Kverneland Exacta-TL-GEOSPREAD GS3 User manual

Exacta-TL-GEOSPREAD
GS3
Operator’s Manual
Item 06-2021
Print date 06.2021
Language EN
From software version V xxx
From machine number 1001
Serial number From VN401
Reference number A148815640
WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov

Exacta-TL-GEOSPREAD GS3
Machine identification
In order to provide you with good service various details about your machine may sometimes be required.
Please complete these details here in order to have them at hand when they are requested.
Type of machine
Serial number
Options
Address
dealer
Address
manufacturer
Kverneland Group Nieuw-Vennep B.V holds all copyrights and rights of use. The contents of this user manual can be modified without prior
notification. All rights reserved. The right to technical revision is reserved.
Kverneland Group Nieuw-Vennep B.V.
Hoofdweg 1278
NL-2153 LR Nieuw-Vennep
The Netherlands

Table of contents
3
Table of contents
Preface ....................................................... 4
Target group of this manual 4
Meaning of symbols 5
Safety ......................................................... 7
For your safety 7
Other guidelines 7
Safety labels 8
Safety requirements 10
Getting familiar with the machine ........... 23
Applications of the machine 23
CentreFlow spreading system 23
Adjust carefully 24
Spreading pattern 28
The ISO control system 30
Technical specifications 36
Technical specifications 37
Before first use ......................................... 38
Inspection of the supplied machine 38
Mounting instructions 38
Tractor provisions 50
Mounting the coupling shaft 51
Connecting to the tractor ......................... 53
Selecting linkage pin height 54
Connecting the machine 55
To be done before spreading .................. 59
Find the correct settings of the spreader
and set it accordingly 59
Setting the spreader 64
Working width 66
Inclination 67
PTO shaft rpm 67
Application rate 68
Filling 75
Spreading pattern check (tray test) 78
Driving on the road ................................... 97
Before taking to the road 97
Preparing the machine to be transported 98
Use in the field .......................................... 99
Adjusting the machine 100
Spreading on field 102
Start spreading 105
Border spreading 111
Stopping work 118
Failure and stoppage 119
Rangement de la machine ....................... 123
Storing the machine ................................. 124
Cleaning 124
Disconnecting the machine 125
Maintenance .............................................. 128
Oil and grease content 130
Maintenance intervals 131
Lubricating points 132
Applying or adding grease 133
Apply oil 134
Torques in ft.lb 135
Stainless steel tightening torques ft.lb 137
Stainless steel tightening torques (Nm) 138
Checking the hydraulic system 139
Checking and setting the dosing
mechanism 141
Checking and setting the discharge point
setting mechanism 144
Checking and setting the discharge bush
height 146
Replacing agitator axle seal 148
Accessories ............................................... 150
Troubleshooting ........................................ 160
Troubleshooting table 160
Falling into disuse ..................................... 163
Liability ....................................................... 164
Liability 164
Complaints 165
Warranty 165
Notes .......................................................... 166
Index ........................................................... 167

Preface
4
Preface
Target group of this
manual
This manual is in6tended for agrarians and others trained in working
in the field of agriculture, people that are competent to operate these
machine, as required by national legislation, and who have knowledge
of assembly activities and familiarity with assembling equipment.
For your safety
Ensure that you are familiar with the contents of this manual before
you start using or assembling the implement. This will ensure that you
obtain an optimum result and are working safely.
See paragraph »Safety requirements« on page 10.
Should you have any questions or if anything is unclear, please
contact the manufacturer.
Make sure that this manual is available to all persons who will be
working with this machine. In this way, you will:
•avoid accidents,
•respect the warranty conditions,
•always have a good functioning machine in good working order.
For the employer
•All personnel who operate this machine must be authorized to do
so in terms of the knowledge and experience.
•All personnel are to be trained in the use of the machine regularly
(at least once a year). Untrained or unauthorized individuals are
not permitted to use the machinery.
•You are responsible for the safe operation and maintenance of
your machine. You must ensure that you and anyone else who is
going to operate, maintain or work around the unit be familiar with
the operating and maintenance procedures and related safety
information as mentioned in this manual.
•You are responsible for providing personal protective gear to
personnel who use the machine or who are performing mainte-
nance or repairs on it as appropriate. This includes: safety goggles,
safety shoes, safety gloves, etc.

