Kimball Grin Occasional User manual

Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
Assembly Instrucon
Kimball International, Inc.
1600 Royal Street
Jasper, IN 47546
800.482.1616
kimballinternational.com
Part # 3521021
Package Contents
Grin Occasional and
Grin Worksurface
Height Tables
Component…………………..………….Qty
Apron Rails 4
Corner Brackets 4
Machine Screw M8x110 8
Flake Board Screw 10X1 8-28
Leg Pin 4
Leg 4
Tools Required
Allen Wrench
Drill
Screw driver
Level
1
Note: These instrucons explain basic installaon of
rail kits and legs to worksurfaces. For safety purpos-
es, it is recommended that more than one person be
used to move worksurfaces and/or assembled tables.
Unpack the worksurface and place it face down on a
smooth, hard surface. Take care not to damage the
worksurface.
2Prep legs for assembly to the rail:
Insert leg pin (Figure A) into top of the leg *If needed, lightly tap in* Use at
head screw driver to turn the pin into the correct posion. (Figure B) Insert
glide (Figure C) into boom of the leg. (Figure D) *If this is a mobile table,
Casters will be used in place of glide.*
Figure A Figure B
Figure C Figure D

Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
Assembly Instrucon
Telephone [phone]
Fax [phone]
www.NationalOfficeFurniture.com
Part # 3521021
Package Contents
Grin Occasional and
Grin Worksurface
Height Tables
3Assembling Rails, Legs and Corner Brackets:
1. Mock up the rails into their posions. (Figure E)
2. Take two of the rails and aach together with a corner bracket. (Figure F)
3. Place the leg upside down in the corner and hold together by placing your
hand around the leg and ngers on the corner bracket pressing together.
(Figure G)
4. Place the socket head machine screws through the corner bracket into the
leg, use an 7/32 Allen wrench to ghten. (Figure H)
5. Repeat process unl all rails & legs are assembled together. (Figure I)
Figure F
Figure E
Figure G
Figure H
Socket Head Machine Screw Locaons
Figure I
Component…………………..………….Qty
Apron Rails 4
Corner Brackets 4
Machine Screw M8x110 8
Flake Board Screw 10X1 8-28
Leg Pin 4
Leg 4
Tools Required
Allen Wrench
Drill
Screw driver
Level
Corner Bracket

Proper product installation, in accordance with these instructions, is the responsibility of the installing agent.
Assembly Instrucon
Telephone [phone]
Fax [phone]
www.NationalOfficeFurniture.com
Part # 3521021
Package Contents
Grin Occasional and
Grin Worksurface
Height Tables
4Final Assembly:
1. Place worksurface upside down, on a study at surface. (Figure J)
2. Place Rail & Leg assembly upside down on worksurface. (Figure K)
3. Line up the mounng holes on the rails, with the pilot holes on the worksurface.
(Figure L)
4. Use 10x1 Flake Board Screws to secure the frame assembly to the worksurface.
5. Flip table and move to nal locaon, use a level for reference and adjust glides to
level the table. (Figure M) *Note: Leveling not need for Mobile Tables*
Figure KFigure J
Figure L Finished Product
Lining up the mounng holes
of the rails, with the pilot
holes in the worksurface.
Using 10x1 Flake Board
Screws to secure.
Figure M
Component…………………..………….Qty
Apron Rails 4
Corner Brackets 4
Machine Screw M8x110 8
Flake Board Screw 10X1 8-28
Leg Pin 4
Leg 4
Tools Required
Allen Wrench
Drill
Screw driver
Level
