Kidzone JC111B User manual

Ride on SUV w/ DIY License Plate (12V) (Fun Letters)
Item number: 060-ROT-10
*Product appearance and colors may vary from the photo.
ATTENTION
Instruction Manual
This vehicle is packed with the battery disconnected. Connect
the battery before use.
This manual contains important safety, performance and
maintenance information. Read the manual thoroughly before
allowing your child to ride your new electric ride-on toy. Failure
to read the user manual can result in property damage or bodily
injuries. Keep this user manual for future reference.
JC111B

Safety Instruction
When using electrical product, basic safety precaution should always be followed including the following:
Read all Instruction before operating this product
WARNING:
• To Protect against electrical shock, do not immerse cord, charger, transformer,
battery, or the product in water or other liquid.
• Only use charging devices, transformer, and battery provided or recommended by
the manufacturer.
• For your children’s safety, the product should be assembled by adult.
• Close and constant adult supervision is required when your child is operating this
product.
• Disconnect the battery if not used for a long time.
• To reduce the risk of injury, adult supervision is required. Never use in roadways,
near motor vehicles, on or near steep inclines or steps, swimming pools or other
bodies of water; always wear shoes, and never allow more than 1 rider.
• RISK OF FIRE. Do not bypass fuse. Replace only with original size and type.
• Do not use this product on slippery surface. Always drive the vehicle on smooth
surface, and do not drive the vehicle on the tall grass or rugged ground.
• Rider should always wear shoes when riding on this product.
• Always keep hands, hair, clothing, and loose items away from moving parts.
• Maximum users’ weight for this product is 66 lb / 30 kg.
• This product is suitable for children age 37 - 95 months old.
• Do not change, modify or add any electrical wiring on this product.
• Avoid using this product in tight environment to prevent damage to the product
or injury to the user.
• Do not use this product in the dark. Only operate this product during daytime or
well-lit area.
• For your child 's safety, please make sure the seatbelt is securely fastened when
operating this product.
• Personal protective equipment such as helmet is needed when using this product.
1

PREVENT FIRE
injury and could also ruin the electrical system.
in serious injury.
• The battery must be handled by adults only. The battery is heavy and contains
sulfuric acid(electrolyte). Dropping the battery could result in serious injury.
• Never allow children to charge the battery. Battery charging must be done by adults
only.
• Never lift or carry the battery by the wires or connector. This can damage the battery
case only.
• Examine the battery, charger and their connectors for excessive wear or damage
each time you charge the battery. If damage or excessive wear is detected, do not
use the charger or the battery until you have replaced the worn or damaged part.
Manufacturer and seller expressly disclaim any and all liability for personal injury,
property damage or loss, whether direct, indirect, or incidental, resulting from the
incorrect attachment, improper use, inadequate maintenance, unapproved
Avoid continuously hitting into obstacle to prevent overheating or
damaging the motor. Drive away or remove obstacle as soon as possible.
Do not drive this vehicle into any puddle or contact with
any liquids to avoid the electrical shock to product or user.
CHOKING HAZARD - Small parts. Not for children under
3 years.
This toy is to be assembled by an adult. Contains
llamssniatnocro,stniopprahsdnasegdeprahssuodrazahyllaitnetop
parts before assembly.
2
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:

FAILURE TO FOLLOW THE SAFETY INSTRUCTIONS LISTED BELOW MAY RESULT
IN SERIOUS INJURY OR DEATH.
The owner’s manual contains assembly, use and maintenance instructions.
Child Safety Warnings
• Adults supervising children must read and understand this entire manual before
allowing any child to use this product.
• Adults must evaluate their own children as to maturity, strength, judgment and
ability to follow safety rules. Published age guidelines are not a substitute for
careful evaluation of your own child.
• Adults must teach children about thinking ahead while riding as this may be the
see through the child’s eyes, and verbally teach them about steering and avoiding
obstacles in the approved riding area.
• Riding a motorized ride-on toy can be a dangerous activity, even under the best
of circumstances. Good choices regarding where and when to ride, constant adult
supervision of riding, and practice and careful riding by the child can all help to
minimize risk. However this ride-on toy is intended to move and therefore it is
that no amount of care, instruction or expertise can eliminate.
• If this inherent risk is not acceptable, adults should not allow children to ride this
ride-on toy.
Safe Riding Warnings
• Not to be used by children under 36 months or children over 96 months..
• Do not exceed the maximum weight capacity of 66 lb (30 kg).
• Do not allow more than one (1) rider.
ADULTS AND SUPERVISORS, PLEASE NOTE:
1• Always instruct all children of common sense rules and safe practices.
3• Do not allow the child rider to operate the ride-on toy near streets, roads,
sidewalks, walkways, or any other place where they may encounter other
moving vehicles.
4• Never leave children unattended with this ride-on toy. Continuous adult
supervision is required.
3
WARNING
WARNING