Preface
5
Meaning of symbols
Various symbols are used to provide a clear understanding of the text.
These are explained below.
•A dot is placed before lists.
A triangle marks tasks you have to perform.
An arrow refers to a different place in the text.
In addition, we use pictograms to help you to easily find
certain text sections.
I NDICATION The words “Tip“ and “Hint” are followed by tips or hints for operation.
The spanner indicates tips for assembly or adjustment work.
A star indicates that examples will follow that are intended to clarify the
text.
All directional rotations are to be interpreted when facing in direction
of travel.
California Proposition 65
\ WARNING
Engine exhaust, some of its constituents, certain machine
components and fluids, contain or emit chemicals known to the
State of California to cause cancer and birth defects or other
reproductive harm
\ SAFETY FIRST
This symbol, the industry's "Safety Alert Symbol", is used
throughout this manual and on labels on the machine itself to warn
of the possibility of personal injury. Read these instructions
carefully. It is essential that you read the instructions and safety
regulations before you attempt to assemble or use this unit.
\ DANGER
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
\ WARNING
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
\ CAUTION
Indicates a potentially hazardous situation which, if not avoided,
could result in minor or moderate injury.

Preface
6

Safety
7
Safety
For your safety
In this chapter you will find general safety instructions. In every next
chapter you will find more specific safety instructions not described
here.
Do not risk injury or death by ignoring good safety instructions.
Many risks can happen when working with agricultural machines.
Avoid accidents! Do not take risks! Be alert!
Think safety! Work in safety!
Disregard of the 'Safety instructions', inadequate maintenance, use of
the machine other than for its intended purpose, overloading or
unauthorized modification of the machine, renders the manufacturer's
warranty and responsibility void.
Familiarize yourself with the function of all machine controls and the
safety instructions, prior to any usage of the machine.
Incorrect use of the machine may lead to dangerous situations. For
this reason, you should always work carefully and never under time
pressure.
Other guidelines
Comply with the rules
In addition to the instructions above you should comply with the
following.
•measures to prevent accidents.
•general safety instructions, occupational health requirements and
road traffic regulations.
•instructions in this manual,
•Rules regarding use, maintenance and repairs.
\

Safety
8
Safety labels
Various safety labels have been affixed to the machine for safety rea-
sons. Do not remove them! Always follow the instructions supplied
and be alert to possible dangers.
Always keep the safety labels clean and clearly legible. Replace
safety decals that are missing, damaged or have become illegible. If
original parts on which a safety label was installed are replaced, be
sure that the replacement part also displays the current safety label.

SHIELD MISSING
DO NOT OPERATE
Vf16661512
READ THE MANUAL
The machine must not be
used before reading the
operating manual.
To avoid fatal or serious injury:
Read the manual first.
DANGER
CAUTION
WARNING
Vf16661498
AREA OF RISK
Risk of death or injury on
coupling, uncoupling or
operating.
To avoid death or serious
injury:
Keep out of this area.
WARNING
Vf16661500
INADVERTENT OPERATION
Risk of death or injury by
inadvertent operation.
To avoid death or serious
injury:
Switch off the engine.
A100017974
VERTICAL MOVEMENT
Lifting point with hook tool
Machine handling by:
- Competent personnel
- Suitable device
To avoid death or serious
injury:
WARNING
WARNING
Vf16661496
RISK OF CRUSHING
Never reach into an area
where parts are still likely to
move.
To avoid fatal or serious injury:
Keep your hands out.
WARNING
Vf16661510
UNEXPECTED MOVEMENT
Machine parts may still rotate
after engine is switched off.
To avoid fatal or serious injury:
Keep away until parts stop
moving.
WARNING
Vertical movement
Risk of injury by lifting or
lowering machine parts.
To avoid death or serious
injury:
Keep out of this area.
WARNING
Vf16661496
RISK OF CRUSHING
Never reach into an area
where parts are still likely to
move.
To avoid fatal or serious injury:
Keep your hands out.
DANGER
Vf16661493
PARTS EJECTED AT SPEED
Parts may become detached and
ejected at speed.
To avoid death or serious injury:
Keep in a safe distance.
DANGER
Vf16661493
PARTS EJECTED AT SPEED
Parts may become detached and
ejected at speed.
To avoid death or serious injury:
Keep in a safe distance.

