Kimball Fluent User manual

Assembly Instructions
Fluent
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Pa t No. 2205353 Revision A-09
Page 1 of 2
Drawer Removal, Adjustment,
and Unit Leveling
Tools Required
Installation
1. For Desk, Credenza, Return, Bridge, Lateral File & Drawer
or Door Storage: Remove all drawers as required to access
leveling glide adjustment holes.
2. o remove drawers: Extend the box or file drawer to its
full extension. Locate the drawer slide release tab, in the
approximate location shown, on each side of the drawer
box. Press both tabs in and pull drawer straight out until
slide drawer members disengage from cabinet members.
(Figure A).
3. o remove lateral file drawers, extend the drawer forward.
Press the two quick-disconnect release tabs and lift the
drawer off the slide assembly. (Figure B).
Note: Shipping screws must be removed from drawer
suspensions before drawer can be removed.
4. urn the leveling glides fully “in” (counterclockwise) prior
to leveling. Level the unit from front to back by first
extending the glides on the outside corners (turn clockwise),
then level the unit from side to side. Check adjustments by
placing the level at the four positions shown. Adjust inside
glides, if applicable, to help support the unit. (Figure C).
5. Replace all drawers to their original locations. o re-install,
fully extend cabinet slide members, making sure the chrome
ball-bearing members are also forward. Carefully align
drawer slide members with cabinet slide members and
gently push drawer closed. Check for proper alignment by
inspecting drawer front margins for spacing and squareness.
Figure A
Figure B
Release
abs
Figure C
Leveling
Glides
7⁄32"
Nut
Driver
Level; Check
at four locations
Release
abs
ape Measure 7⁄32" Nutdriver
Level
Phillips Screwdriver
1⁄4" Allen Wrench
1⁄4" Allen Wrench

Assembly Instructions
Fluent
Proper product installation, in accordance with these instructions, is the responsibilit of the installing agent.
If ou have an questions concerning these instructions, please call Kimball Office Customer Service.
Pa t No. 2205353 Revision A-09
Page 2 of 2
Installation (continued)
6. If drawer front needs adjustment, open drawer and locate
the four (4) Deerwood screws that attach the drawer front
to the drawer box. (Figure D).
Note: Lateral file drawer fronts use six (6) screws.
7. For Bookcase and Cabinet Storage: he lower shelf has
holes which access the leveling glides. urn the glides fully
“in” (counterclockwise) prior to leveling. Level the unit
from front to back by extending the glides (turn clockwise).
Level the unit from side to side. Check adjustments by plac-
ing the level in the four positions shown. (Figure E).
Figure D
Figure E
P inted in U.S.A. © 2009 Kimball Inte national, Inc. T 800.482.1818 F 812.482.8300
Deerwood Screws (4)
Level; check
four positions
Leveling glide
adjustment hole
7⁄32"
Nut
Driver
