LAI Games Timebuster User manual

© LAI GAMES
www.laigames.com
►READ THIS MANUAL BEFORE OPERATING THE MACHINE.
►KEEP THIS MANUAL FOR YOUR REFERENCE.

Correspondence regarding this machine should be addressed to your
closest
LAI GAMES office, or LAI GAMES Distributor.
For contact details, refer to the back page of this manual.
LAI GAME
S
© LAI GAME
S
Copyright Notice:
Authorization is hereby provided to you to copy this
manual in its entirety provided such copies are used for
non-commercial purposes and solely for use with
LAI GAMES products. This authorization is specifically
conditioned to include all legends, copyright, proprietary
and other notices which appear herein are unaltered on
any and all copies you make.
LAI GAME
S
[e-mail] www.laigames.com

Operator's Manual – Timebuster
©
LAI GAMES
i
LAI GAMES
NOTES
Dear Customer,
Keep up-to-date with any new Software release or Service Bulletins for
this Game.
Check our Website at www.laigames.com and click on Product Support,
here you will find links to all the Bulletins and Software Updates to keep
your game in top working order.
Thanks,

Operator's Manual – Timebuster
©
LAI GAMES
ii
TABLE OF CONTENTS
SAFETY PRECAUTIONS ......................................................................................................1
MACHINE INSTALLATION AND INSPECTION .............................................................2
INTRODUCTION ....................................................................................................................3
DESCRIPTION...................................................................................................................3
PACKAGING .....................................................................................................................3
DELIVERY ...............................................................................................................................3
CONTENTS ..............................................................................................................................3
SPECIFICATIONS ..................................................................................................................4
DIMENSIONS....................................................................................................................4
ELECTRIC SUPPLY..........................................................................................................4
LOCATION REQUIREMENTS.........................................................................................4
FITTING PRIZES TO THE PRIZE ARM .........................................................................5
HOW TO PLAY .......................................................................................................................7
PLAYERS AIM IS TO HIT ‘1000’ TO WIN THE “JACKPOT PRIZE”. .........................7
OPERATION............................................................................................................................8
ATTRACT MODE..............................................................................................................8
PLAY MODE......................................................................................................................8
COIN PLAY........................................................................................................................8
FREE PLAY........................................................................................................................8
PRIZE SELECTION AND PAYOUT ADJUSTMENT.....................................................9
PRIZE PAYOUT QUICK REFERENCE TABLE..............................................................9
TEST MODE ..........................................................................................................................10
SOUND, LIGHT &DISPLAY TEST ...............................................................................11
SWITCH TEST.................................................................................................................11
PRIZE ARM, LIGHTS &MOTORS TEST......................................................................12
PROGRAMMABLE ADJUSTMENTS MODE ..................................................................13
GAME ADJUSTMENTS..................................................................................................13
PROGRAMABLE ADJUSTMENTS QUICK REFERENCE TABLE ..........................14
PROGRAMABLE ADJUSTMENTS DETAILED...........................................................15
AUDITS MODE .....................................................................................................................18
GAME AUDITS QUICK REFERENCE TABLE ............................................................19
GAME AUDITS DETAILED...........................................................................................20
SECOND AUDITS MODE...............................................................................................21
SCORE HISTORY MODE ...................................................................................................22

Operator's Manual – Timebuster
©
LAI GAMES
iii
SCORE HISTORY QUICK REFERENCE TABLE .......................................................22
ERRORS AND TROUBLESHOOTING..............................................................................23
TROUBLESHOOTING GAME ERRORS..........................................................................24
SECTION A: SERVICE INSTRUCTIONS ........................................................................26
FUSE LOCATION DIAGRAM.........................................................................................27
LOCATING &ACCESSING PARTS...............................................................................29
SECTION B: TECHNICAL DETAILS ...............................................................................30
MAINS VOLTAGE ADJUSTMENTS..............................................................................31
TRANSFORMER CONNECTOR....................................................................................31
FUNCTION .........................................................................................................................31
POWER SUPPLY.............................................................................................................31
3 D PARTS TIMEBUSTER ..................................................................................................32
TIMEBUSTER MAIN WIRING DIAGRAM .....................................................................36
TIMEBUSTER DISPLAY WIRING DIAGRAM ..........................................................37
TIMEBUSTER DC CONTROL WIRING DIAGRAM...................................................38
TIMEBUSTER POWER WIRING DIAGRAM ..............................................................39
TIMEBUSTER OPTIONAL WIRING DIAGRAM ........................................................40

