Kusam-meco KM 36 User manual

®
NETWORK
CABLE TESTER
MODEL - KM 36
OPERATION
MANUAL
G 17,Bharat Industrial Estate, T. J. Road,
Sewree (W), Mumbai - 400 015. INDIA.
Sales Direct : [phone]
Tel. : [phone]. Fax : [phone]
Email : [email protected]
Website : www.kusamelectrical.com
www.kusam-meco.co.in
®

01
This series cable tester are specified to
quickly test by auto scanning the wires
continuity, miswiring and polarization of
Ethernet (BNC/TNC). 10-Base-T (UTP/STP),
AT & T 258A, TIA 568A/B, Token Ring, and
modular cable. By using the attached remote
terminator, you can easily test the cable
whatever before or after the cables installed.
Easy access and quickly check up.
NETWORK CABLE TESTER
USER'S MANUAL
1. Open the Power, indicate LCD will be Light.
2. Test Unshield TP : If all cables are all right, green
indicator LED will flash from 1&2 to 7&8 in order.
if red LED is lighting or all LED are not lighting, or
in wrong order, the cables must be wrong.
3. Test shield UTP : If all cables are all right, the green
indicator LED will flash from 1&2 to SHIELD+BNC
If red LED is lighting, or is wrong order, the cables
must be wrong.
4. Test coaxial cable : If all cables are all right,
SHIELD + BNC, will light green, or will not light.
OPERATION :
2 In 1 Multiple Network Test Instrument
INTRODUCTION
PIN NO.
KM-36
1&2
3&6
4&5
7&8
SHIELD
BNC
OPEN
SHORT
GOOD
REVERSAL
KM-36
NETWORK CABLE TESTER
ON
POWER
OFF
C
Pr2
Pr4
Pr3
Pr2
Pr2Pr1 Pr1
Pr2 Pr2
Pr1 Pr1
E t h e r n e t
1 0 B o s e - T
8 - P o s i t i o n
To k e n R i n g
E I A / T I A - 5 6 8 A E I A / T I A - 5 6 8 B
AT & T 2 5 8 A
12345678 12345678
1 2 3 4 5 6 7 81 2 3 4 5 6 7 8
NETWORK
CABLE TESTER
MODEL - KM 36

02 03
Attention : The power supply is 9V DC
The occlusive place of main Unit
and remote unit has a secret lock
opening, press the edge and
push.
When
5. If any pair cables is not connected well, the
corresponding LEDs will not light. If
connecting reversibly, the red LED will light.
Pr2
Pr4
Pr3
Pr2
Pr2Pr1 Pr1
Pr2 Pr2
Pr1 Pr1
E t h e r n e t
1 0 B o s e - T
8 - P o s i t i o n
To k e n R i n g
E I A / T I A - 5 6 8 A E I A / T I A - 5 6 8 B
AT & T 2 5 8 A
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
MUMBAI
TEST CERTIFICATE
NETWORK CABLE TESTER
This Test Certificate warrantees that the product
has been inspected and tested in accordance with
the published specifications.
The instrument has been calibrated by using
equipment which has already been calibrated to
standards traceable to national standards.
MODEL NO. __________
KM 36
SERIAL NO. ___________
DATE: ___________
ISO 9001
REGISTERED
QC
PASS
KUSAM-MECO

04 05
WARRANTY
Each “KUSAM-MECO” product is
warranted to be free from defects in
material and workmanship under normal
use & service. The warranty period is one
year (12 months) and begins from the date
of despatch of goods. In case any defect
occurs in functioning of the instrument,
under proper use, within the warranty
period, the same will be rectified by us free
of charges, provided the to and fro freight
charges are borne by you.
This warranty extends only to the original
buyer or end-user customer of a “KUSAM-
MECO” authorized dealer.
This warranty does not apply for damaged
Ic’s, fuses, burnt PCB's, disposable
batteries, carrying case, test leads, or to
any product which in “KUSAM-MECO’s”
opinion, has been misused, altered,
neglected, contaminated or damaged by
accident or abnormal conditions of
operation or handling.
“KUSAM-MECO” authorized dealer shall
extend this warranty on new and unused
products to end-user customers only but
have no authority to extend a greater or
different warranty on behalf of “KUSAM-
MECO”.
“KUSAM-MECO’s” warranty obligation is
limited, at option, free of charge repair, or
replacement of a defective product which is
returned to a “KUSAM-MECO” authorized
service center within the warranty period.
THIS WARRANTY IS BUYER’S SOLE AND
EXCLUSIVE REMEDY AND IS IN LIEU OF
ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING BUT NOT
LIMITED TO ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS
FOR A PARTICU L A R PUR P OSE.
“KUSAM-MECO” SHALL NOT BE LIABLE
F O R A N Y S P E C I A L , I N D I R E C T,
INCIDENTAL OR CONSEQUENTIAL
DAMAGES OR LOSSES, INCLUDING
LOSS OF DATA, ARISING FROM ANY
CAUSE WHATSOEVER.
All transaction are subject to Mumbai
Jurisdiction.
