Landoll 3631-30 User manual

®
LANDOLL COMPANY, LLC
1900 North Street
Marysville, Kansas 66508
[phone]
800-428-5655 ~WWW.LANDOLL.COM
‘
Pulvi-Mulcher
3631-30 Model
Operator’s Manual
F-982-0223

Manuals for 3631-30 Pulvi-Mulcher
Manual Number Manual Type
F-982 Operator’s Manual
F-981 Parts Manual
F-984 3631-25 / 3631-30 Coil Tine Harrow Kit, Instruction Sheet

DANGER
Failure to comply with this warning may result
in serious injury or possibly death.
DO NOT operate or perform any maintenance tasks on this
equipment until you have completed the following:
1. Receive proper training to operate this equipment safely.
2. Read and understand the operator’s manual.
3. Be thoroughly trained on inspection and repair procedures.

F-982-0223 i
Table of Contents
1 Safety Information
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Description of Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Using this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Owner Assistance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Warranty Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Understanding Safety Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Transporting Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Safety Instructions for Towing Vehicles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Attaching, Detaching and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Maintenance Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Protective Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Tire Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Chemical Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Prepare for Emergencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
High Pressure Fluid Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Safety Chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2 Assembly
Frame Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Rockshaft Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-6
Tire and Wheel Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Rockshaft Cylinder and Transport Lock Installation . . . . . . . . . . . . . . . . . . . . . 2-8
Drawbar Installation (Manual Jack). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-10
Drawbar w/ Hydraulic Jack Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-12
Drawbar Leveling Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Manual Holder and Wrenches Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-16
Wing Fold Hydraulic Cylinder Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-17
Tooth Control Center Frame Cylinder Installation. . . . . . . . . . . . . . . . . . . . . . 2-19
Hydraulics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-19
Plumb Tooth Control Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Plumb Fold Circuit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Plumb Lift Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28

ii F-982-0223
TABLE OF CONTENTS
Purging the Hydraulic System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Purge the Lift Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Purge Fold Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-31
Center Frame Tooth Tube Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-33
Center Frame Shank Mounting Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . 2-34
Center Frame Tooth Control Brackets Mounting Dimensions . . . . . . . . . . . . 2-35
Center Frame Tooth Control Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
Shank Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-38
Shank Depth Control Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-40
Center Frame 2-Row Harrow Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-42
LED Warning Lamp Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-46
SMV Sign Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-46
Bearing Hanger and Wing Rest Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 2-49
Wing to Frame Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-50
Wing Lift Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-52
Left and Right Hand Wing Roller Installation . . . . . . . . . . . . . . . . . . . . . . . . . 2-55
Wing Tooth Control Cylinder Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-58
Wing Tooth Tube Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-59
Wing Shank Mounting Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-60
Wing Tooth Control Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-62
Wing Tooth Control Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-65
Plumb Wing Tooth Control Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-68
Purging the Tooth Control Cylinders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-68
Wing Shank Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-69
Wing 2-Row Harrow Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-70
Roller Clamp Spacer Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-74
Center Rear Scraper Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-76
Wing Rear Scraper Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-78
Center Front Scrapers - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-80
Center Front Scraper Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . 2-81
Wing Front Scraper Installation - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-82
Wing Front Scraper Mounting Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . 2-83
Rear 3-Bar Coil Tine Harrow Kit - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . 2-85
Rear 3-Bar Coil Tine Harrow Without Lift Installation . . . . . . . . . . . . . . . . . . . 2-86
Land Leveler Installation - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-89
Center V-Leveler Installation - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-92
Rear Hitch Installation - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-94
Wing Fold Hydraulic Cylinder With Internal Stop - Optional . . . . . . . . . . . . . . 2-95

F-982-0223 iii
TABLE OF CONTENTS
3 Operation
Tractor Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Pulvi-Mulcher Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Attaching to the Tractor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Hydraulic Lift System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Hydraulic Fold System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Hydraulic Tooth Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
General Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Operation of Rockshaft Transport Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Drawbar Turnbuckle Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Coil Tine Harrow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-10
Land Leveler/V-Leveler - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-11
Scraper Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-13
4 Maintenance
General Torque Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Hydraulic Fitting Torque Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Fasteners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Wheel Hub Bearing Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Hydraulic Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Lubrication Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Roller Axle Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Clamp Tightening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Clamp End Spacers - Optional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
LED Warning Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Maintenance Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
5 Specifications