Operator's Manual – Timebuster
©
LAI GAMES
Page 1
SAFETY PRECAUTIONS
The following safety precautions and advisories are used throughout this manual and
are defined as follows.
BE SURE TO READ THE FOLLOWING
* WARNING! *
Disregarding this text could result in serious injury.
* CAUTION! *
Disregarding this text could result in damage to the machine.
* WARNING! *
Always turn OFF Mains AC power and unplugged the game, before
opening or replacing any parts.
Always when unplugging the game from an electrical outlet, grasp the
plug, not the line cord.
Always connect the Game Cabinet to grounded electrical outlet with a
securely connected ground line.
Do Not install the Game Cabinet outdoors or in areas of high humidity,
direct water contact, dust, high heat or extreme cold.
Do Not install the Game Cabinet in areas that would present an
obstacle in case of an emergency, i.e. near fire equipment or emergency
exits.
* NOTE! *
An advisory text to hint or help understanding.
* CAUTION! *
Always use a Digital Multimeter, logic tester or oscilloscope for testing
integrated circuit (IC) logic PC boards. The use of a continuity tester is
not permitted.
Do Not Connect or disconnect any of the integrated circuit (IC) logic PC
boards while the power is ON.
Do Not use any fuse that does not meet the specified rating.
Do Not Subject the game cabinet to extreme temperature variations.
Reliability of electrical components deteriorates rapidly over 60 oC.

Operator's Manual – Timebuster
©
LAI GAMES
Page 2
MACHINE INSTALLATION and INSPECTION
When installing and inspecting “Mouse Trapper”, be very careful of the following
points and pay attention to ensure that the players can enjoy the game safely.
Be sure to turn the power OFF before working on the machine.
Make sure the power cord is not exposed on the surface (floor, ground, etc.) where
people walk through.
Check that the rubber glide feet levelers are set evenly on the floor so that the
game cabinet is unable to roll and is stable.
Always make complete connections for the integrated circuit (IC) logic PC Boards
and other connectors. Insufficient insertion can damage the electrical
components.
Only qualified personnel should inspect or test the integrated circuit (IC) logic PC
Boards.
If any integrated circuit (IC) logic PC Boards should need servicing. Please
contact the nearest
LAI GAMES distributor. (Refer to the back page of this manual)
* CAUTION! *
Before switching the machine on be sure to check that it has been set on the
correct voltage for your area!
Refer to the mains voltage adjustment section of this manual on page 21.
Machines are normally shipped on 220V AC unless otherwise specified.
* WARNING! *
Always Turn OFF mains power before removing safety covers and refit all safety
covers when work is completed.

Operator's Manual – Timebuster
©
LAI GAMES
Page 3
INTRODUCTION
CONGRATULATIONS! You have just bought “Time Buster”. Another sensational
product from LAI games. This is, in our opinion, one of the best prize vending games
made in the world. It is very simple, yet challenging to play and includes features based
on the internationally successful "Stop The Clock on 1000".
I hope you take the time to read this manual and learn about the many other features and
user-friendly adjustments that can be made to “fine-tune” the game for maximum
earning potential.
DESCRIPTION
The “Time Buster” is a one-player, prize vending game, requiring players to use
their timing skill to stop the counting display on 1000 to win a jackpot prize or, an
adjustable near miss zone for a consolation prize.
PACKAGING
DELIVERY
At delivery, the machine should arrive in good condition. To move the packaged
machine for transport or placement, use a fork lift and take care not to hit the
package or stack heavy objects on top, as this may cause damage to the machine.
CONTENTS
“Time Buster” game machine fully assembled, on castors.
Keys: 1 ×coin door key
1×back door key
1×prize door key
Operator’s manual

