LAI Games Most Wanted User manual

© LAI GAMES
► Read this manual BEFORE operating the machine.
► Keep this manual for your reference.
►Go to www.LAIGames.com click on Operator Access to register your
games and receive of future updates.
PLEASE NOTE:
V 3.1

Correspondence regarding this machine should be addressed to
your closest LAI GAMES office, or LAI GAMES Distributor.
For contact details, refer to the back page of this manual.
LAI GAMES
[email protected] www.laigames.com
LAI GAMES
© LAI GAMES
Copyright Notice:
Authorization is hereby provided to you to copy this
manual in its entirety provided such copies are used for
non-commercial purposes and solely for use with LAI
GAMES products. This authorization is specifically
conditioned to include all legends, copyright, proprietary
and other notices which appear herein are unaltered on
any and all copies you make.

i
LAI GAMES NOTES
Dear Customer,
Keep up-to-date with any new Software release or Service Bulletins for
this Game.
Check our Website at www.laigames.com and click on Product Support,
here you will find links to all the Bulletins and Software Updates to keep
your game in top working order.
Thanks,

Operator's Manual –Most Wanted
© LAI GAMES
i
TABLE OF CONTENTS
SAFETY PRECAUTIONS..........................................................................................1
MACHINE INSTALLATION AND INSPECTION ...................................................2
INSTALLING GUN BRACKET AND LEATHER HOLSTER................................3
INTRODUCTION .....................................................................................................5
SPECIFICATIONS....................................................................................................6
HOW TO PLAY.........................................................................................................7
OPERATION ...............................................................................................................8
OPERATIONAL DIAGRAM ..................................................................................8
POWER UP............................................................................................................8
ATTRACT MODE ..................................................................................................8
GAME PLAY MODE..............................................................................................8
GUN ALIGNMENT MODE......................................................................................9
GUN ALIGNMENT SCREEN................................................................................9
TEST MODE ...........................................................................................................10
TEST MODE MAIN SCREEN V3.1.....................................................................10
TEST MODE PROCEDURE................................................................................10
TEST MODE OPTIONS DETAILED...................................................................11
SETTINGS............................................................................................................12
SETTINGS SCREEN............................................................................................12
SETTINGS DETAILED........................................................................................13
AUDITS................................................................................................................14
AUDITS SCREEN................................................................................................15
PARTS OF AUDITS SCREEN.............................................................................15
AUDITS DETAILED............................................................................................16
SWITCH TEST.....................................................................................................16
SWITCH TEST SCREEN......................................................................................17
SCREEN TEST.....................................................................................................18
SCREEN TEST MAIN SCREEN...........................................................................18
SCREEN TEST DETAILED.................................................................................18
SOUND TEST ......................................................................................................19
SOUND TEST SCREEN.......................................................................................19
SOUND TEST DETAILED ..................................................................................19
ERRORS AND TROUBLESHOOTING.................................................................20
TROUBLESHOOTING GAME ERRORS ............................................................20
FUSE INFORMATION...........................................................................................21
FUSE LOCATION DIAGRAM.............................................................................21
SECTION A: SERVICE INSTRUCTIONS ...........................................................22

Operator's Manual –Most Wanted
© LAI GAMES
ii
LOCATING AND ACCESSING PARTS ...............................................................23
PARTS LOCATION DIAGRAM...........................................................................23
PARTS DESCRIPTION........................................................................................25
LAMPS ....................................................................................................................27
MAINTENANCE ....................................................................................................28
SECTION B: TECHNICAL DETAILS...................................................................29
MAINS VOLTAGE ADJUSTMENT......................................................................30
TICKET DISPENSER REFERENCE GUIDE ........................................................31
MOST WANTED JAMMA &CONNECTOR LIST...............................................36
3D EXPLODE PARTS............................................................................................37
MOST WANTED WIRING DIAGRAM.................................................................38

