LAI Games MEGA STACKER User manual

Version 1.4.2
© LAI Games
► Read this manual BEFORE operating the machine.
► Keep this manual for your reference.
► Go to www.LAIGames.com Click on Support to register your
Game and receive future updates.
PLEASE NOTE:

Correspondence regarding this machine should be addressed to your
closest LAI Games office, or LAI Games Distributor.
For contact details, refer to the back page of this manual.
LAI Games
© LAI Games
Copyright Notice:
Authorization is hereby provided to you to copy this
manual in its entirety provided such copies are used for
non-commercial purposes and solely for use with
LAI Games products. This authorization is specifically
conditioned to include all legends, copyright, proprietary
and other notices which appear herein are unaltered on
any and all copies you make.
LAI Games
[email protected] www.laigames.com

Operator's Manual –Mega Stacker
© LAI GAMES
i
LAI Games NOTES
Dear Customer,
Keep up to date with any new Software release or Service Bulletins for
this Game.
Check our Website at www.laigames.com and click on Support, here you
will find links to all the Bulletins and Software Updates to keep your
game in top working order.
Thanks,

Operator's Manual –Mega Stacker
© LAI GAMES
ii
TABLE OF CONTENTS
SAFETY PRECAUTIONS......................................................................................................1
MACHINE INSTALLATION AND INSPECTION.............................................................2
INTRODUCTION....................................................................................................................3
SPECIFICATIONS..................................................................................................................4
ASSEMBLY INSTRUCTION.................................................................................................5
TICKET TO CAPSULE CONVERSION............................................................................14
HOW TO PLAY.....................................................................................................................15
PLAYERS AIM TO BUILD A VERTICAL STACK OF BLOCKS.................................15
FITTING PRIZES IN PRIZE COMPARTMENTS ...........................................................16
PRIZE SELECTION AND PAYOUT ADJUSTMENT......................................................17
OPERATION..........................................................................................................................19
OPERATIONAL DIAGRAM...........................................................................................19
ATTRACT MODE............................................................................................................19
PLAY MODE....................................................................................................................19
TEST MODE ..........................................................................................................................20
TEST MODE DIAGRAM.................................................................................................20
SOUND, LAMPS &DISPLAY TEST..............................................................................21
SWITCH TEST.................................................................................................................21
RUN TEST (TICKET/CAPSULE DISPENSER MOTOR) ........................................................22
PROGRAMMABLE ADJUSTMENTS MODE..................................................................23
PROGRAMMABLE ADJUSTMENTS MODE DIAGRAM............................................23
PROGRAMMABLE ADJUSTMENTS PROCEDURE ...................................................23
PROGRAMMABLE ADJUSTMENTS QUICK REFERENCE TABLE V1.4.2..............24
PROGRAMMABLE ADJUSTMENTS DETAILED .......................................................25
AUDITS MODE .....................................................................................................................32
AUDITS MODE DIAGRAM............................................................................................32
AUDIT PROCEDURE......................................................................................................33
AUDITS QUICK REFERENCE TABLE .........................................................................34
AUDITS DETAILED........................................................................................................35
GAME HISTORY MODE.....................................................................................................38
GAME HISTORY MODE DIAGRAM.............................................................................38
GAME HISTORY PROCEDURE ....................................................................................38
GAME HISTORY QUICK REFERENCE TABLE..........................................................39

Operator's Manual –Mega Stacker
© LAI GAMES
iii
ERRORS AND TROUBLESHOOTING..............................................................................40
ERROR CODE QUICK REFERENCE TABLE...............................................................40
TROUBLESHOOTING GAME ERRORS.......................................................................41
SECTION A: SERVICE INSTRUCTIONS ........................................................................43
LOCATING AND ACCESSING PARTS ............................................................................44
PARTS LOCATION DIAGRAM .....................................................................................44
PARTS LOCATION DIAGRAM .....................................................................................45
PARTS LOCATION DIAGRAM .....................................................................................46
PARTS LOCATION DIAGRAM .....................................................................................47
LAMPS....................................................................................................................................48
MAINTENANCE ...................................................................................................................49
BASE EXPLODED VIEW ....................................................................................................50
SECTION B: TECHNICAL DETAILS ...............................................................................51
LOCKING MECHANISM EXPLODED VIEW.................................................................52
MAINS VOLTAGE ADJUSTMENT ...................................................................................53
COIN OPTIONS REFERENCE GUIDE.............................................................................54
TICKET DISPENSER REFERENCE GUIDE ...................................................................55
CONNECTION INFORMATION........................................................................................59
3D PART EXPLODE VIEW.................................................................................................61
MEGA STACKER MAIN WIRING 1.................................................................................67
MEGA STACKER MAIN WIRING 2.................................................................................68
MEGA STACKER CONTROL WIRING 1........................................................................69
MEGA STACKER CONTROL WIRING 2........................................................................70
MEGA STACKER POWER WIRING 1.............................................................................71
MEGA STACKER POWER WIRING 2.............................................................................72
MEGA STACKER POWER WIRING 3.............................................................................73
MEGA STACKER OPTIONAL WIRING..........................................................................74