Operator's Manual – Timebuster
©
LAI GAMES
Page 4
SPECIFICATIONS
DIMENSIONS
Weight: 140kg (310lb)
Height: 2000mm (78.½")
Width: 640mm (25")
Length: 770mm (30.½")
Power: Maximum 550w – (220V @ 2·5A)(120V @ 4·6A)
Average 330w – (220V @ 1·5A)(120V @ 2·8A)
ELECTRIC SUPPLY
The game has the option to operate on a 120V, 220V, 240V AC 50/60Hz mains
electric supply. The supply must be a three wire grounded supply.
LOCATION REQUIREMENTS
Ambient temperature: between 5oC and 40oC.
Ambient humidity: Low
Ambient U.V. radiation: Very low
Vibrations level: Low
* NOTE: BEWARE!!! Before switching the machine on be sure to check
that it has been set on the correct voltage for your area!! Refer to the mains
voltage adjustment section of this manual. Page 34. Machines are normally
shipped on 220V AC unless otherwise specified.

Operator's Manual – Timebuster
©
LAI GAMES
Page 5
FITTING PRIZES TO THE PRIZE ARM
STEP ONE: Removal of Prize Locking Pin.
STEP TWO: Attachment of Hanging Ties.
STEP THREE: Loading of Prizes.
STEP FOUR: Correct positioning of prizes.
1. Unscrew the Prize Locking pin (left-
hand thread), by turning it in a
clockwise direction.
2. Remove the
p
in b
y
p
ullin
g
it all the
1
2
Allow a
loose, 3-
finger gap
Attach the prizes securely to the
Hanging Ties.
* NOTE: Be sure to allow a loose,
3-finger gap in the ‘hanging tie’ to
ensure that the ‘hanging tie’ does not
interfere with the operation of the Prize
Arm mechanism.
Load the prize arm by sliding the
Hanging Tie over the entire arm, as
shown making sure that the prizes are
facing towards the customer.
STAR
FINIS

Operator's Manual – Timebuster
©
LAI GAMES
Page 6
STEP FIVE: Reinsertion of Prize Locking Pin.
STEP SIX: Correct positioning of Prize Locking Pin.
Position the Hanging Ties on the
prize arm as shown. Space the prizes
apart on the arms so they present well
looking from the front. Ensure the
prizes do not restrict the viewing of
the 4-digit display. Do not have the
prizes spaced more than ‘five spring
turns’ apart, or the prize arm will time
out and display error Err4.
* NOTE: If completely filling the
prize arm, start filling the prize arm
from the back and work your way
t
ow
ar
ds
th
e
fr
o
nt
.
1. Reinsert the Prize Locking pin by
positioning it in the centre of the
spiral making sure it ALWAYS stays
ABOVE the hanging ties.
2. Re-fit and tighten the Prize Locking
pin (Left-hand thread), by turning it
i
ti
lkidi ti
2
1
Ensure the Prize Locking Pin
ALWAYS remains ABOVE the
Hanging Ties.