ROTATING DRIVELINE
KEEP AWAY!
CONTACT CAN CAUSE DEATH
DO NOT OPERATE WITHOUT-
ALL DRIVELINE, TRACTOR AND
EQUIPMENT SHIELDS IN PLACE.
DRIVELINES SECURELY ATTACHED
AT BOTH ENDS.
DRIVELINE SHIELDS THAT TURN
FREELY ON DRIVELINE.
\

Safety
9
Safety labels

SHIELD MISSING
DO NOT OPERATE

ROTATING DRIVELINE
KEEP AWAY!
CONTACT CAN CAUSE DEATH
DO NOT OPERATE WITHOUT-
ALL DRIVELINE, TRACTOR AND
EQUIPMENT SHIELDS IN PLACE.
DRIVELINES SECURELY ATTACHED
AT BOTH ENDS.
DRIVELINE SHIELDS THAT TURN
FREELY ON DRIVELINE.
WARNING
Vertical movement
Risk of injury by lifting or
lowering machine parts.
To avoid death or serious
injury:
Keep out of this area.
WARNING
Vf16661498
AREA OF RISK
Risk of death or injury on
coupling, uncoupling or
operating.
To avoid death or serious
injury:
Keep out of this area.
WARNING
Vf16661500
INADVERTENT OPERATION
Risk of death or injury by
inadvertent operation.
To avoid death or serious
injury:
Switch off the engine.
WARNING
Vf16661510
UNEXPECTED MOVEMENT
Machine parts may still rotate
after engine is switched off.
To avoid fatal or serious injury:
Keep away until parts stop
moving.
WARNING
Vf16661496
RISK OF CRUSHING
Never reach into an area
where parts are still likely to
move.
To avoid fatal or serious injury:
Keep your hands out.
Vf16661512
READ THE MANUAL
The machine must not be
used before reading the
operating manual.
To avoid fatal or serious injury:
Read the manual first.
DANGER
CAUTION
DANGER
Vf16661493
PARTS EJECTED AT SPEED
Parts may become detached and
ejected at speed.
To avoid death or serious injury:
Keep in a safe distance.
Vf16661492
PARTS EJECTED AT SPEED
Parts may become detached
and ejected at speed.
To avoid death or serious
injury:
Keep in a safe distance.
DANGER
A100017974
VERTICAL MOVEMENT
Lifting point with hook tool
Machine handling by:
- Competent personnel
- Suitable device
To avoid death or serious
injury:
WARNING
\

