Lattice Semiconductor CrossLink-NX User manual

CrossLink-NX Background Segmentation
Using VVML Board Demonstration
User Guide
FPGA-UG-02161-1.0
June 2022

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
2 FPGA-UG-02161-1.0
Disclaimers
Lattice makes no warranty, representation, or guarantee regarding the accuracy of information contained in this document or the suitability of its
products for any particular purpose. All information herein is provided AS IS, with all faults and associated risk the responsibility entirely of the Buyer.
Buyer shall not rely on any data and performance specifications or parameters provided herein. Products sold by Lattice have been subject to limited
testing and it is the Buyer's responsibility to independently determine the suitability of any products and to test and verify the same. No Lattice
products should be used in conjunction with mission- or safety-critical or any other application in which the failure of Lattice’s product could create a
situation where personal injury, death, severe property or environmental damage may occur. The information provided in this document is
proprietary to Lattice Semiconductor, and Lattice reserves the right to make any changes to the information in this document or to any products at
any time without notice.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02161-1.0 3
Contents
Acronyms in This Document.................................................................................................................................................5
1. Introduction..................................................................................................................................................................6
2. Functional Description..................................................................................................................................................6
3. Demo Setup..................................................................................................................................................................7
3.1. Hardware Requirements.....................................................................................................................................7
3.2. Software Requirements ......................................................................................................................................7
4. Programming the Demo ...............................................................................................................................................8
4.1. Package folder structure.....................................................................................................................................8
4.2. Load Firmware in FX3 I2C EEPROM.....................................................................................................................8
4.3. Programming the CrossLink-NX Voice and Vision SPI Flash................................................................................9
4.3.1. Erasing the CrossLink-NX Voice and Vision SRAM Prior to Reprogramming..................................................9
4.3.2. Programming the CrossLink-NX Voice and Vision Board..............................................................................10
4.3.3. Programming SensAI Firmware Binary to the CrossLink-NX Voice and Vision SPI Flash..............................13
5. Running the Demo......................................................................................................................................................15
5.1. Run Demo..........................................................................................................................................................15
5.2. Ideal Conditions for testing the demo ..............................................................................................................15
Technical Support Assistance .............................................................................................................................................16
Revision History..................................................................................................................................................................17

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
4 FPGA-UG-02161-1.0
Figures
Figure 2.1. VVML Rev-B board - Top View............................................................................................................................6
Figure 4.1. Demo Package Folder Structure .........................................................................................................................8
Figure 4.2. Cypress USB Bootloader –Default Screen..........................................................................................................9
Figure 4.3. Radiant Programmer –Default Screen ...............................................................................................................9
Figure 4.4. Radiant Programmer –Device Selection ............................................................................................................9
Figure 4.5. Radiant Programmer –Device Operation.........................................................................................................10
Figure 4.6. Radiant Programmer –Selecting Device Properties Options for CrossLink-NX Flashing..................................11
Figure 4.7. CrossLink-NX Voice and Vision Flashing Switch –SW5 Push Button ................................................................12
Figure 4.8. Radiant Programmer –Output Console............................................................................................................12
Figure 4.9. Radiant Programmer –Selecting Device Properties Options for CrossLink-NX Flashing..................................13
Figure 4.10. Radiant Programmer –Output Console..........................................................................................................14
Figure 5.1. Running the Demo............................................................................................................................................15

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02161-1.0 5
Acronyms in This Document
A list of acronyms used in this document.
Acronym
Definition
CNN
Convolutional Neural Network
EVDK
Embedded Vision Development Kit
FPGA
Field-Programmable Gate Array
LED
Light-emitting diode
MLE
Machine Learning Engine
NN
Neural Network
NNC
Neural Network Compiler
SD
Secure Digital
SDHC
Secure Digital High Capacity
SDXC
Secure Digital extended Capacity
SPI
Serial Peripheral Interface
VIP
Video Interface Platform
USB
Universal Serial Bus
VVML
Voice & Vision Machine Learning Board

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
6 FPGA-UG-02161-1.0
1. Introduction
This document describes the Semantic Segmentation Demo running process using the Crosslink-NX™ Voice and Vision
Machine Learning platform.
2. Functional Description
Figure 2.1 shows the top view of the VVML board used in this demonstration.
Figure 2.1. VVML Rev-B board - Top View