Operator's Manual –Most Wanted
© LAI GAMES
SAFETY PRECAUTIONS
The following safety precautions and advisories are used throughout this manual and
are defined as follows.
BE SURE TO READ THE FOLLOWING
* WARNING! *
Disregarding this text could result in serious injury.
* CAUTION! *
Disregarding this text could result in damage to the machine.
* WARNING! *
Always turn OFF Mains AC power and unplugged the game, before
opening or replacing any parts.
Always when unplugging the game from an electrical outlet, grasp the
plug, not the line cord.
Always connect the Game Cabinet to grounded electrical outlet with a
securely connected ground line.
Do Not install the Game Cabinet outdoors or in areas of high humidity,
direct water contact, dust, high heat or extreme cold.
Do Not install the Game Cabinet in areas that would present an
obstacle in case of an emergency, i.e. near fire equipment or emergency
exits.
* NOTE! *
An advisory text to hint or help understanding.
* CAUTION! *
Always use a Digital Multimeter, logic tester or oscilloscope for testing
integrated circuit (IC) logic PC boards. The use of a continuity tester is
not permitted.
Do Not Connect or disconnect any of the integrated circuit (IC) logic PC
boards while the power is ON.
Do Not use any fuse that does not meet the specified rating.
Do Not Subject the game cabinet to extreme temperature variations.
Reliability of electrical components deteriorates rapidly over 60 oC.

Operator's Manual –Most Wanted
© LAI GAMES
2
MACHINE INSTALLATION and INSPECTION
When installing and inspecting “Most Wanted”, be very careful of the following points
and pay attention to ensure that the players can enjoy the game safely.
Be sure to turn the power OFF before working on the machine.
Make sure the power cord is not exposed on the surface (floor, ground, etc.) where
people walk through.
Check that the rubber glide feet levelers are set evenly on the floor so that the game
cabinet is unable to roll and is stable.
Always make complete connections for the integrated circuit (IC) logic PC Boards
and other connectors. Insufficient insertion can damage the electrical components.
Only qualified personnel should inspect or test the integrated circuit (IC) logic PC
Boards.
If any integrated circuit (IC) logic PC Boards should need servicing. Please contact
the nearest LAI GAMES distributor. (Refer to the back page of this manual)
* CAUTION! *
Before switching the machine on be sure to check that it has been set on the
correct voltage for your area!
Refer to the mains voltage adjustment section of this. Machines are normally
shipped on 220V AC unless otherwise specified.
* WARNING! *
Always Turn OFF mains power before removing safety covers and refit all safety
covers when work is completed.

Operator's Manual –Most Wanted
© LAI GAMES
3
INSTALLING GUN BRACKET AND LEATHER
HOLSTER
For transportation safety we put the gun, bracket and leather holster with 4 L bolts
M5x 15 on top of the control panel,
Installation process, before proceed you need to equipped with M5 Allen key.
Step 1.
Take the gun, bracket and leather holster from control panel. As shown down here
Step 2.
Unscrew 4 L bolts on each side of control panel, as shown below,

Operator's Manual –Most Wanted
© LAI GAMES
4
Step 3,
Open the control panel by pull the whole control panel as shown below,
Step 4,
Position the bracket on it’s hole until all the four hole match with bracket inside the
control panel as shown below,
Step 5,
Screw the 4 supplied L bolts to hold the bracket as shown below,
Step 6 Finishing,
Close the control panel and screw the 4 L bolts to its position,

Operator's Manual –Most Wanted
© LAI GAMES
5
INTRODUCTION
CONGRATULATIONS! You have just bought the “Most Wanted”,another great
product from LAI GAMES. In the old Wild West, it was easy to tell the difference
between the good guys and the villains. In this fast action shooting game, players have
to make quick decisions to shoot only the bad guys and leave everyone else alive.
We hope you take the time to read this manual and learn about the many other features
and user-friendly adjustments that can be made to “fine-tune” the game for maximum
earning potential.
DESCRIPTION
The “Most Wanted”is a single player fast action shooting game. Players aim to
shoot as many villains before the game timer expires. The more villains hit, the more
tickets won.
PACKAGING
At delivery, the machine should arrive in good condition. To move the packaged
machine for transport or placement, use a forklift and take care not to hit the package
or stack heavy objects on top, as this may cause damage to the machine.
CONTENTS
The “Most Wanted” cabinet
Keys: 2 x coin door keys
2 x back door keys
2 x ticket door key
Operator’s manual
IEC Power Cord (In cash box)
Parts & Accessories (In cash box)