Operator's Manual –Mega Stacker
© LAI GAMES
Page 1
SAFETY PRECAUTIONS
The following safety precautions and advisories are used throughout this manual and
are defined as follows.
BE SURE TO READ THE FOLLOWING
* WARNING! *
Disregarding this text could result in serious injury.
* CAUTION! *
Disregarding this text could result in damage to the machine.
* WARNING! *
Always Turn OFF Mains AC power and unplug the game, before
opening or replacing any parts.
Always When unplugging the game from an electrical outlet, grasp the
plug, not the line cord.
Always Connect the Game Cabinet to grounded electrical outlet with a
securely connected ground line.
Do Not Install the Game Cabinet outdoors or in areas of high humidity,
direct water contact, dust, high heat or extreme cold.
Do Not Install the Game Cabinet in areas that would present an
obstacle in case of an emergency, i.e. near fire equipment or emergency
exits.
* NOTE! *
An advisory text to hint or help understanding.
* CAUTION! *
Always Use a Digital Multi meter, logic tester or oscilloscope for testing
integrated circuit (IC) logic PC boards. The use of a continuity tester is
not permitted.
Do Not Connect or disconnect any of the integrated circuit (IC) logic PC
boards while the power is ON.
Do Not Use any fuse that does not meet the specified rating.
Do Not Subject the game cabinet to extreme temperature variations.
Reliability of electrical components deteriorates rapidly over 60 o C.

Operator's Manual –Mega Stacker
© LAI GAMES
Page 2
MACHINE INSTALLATION and
INSPECTION
When installing and inspecting “Mega Stacker”, be very careful of the following
points and pay attention to ensure that the players can enjoy the game safely.
Be sure to turn the power OFF before working on the machine.
Make sure the power cord is not exposed on the surface (floor, ground, etc.) where
people walk.
Check that the rubber glide feet levelers are set correctly on the floor so that the
game cabinet is level and stable.
Always make complete connections for the integrated circuit (IC) logic PC Boards
and other connectors. Insufficient insertion can damage the electrical
components.
Only qualified personnel should inspect or test the integrated circuit (IC) logic PC
Boards.
If any integrated circuit (IC) logic PC Boards should need servicing. Please
contact the nearest LAI Games Distributor. (Refer to the back page of this manual)
* CAUTION! *
Before Switching the machine on be sure to check that it has been set on the
correct voltage for your area!
Refer To the mains voltage adjustment section of this manual. Machines are
normally shipped on 220V AC unless otherwise specified.
* WARNING! *
Always Turn OFF mains power before removing safety covers and refit all safety
covers when work is completed.

Operator's Manual –Mega Stacker
© LAI GAMES
Page 3
INTRODUCTION
CONGRATULTIONS! Your “Mega Stacker” is a great centre piece game with a
large bright and attractive display panel. The spacious prize compartments will
illuminate your prizes which makes them stand out to the customer. It also has
dynamic sound effects with a powerful subwoofer for that great game experience.
Another great product from LAI Games.
We hope you take the time to read this manual and learn about the many features and
user friendly adjustments that can be made to “fine-tune” the game for maximum
earning potential.
DESCRIPTION
“Mega Stacker” is a quick skill game that is simple to learn and fast to play. The
player uses the start/stop button to stop the moving blocks on top of the blocks in the
previous level. Each level higher the blocks are stacked the game will get
progressively harder.
Once the player reaches the Ticket Level, they can collect the Tickets or continue to
play on for the Major Prize but if they lose, they get nothing unless the Mercy Prize
option has been activated. Most players who reach the Ticket Level will continue to
play for the Major Prize believing they can reach it easily.
PACKAGING
At delivery, the machine should arrive in good condition. To move the packaged
machine for transport or placement, use a forklift and take care not to hit the
package or stack heavy objects on top, as this may cause damage to the machine.
CONTENTS
The “Mega Stacker” cabinet
Keys: 2 x coin door keys
2 x back door keys
2 x ticket door key
Operator‟s manual
IEC Power Cord (In cash box)
Parts & Accessories (In cash box)

Operator's Manual –Mega Stacker
© LAI GAMES
Page 4
SPECIFICATIONS
DIMENSIONS
Weight : 490 kg (1080.3lb)
Height : 2930 mm (115.4”)
Width : 2510mm (99”)
Length : 1770mm (70”)
Power : 792 Watts (3.6 amp @ 240 volts) (7.2 amp @ 110 volts)
Prize door : 34” x 19” 19” x 19”
ELECTRIC SUPPLY
The game has the option to operate on an 110V, 120V, 220V or 240V AC 50/60Hz
single phase mains electric supply.
The supply must be a three wire grounded supply.
LOCATION REQUIREMENTS
Ambient temperature: between 5°C and 40°C.
Ambient humidity: Low
Ambient U.V. radiation: Very low
Vibrations level: Low
* CAUTION! *
Before Switching the machine on be sure to check that it has been set on the
correct voltage for your area!
Please Refer to the mains voltage adjustment section of this manual.. Machines are
normally shipped on 220V AC unless otherwise specified.

