Kingsley-Bate
SC25 Serving Cart
Assembly Instructions

KINGSLEY – BATE
Fine Garden Furniture
ASSEMBLY INSTRUCTIONS FOR THE TROLLY
LIFT OUT TRAY DRAWERS TOP FRAME BOTTOM FRAME
DRAWER FRAME END FRAME WITH WING END FRAME W/O WING
* NOTE
A TENON
B MORTISE HOLE
STEP-I
Unpack, inspect and lay the parts on a clean, flat, soft surface to avoid marring the wood.
NOTE: During assembly of the furniture please match all joints with the corresponding
letter or numbers stamped on the furniture.
STEP-II
Find the END FRAME W/O WING (should be the
one with num bers stamped on it). Lay this END
FRAME down first. Matching the num bers on the
END FRAME wit h those on the TOP FRAME,
BOTTOM FRAME, HANDLE BARS and
DRAWER FRAME, carefully line up all parts. Using a rubber mallet, evenly drive all the
tenons into the mortise holes as shown in the assembly photos.

STEP-III
Carefully place & align th e END FRAME WI TH WING onto the assembl ed TOP
FRAME, BOTTOM FRAME, HANDLE BARS, BOTTLE RACK and DRAWER
FRAME. Drive the wooden dowels as shown on diagram.
*NOTE: Drive the wooden dowels into their corresponding
holes before flipping the cart around.
STEP-IV
Gently flip the TROLLY ov er so that it is upside
down and attach the SMALL WHEELS onto the
bottom holes as shown in the assem bly photo.
Slide the washer into the bolt, put into the pivot
wheel house, then the long pivot and t hen after a
small washer. Secure it with allen wrench.
STEP-V
To attach the wheels take one washer and sli de it onto one
of the bolts, next slide one of the wheels onto t he bolt and
then add another washer. Repeat this step with the other
bolt. Slide one wheel through either END FRAME so that
the wheels are on the out si de of the END FRAME and
secure with the nut.
STEP-VI
Slide the drawers into it place as shown on
diagram.
IF YOU HAVE ANY QUESTIONS REGA RDING THE ASSEMBLY OF YOUR
KINGSLEY-BATE FURNITURE, PLEASE CONTACT THE KINGSLEY-BATE
DEALER NEAREST TO YOU OR KINGSLEY-BATE DIRECTLY. WE THANK YOU
FOR CHOOSING OUR FURNITURE.
* KINGSLEY-BATE WILL NOT TAKE RESPONSIBILITY FOR DAMAGE
0 IF THESE INSTRUCTIONS ARE NOT FOLLOWED PROPERLY