Operator's Manual –Most Wanted
© LAI GAMES
6
SPECIFICATIONS
DIMENSIONS
Weight: 160 kg (353lb)
Height: 2134.5mm (84”)
Width: 989 mm (39”)
Length: 895 mm (35.2”)
Power: Maximum 450 W –(220V @ 2.1A)(120V @ 3.8A)
ELECTRIC SUPPLY
The game has the option to operate on a 110V, 120V, 220V or 240V AC 50/60Hz
single phase mains electric supply.
The supply must be a three wire grounded supply.
LOCATION REQUIREMENTS
Ambient temperature: between 5oC and 40oC.
Ambient humidity: Low
Ambient U.V. radiation: Very low
Vibrations level: Low
* CAUTION! *
Before switching the machine on be sure to check that it has been set on the
correct voltage for your area!
Please Refer to the mains voltage adjustment section of this manual. Machines are
normally shipped on 220V AC unless otherwise specified.

Operator's Manual –Most Wanted
© LAI GAMES
7
HOW TO PLAY
PLAYERS SHOOT VILLAINS TO
SCORE POINTS FOR TICKETS
Insert coin/s for credits.
Take the Gun from the holster and
Press the Start Button to begin a game.
Use the Gun to shoot the villains when
the windows open to score points.
The faster you can shoot the villains
the more sets of windows are available
before the game timer expires.
Shooting the innocent will result in lost
time and points.
Bonus Round can be played by
shooting a certain number of villains
before the game timer expires.
In Bonus Round, try to shoot all the
villains before the window sets change.
Tickets are awarded based on points
scored during the game.
At the end of a game, Extra Tickets can
be won by shooting one of the closed
windows in the Mystery Bonus
Jackpot.
Players with the highest scores can use
the gun to enter their initials for
display in the High Score table.

Operator's Manual –Most Wanted
© LAI GAMES
8
OPERATION
The “Most Wanted”game has five operational modes: Power Up mode, Attract mode,
Game Play mode, Gun Alignment Mode and Test Mode.
OPERATIONAL DIAGRAM
POWER UP
The Power Up mode is active when power is first applied to the game. During this
time, a LOADING PLEASE WAIT! phrase will appear on screen. Please wait for
about 10 seconds for the loading to complete.
ATTRACT MODE
The Attract mode provides game sound and display while the game is not being
played. This feature is to attract potential customers to play the game.
GAME PLAY MODE
The Most Wanted has two play modes. The Standard Coin Play mode, where a
coin, or coins are inserted. Or Free Play where no coins are necessary.
COIN PLAY
The Coin Play mode is entered from Attract mode, by inserting coins in any of the
two coin slots on the front of the machine cabinet, then following the instructions
in the “How to Play” section of this manual.
FREE PLAY
The Free Play mode is entered by setting the Coin per Credit to “free”.
For a single free game, just press the Service button once. When issuing single
free games in this manner, Tickets can be won as normal.
POWER UP
Loading Please Wait!
ATTRACT
MODE
TEST
MODE
GUN ALIGNMENT
MODE
GAME PLAY
MODE
Settings
Audits
Switch Test
Screen Test
Sound Test
Exit

Operator's Manual –Most Wanted
© LAI GAMES
9
GUN ALIGNMENT MODE
The Most Wanted has a Gun Alignment Mode allowing you to set the calibration for
gun accuracy. To enter Gun Alignment Mode, press the yellow Gun Calibration push
button located on the service bracket.
The screen will display a background with white and red targets; one will appear in
the upper left of the screen and the other in the lower right. To calibrate the gun
alignment, aim and shoot first the upper left target and then the lower right target. The
game will exit into Attract Mode automatically.
(Refer to the Gun Alignment Screen below).
GUN ALIGNMENT SCREEN
Aim & Shoot this
Target First
Aim & Shoot this
Target Second

