LAI Games Speed Of Light User manual

► Read this manual BEFORE operating the machine.
► Keep this manual for your reference.
►Go to www.LAIGames.com click on Support to register your
games and receive of future updates.
PLEASE NOTE:
© LAI Games

Correspondence regarding this machine should be addressed to your
closest LAI Games office, or LAI Games Distributor.
For contact details, refer to the back page of this manual.
LAI Games
© LAI Games
Copyright Notice:
Authorization is hereby provided to you to copy this
manual in its entirety provided such copies are used for
non-commercial purposes and solely for use with
LAI Games products. This authorization is specifically
conditioned to include all legends, copyright, proprietary
and other notices which appear herein are unaltered on
any and all copies you make.
LAI Games
[email protected] www.laigames.com

Operator's Manual –Speed Of Light
© LAI GAMES
i
LAI Games Notes
Dear Customer,
Keep up to date with new software updates or Service Bulletins for this
game.
Check our Website at www.laigames.com and click on Support, here you
will find links to all the Bulletins and Software Updates to keep your
game in top working order.
Thanks,

Operator's Manual –Speed Of Light
© LAI GAMES
ii
TABLE OF CONTENTS
SAFETY PRECAUTIONS......................................................................................................1
MACHINE INSTALLATION AND INSPECTION............................................................2
INTRODUCTION ................................................................................................................3
SPECIFICATIONS ..............................................................................................................4
ASSEMBLY THE HEADER ...............................................................................................5
ASSEMBLY THE WING SIGN..........................................................................................6
ASSEMBLY THEPLATFORM..........................................................................................7
HOW TO PLAY....................................................................................................................8
OPERATION............................................................................................................................9
OPERATIONAL DIAGRAM.............................................................................................9
ATTRACT MODE..............................................................................................................9
PLAY MODE......................................................................................................................9
TEST MODE.......................................................................................................................10
TEST MODE DIAGRAM.................................................................................................10
SOUND, LAMPS &DISPLAY TEST..............................................................................11
SWITCH TEST.................................................................................................................11
PROGRAMMABLE ADJUSTMENTS QUICK REFERENCE TABLE V1.5.2..............13
PROGRAMMABLE ADJUSTMENTS DETAILED .......................................................14
AUDITS MODE..................................................................................................................21
AUDITS MODE DIAGRAM............................................................................................21
AUDIT PROCEDURE......................................................................................................22
AUDITS QUICK REFERENCE TABLE .........................................................................23
AUDITS DETAILED........................................................................................................24
GAME HISTORY MODE..................................................................................................26
GAME HISTORY MODE DIAGRAM.............................................................................26
GAME HISTORY QUICK REFERENCE TABLE..........................................................26
GAME HISTORY PROCEDURE ....................................................................................27
ERRORS AND TROUBLESHOOTING..........................................................................28
ERROR CODE QUICK REFERENCE TABLE...............................................................28
TROUBLESHOOTING GAME ERRORS.......................................................................29
SECTION A: SERVICE INSTRUCTIONS ........................................................................30
LOCATING AND ACCESSING PARTS.........................................................................31
ELECTRONIC DETAIL POSITION...............................................................................32
PARTS DESCRIPTION.....................................................................................................33
LAMPS ................................................................................................................................35
MAINTENANCE................................................................................................................36
SECTION B: TECHNICAL DETAILS ...............................................................................37

Operator's Manual –Speed Of Light
© LAI GAMES
iii
MAINS VOLTAGE ADJUSTMENT................................................................................38
COIN OPTIONS REFERENCE GUIDE..........................................................................39
TICKET DISPENSER REFERENCE GUIDE ................................................................40
EDGE CONNECTOR PINOUT........................................................................................45
SPEED OF LIGHT MAIN WIRING DIAGRAM............................................................48
SPEED OF LIGHT MAIN WIRING 1...............................................................................49
SPEED OF LIGHT CONTROL WIRING.........................................................................50
SPEED OF LIGHT CONTROL WIRING 1......................................................................51
SPEED OF LIGHT CONTROL WIRING 2......................................................................52
SPEED OF LIGHT OPTIONAL WIRING .......................................................................53
SPEED OF LIGHTPOWER WIRING..............................................................................54