Operator's Manual – Timebuster
©
LAI GAMES
Page 7
HOW TO PLAY
PLAYERS
PLAYERS AIM IS TO HIT ‘1000’ TO WIN THE
“JACKPOT PRIZE”.
Insert coins.
Press the Start/Stop button to begin the game. The clock’s display will start
counting from 0 up to 1100.
Press the button to stop the count on 1000 to win the ‘JACKPOT’ prize. The
jackpot prizes are displayed on the top three prize arms.
If the count is stopped within a programmable range close to 1000, then a
consolation prize is won. The consolation prizes are displayed on the bottom five
prize arms.
The player can select a prize within the permitted prize zone by using the green
select button on the control panel. If a jackpot is won, then ANY prize arm can be
selected. A lamp above the prize arm, ‘lights up’ to display the selected arm.
To dispense a prize after selection, the large red Start/Stop button is pressed on the
control panel.
The clock will not stop if the button is pressed earlier than the 500th count. A
warning sound will be played to mark the incident, but the clock will continue
counting as in a normal game.
IF the Start/Stop button is not pressed after the game is started, the clock will
automatically stop after counting up to 1100, signifying “GAME OVER”.
CONSOLATION
ARM
4
ARM
5
ARM
6
ARM
7
ARM
8
JACKPOT
ARM
1
ARM
2
ARM
3
10 0 0

Operator's Manual – Timebuster
©
LAI GAMES
Page 8
OPERATION
The “Time Buster” game has five operational modes: Attract mode, Play mode,
Test Mode, Programmable Adjustments Mode and Audits Mode.
ATTRACT MODE
The Attract mode provides a light and sound display and a demo game, while the
game is unattended. This feature is to attract potential customers to play the game.
The attract mode sound can be turned on and off (refer to programmable
adjustment P08, page 13 of this manual).
PLAY MODE
This game has two Play modes. The Standard coin play mode, where a coin, or
coins are inserted. Or free play where no coins are necessary.
COIN PLAY
The Coin play mode is entered from Attract mode, by inserting coins in any of the
two coin slots on the front of the machine cabinet, then following the instructions
in the “How to Play” section of this manual.
FREE PLAY
The free play mode is entered from attract mode by holding the Service button for
longer than five seconds. will be displayed on the 4-digit LED display
until the first game is played or attract mode starts.
For a single free game, just press the Service button once. When issuing single
free games in this manner, prizes will be dispensed as normal.
N
OTE: Entering test mode wil
l
lose any unplayed credits.
PROGRAMMABLE
ADJUSTMENTS
MODE
au
dit
s
MODE
Press
TEST
Press
TEST
Press
TEST
Press
TEST
POWER
ATTRACT
MODE
PLAY
MODE
T
EST MODE
* NOTE: Free play mode can only be exited by turning the machine Off
and On. Option P09, determines if prizes are dispensed during Free Play.
FrE
E

Operator's Manual – Timebuster
©
LAI GAMES
Page 9
PRIZE SELECTION AND PAYOUT ADJUSTMENT
Please read the following guide as a good starting point for setting up of your new
“Time buster” machine. By testing different merchandise and fine-tuning the settings
you can maximize your game earnings.
The recommended game operation for maximum earnings, are as follows:
JACKPOT WINS – Approximately ‘1’ win every ‘100’ games. The jackpot prizes
should make up about one half of the machines overall payout.
JACKPOT PRIZE VALUE – Approximately 15 – 20 times the price per play.
JACKPOT PRIZES – Use good quality stock that is currently in demand by the
customers who frequent the machines. Try to use three different types of prizes to
determine which prizes are most desired by the players. You can then use the game
audits (page 15 – 18), to vary the stock accordingly. Varying the prize stock will also
keep interest in the game.
CONSOLATION WINS – Approximately ‘1’ win every ‘10 – 15’ games. The
consolation prizes should make up the other half of the machine payout.
CONSOLATION PRIZE VALUE – Approximately ‘one’ to ‘two’ times the price per
play.
CONSOLATION PRIZES – Use cheaper prizes or sweets for consolation prizes.
Cheaper prizes work well. E.g. If large Disney plush toys are used as a jackpot prize, try
Disney pens or keyrings, as a consolation prize. You can then use the game audits (page
15 – 18) to determine which prizes are most in demand.
PRIZE PAYOUT QUICK REFERENCE TABLE
PRICE PER PLAY 25¢ 50¢ $1.00 $2.00
JACKPOT PRIZE
VALUE $3.50 to $5.00 $7.50 to $10.00 $15.00 to $20.00 $30.00 to $40.00
CONSOLATION PRIZE
VALE 25¢ to 50¢ 50¢ to $1.00 $1.00 to
$2.00 $2.00 to $4.00
AUTOMATIC JACKPOT
PRIZE WINS (P11) 100 100 100 100
AUTOMATIC
CONSOLATION PRIZE
WINS (P12) 10 10 10 10
AUTOMATIC SETTING
(P10) 1 1 1 1
* NOTE: All the following recommendations are based on an approximate
payout of 30%. This payout is recommended for maximum earnings. 30%
payout means that approximately 30% of the game income will be paid out in
prizes. E.g. For every $100 in the cashbox, $30 worth of prizes should be
won.
* NOTE: If manual adjustments are used, adjust the game difficulty (P05) to
achieve similar results.