Operator's Manual –Mega Stacker
© LAI GAMES
Page 5
ASSEMBLY INSTRUCTION
Side joint cabinet
Front joint
cabinet
Rear joint cabinet
Back joint
support cabinet

Operator's Manual –Mega Stacker
© LAI GAMES
Page 6
(Step 1)
(Step 2)
Position and secure the button
assembly to the front lower
cabinet using 4 screws M6 X20
Secure the Stainless Steel Seat bar
to the Center base using 8 screws
M6 x 20
Connect the wire connections
underneath the button assembly

Operator's Manual –Mega Stacker
© LAI GAMES
Page 7
(Step 3)
Using at least two persons lift
the display panel onto the base
unit and hold until secured
Fasten the back brackets in
place using the M10 bolts
Secure the bolts tight and
make sure all connections are
firmly connected

Operator's Manual –Mega Stacker
© LAI GAMES
Page 8
(Step 4)
Connect the center floor to the base cabinet with
4 Hex Bolts M10 X 30
make the cabinet more stable the center base
with the control panel connects the
connectors form the control panel and secure
it to control panel with 4 Hex Bolts M10 x 30
Adjust the Rubber feet to make
the floor level and stable
Connect the wire connections on
front bottom of the center base

Operator's Manual –Mega Stacker
© LAI GAMES
Page 9
(Step 5)
Connect all wire connections
before pushing completely
together.
Position the Right Prize cabinet
(facing the machine from front)
Level and adjust height of prize
cabinet same as main base unit
Secure the prize cabinet with 3 X
M10 bolts from the back.
Caution: We recommend the use
of step ladders for safety
Adjustable foot for
leveling and height
Open the bottom
door for access

Operator's Manual –Mega Stacker
© LAI GAMES
Page 10
(Step 6)
Secure the prize cabinet with 3 X
M10 bolts from the back.
Caution: We recommend the use
of step ladders for safety
Connect all wire connections
before pushing completely
together.
Position the Right Prize cabinet
(facing the machine from front)
Level and adjust height of prize
cabinet same as main base unit
Adjustable foot for
leveling and height
Open the bottom
door for access

Operator's Manual –Mega Stacker
© LAI GAMES
Page 11
(Step 7)
Position the left and right floor bases
either side of the center floor base
slightly apart.
Connect all the wire
connectors firmly
together and push the
two sides into the
correct position.
Secure the sides to
the centre with the
brackets using M6 x
30 screws
Secure the sides with brackets to
the centre floor and the prize
compartments as shown and do
same on both sides

Operator's Manual –Mega Stacker
© LAI GAMES
Page 12
(Step 8)
Take off the back panel of the
header to make it lighter to lift
Lift top header into position and
secure with 4 x M6 bolts. While
the cover is off connect all wire
connections firmly together
Replace the top header back
panel and remember to plug the
lights back in and secure the
panel with its screws.
Caution: We recommend the
use of two persons and step
ladders for fitting the Top
Header in position

Operator's Manual –Mega Stacker
© LAI GAMES
Page 13
(Finished)
* NOTE! *
Make sure all bolts and screws are securely fixed to the cabinet

Operator's Manual –Mega Stacker
© LAI GAMES
Page 14
TICKET TO CAPSULE CONVERSION

Operator's Manual –Mega Stacker
© LAI GAMES
Page 15
HOW TO PLAY
PLAYERS AIM TO BUILD A VERTICAL STACK OF BLOCKS
Pay to play.
Press the Start/Stop button to start a game.
Press the Start/Stop button to stop the moving blocks.
Stop the moving blocks on top of the blocks in previous level.
Players win a prize when ether the Ticket Level or Major Prize is reached.
On a Ticket level win, players will win Tickets or press the Continue button to try
for the Major Prize.
(The player will not win any prizes if they choose to continue and fail to reach the Major
level)
Game ends when a prize is collected or any time the player fails to stop the moving
blocks directly above a block on the previous level.
Prize Selection
Once you have won a prize, press the select button to step through the Prize doors.
If you win at Ticket Level and press collect you win Tickets, the amount which has
been set in “P” settings.
If you win a Major Prize you can select from any of the active Major Prize doors.
Press the Start/Stop button to open your selected prize door.
Note :
Staying Blocks
Lost Blocks
Perfect
Perfect
Not bad
Not bad
Missed
Game over
Missed
Game over