iv F-982-0223
TABLE OF CONTENTS

F-982-0223 1-1
TABLE OF CONTENTS Chapter 1
Safety Information
Introduction
The implement described in this manual has been
designed with care and built by skilled workers using
quality materials and processes. Proper assembly and
maintenance will provide you with satisfactory use for
seasons to come.
DANGER
DANGER
Description of Unit
The 3631-30 Pulvi-Mulcher features three rows of 2-piece
Field Cultivator S-Tine Shanks for additional frame
clearance and residue flow. 8" Roller Axles with 61mm
bearings include 24" Roller Wheels. A 2-Bar Coil Tine
Harrow located in front of the rear roller provides
additional seedbed leveling. Active Hydraulic Wing Down
Pressure ensures the wings follow the soil contour and
distributes the weight uniformly across the width of the
machine.
Using this Manual
This manual will familiarize you with safety, assembly,
operation, adjustment, and maintenance. Read this
manual and follow the recommendations to help ensure
safe and efficient operation.
• The information in this manual is current at time of
printing. Some parts may have changed to assure top
performance.
• Location reference: Right and Left designations in this
manual are determined by facing the direction the
implement will travel during field operation, unless
otherwise stated.
Owner Assistance
If customer service or repairs are needed, contact your
Brillion dealer. They have trained personnel, parts and
service equipment specially designed for Brillion
products. Your implement’s parts should only be replaced
with Brillion parts. If items covered in this manual are not
understood, contact your local Brillion Dealer.
Warranty Registration
Brillion Farm Equipment, by Landoll, shall have no
warranty obligation unless each product is registered
within 10 days of retail purchase, using the Landoll
Corporation Ag Products on-line registration process.
Please refer to the Ag Products Policy and Procedures
Manual, accessible at www.landoll.com for step by step
instructions regarding product registration.
Enter your product information below for quick reference.
Refer to the ID plate as shown. See Figure 1-1.
MODEL NUMBER
SERIAL NUMBER
DATE OF PURCHASE
Figure 1-1: ID Plate
Read this entire manual before attempting to
assemble, adjust or operate this implement.
Failure to comply with this warning can result in
personal injury or death, damage to the implement
or its components and inferior operation.
MODEL #
SERIAL #
MADE IN USA 1-573-010006
Landoll Company, LLC
Marysville, Kansas
www.landoll.com

1-2 F-982-0223
SAFETY INFORMATION
TABLE OF CONTENTS
Safety
NOTE
Investigation has shown that nearly 1/3 of all farm
accidents are caused by careless use of machinery. Insist
that all people working with you or for you abide by all
safety instructions.
Understanding Safety
Statements
You will find various types of safety information on the
following pages and on the implement decals (signs)
attached to the implement. This section explains their
meaning.
NOTICE
CAUTION
WARNING
DANGER
DANGER
NOTE
You should read and understand the information
contained in this manual and on the implement decals
before you attempt to operate or maintain this equipment.
• Examine safety decals and be sure you have the correct
safety decals for the implement. See Figure 1-3.
• Order replacement decals through your Brillion dealer.
• Keep these signs clean so they can be observed
readily. It is important to keep these decals cleaned
more frequently than the implement. Wash with soap
and water or a cleaning solution as required.
• Replace decals that become damaged or lost. Also,
be sure that any new implement components installed
during repair include decals which are assigned to
them by the manufacturer.
• When applying decals to the implement, be sure to
clean the surface to remove any dirt or residue.
Where possible, sign placement should protect the
sign from abrasion, damage, or obstruction from mud,
dirt, oil etc.
DANGER
DANGER
Transporting Safety
IMPORTANT
It is the responsibility of the owner/operator to
comply with all state and local laws.
• When transporting the implement on a road or
highway, use adequate warning symbols, reflectors,
lights and slow moving vehicle sign as required. Slow
moving tractors and towed implements can create a
hazard when driven on public roads. They are difficult
to see, especially at night.
• Do not tow an implement that, when fully loaded,
weighs more than 1.5 times the weight of the towing
vehicle.
• Carry reflectors or flags to mark the tractor and
implement in case of breakdown on the road.
• Do not transport at speeds over 20 MPH under good
conditions. Never travel at a speed which does not
allow adequate control of steering and stopping.
Reduce speed if towed load is not equipped with
brakes.
• Avoid sudden stops or turns because the weight of
the implement may cause the operator to lose control
of the tractor. Use a tractor heavier than the
implement.
• Use caution when towing behind articulated steering
tractors; fast or sharp turns may cause the implement
to shift sideways.
• Keep clear of overhead power lines and other
obstructions when transporting. Know the transport
height and width of your implement. See
“Specifications” on page 5-1.
Special notice - read and thoroughly understand.
Proceed with caution. Failure to heed caution may
cause injury to person or damage product.
Proceed with caution. Failure to heed warning will
cause injury to person or damage product.
Proceed with extreme caution. Failure to heed
notice will cause injury or death to person and/or
damage product.
• Do not allow anyone to ride on the tractor or
implement. Riders could be struck by foreign
objects or thrown from the implement.
• Never allow children to operate equipment.
• Keep bystanders away from implement during
operation.