Safety
10
Safety requirements
This chapter contains all the requirements, everything that is not
permitted and requirements for each form of usage, maintenance and
reparation of the machine.
The chapters in the manual contain additional safety measures.
Knowledge of the safety regulations forms the basis for safety and
proper usage of the machine.
Always follow the safety instructions. Most accidents are avoidable.
Do not run the risk of serious or fatal accidents through ignorance of
these safety instructions.
Intended use
This machine is exclusively intended to spread granular products,
specifically fertilizer types and seeds.
Any other application would be considered to be irregular. The
manufacturer is not responsible for damage that may result from such
usage; risks are taken exclusively by the user.
The instructions, maintenance requirements and reparation
stipulations as indicated by the manufacturer must be adhered to at all
times.
Person
Responsibility of the user
The user may only operate the machine if he/she:
•is familiar with the basic safety requirements and the working
conditions requirements,
•is familiar with current traffic regulations,
•has been duly instructed on how to work on/with the machine and
the related dangers,
•has read and understood this manual,
•is familiar with all the systems and operating elements and their
functions.
•is familiar with the regulations for using, maintaining and repairing
machines.
It will be too late for that once you are working!
Irresponsible usage could lead to injury to the user or third parties and
could lead to damage to the machine.
\

Safety
11
Authorization
Only to be used by an authorized person
The machine may be used by authorized people only. A person is
authorized if he/she:
•received training as required by the national authorities,
•has taken responsibility as described in
paragraph »Person« on page 10.
Maintenance and repairs by experts
Maintenance, replacement of parts and repairs to the machine may
only be performed by experts.
A person is considered to be an expert if he/she has sufficient
knowledge in the fields of safety, maintenance, production and repairs
as a result of training and experience.
Maintenance or repairs performed by a person who is not so qualified
could lead to injury and damage to the machine.
Clothes/protection
Wear close-fitting clothing
Avoid wearing loose fitting clothing. Loose clothing could become
entangled with moving parts, which could lead to serious
consequences.
Ensure personal protection
Ensure your personal protection. Outfit:
•safety goggles,
•safety shoes,
•safety gloves.
Prevent hearing damage
Your hearing could be damaged when working with the tractor and
machine with noise levels in excess of 80 dB. Use the appropriate ear
protection in order to prevent hearing damage. Remaining in an area
with high noise levels for a long period of time could lead to serious
damage to your hearing.
What to do in the event of injury
In the event of injury and if you suspect that you made contact with
materials you should:
•clean the point of contact with a lot of water,
•contact your physician immediately!
\

Safety
12
Workplace
To be used and operated by 1 person
The machine may only be operated by one person, from the tractor.
Operating the machine from the tractor will keep you out of harm's
way. Other people should not be in the direct vicinity of the machine
and the tractor. Those who are within the working area and the danger
zone could be injured.
Check the direct surroundings
Check the immediate environment and keep a constant eye on it at the
start, as well as while you are working with the machine. Familiarize
yourself with the immediate vicinity. Do not start working until all
people and obstacles within the working area and danger zone of the
tractor and machine have been removed.
Never stay or allow anyone to stay within the danger area while the
machine is running! If there are people within the working area and the
danger zone it could lead to injury.
Work with a closed cabin
Fertilizer dust can blow indoors through open windows, doors or other
openings. Moreover, the sound level is higher in an open cabin. It is
therefore recommended to always work with a closed cabin with active
carbon filters in the air inlets. Fertilizer dust and a high sound level can
cause physical damage.
Tractor
Check the state of the tractor and machine
Only work with the tractor and machine if they are in good condition.
Always check that:
•all lighting, safety and warning provisions must be mounted
correctly and be in good working condition,
•the lifting and pulling capabilities must be sufficient,
see paragraph »Calculate the axle load with tractor-mounted
machines« on page 13,
•the tractor must be suitable for the machine, such as in the area of
stability, engine capability, axle load and total weight,
•the visibility is sufficient for the work with the machine and for trans-
port.
Adhere to maximum permissible axle loads, total weights and
transport dimensions! Using a tractor which is not proper can cause
serious or deadly injuries or machine damage.
See the tractor’s technical details.
\