Operator's Manual – Timebuster
©
LAI GAMES
Page 10
PROGRAMMABLE ADJUSTMENTS MODE
PLAY
MODE
N
OTE: Unplayed credits will be lost.
TEST
MODE
The Display counts, all Lamps are
flashing and Sound is played.
Press
TEST
ATTRACT
MODE
000 0
1
1
1 1
9 9 9 9
Press
S
TART Press COIN
Press
TEST
N
OTE: Switches can be tested in any order.
C 0
C 1 C 2 C 7 C 8
Press
TEST to exit at any time during the Test mode
r r r r
Press
SERVI
TO ENTER TEST
Press
SERVICE Press SERVICE
Press
SERVICE
Press
SERVICE
Press
SERVICE
Press
SERVICE
Press
SERVICE
Press
SERVICE
Press
TEST
TEST MODE
The Test mode has three test configurations allowing you to test the function of the
Sound, Lamps & Display, the Game Switches, and to test the Prize Arm Lights &
motors. (Refer to Diagram below). Test mode can also be used for Clearing Game
Errors, Setting Game Options and Checking Game Audits. (For Game Errors, refer to
the Errors and Troubleshooting section of the manual page 22). Once test mode is
entered, and if there is an active error, it's code will be displayed. To bypass or try to
clear the error code, press the test button.
SOUND, LAMPS & DISPLAY TEST
No INPUT is active
Press SERVICE
STEP
switch is active
TICKET
Notch (optional)
GAME SWITCHES TEST
SERVICE switch is
active TILT sensor is
active
- - - - - - - -
To
PRIZE ARM & MOTOR
TEST
ARM
3
ARM
1 ARM 2
ARM
6ARM
5 ARM
4
ARM
8 ARM
7
STEP TO PRIZE ARM USING SERVICE, PUSH STOP BUTTON TO TEST ARM.
Press STEP BUTTON
TO EXIT

Operator's Manual – Timebuster
©
LAI GAMES
Page 11
ADDITIONAL TEST BUTTON INFORMATION
∗The test button is also used for DISPLAYING & CLEARING
ERRORS. For more information refer to Errors &
Troubleshooting Page 22.
∗Entering Test Mode will CLEAR any CREDITS remaining
in the game.
∗If during test mode no ADJUSTMENTS or actions are made
to the game for approximately four minutes, it will
automatically RETURN to Attract Mode.
SOUND, LIGHT & DISPLAY TEST
ENTER The Sound, Light & Display test is entered from Attract mode by
pressing the test button once.
DURING THE TEST:
♦Game music will be played.
♦All lamps will flash ON and OFF.
♦The 4-digit display will count from 0000 to 9999 and then repeat.
EXIT The Sound, Light & Display test is exited by pressing the test button.
The next test will be switch test.
SWITCH TEST
ENTER The Switch Test can be entered by pressing the Test button once while
in the Sound, Light & display test or by pressing the Test button
twice while in Attract mode. will be displayed on the
4-digit display where ‘X’ is the switches that are active.
TESTING THE GAME SWITCHES
♦All game switches have a code from C1 to C8 as tabled below. By activating
any of the switches, their code will be displayed on the 4-digit display. If no
switches are active, will be displayed.
C0
CX