SAFETY INFORMATION
F-982-0223 1-3
TABLE OF CONTENTS
Safety Instructions for Towing
Vehicles
The maximum travel speed is the lesser of
• The limit of the road conditions;
• The maximum specified ground speed;
— for towing operations as indicated in this manual
or SIS;
— of the towed vehicle as indicated in its operator’s
manual, SIS, or information sign;
• The maximum ground speed of the towed equipment
combination shall be limited to the lowest specified
ground speed of any of the towed machines. This
speed is the ground speed limitation.
EXAMPLE: If the tractor is capable of 25 mph, the first
implement has a SIS for 19 mph, and the last implement’s
operator’s manual states its specified ground speed is 15
mph, the towed equipment combination ground speed
limitation is 15 mph.
Attaching, Detaching and Storage
• Do not stand between the tractor and implement
when attaching or detaching implement unless both
are blocked from moving.
• Before applying pressure to the hydraulic system, be
sure all connections are tight and that hydraulic lines
and hoses are not damaged.
• Block implement so it will not move when unhitched
from the tractor.
• Relieve pressure in hydraulic lines before uncoupling
hydraulic hoses from tractor.
NOTE
To relieve hydraulic pressure: depending on tractor
hydraulic system, some can be relieved by actuating
control lever after engine is stopped. If tractor has electric
over hydraulic controls, it may be necessary to move the
control lever to the float position with engine running. Refer
to tractor’s operator’s manual. The implement should be
lowered to the ground, this will put the weight on the rollers.
Wear protective gloves and safety glasses or goggles
when working with hydraulic systems.
Maintenance Safety
• Block the implement so it will not move when working
on or under it to prevent injury.
• Transport Locks installed.
• Do not make adjustments or lubricate the machine
while it is in motion.
• Make sure all moving parts have stopped.
• Understand the procedure before doing the work. Use
proper tools and equipment.
Protective Equipment
• Wear protective clothing & equipment appropriate for
the job. Avoid loose fitting clothing.
• Because prolonged exposure to loud noise can cause
hearing impairment or hearing loss, wear suitable
hearing protection, such as earmuffs or earplugs.
Tire Safety
Tire changing can be dangerous and should be performed
by trained personnel using correct tools and equipment.
• When inflating tires, use a clip-on chuck and
extension hose long enough to allow you to stand to
one side, not in front of or over the tire assembly. Use
a safety cage if available.
• When removing and installing wheels use
wheel-handling equipment adequate for the weight
involved.
Chemical Safety
Agricultural chemicals can be dangerous. Improper use
can seriously injure persons, animals, plants, soil &
property.
• Read chemical manufactures instructions and store
or dispose of unused chemicals as specified. Handle
chemicals with care & avoid inhaling smoke from any
type of chemical fire.
• Store or dispose of unused chemicals as specified by
the chemical manufacturer.
Prepare for Emergencies
• Keep a First Aid Kit and Fire Extinguisher handy
• Keep emergency numbers for doctor, ambulance,
hospital and fire department near phone.
High Pressure Fluid Safety
Escaping fluid under pressure can be nearly invisible and
have enough force to penetrate the skin causing serious
injury. Use a piece of cardboard, rather than hands, to
search for suspected leaks.
• Any fluid injected into the skin must be surgically
removed within a few hours or gangrene may result.
• Avoid the hazard by relieving pressure before
disconnecting hydraulic lines.
NOTE
Relieve hydraulic pressure by shifting the control valve
lever to float.
Wear protective gloves and safety glasses or goggles
when working with hydraulic systems.

