Proper product installation, in accordance with these instructions, is the responsibility of the installing agent. If you have
any questions concerning these instructions, please call Kimball Customer Care.
Part 3558009, Revision -
Assembly Instructions
Height Adjustable Return
Tools Required
• Box Cutter/Utility Knife
• Cordless Drill w/#2 Phillips head bit drive
• M5 Allen key
• Level
Hardware Required
2 - Single or double sided base cabinets
1 - Storage base assembly
2 - Shroud assemblies
2– Flat mounting plates
2 one side, 4 two side return - Height adjustable leg
16 - #8 X 1 1/4” pan head screws
12 - #8 x 1” pan head screws
23 - #8 x 5/8” pan head screws
8 one side, 16 two side return - M6 x 25mm Machine screws
16 - #10 x 1 1/4” flat head screws
M4 x 15 Connecting bolts for ganging
M4 Connecting sleeve for ganging
Installation
1. Using a knife open boxes removing all components careful-
ly and place aside. See components in Figure A and hard-
ware required.
2. Carefully place the left and right cabinets on their top so
that the bottom is facing up. Align and square the end pan-
els so everything is flush, using the provided ganging hard-
ware secure and fasten the two cabinets together. See Fig-
ure B.
3. With the cabinets still on their top, place the two flat
mounting plates in the machined area of the bottom panel
and secure the flat mounting plates to the bottom of each
cabinet through the holes marked with #8 x 1” pan head
screws. See Figure C.
4. Attach the base assembly by aligning the (4) outer holes in
the metal feet with the predrilled holes in the bottom panel.
Using the #10 x 1 1/4” flat head screws, drive them in to
the bottom panel. See Figure D for hole locations. With
the outer 4 screws secure, drive and secure the remaining
(12) #10 x 1 1/4” flat head screws through the remaining
holes in the metal feet and in to the bottom panel.
5. With all #10 x 1 1/4” screws secure, insert and secure the
rest of the frame to the bottom of the cabinets with the #8 x
5/8” pan head screws provided. See Figure E.
Figure A
Figure C
Figure B

EVERYSPACE™
2
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent. If you have
any questions concerning these instructions, please call Kimball Customer Care.
Part 3558009, Revision -
Assembly Instructions
Figure D
Installation
6. Stand the base units on the newly installed base in the final
location and level the assembly. With the base unit leveled
you can now place the display unit on top (recommend a
minimum of two people, display units are heavy) align
the end panels front/back, left/right to the base assembly.
Using the #8 x 1/14” pan head screws, secure the display
unit through the pre-bored holes in the top panel of the base
units. See Figure F.
7. Installing the shrouds for the height adjustable legs. Sepa-
rate shroud components into lower shroud, middle shroud
and inner shroud. See Figure G. Install lower shroud com-
ponent first by sliding it into position and securing it
through the mounting flanges with #8 x 5/8” pan head
screws (4 screws through the bottom flanges into the
bottom and 3 screws through the rear top flange into
the top)
8. Next, slide the middle shroud into position with the mount-
ing flanges against the bottom of the base cabinets top pan-
el and secure with (4) #8 x 5/8” pan head screws. See Fig-
ure G.
9. With lower and middle shroud now secure, lower the inner
shroud into position making sure the front fixed cover is
facing the rear of the doors. See Figure G.
Figure E
Figure F
Drive #8 x 1/4” screws into the bottom panel
of the display unit above from the interior of
the base units.

EVERYSPACE™
3
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent. If you have
any questions concerning these instructions, please call Kimball Customer Care.
Part 3558009, Revision -
Assembly Instructions
Lower shroud
Middle shroud
Inner shroud
Lower shroud
Figure G
Middle shroud
Inner shroud
Shown with doors for clarity
Shrouds installed, doors removed. Shrouds installed, doors installed.

EVERYSPACE™
4
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent. If you have
any questions concerning these instructions, please call Kimball Customer Care.
Part 3558009, Revision -
Assembly Instructions
10. Insert the height adjustable leg into the open area of the
shroud assembly and let it rest on the flat mounting plate at
the bottom. Align the (4) mounting holes in the bottom of
the leg to the (4) holes in the flat plate. Insert and secure
leg to plate with (4) M6 x 25 machine screws. See Figure
H. Repeat process for the remaining legs.
11. Locate the undersurface support rail assemblies, height
adjustable leg assembly with foot and cantilever bracket.
See Figure J.
12. Attach the main surface support rail to the adjustable leg
assembly with foot using (4) M6 X 20mm machine screws
then attach the other rail plate to the adjustable leg mounted
on the base cabinet. See Figure K.
13. Attach the return surface support rail assembly to the re-
maining adjustable leg mounted on the base cabinet. See
Figure L. On the bottom side of the rail assemblies where
the return rail and main surface rail meet, attach the two
with the cantilever bracket using the provided sheet metal
screws. See Detail L-1, sheet 5.
Figure H
Cover removed for clarity
Figure J
Return support rail assembly
Cantilever bracket
Adjustable height leg with foot
Main surface support rail assembly

EVERYSPACE™
5
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent. If you have
any questions concerning these instructions, please call Kimball Customer Care.
Part 3558009, Revision -
Assembly Instructions
Figure K
Figure L
Detail L-1

EVERYSPACE™
6
Proper product installation, in accordance with these instructions, is the responsibility of the installing agent. If you have
any questions concerning these instructions, please call Kimball Customer Care.
Part 3558009, Revision -
Assembly Instructions
14. Unbox the main and return surfaces. Position the surfaces
in their final location on top of the support rails below, take
care and maintain a 1” distance from any back or end
panel to eliminate any pinch points when installed. See
Figure M. Using the #10 x 1” pan head screws, insert
through the clearance holes in the 1” mounting plates of the
rail assemblies the surfaces are resting on. With the #10 x
1” screws secured, insert and secure the #8 x 3/4” pan head
screws into the mounting holes of the rectangular tubes of
the support rail assemblies. With surfaces secure, slide the
inner shroud up and secure to the bottom of the surfaces.
(make sure the inner shroud stays perfectly vertical and
maintains ability to rise and lower with the surfaces
without binding) Secure the inner shroud with #8 x 5/8”
pan head screws. Installation is now complete.
Main Surface
Return Surface
Figure M
#10 x 1” screws
Inside dashed border
#8 x 3/4” screws
Detail M-1