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02161-1.0 7
3. Demo Setup
This section describes the demo setup.
3.1. Hardware Requirements
•CrossLink-NX Voice and Vision Machine Learning Board, Rev. B
•USB 3.0 A to Micro B cable (To load firmware in FX3 and to run demo using video visualizing tool), USB 2.0 A to
Micro B cable (to program Crosslink-NX VVML board)
•Personal computer
3.2. Software Requirements
•Lattice Radiant™ Programmer version 3 (Refer to http://www.latticesemi.com/programmer)
•Cypress - EZ-USB FX3 Software Development Kit (Refer to https://www.cypress.com/documentation/software-
and-drivers/ez-usb-fx3-software-development-kit)
•Video visualizing tool to see output, user can use one of below tool:
1. VLC Media Player: https://www.videolan.org/vlc/download-windows.html
2. Windows Camera APP: To use windows camera app user must change default webcam if other camera device is
connected to system. For more info user can follow steps mentioned in link: https://answers.microsoft.com/en-
us/windows/forum/all/how-to-change-default-webcam-in-windows-10/1e8377c8-4fd5-4e9c-8ab6-67913c5c8e0c.
3. AMCap: http://noeld.com/programs.asp?cat=video.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
8 FPGA-UG-02161-1.0
4. Programming the Demo
This chapter describes the Semantic Segmentation Demo running process using the Crosslink-NX Voice and Vision
platform.
To Run the demo user will need prebuilt ‘.mcs’ and ‘.bit’ file to program the Crosslink-NX VVML board.
4.1. Package folder structure
Figure 4.1 shows the demo directory structure.
Figure 4.1. Demo Package Folder Structure
4.2. Load Firmware in FX3 I2C EEPROM
4. Connect the USB3 port of the CrossLink-NX Voice and Vision Machine Learning (VVML) Board, Rev B to PC using
USB3 cable and Open the USB Control Centre application (Cypress FX3 SDK needs to be installed for same).
5. Use CrossLink-NX Voice and Vision Machine Learning (VVML) Board, Rev B board and put jumper on J13 to make it
FX3 firmware programmable and connect FX3 cable to PC.
6. Press the Push button switch SW2 on the board to reset the FX3 chip
7. Screen will show the boot loader device as shown in below Figure 4.2. Cypress USB Bootloader – Default
ScreenFigure 4.2.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02161-1.0 9
Figure 4.2. Cypress USB Bootloader –Default Screen
8. Select Cypress USB Bootloader
9. In Menu Bar: Select Program -> FX3 -> I2C E2PROM Browse and Select the FX3 image file for the 640x480p60 16bit
configuration and Firmware will be programmed in the I2C E2PROM
10. Wait for the programming successful message in bottom taskbar
11. After successfully programming the files, remove jumper J13.
12. Power off and power on the board, now FX3 will boot from I2C E2PROM
4.3. Programming the CrossLink-NX Voice and Vision SPI Flash
4.3.1.Erasing the CrossLink-NX Voice and Vision SRAM Prior to Reprogramming
Note: Erase the board if board is already programmed with different demo.
To erase CrossLink-NX Voice and Vision:
1. Launch Lattice Radiant Programmer with Create a new blank project.
Figure 4.3. Radiant Programmer –Default Screen
2. Select LIFCL for Device Family and LIFCL-40 for Device as shown in below image.
Figure 4.4. Radiant Programmer –Device Selection
3. Right-click and select Device Properties.
4. Select JTAG for Port Interface, Direct Programming for Access Mode and Erase Only for Operation as shown in Figure
4.5.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
10 FPGA-UG-02161-1.0
Figure 4.5. Radiant Programmer –Device Operation
5. Click OK to close the Device Properties dialog box.
6. Now press SW5 push button switch before clicking program button in below step and keep it pressed till you see
Successful message in Radiant log window.
7. In the Radiant Programmer main interface, click the Program button to start the erase operation.
4.3.2.Programming the CrossLink-NX Voice and Vision Board
To program the CrossLink-NX Voice and Vision SPI flash:
1. Ensure that the CrossLink-NX Voice and Vision device SRAM is erased by performing the steps in Erasing the CrossLink-
NX Voice and Vision SRAM Prior to Reprogramming.
2. In the Radiant Programmer main interface, right click the CrossLink-NX Voice and Vision row and select Device
Properties to open the Device Properties dialog boxes as shown in Figure 4.6.
3. Select SPI FLASH for Access mode, JTAG2SPI for Port Interface, and Direct Programming for Access Mode.
4. For Programming File, browse and select the CrossLink-NX Voice and Vision bitfile (*.bit).
5. For SPI Flash Options, make the selections in Figure 4.6 to select the Macronix 25L12833F device.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02161-1.0 11
Figure 4.6. Radiant Programmer –Selecting Device Properties Options for CrossLink-NX Flashing
6. Click Load from File to update the Data file size (Bytes) value.
7. Ensure that the following addresses are correct:
•Start Address (Hex): 0x00000000
•End Address (Hex): 0x00110000
8. Click OK.
9. Now press SW5 push button switch before clicking program button in below step and keep it pressed till you see
Successful message in Radiant log window.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
12 FPGA-UG-02161-1.0
Figure 4.7. CrossLink-NX Voice and Vision Flashing Switch –SW5 Push Button
10. In the Radiant Programmer main interface, click the Program button to start the programming operation.
11. Successful programming is displayed in the Radiant Programmer Output console as shown in Figure 4.8.
Figure 4.8. Radiant Programmer –Output Console