1-4 F-982-0223
SAFETY INFORMATION
TABLE OF CONTENTS
Safety Chain
Use a Safety Chain to help control drawn machinery
should it separate from the Tractor Drawbar.
• Use a chain with a strength rating equal to or greater
than the gross weight of towed machinery, in
accordance with ASAE S338.2 specifications. If two
or more machines are pulled in tandem, a larger chain
may be required. Chain capacity must be greater that
the total weight of all towed implements.
A second chain should be used between each
implement.
• Attach the chain to the tractor drawbar support or
specified anchor location. Never attach the chain to
an intermediate support. Allow only enough slack in
the chain to permit turning. The distance from hitch
pin to attachment point or intermediate support point
should not exceed 9 inches. See Figure 1-2. If the
distance from the drawbar pin to either the front or
rear chain attachment point exceeds 9 inches,
Intermediate Chain Support is required. See Tractor
Operator’s Manual.
• Replace chain if any links or end fittings are broken,
stretched or damaged.
• Do not use a Safety Chain for towing.
Figure 1-2: Safety Chain
Bolt,1-8 x 8-1/2"
Tractor
Drawbar
Drawbar
Safety Chain Locknut,1-8
Flat Washer,1"
Intermediate
Support
Drawbar
Support

SAFETY INFORMATION
F-982-0223 1-5
TABLE OF CONTENTS
Decals
Figure 1-3: Decals
WARNING
DO NOT GO NEAR LEAKS
High pressure oil easily punctures
skin causing serious injury,
gangrene or death.
If injured, seek emergency medical
help. Immediate surgery is
required to remove oil.
Do not use fingers or skin to
check for leaks.
Lower load or relieve hydraulic
pressure before loosening fittings.
DANGER
FALLING WINGS CAN CAUSE INJURY
OR DEATH. STAND CLEAR WHEN WINGS
ARE BEING RAISED OR LOWERED.
DANGER
To prevent serious injury or death
from pinching:
Keep all persons and objects clear
while any part of this machine is in
motion.
2-573-010335
20
mile/h
144193
ITEM 1
3K706
DANGER
WATCH FOR ELECTRICAL WIRES AND
OTHER OVERHEAD OBSTRUCTIONS WHEN
FOLDING WINGS.
FAILURE TO HEED THESE WARNING
MAY RESULT IN PERSONAL INJURY
OR DEATH.
9J629
ITEM 2
9J629
CAUTION
1.
2.
3.
4.
5.
DO NOT ALLOW ANYONE TO RIDE ON THIS IMPLEMENT.
DO NOT TRANSPORT AT SPEEDS OVER 20 MPH.
DO NOT STAND BETWEEN TRACTOR AND IMPLEMENT WHILE TRACTOR IS MOVING.
WHEN SERVICING IN RAISED POSITION, PLACE BLOCKING UNDER ROLLERS.
WITH WINGS FOLDED AND WEIGHT ON CENTER ROLLER, THE IMPLEMENT IS
DRAWBAR LIGHT.
ITEM 4
5J859
ITEM 6
2-573-010198
ITEM 7
2-573-010335
ITEM 8
3J675
ITEM 10
528933
ITEM 11
528938
ITEM 12
528934
ITEM 13
170510
ITEM 14
144193
BLEED THE AIR FROM WING LIFT CYLINDERS
BEFORE OPERATING. FAILURE TO DO SO WILL
CAUSE MACHINE DAMAGE. SEE OPERATORS
MANUAL FOR CORRECT PROCEDURE.
IMPORTANT
8J635
ITEM 16
8J635
ITEM 9
214146
FARM EQUIPMENT
MANUFACTURERS
ASSOCIATION
MEMBER
ITEM 3
2-573-010037
CAUTION
MOVING MACHINES CAN CAUSE INJURY. KEEP AWAY!
1. KEEP AWAY FROM MOVING TRACTORS OR IMPLEMENTS.
KEEP OTHERS AWAY.
2. DO NOT RIDE OR ALLOW OTHERS TO RIDE ON TRACTOR
OR IMPLEMENT.
3. BLOCK IMPLEMENT TO PREVENT MOVEMENT WHEN
UNHITCHED FROM TRACTOR.
4. KEEP ALL GUARDS AND SHIELDS IN PLACE WHILE
MACHINE OR PARTS ARE IN MOTION. 8J309
ITEM 17
8J309
ITEM 15
2P151
A LANDOLL PRODUCT
ITEM 5
196678
BLUE - LIFT WHEELS
YELLOW - WING FOLD
BLACK - TOOTH CONTROL
RED - HARROW
HOSE IDENTIFICATION
196678
ITEM 18
1-573-010006
MODEL #
SERIAL #
MADE IN USA 1-573-010006
Landoll Company, LLC
Marysville, Kansas
www.landoll.com
PULVIMULCHER
P/N: 232191
ITEM 19
232191