Safety
13
Put a fire extinguisher in place
Carry a fire extinguisher at all times, especially when operating in dry
crop materials. This should be a multipurpose ABC rated extinguisher
with a 11 lb. capacity, approved by the appropriate authority. Mount
this on the tractor and/or on the machine. Fire could damage the
machine and cause injury.
Use active carbon filters
Depending upon use, harmful gasses and mists could enter the air
duct of the tractor while it is in use. An active carbon filter should
therefore be mounted in the air ventilation of the tractor. Harmful
materials could cause serious personal injury. Use appropriate
personal protective gear.
Ensure the tractor is safe when leaving it
Never leave the tractor without:
•placing the tractor and machine on a firm, flat surface,
•switching off the PTO shaft,
•switching off the electronic control system,
•releasing the pressure from the hydraulic system,
•placing all controls in their neutral or park position,
•switching off the tractor engine,
•the key must be removed from the ignition,
•engaging the parking brake of the tractor.
Leaving the tractor unsafe could create dangerous situations that
could lead to injury.
Responding to problems
In the event of operational problems you should:
•stop immediately,
•switch the tractor and machine off,
•attend to the problem or call in the assistance of an expert.
Never use the tractor in a closed area
The tractor must never be used in a closed area. Exhaust fumes
collect without being noticed. Exhaust fumes can cause serious or
deadly injuries.
Calculate the axle load with
tractor-mounted machines
The following is of importance with the loading machine to ensure safe
operation:
•the maximum load of the machine,
•the maximum axle load of the tractor,
•weight distribution over the axles,
•and the carry load per wheel.
At least 20% of the total weight of the tractor must rest on the front axle
and 45% on the rear axle in order to maintain good maneuvrability.
Check if these conditions are adhered to before purchasing a
machine! Adhere to maximum permissible axle loads, total weights
and transport dimensions! Using a tractor which is not proper can
cause serious or deadly injuries or tractor and machine damage.
\

Safety
14
Required details
The following details are necessary in order to calculate the minimum
requirements and actual axle load, as well as the actual and maximum
total weight. The details of the tractor should be given in the tractor
manual. The details of the tires should be supplied by the
manufacturer. The details of the machine are in this manual.
in paragraph »Technical specifications« on page 36.
Letter Description Unit
AThe basic weight of the tractor without the machine (1) lb
BThe weight on the front axle of the tractor without the machine
(1)
lb
CThe weight on the rear axle of the tractor without the machine
(1)
lb
DThe total weight of the forward end hooked machine or
weights
lb
EThe total weight of the rear-end hooked machine or weights lb
fThe distance between the centre of gravity of the
machine and the middle point of the axle
ft
gWheel base of the tractor ft
hThe distance between the centre of the rear axle and the
centre point of attachment of the lifting arm.
ft
iThe distance between the centre of gravity of the machine and
the middle of the point of attachment of the lifting arm (2).
ft
(1) Also include the weight of the accessories and the weight of the water in the tires
(2) If unknown, suppose i = half the machine length
DBC
A
E
i
hgf
\

Safety
15
Calculations
The calculations can be made with the values given in the above-
mentioned chart.
Actual total weight
The actual total weight must not exceed the permitted total weight.
The actual total weight (in lb) is calculated as follows:
Actual front axle load
The actual front axle load must not exceed the permitted maximum
load. The actual total front axle load (in lb) is calculated as follows:
Actual rear axle load
The actual rear axle load must not exceed the permitted maximum
load. The actual total rear axle load (in lb) is calculated as follows:
Ballast required in the front
The minimum load on the front axle must be 20% of the basic weight
of the tractor. With a mounted machine in the power lift behind the
tractor the minimum required ballast (in lb) in front of the tractor is
calculated as follows:
If the calculated value is negative no additional ballast is required.
Actual total weight (lb) = A + D + E
g
Actual front axle load = D x ( f + g ) + ( B x g ) - E x (h + i )
Actual
rear axle load (lb) =
actual
total weight (lb) -
actual
front axle load (lb)
f + g
Front ballast required (lb) = E x ( h + i ) - ( B x g ) + (0.2 x A x g )
\