Operator's Manual –Most Wanted
© LAI GAMES
10
TEST MODE
The Most Wanted has Test Mode from which you can adjust the game settings, see the
audits, do switch test, screen test, and sound test. From the main screen of the Test
Mode you can choose one of the six options available that is suitable to your need.
(Refer to the Test Mode Main Screen below).
TEST MODE MAIN SCREEN V3.1
TEST MODE PROCEDURE
ENTER The Test Mode can be entered by pressing the red Test button located
on the service bracket while in Attract mode once.
SELECT The green Service button is pressed to step through each of the Test
Mode options, starting from Settings stepping down through Exit and
then looping again until the mode is exited.
ENTERING OPTIONS SETTINGS
The two white Up and Down buttons are used to enter the chosen Test
Mode option.
EXIT The Test mode is exited by highlighting the Exit using Service button
and pressing one of the white buttons.
* NOTE! *
By holding down the
SERVICE button, you can step through the options quicker.
Settings
Audits
Switch Test
Screen Test
Sound Test
Exit

Operator's Manual –Most Wanted
© LAI GAMES
11
SERVICE BRACKET
TEST MODE OPTIONS DETAILED
SETTINGS
Highlighting SETTINGS and pressing one of the two white buttons will advance
to the Settings screen. In this screen you can do some adjustments related to the
game.
AUDITS
Highlighting AUDITS and pressing one of the two white buttons will advance to
the Audits screen. In this screen you can see the audits of the game.
SWITCH TEST
This test is used to test all the game switches. To enter the Switch Test, highlight
SWITCH TEST in the Test Mode main screen and press one of the white
buttons.
SCREEN TEST
This test is used to test the game screen. To enter the Screen Test, highlight
SCREEN TEST in the Test Mode main screen and press one of the white
buttons.
SOUND TEST
This test is used to test the audio channel of the game. To enter the Sound Test,
highlight SOUND TEST in the Test Mode main screen and press one of the white
buttons.
EXIT
To exit the Test Mode main screen, highlight EXIT in the Test Mode main screen
and press one of the white buttons.
Coin
Meter
Ticket
Meter
Gun Calibrate
Push Button
SERVICE
Push Button
DOWN
Push Button
Volume
Control
UP
Push Button
TEST
Push Button

Operator's Manual –Most Wanted
© LAI GAMES
12
SETTINGS
ENTER The Settings can be entered by highlighting SETTINGS while in Test
Mode main screen and pressing the white buttons. Or, by pressing the
red Test button while in Attract mode once, highlighting SETTINGS,
and pressing the white buttons.
SELECT The Service button is pressed to step through each of the adjustment
configurations, starting from the highlighted “Cancel”dialog button,
stepping through each adjustment and then looping again until the
Settings is exited.
CHANGE The two white buttons change the displayed value, Up to increase and
Down to decrease. For the dialog buttons, either of the white buttons
will activate the highlighted dialog button.
EXIT The Settings is exited into Test Mode main screen by highlighting and
pressing one of the white buttons on the “OK” dialog button to exit &
save the changes. Or by highlighting and pressing the white buttons on
the “CANCEL”dialog button to exit without saving the changes.
SETTINGS SCREEN
* NOTE! *
Certain adjustments have a fast adjustment feature. By holding down the
UP or DOWN push buttons, the values step through quicker.