1-6 F-982-0223
SAFETY INFORMATION
TABLE OF CONTENTS
Figure 1-4: Decal Locations (1 of 5)
3630-25 Decal Drawbar
12
1
2
4
5
12

SAFETY INFORMATION
F-982-0223 1-7
TABLE OF CONTENTS
Figure 1-5: Decal Locations (2 of 5)
Front View
Rear View
13 9
10 1313 15 11
10
11
11
11
77
14
6
12
12
10
10

1-8 F-982-0223
SAFETY INFORMATION
TABLE OF CONTENTS
Figure 1-6: Decal Locations (3 of 5)
Side Views 3630-30NC Decal CtrSide
14
8
17
12
17
14
8
12
13
13
9
9
16
12
88
16
12
18
20

SAFETY INFORMATION
F-982-0223 1-9
TABLE OF CONTENTS
Figure 1-7: Decal Locations, Right Hand Wing (4 of 5)
3630-30NC Decal RHWing
3
398
8
8
8

1-10 F-982-0223
SAFETY INFORMATION
TABLE OF CONTENTS
Figure 1-8: Decal Locations, Left Hand Wing (5 of 5)
3630-30NC Decal LHWing
3
8
8
8
3
9
8

F-982-0223 2-1
TABLE OF CONTENTS Chapter 2
Assembly
CAUTION
WARNING
NOTE
Refer to the repair parts manual F-981 for identification of
parts and for the approximate relationship of the parts in
assembly.
To ensure alignment of assemblies, leave the nuts
loose until completion of final assembly. Use lock
washers or flat washers as specified. Spread all cotter
pins.
After completion of final assembly, tighten all nuts
evenly to prevent misalignment, distortion or binding.
Tighten all screws and nuts to the recommended torques.
IMPORTANT
• If pre-assembled parts or fasteners are temporarily
removed, remember where they go. It is best to keep
parts separated.
• Check that all working parts move freely, bolts are
tight and cotter pins spread.
• Refer to the Torque Table for proper torque valves.
Note the different torque requirements for bolts with
locknuts. See Page 5-1.
“Left” and “Right” refer to directions seen as if standing
behind the machine and facing in the direction of forward
travel.
Frame Installation
NOTE
Prior to starting assembly refer to Figure 2-3 for proper
frame placement dimensions. After laying out the
dimensions use a chalk or other marker to help place the
components.
1. Position the Rockshaft on a level surface under the
designated frame assembly area. This will aid in ease
of assembly. See Figure 2-4.
2. Using blocks or other supports, block up the Right
Hand Center Frame approximately 36". Ensure that it
is secure and cannot topple. The Rockshaft should be
positioned approximately halfway between the
supports.
3. Attach the Front and Rear Roller Frame Assembly to
the Right Hand Center Frame Assembly. The Right
Hand Center Frame Assembly consists of an outside
and inside tube. Assemble the outside frame tube
using two 3/4-10 U-Bolts, and Locknuts. Assemble
the inside frame tube using four 3/4-10 x 2-1/2 Bolts
and Locknuts. Do Not tighten at this time. Be sure to
support roller frames.
The process for assembling the Left Hand Center Frame
is the same as the Right Hand. See Figure 2-5.
4. Double check mounting dimensions at this time.
5. Join the front Right and Left Hand Frames together
with Front Cross Tube. Secure with 3/4-10 x 2-1/2
Bolts, Flat Washers and Locknuts. Join the rear Right
and Left Hand Frames with Rear Wing Rest Tube.
Secure using 3/4 x 5-1/4 Pins, Flat Washers and 1/4
x 1-1/2 Roll Pins.
6. Tighten all frame hardware.
7. On the inside frame, position the Front Roller Support
Plate under the Front Roller Frame Tube and secure
with eight 3/4-10 x 2-1/2 Bolts and Locknuts. See
Figure 2-2.
Do not work on or under this machine unless
securely blocked and supported by a hoist or
tractor or by other sufficient means.
Do not attempt to lift heavy parts (such as the
frame, rockshaft, and pull hitch) manually. Use a
hoist or a fork lift to move these parts into
position.

2-2 F-982-0223
ASSEMBLY
TABLE OF CONTENTS
Figure 2-1: Front Roller Support
Front Roller
Support
Bolt,
3/4-10 x 2-1/2
Locknut,3/4-10
Bolt,
3/4-10 x 2-1/2
Locknut, 3/4-10
Front Roller
Frame Asm
