charger could cause a re or explosion resulting in serious injury.
Never modify the electrical system. Alterations could cause a re resulting in serious injury and could
The battery must be handled by adults only. The battery is heavy and contains sulfuric acid(electrolyte).
Dropping the battery could result in serious injury.
Never allow children to charge the battery. Battery charging must be done by adults only.
Never lift or carry the battery by the wires or connector. This can damage the battery and possibly
cause a re resulting in serious injury. Lift and carry the battery by the case only.
Examine the battery, charger and their connectors for excessive wear or damage each time you
charge the battery. If damage or excessive wear is detected, do not use the charger or the battery
until you have replaced the worn or damaged part.
• For your children’s safety, the product should be assembled by adult.
This toy is not intended for children under 18 months.
• Closely adultsupervision is necessary when your child is operating this product.
• Disconnect the battery if not used for a long time.
Do not use this product as a traffic tool.
To reduce the risk of injury, adult supervision is required. Never use in roadways, near motor vehicles,
on or near steep inclines or steps, swimming pools or other bodies of water; always wear shoes, and
never allow more than 1 rider.
Do not use this product on slippery surface.
Always keep hands, hair, and clothing away from moving parts.
Maximum users’ weight for this product is 66 lb/ 30 kg.
Do not change, modify or add any electrical wiring on this product.
Charge the battery at least once a month even not operating the vehicle to maximize the battery life.
Avoid using this product in tight environment to prevent damage to the product or injury to the user.
Do not use this product in the dark. Only operate this product during daytime or well-lit area.
For your chlid's safety, please make sure the seat belt is securely fasten when operating this product.
Personal protective equipment such as helmet is needed when operating this product.
To Protect against electrical shock, do not immerse cord, charger, transformer, battery, or the product
When using electrical product, basic safety precaution should always be followed including the following
in water or other liquid.
Only use charging devices, transformer, and battery provided or recommended by the manufacturer.

WARNING:
WARNING:
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage
or loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
Stop operating this product whenever it stuck under any circumstances.
WARNING: Friction Hazards! Do not operate this product on carpets or rugs, it may cause burn
Motor: 2 x 12V, 380 / 20000rpm
Battery: 12V 4.5 AH
Charger : 12V 500 MA
Speed: 0.7 - 1.3 mph (1.1 - 2.1 km/h)
Suitable Age : 18 - 72 months
Maximum Users’Weight: 66 lb / 30 kg
Dimension : 28.35”x28.35"x16.93" (72x72x43cm)
Battery Charging Time: 8 - 12 hours
First Charging Time:4- 5 hours
Max Charging Time:12 hours
Battery (Temperature Tolerance): 104°F
or operated incorrectly, wait for 10 - 15 seconds to reactivate this product automatically.

10
10. Lighting
1. Vehicle Body
2. Seat Cover
4. Control Stick
3. Seat Belt 8. Charging Port
6. Light Switch
9. Remote Control
7. Speed Switch
5. Power Switch

Unscrew to detach the seat cover.
Connect the battery terminals. (Red terminal connect to Red connector, Black terminal
connect to Black connector).
Attach the seat cover and tighten the screws.
- low speed
= hight speed
Before activating this vehicle
Charging the battery
Note: charge the battery at least once a month even not operating the vehicle to maximize the
battery life.
WARNING! The battery should only be charged by adult. The battery is not replaceable.
Plug the charger to the charging port. (the charger indicator turns red when charging, turns
green after charging completed).
Fully charge the battery for 8 - 12 hours.
Do not charge the battery for more than 20 hours.
Make sure the battery and charger are not damaged. Do not charge if any sign of
wear or damage is found.

Operating this vehicle.
To turn on the vehicle, press the power switch “I”.
To turn o the vehicle, press the power switch “O”.
To select low speed, press “--” speed switch.
To select high speed, press “=” speed switch.
To light on the vehicle, press light symbol switch.
To move the vehicle forward, push both control sticks forward at the same time.
To move the vehicle backward, pull both control sticks backward at the same time.
To left turn the vehicle forward, push the right control stick forward.
To right turn the vehicle forward, push the left control stick forward.
To left turn the vehicle backward, pull the right control stick backward.
To right turn the vehicle backward, pull the left control stick backward.
To left spin the vehicle, pull the left control stick backward and push the right control stick
forward at the same time.
To right spin the vehicle, push the left control stick forward and pull the right control stick
backward at the same time.
To stop the vehicle, release both control sticks and returns them to the center position.
“S” button for speed selection
Low speed: default and 1 solid red light
Middle speed: press once, 2 solid red lights
High speed: press again, 3 solid red lights
Back to low speed: press again
speed
backwad
forward
frequency
low speed
middle speed
hight speed
emergency brake
turn left turn right
Indicator

Using the remote control
The remote control should only be used by adult.
The remote control overrides the manual control from the vehicle.
Frequency Matching
after changing the batteries is required.
To activate this vehicle, match the remote control frequency to the vehicle at the rst time or
• Insert batteries into the remote control.
• Turn on the power of the vehicle, the indicator changes to solid red.
• Press the "M" button for 2 - 4 seconds, the red indicator ash.
If failed to match, remove and replace the batteries from the remote control and repeat the
above steps.
NOTE : The remote control goes into sleep mode after 10 seconds of idle time.
Control the vehicle
For your child's safety, please make sure the seat belt is securely fastened when operating
this vehicle.
To move the vehicle forward, press the up arrow switch.
To move the vehicle backward, press the down arrow switch.
To left turn the vehicle forward, press the up arrow switch followed by the left arrow switch.
To right turn the vehicle forward, press the up arrow switch followed by the right arrow
switch.
To left turn the vehicle backward, press the down arrow switch followed by the left arrow
switch.
To right turn the vehicle backward, press the down arrow switch followed by the right arrow
switch.
To left spin the vehicle, press the left arrow switch.
To right spin the vehicle, press the right arrow switch.
To stop the vehicle, release all switches.
working. Press the "P " switch again to activate the vehicle.
To enable emergency brake, press the "P" switch , all 3 red lights ash and all switches stop
Bluetooth connection
To connect your mobile device to the vehicle, turn on the Bluetooth and select "Kidzone Bumper
Car". Voice message "Connected Note” followed by “Your device is connected successfully” after
pairing. Music can be played from the vehicle speaker according to the user preferences.
To disconnect your mobile device to the vehicle speakers, turn o the Bluetooth.
WARNING
• Closely adult supervision is needed when children are operating the vehicle.
•
•
•
•
•
•
•
•
•
•
•
•
Change Battery
Remove the cover on the back of the controller and insert two AAA (LR03) batteries in correct
polarity.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries.

Model: TX4
FCC ID: 2AJ2H-WYTX4
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1)This device may not cause harmful interference, and
(2)this device must accept any interference received, including interference that may cause
undesired operation.
NOTE: This product has been tested and found to comply with the limits for Class B digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radiofrequency energy and if not installed and used in accordance with the instructions,
may cause harmful interference to radio or television reception, which can be determined by
one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and the receiver.
connected.
- Consult the dealer or an experienced radio/TV technical for help.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
compliance could void the user's authority to operate the equipment.
Caution: Changes or modications not expressly approved by the party responsible for
turning the equipment o and on, the user is encouraged to try to correct the interference by
This product conforms to toy safety standards CPSIA and ASTM-F963.
Importer: ONE BIG OUTLET
Importer Address: 19301 E Walnut dr. N. City of Industry CA91748 United States
Importer Tel.: 800 - 946 - 6151

V2-2021-05-20