Operator's Manual – Timebuster
©
LAI GAMES
Page 12
CODE DISPLAY MESSAGE DELIVERED SWITCH LOCATION
C0 C 0 No Input is active
C1 C 1 Ticket Notch Ticket door (Optional)
C2 C 2 Service Switch is active Service Bracket
C3 C 3 Stop Switch is Active Player Control Panel
C4 C 4 Coin Mech. 1 Switch Active Coin Door
C5 C 5 Coin Mech. 2 Switch Active Coin Door
C6 C 6 Prize Sensor is Active Inside Prize Chute
C7 C 7 Tilt Sensor is Active Inside Rear of Cabinet
C8 C 8 Step Switch is Active Player Control Panel
♦Normal condition for the game is either:
∗indicating that no switches are active, or
∗indicating that the Ticket Notch is active (If optional Ticket
Dispenser is fitted).
NOTE: Several switches can be simultaneously activated in Switch test. The
display will then consecutively show their codes, indicating which
switches are active. However, it is much easier to test the game
switches individually.
EXIT The Switch Test is exited into Ball Gate Run Test by pressing the Test
Button once.
PRIZE ARM, LIGHTS & MOTORS TEST
ENTER The Prize Arm, Lights and Motors Test can be entered by pressing
the Test button once, while in Switch test, or by pressing the Test
button three times while in Attract mode. The 4-digit LED display
will show .
DURING THE TEST:
♦Operation of the Prize Arm, Lights and Motors can be tested. To start the test,
press the Service button. The Service button is then pressed again to step
through each prize arm; the arm lamp flashing indicates this. When the start
button is pressed, the motor on the current prize arm i.e., the one with the
flashing lamp, will be powered on. It will keep turning while the start button
is pressed
EXIT The Prize Arm, Lights and Motors Test is exited into Programmable
Adjustments by pressing the Test button once.
C 0
C 1
r r rr

Operator's Manual – Timebuster
©
LAI GAMES
Page 13
PROGRAMMABLE ADJUSTMENTS MODE
GAME ADJUSTMENTS
♦The game has thirteen programmable adjustments that can be changed in this
mode. They are P1 to P13 and their codes and values are displayed
alternatively during the adjustment procedure.
Example: displayed adjustment alternates with its value .
Refer to the diagram below:
♦There is a range of values for each variable of the game, and any value in this
range can be chosen for the game settings, using the change procedure.
ADJUSTMENT PROCEDURE
ENTER The Programmable Adjustments mode is entered from Switch test
button. by pressing the Test button once, or from Attract mode by pressing
the Test button 4 times. This will prompt the code on the
display indicating the program mode.
SELECT The Service button is pressed to step through each of the adjustment
configurati configurations, starting from the display, P01 being the
first step, continuing through to P13, and then looping again from
P01 to P13 until the mode is exited.
CHANGE The Start/Stop button is pressed to change the displayed value. The
value can ONLY be stepped up by using the Start/Stop button, but
the value will loop back to its min value the next step after its max
value.
EXIT The Programmable Adjustments mode is exited into Audits mode, by
button. pressing the Test button once.
* NOTE: Certain program adjustments have a fast adjustment feature. By
holding the Start/Stop button down, the values step through
quicker.
10P 0 1
PPPP
P 0 1
Press
SERVICE
NUMBER OF COINS MECH 1
1, 2, 3, ..., 10
to
change
value
Press
S
TA
R
T
P
1
0
0
1
TEST MODE
Press
TEST
P
P
P
P