Safety
16
Ballast required in the rear
The minimum load on the rear axle must be 45% of the basic weight
of the tractor. With a machine mounted in the front power lift the
minimum required ballast (in lb) in the power lift behind the tractor is
calculated as follows:
If the calculated value is negative no additional ballast is required.
The calculated value must be less or equal to ( < ) the permitted
values. The front and rear loads must be greater than the minimum
load of the front and rear axles respectively.
T IP If you have access to a weigh bridge with sufficient measuring range
the total weight and the front and rear axle load can also be
determined by weighing them.
g + h + i
Rear ballast required (lb) = ( D x f ) - ( C x g ) + (0.45 x A x g )
Actual calculated
value
Value permitted in the
manual
Load capacity of 2
wheels
Front/rear axle mini-
mum load
/ lb -- --
Total weight lb <lb --
Front axle load lb < lb < lb
Rear axle load lb <lb <lb
\

Safety
17
Machine
Check the condition of the machine before use
Check the following before using the machine:
•is the machine in a proper, functioning condition?
•are all lights, safety and warning provisions correctly mounted and
in good working condition?
•are the brakes of the machine working properly and have they
been adjusted to the correct position?
Using an unsafe machine could result in personal injury and damage
to the machine.
The machine should only carry, not pull!
It is not permitted to use the machine for pulling as this would have
detrimental consequences to its construction. This could lead to
dangerous situations for bystanders, unsafe operation or damage to
crops.
Do not stand on the machine
Being on the machine during activities and transport is prohibited. You
may only be on the parts of the machine intended for the purpose if it
is standing still and prevented from rolling by means of parking brake
and wheel chocks. Being on the machine while in any other state
could lead to serious injury.
Never work on a running machine
Never work on the machine while it is running. A running machine has
several moving parts which can not be seen. Wait until all parts have
come to a complete halt. Moving parts can cause serious injuries.
Safety labels
Follow the instructions on the safety labels
The safety labels on the machine give important advice for a risk free
operation. Respect them to ensure your safety.
Replace any safety labels missing or illegible
When parts with a safety labels are replaced, the replacement part
must be provided with the same safety label. safety labels that are not
legible must be replaced so that they would be clearly legible at all
times.
\

Safety
18
Coupling shaft
Use the correct coupling shaft
Only use coupling shafts complying with the manufacturer’s
specification for that specific use! In order to ensure protection of both
man and machine exercise extreme caution when working at a
coupling shaft other then described in this manual and/or on the
instruction at the coupling shaft.
Modification of, and other special jobs on coupling shafts, require
written explicit order and procedure of both machine and coupling
shaft manufacturer is available! Use the correct tools and original
parts to ensure a good performance and maximum safety. The use of
an incorrect coupling shaft can cause damage to the machine.
Mount the appropriate protection
Externally accessible coupling shafts, the tractor's PTO shafts and
machine input-axle must be equipped with appropriate guards and
tubes. Working without guarding can cause serious or deadly injuries.
Replace protective coupling shaft tubes when required
Replace the coupling shaft protection sleeves at the first signs of wear.
Protection sleeves can wear without being noticed. Worn or damaged
protection sleeves can cause serious or deadly injuries.
Protect the PTO shaft end well
Slide the protection sleeve over the PTO shaft as soon as the coupling
shaft has been removed! Clothing could become entangled into an
unprotected PTO shaft end that could lead to serious injury.
Hydraulic system
Hydraulic oil is under high pressure
Never try to stop a leak with your fingers. Never try to locate a
hydraulic leak or try to contain it by hand! When inspecting always use
appropriate aid (e.g. a piece of wood or sheet metal) and wear safety
goggles, and gloves! High pressure fluid easily penetrates skin and
clothes, causing severe injuries. In the event of injury, contact your
physician immediately!
Electronic control system
Disconnect the control box
Disconnect the control box from the electric system as soon as no
more functions are needed in order to prevent unintentional operation.
Keeping the control box connected can be dangerous and can
damage the machine
as well as cause bodily injury.
Battery cables must be connected properly
Always disconnect the battery cable (negative pole) from the electric
system when working on the machine. Connect the battery cables
correctly: Positive pole first, followed by the negative pole. Always
equip the positive pole with the appropriate protective cap to avoid a
short circuit as this could lead to damage to the tractor and machine.
\