Operator's Manual –Most Wanted
© LAI GAMES
13
SETTINGS DETAILED
CANCEL
(Exit Without Save Changes)
Highlighting the CANCEL dialog button and pressing either of the two white
buttons will exit the Settings without save any changes made.
OK
(Exit & Save Changes)
Highlighting the OK dialog button and pressing either of the two white buttons
will exit the Settings and save any changes made.
RESET DEFAULT
(Reset all Adjustments to Default)
Highlighting the RESET DEFAULT dialog button and pressing either of the two
white buttons will reset all adjustments back to factory defaults.
BASE TIME
(Default 45) (Adjustable 45 –90, Steps ±15)
This variable sets the minimum time a game will play, this is regardless if player
hits or misses any villains.
COINS PER CREDIT
(Default 1) (Adjustable Free, 1 –5, Steps ±1)
This sets the number of coins that need to be inserted into the coin mechanisms
for each credit. The setting “Free”will sets the game in Free Play Mode.
BONUS ROUND TIME
(Default 15) (Adjustable 10 –30, Steps ±5)
This variable sets the time in seconds that the bonus round is active. Bonus Round
Time is added to the Base Time if the play hits the required number of Villains.
VILLAINS HIT FOR BONUS
(Default 50) (Adjustable 20 –100, Steps ±5)
This variable sets the number of Villains that need to be hit to get to the bonus
round.
MYSTERY BONUS AVERAGE
(Default 5) (Adjustable 1 –9, Steps ±1)
This variable sets the desired number of tickets the operator would like to average
on the Mystery Bonus Round at the end of a game.
JACKPOT TICKETS
(Default 10) (Adjustable 1 –20, Steps ±1)
This variable sets the maximum number of Jackpot tickets that can be won on a
Mystery Bonus Round at the end of a game.

Operator's Manual –Most Wanted
© LAI GAMES
14
TICKET PAYOUT
(Default ON) (Adjustable ON-OFF)
This setting turns the ticket payout ON or OFF. If sets to ON, the machine will
payout tickets won by player. If sets to OFF,the machine will not dispense
tickets.
ATTRACT MODE SOUNDS
(Default ON) (Adjustable ON-OFF)
This adjustment turns the attract mode sounds ON or OFF. This is the sound and
music that the game generates to attract customers when it is not being played.
CALIBRATE X &CALIBRATE Y
(Displayed for Information Only)
This displays the X & Y off-set values stored in memory for the Gun Calibration.
The display of “#” indicates an invalid value and calibration is required.
TICKET PAYOUT TABLE
(Adjustable 0 –30,000, Steps ±50)
Default Values
No. of Tickets
Score
No. of Tickets
Score
1
0
5
6000
2
1500
6
7500
3
3000
+1
3000
4
4500
These variables set the number of score points required for tickets. The points
needed from 1 to 6 tickets can be set individually for scalable payout. For more
than 6 tickets, +1is set to the number of extra points needed for each additional
ticket above 6 tickets.
AUDITS
ENTER The Audits can be entered by highlighting AUDITS while in Test
Mode main screen and pressing the white buttons. Or, by pressing
the red Test button while in Attract mode once, highlighting
AUDITS, and pressing the white buttons.
SELECT The Service button is pressed to step between “Clear” and “Exit”
dialog buttons repeatedly until the Audits is exited.
ACTIVATE The two white buttons will activate the highlighted dialog button.
EXIT The Audits is exited into Test Mode main screen by highlighting
and pressing one of the white buttons on the “Exit”dialog button.
* NOTE! *
It is recommended that Number of Tickets 1 to 6 have progressively
increasing score values, or unpredictable ticket payout may occur.

Operator's Manual –Most Wanted
© LAI GAMES
15
AUDITS SCREEN
PARTS OF AUDITS SCREEN
USER
The User section enables the operator to see statistics for number of coins
inserted, tickets dispensed, Service button pressed, and games played since the last
game audits cleared. The statistics in this section can be cleared by highlighting
the Clear dialog button, press one of the white buttons, and choose YES in the
dialog box that appears.
MACHINE
The Machine section displays total statistics for number of coins inserted, tickets
dispensed, Service button pressed, and games played. The statistics in this section
is the total number of statistics that were in the User section. Every statistics that
were in the User section will be added to statistics in this section. Statistics in this
section cannot be cleared.
* NOTE! *
If an audit value in the User section reaches the value of 999,999, it will
automatically stop increasing.
* NOTE! *
If an audit value in the Machine section reaches the value of 999,999, it will
reset itself to 0.