Operator's Manual – Timebuster
©
LAI GAMES
Page 14
PROGRAMABLE ADJUSTMENTS QUICK
REFERENCE TABLE
CODE PROGRAMMABLE
ADJUSTMENTS
OPTIONAL
VALUES
DEFAUL
T
SETTIN
GS
FEATURES
P01 1 – 10 1, 2, 3…10 1 COIN SLOT 1 COINS / CREDIT
P02 1 – 10 1, 2, 3…10 1 Coin Slot 1 Plays / Credit
P03 1 – 10 1, 2, 3…10 1 Coin Slot 2 Coins / Credit
P04 1 – 10 1, 2, 3…10 1 Coin Slot 2 Plays / Credit
P05 0.4 – 15milisec 0.4, 0.5, 0.6…15 Auto JACKPOT TIMING
(Adjustable in Manual Only)
P06 1 – 10 1, 2, 3…10 05 CONSOLATION PRIZE RANGE
P07 1 – 20 if range 1 – 5
4.5 – 20 if range 6 – 10 1, 1.2, 1.4…20 4.5, 5.5, 6.5…20 Auto CONSOLATION TIMING
(Adjustable in Manual Only)
P08 ON [ 1 ] or
OFF [ 0 ] [ 1 ] (on), [ 0 ] (off) ON Attract Sound ON / OFF
P09 ON [ 1 ] or
OFF [ 0 ] [ 1 ] (on), [ 0 ] (off) ON PRIZES PAID OUT IN FREE PLAY
ON / OFF
P10 ON [ 1 ] or
OFF [ 0 ] [ 1 ] (on), [ 0 ] (off) ON (Auto) Auto / Adjust ON / OFF
P11 50 – 200 20, 25, 30…800 100 GAME / JACKPOT PRIZE WIN
(Auto on Only)
P12 5 – 20 5, 6, 7…40 10 Games / Consolation Prize Win
(Auto on Only)
P13 0 – 10 0, 1, 2…20 0
Number of Mercy
Tickets / Capsules
(If Optional Ticket Dispenser
or Capsule System Fitted)
P14
Disable Mercy System [0]
Mercy Paid No-win [1]
Mercy Paid all games [2] 1, 2, 3. 0
Mercy System Mode. Disable,
Tickets / Capsules Paid on a No-
Win game or Paid at game credit
(every Game)

Operator's Manual – Timebuster
©
LAI GAMES
Page 15
PROGRAMABLE ADJUSTMENTS DETAILED
P01 = COIN MECH 1: NUMBER OF COINS PER CREDIT
(default 01) (Adjustable 1 – 10)
This variable sets the number of coins that need to be inserted for each game
credit. It can be set to either of 1, 2, 3… to 10 coins for one credit.
P02 = COIN MECH 1: NUMBER OF PLAYS PER CREDIT
(default 01) (Adjustable 1 – 10)
This sets the number of game plays for each credit. It can be set to either of 1, 2,
3… to 10 plays for each credit.
P03 = COIN MECH 2: NUMBER OF COINS PER CREDIT
(default 01) (Adjustable 1 – 10)
This variable sets the number of coins that need to be inserted for each game
credit. It can be set to either of 1, 2, 3… to 10 coins for one credit.
P04 = COIN MECH 2: NUMBER OF PLAYS PER CREDIT
(default 01) (Adjustable 1 – 10)
This sets the number of game plays for each credit. It can be set to either of 1, 2,
3… to 10 plays for each credit.
P05 = JACKPOT PRIZE DIFFICULTY (default Auto)
(Adjustable 0.4 – 15ms)
This adjustment is used to manually adjust the playing difficulty of the top three
jackpot prize arms. It is the time period, in milliseconds, that the jackpot can be
won. A lower number makes the jackpot prizes harder to win. A higher number
makes the jackpot prizes easier to win.
* NOTE: Values of less than 1.0ms is EXTREMELY DIFFICULT to
win
p
rizes on.
* NOTE: The P05 setting is ONLY adjustable if the game is set to
MANUAL. (P10 set to [ 0 ])
If P10 is set to [ 1 ] (automatic game adjustment), the display will show
in the LED display, and cannot be adjusted.
A
u o
t