Safety
19
Use
Only use after training
The machine may not be operated before the user has been properly
instructed by the dealer or an authorized representative of the
manufacturer.
Ensure that you are familiar with all systems and control machines and
their functions prior to working with them! It will be too late for that once
you are working! Careless usage could lead to injury and damage to
the machine.
To be used and operated by 1 person
The machine may only be operated by one person, from the tractor.
Operating the machine from the tractor will keep you out of harm's
way. Other people should not be in the direct vicinity of the machine
and the tractor. Those who are within the working area and the danger
zone could be injured.
Check the direct surroundings
Check the immediate environment and keep a constant eye on it at the
start, as well as while you are working with the machine. Familiarize
yourself with the immediate vicinity. Do not start working until all
people and obstacles within the working area and danger zone of the
tractor and machine have been removed.
Never stay or allow anyone to stay within the danger area while the
machine is running! If there are people within the working area and the
danger zone it could lead to injury.
Do not stand on the machine
Being on the machine during activities and transport is prohibited. You
may only be on the parts of the machine intended for the purpose if it
is standing still and prevented from rolling. Being on the machine while
in any other state could lead to serious injury.
Keep the protection intact
The protection of the machine, e.g. shields and guards, protects from
penetrating into danger areas! Therefore all protection must be kept in
optimal condition and moved into the right position prior to starting to
work! The absence of protective gear could lead to injury.
Safety for children
•Never assume that children will remain where you last saw them.
•Be alert and shut your machine down if children into the work area.
•Never allow children to play on or operate the machine.
\

Safety
20
Transport
Check the decoupling ropes of the quick coupling
The decoupling ropes must never be tense and must provide sufficient
freedom for movement, even with the power lift in the lowest position
as it could otherwise accidentally disconnect the quick coupling.
Drive carefully
Moving behaviour, maneuverability and braking performance are
influenced by a trailed machine. When taking turns, pay attention to
the extended width/length (turning circle) and/or large mass
(sluggishness) of the machine! Ensure sufficient braking effect and
safe manageability! Careless driving could lead to serious injury and
damage to the machine.
Adjust the driving speed
High driving speeds and uneven surfaces on the road or field can put
considerable strain on the machine and cause the tractor or machine
to be overstrained, which could lead to damage. Always adjust the
driving speed to the conditions of the environment and the terrain!
When driving up and down hills and across slopes, do not make any
sudden turns!
On the field
Do not leave the driving cabin
Never leave the operator’s seat during operation or transport. The
driver can be in the danger zone of the tractor or the machine and
could not have a proper view of the immediate vicinity. This could lead
to injury to the driver or third parties.
Do not allow the machine to tilt
When driving up and down hills and across slopes, do not make any
sudden turns! Do not drive transverse on a slope with a steep angle.
Tilting can cause serious machine damage.
Blockade of a security device
In case of blockade or operation of a security device, never work on
the machine without:
•placing the tractor and machine on a firm, flat surface,
•switching off the PTO shaft,
•switching off the electronic control system,
•releasing the pressure from the hydraulic system,
•placing all controls in their neutral or park position,
•switching off the tractor engine,
•the key must be removed from the ignition,
•engaging the parking brake of the tractor.
PTO shaft rotates after disengaging
After switching off the PTO shaft, the machine will continue running
because of inertia. Keep a safe distance to the machine until the
moving parts have come to a complete stop. Approaching the
machine while it is rotating can cause serious or deadly injuries.
\