Operator's Manual –Speed Of Light
© LAI GAMES
Page 1
SAFETY PRECAUTIONS
The following safety precautions and advisories are used throughout this manual and
are defined as follows.
BE SURE TO READ THE FOLLOWING
* WARNING! *
Disregarding this text could result in serious injury.
* CAUTION! *
Disregarding this text could result in damage to the machine.
* WARNING! *
Always turn OFF Mains AC power and unplugged the game, before
opening or replacing any parts.
Always when unplugging the game from an electrical outlet, grasp the
plug, not the line cord.
Always connect the Game Cabinet to grounded electrical outlet with a
securely connected ground line.
Do Not installs the Game Cabinet outdoors or in areas of high
humidity, direct water contact, dust, high heat or extreme cold.
Do Not installs the Game Cabinet in areas that would present an
obstacle in case of an emergency, i.e. near fire equipment or emergency
exits.
* NOTE! *
Is an advisory text to hint or help understand .
* CAUTION! *
Always use a Digital Multimeter, logic tester or oscilloscope for testing
integrated circuit (IC) logic PC boards. The use of a continuity tester is
not permitted.
Do Not Connect or disconnect any of the integrated circuit (IC) logic PC
boards while the power is ON.
Do Not uses any fuse that does not meet the specified rating.
Do Not Subject the game cabinet to extreme temperature variations.
Reliability of electrical components deteriorates rapidly over 60 oC.

Operator's Manual –Speed Of Light
© LAI GAMES
Page 2
MACHINE INSTALLATION and INSPECTION
When installing and inspecting “Speed of Light”, be very careful of the following
points and pay attention to ensure that the players can enjoy the game safely.
Be sure to turn the power OFF before working on the machine.
Make sure the power cord is not exposed on the surface (floor, ground, etc.) where
people walk.
Check that the rubber glide feet levelers are set correctly on the floor so that the
game cabinet is level and stable.
Always make complete connections for the integrated circuit (IC) logic PC Boards
and other connectors. Insufficient insertion can damage the electrical
components.
Only qualified personnel should inspect or test the integrated circuit (IC) logic PC
Boards.
If any integrated circuit (IC) logic PC Boards should need servicing. Please
contact the nearest LAI Games Distributor. (Refer to the back page of this manual)
* CAUTION! *
Before Switching the machine on be sure to check that it has been set on the
correct voltage for your area!
Refer To the mains voltage adjustment section of this manual. Machines are
normally shipped on 220V AC unless otherwise specified.
* WARNING! *
Always Turn OFF mains power before removing safety covers and refit all safety
covers when work is completed.

Operator's Manual –Speed Of Light
© LAI GAMES
Page 3
INTRODUCTION
CONGRATULATIONS! On your purchase of “Speed of Light”, interactive game
that will challenge player to move hands fast to try to turn off the illuminated light on
the buttons as many as they can the many buttons pressed that much ticket they will
get it is another great product from LAI GAMES.
We hope you take the time to read this manual and learn about the many other
features and user-friendly adjustments that can be made to “fine-tune” the game for
maximum earning potential.
DESCRIPTION
The “Speed of Light”is.
PACKAGING
At delivery, the machine should arrive in good condition. To move the packaged
machine for transport or placement, use a forklift and take care not to hit the
package or stack heavy objects on top, as this may cause damage to the machine.
CONTENTS
The “Speed of Light” cabinet
Keys: 2 x coin door keys
2 x back door keys
2 x ticket door key
Operator‟s manual
IEC Power Cord (In cash box)
Parts & Accessories (In cash box)

Operator's Manual –Speed Of Light
© LAI GAMES
Page 4
SPECIFICATIONS
DIMENSIONS
Weight: 240 kg ( 529 lb)
Height: 1870 mm (73.6”)
Width: 2000 mm (78.7”)
Length: 1640 mm (65”)
Power: Maximum 228 W –(220V @1.4 A)(120V @ 2.8A)
ELECTRIC SUPPLY
The game has the option to operate on an 110V, 120V, 220V or 240V AC 50/60Hz
single phase mains electric supply.
The supply must be a three wire grounded supply.
LOCATION REQUIREMENTS
Ambient temperature: between 5oC and 40oC.
Ambient humidity: Low
Ambient U.V. radiation: Very low
Vibrations level: Low
* CAUTION! *
Before switching the machine on be sure to check that it has been set on the
correct voltage for your area!
Please Refer to the mains voltage adjustment section of this manual. Machines are
normally shipped on 220V AC unless otherwise specified.

Operator's Manual –Speed Of Light
© LAI GAMES
Page 5
ASSEMBLY THE HEADER
Position the header on top and secure with the 8 hex Bolt supplied, make sure
to connect the speaker and LED connector from inside of the header.