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02161-1.0 13
4.3.3.Programming SensAI Firmware Binary to the CrossLink-NX Voice and Vision SPI Flash
4.3.3.1. Flash SensAI Firmware Hex to Crosslink-NX SPI Flash
To program the CrossLink-NX SPI flash:
1. Ensure that the CrossLink-NX device SRAM is erased by performing the steps in Erasing the CrossLink-NX Voice and
Vision SRAM Prior to Reprogramming once before flashing bitstream & SensAI firmware binary.
2. In the Radiant Programmer main interface, right click the CrossLink-NX row and select Device Properties to open the
Device Properties dialog boxes as shown in Figure 4.9.
3. Select SPI FLASH for Target Memory, JTAG2SPI for Port Interface, and Direct Programming for Access Mode.
4. For Programming File, browse and select the CrossLink-NX SensAI firmware binary file after converting it to hex
(*.mcs).
5. For SPI Flash Options, make the selections in Figure 4.9 above to select the Macronix 25L12833F device.
Figure 4.9. Radiant Programmer –Selecting Device Properties Options for CrossLink-NX Flashing
6. Click Load from File to update the Data file size (Bytes) value.
7. Ensure that the following addresses are correct:
•Start Address (Hex): 0x00300000
•End Address (Hex): 0x00400000
8. Click OK.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
14 FPGA-UG-02161-1.0
9. Now press SW5 push button switch before clicking program button in below step and keep it pressed till you see
Successful message in Radiant log window.
10. In the Radiant Programmer main interface, click the Program button to start the programming operation.
11. Successful programming is displayed in the Diamond Programmer Output console as shown below.
Figure 4.10. Radiant Programmer –Output Console

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02161-1.0 15
5. Running the Demo
5.1. Run Demo
To run the demo:
1. Power on Voice and Vision Board.
2. Connect the Voice and Vision board to the PC via board’s USB3 port
3. Open the Windows utility and select the FX3 Device as source and usb port to maximum number port available.
4. The camera image should be displayed on monitors shown in below figure Figure 5.1.
Figure 5.1. Running the Demo
5.2. Ideal Conditions for testing the demo
•Distance: Users should be in range up to 3 feet distance.
•Decent light is needed to run demo. Too low and direct light from light source may reduce the performance of
demo.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
16 FPGA-UG-02161-1.0
Technical Support Assistance
Submit a technical support case through www.latticesemi.com/techsupport.

CrossLink-NX Background Segmentation Using VVML Board Demonstration
User Guide
© 2022 Lattice Semiconductor Corp. All Lattice trademarks, registered trademarks, patents, and disclaimers are as listed at www.latticesemi.com/legal.
All other brand or product names are trademarks or registered trademarks of their respective holders. The specifications and information herein are subject to change without notice.
FPGA-UG-02161-1.0 17
Revision History
Revision 1.0, June 2022
Section
Change Summary
All
Initial release.

www.latticesemi.com