5• If necessary, adults and supervisors are always responsible for setting up gates
and barriers to ensure a safe riding environment for the child rider.
6• Be aware that this ride-on toy does not have braking capabilities. Allowing use
of this ride-on toy in areas that require braking may cause rolls, crashes, serious
injury, or death to the child rider.
7• Teach children not to allow other children to use this ride-on toy. Communicate
this message to other adults and supervisors of fellow children with which your
child interacts.
8• Sternly alert children that hands, legs, hair, and clothing can potentially get
caught in moving parts. Ensure they never place a body part or piece of clothing
near a moving part of the ride-on toy. Avoid loose clothing.
9• Instruct children to always wear shoes when using the ride-on toy.
into contact with any part of the ride-on toy while it is charging.
11• Do not mix old and new batteries.
12. Do not mix alkaline, standard (carbon zinc), or rechargeable batteries.
13. Firmly instruct children to use the ride-on toy in a safe manner. Unsafe
behaviors include, but are not limited to:
• Traveling at unsafe speeds
• Not riding in the seated position
• Riding at night or in any conditions of low visibility
• Riding in any wet conditions including rain, snow, and ice
• Any kind of stunt riding: jumps, ramps, stairs, hills, sloped surfaces, or other
that involve notable risk
actions involving any notable risk
• Riding near any pool or open body of water
• Pushing, pulling, or shoving the driver in any way while operating the ride-on
toy
• Using the ride-on toy without the battery cover or any other safety cover fully
closed
• Pulling or hitching the ride-on toy with other similar moving ride-on toys or
products
4
WARNING

Flammable and Explosive Materials Warnings
• Use of a battery or charger other than the supplied rechargeable battery and
battery and charger with the ride-on toy.
• Using the rechargeable battery and charger for any other product many
and charger with another product.
explosion. Avoid direct contact between the terminals. Lifting the battery
by the wires or charger can cause damage to the battery and may result in a
• Plug wall charger directly into a wall outlet. Do not use an extension cord
Electric Shock / Fire Warnings
liquids away from the battery and keep the battery dry.
or explosion and permanently damage the system. Exposed wiring, circuitry
in the charger may cause electric shock. Always keep the charger housing
closed.
•Battery posts, terminals and related accessories contain lead and lead
compounds (acids) chemicals and are toxic and corrosive. Never open the
Contact or exposure to battery leakage (lead acid) may cause serious injury.
If contact or exposure occurs with the skin or in the eyes, or if the chemical is
swallowed, immediately call 911.
Corrosive Material Warnings
•
The following safety hazards may result in serious injury or death to the user
of the ride-on:
Battery and Charging Warnings
•
• .seirettabelbaegrahcerro,)cniz-nobrac(dradnats,enilaklaximtonoD
Do not mix old and new batteries.
battery.
5
WARNING

• Regularly check charger, supply cord and connector for wear and damage.
Look for frayed or kinked wires, any exposed inner wires, any missing
insulation. If any damage is observed do not plug in the charger and do not
charge the battery.
Product Warning
This product can expose you to chemicals, including Lead, which is known to
the State of California to cause birth defects and or other reproductive harm,
and Di (2-ethylhexyl) phthalate (DEHP), which is known to the State of
California to cause cancer and birth defects or other reproductive harm. For
more information, go to www.P65Warnings.ca.gov.
Assembly Warnings
• The ride-on toy must be assembled by an adult who has read and
understands the instructions in this manual.
Choking hazard to children under the age of 3 years.
This ride-on toy contains small parts that are for adult assembly only. Keep
small children away when assembling.
• Remove and dispose of all protective materials, plastic bags and packaging
before assembly.
•
•
•
Re-Charge Interval and Time
Important!
Damage to the battery may occur if it is allowed to drain completely. Do not
allow the battery to drain completely.
Check the battery and charger (supply cord, connector) for wear and damage
before charging. Do not charge the battery if damage has occurred. Do not
use an extension cord when charging the ride-on toy.
On average you will need to charge the battery for 8-12 hours and no more
than 20 hours. Failure to charge the battery as directed could cause
permanent damage to the battery and void the warranty.
Only an adult who has read and understands the safety warnings should
handle, charge and recharge the battery.
•
•
•
6
WARNING
WARNING
CAUTION
WARNING:

Model No.: 060-ROT-10
Battery: 12V 4.5AH x 1
Charger input: 100 - 240V AC
Charger output: 12V 500mA
Speed: 1.86 - 3.1 mph (3 - 5 km/h)
Suitable Age: 37 - 95 months
Maximum User Weight: 66 lb / 30 kg
Dimension: 39.4” x 25.6” x 28.4” (100 x 65 x 72 cm)
Battery Charge Time: 8 - 12 hours
Operation Time: 40-60 Minutes
7

Parts and Feature
A. Car Body
1x
E. Small Wheel Cover
4x
H. Rearview Mirror
2x
L. Search Light
1x
B. Windshield
1x
I. Door
2x
M. Front Spring
2x
C. Steering Wheel
1x
F. Rear Spring Holder
2x
J. Motor
2x
N. Rear Axle
1x
D. Wheel
4x
G. Rearview Mirror Holder
2x
K. Search Light Holder
2x
O. Front Axle
x
8

Parts and Feature
P. Seat
1x
T. Remote Control
1x
Q. Spanner
2x
Q. Spanner
2x
U. Charger
1x
Y. MP3 Cable
1x
R. M4 x 14 Screw
14x
V. Flat Iron
1x
W. Big Washer
Tool Required:
2x
(For front axle inner side) ( 2pcs pre-installed on the front axle)
X. Small Washer
7x
S. Nut
( 2pcs pre-installed
on the front axle)
7x
9
Screwdriver
(Not included)

Assembly Instruction (The following diagrams for reference only, the photos may vary from
• Assemble the Flat Iron (V ) to the Front Axle(Q) .
• Insert Front Spring (M) on the square tube, then insert the Front Axle (Q) assemblyto the hole on the side
of the square tube.
• Assemble the tie rod of the Front Axle to the Steering rod and tighten with Small Washer (X) and Nut (S).
• Then secure the front axle assembly on the square tube with Small Washer(X) and Nut(S) ( the small
washers and nuts were pre-installed on the front axle).
( V ) Flat Iron
(Q)Front Axle
(M)Front Spring (X) Small Washer
(S) Nut
(X) Small Washer
(S) Nut
Attach the Flat Iron
as arrow. then turn
the whole front axle
assembly upside down
10
actual product.)

Assembly Instruction
• Insert a Big Washer (W) to a side of the Front Axle, follow by the Wheel (D), then secure a Small washer (X)
and Nut (S) by the spanner. Cover the nut with a Small Wheel Cover (E)
• Repeat the same st .
• Insert 2 Rear Spring Holders ( F) to the car body, and secure using M4 x 14 screws (R).
(W) Big Washer
(D) Wheel
(X) Small Washer
(S) Nut
(E) Small Wheel Cover
Tool required:
Front wheel assembly:
Parts and Feature
P. Seat
1x
T. Remote Control
1x
Q. Spanner
2x
U. Charger
1x
R. M4 x 14 Screw
14x
W. Big Washer
2x
(For front axle inner side)
X. Small Washer
5x
11
(R) M4 x 14 Screw
(F) Rear Spring Holder
ep on the other side

Assembly Instruction
• Insert Rear Axle (N) through the opening hole of the Rear Spring Holders.
• Insert Motors (J) to each end of the rear axle. (the motor mark with “L” or “R”, pls. match to
corresponding marking (L/R) on the chassis as above diagram for assemble)
• Assemble Wheel (D) to the rear axle and secure with a Small Washer (X) and Nut (S). Then cover with
Small Wheel Cover (E).
• Repeat the same step for the another wheel.
(J) Motor
(N) Rear Axle
(D) Wheel
(X) Small Washer
(S) Nut
Tool required:
(E) Small Wheel Cover
Parts and Feature
P. Seat
1x
T. Remote Control
1x
Q. Spanner
2x
U. Charger
1x
W. Big Washer
2x
(For front axle inner side)
L
L
R
R
R
R
R
12

Assembly Instruction
• Insert the Door (I) into the side of the car body.
• Assemble a Rearview Mirror Holder (G) on the door and car body using M4 x 14 Screws (R).
• Repeat the same step on the other side.
(1) Unscrew the screw and nut from the Steering Wheel (C).
(2) Insert the steering wheel to the steering column and secure with the screw and nut.
(I) Door
(G) Rearview Mirror Holder
(C) Steering Wheel
(R) M4 x 14 Screw
(1) (2)
13

Assembly Instruction
•
•
Insert Windshield (B), Rearview Mirrors (H), Search Light Holder (K), and Search Light (L) to the car body in
their corresponding position.
The search light holder marked with L / R , please ensure them assemble in correspoinding position
( L to Left side, R to Right side).
• Connect the electric wires of the motors.
• Connect the red battery wire to the red terminal.
(H) Rearview Mirror (L) Search Light(K) Search Light Holder(B) Windshield
14
R
L

Assembly Instruction
sAlign and assemble the Seat (P) to the car body and secure using 2 M4 x 14 screws (R).
(P) Seat
(R) M4 x 14 Screw
15

User Instruction (Control Panel)
Charging Port
MP3 Port
Horn Button
Voltage Display
High/low speed
Bluetooth / USB / MP3
Increase Volume/ Next track Button
Decrease Volume / Previous Track Button
Reverse Button
Forward Button
Power / Lamp button
USB Port
Play / Pause
Control the vehicle
A. Power / Lamp Button
Press and hold the button 2-3 seconds to turn ON or OFF the vehicle; Quick press
Press the button to play or pause the music.
B.High /Low Speed Button
Press the button to move the vehicle in high or low speed.
C.Horn Button
Press the horn button to make a beeping sound.
D.Play / Pause Button
E. Charging Port
Connect the charger to the charging port to recharge the battery
F. Decrease Volume / Previous Track Button
Press and hold the button to decrease volume; Press once to play the previous track.
G.Forward / Reverse Button
Press the switch to control the vehicle to move forward / reverse.
Do not switch between forward and reverse until the vehicle comes to a complete stop.
H. Increase Volume / Next track Button
Press and hold the button to increase volume; Press once to play the next track.
I.Voltage Display
J. Mode Button
K. USB Port
Display the voltage of the battery.
Press to switch between bluetooth / USB / MP3.
Connect to USB.
L. MP3 Port
Connect to MP3.
16

User Instruction (Remote Control)
Light Indicator
Speed button Stop button
Foward Button
Reverse Button
Right Button
Left Button
Remote Control Buttons
1. Forward Button
Press to move the vehicle forward.
Do not switch between forward and reverse until the vehicle comes to a complete stop.
2. Reverse Button
Press to move the vehicle backward.
Do not switch between forward and reverse until the vehicle comes to a complete stop.
3. Speed Selection Button
Press to switch between low, middle and high speed.
The light indicator will indicate the speed as this: one light=low speed, two lights = middle speed,
three lights= high speed.
4. Stop Button
Press to stop the vehicle.
5. Right Button
Press to turn the vehicle to the right.
6. Left Button
Press to turn the vehicle to the Left.
7. Light Indicator
Light indicator will indicate the pairing status between the car and the remote control. It also indicate
the speed as this: one light=low speed, two lights = middle speed, three lights= high speed.
17

User Instruction (Remote Control)
Using the remote control
The remove control should only be used by adult or under adult supervision.
ATTENTION:
The remote control will override all control input from the vehicle.
Insert / Changing Battery
1. Open the battery cover on the back of the remote control.
2. Insert 2 x AAA 1.5Vbatteries in the correct polarity.
3. Put the cover back to the remote control.
Do not mix old and new batteries. Do not mix alkaline, standard (carbon-zinc),
or rechargeable batteries.
Pairing the remote control to the vehicle
1.
2. Then turn on the vehicle power.
3. The indicator light should stay on after successful pairing.
The battery should only be changed by an adult.
WARNING:
WARNING:
18

User Instruction (Charging)
The battery should only be charged by an adult.
Charging the battery
1. Locate the charging port on the control panel.
2. Connect the charger to the charging port.
3. Plug the charger into a wall outlet. The battery will start charging.
4. The indicatoron the charger willred during charging, and turn to green after charging completed.
5. BatteryCharge Time: 8 - 12 hours. Do not charge the battery for more than 20 hours.
• The vehicle must be OFF when charging.
• Recharge the battery if the vehicle operates slowly.
•
•
The vehicle has equipped with charging protection. All function of the vehicle will not be operational
when charging.
The chargeable battery is not replaceable.
NOTE:
Damage to the battery may occur if it is completely drained.
Charge the battery at least once a month even if not operating the vehicle to
maximize the battery life.
WARNING:
19
