LEGRAND DRD5 v2 User manual

Recall a recorded scene
1. Press the appropriate scene button.
2. Watch the scene smoothly transition from the previous lighting state.
You can recall the same scene from any house scene controller assigned to
the same set of house scenes (see More Scenes, below).
Modify the light levels of a house scene
1. Recall the recorded scene.
2. Change lighting levels as desired by pressing or on individual devices.
3. Press and hold the scene button until the LED flashes once (approximately 2
seconds) to save the new settings.
Modify a previously recorded house scene
Use the Record a Whole-house Scene procedure to modify the devices assigned to
an existing house scene.
More Scenes
You can increase the number of house scenes to 10 by adding a second DRD5 to
the house, then changing the “scene set assignment” on one of them. The DRD5
scene set assignment is 1-5 when shipped. Changing the second DRD5 scene set
assignment to 6-10 allows you to record another 5 scenes that can be accessed by
any house scene controller (DRD5 and MRH5G) that has a scene set assignment
of 6-10.
All house scene controllers that have the same scene set
assignment operate the 5 scenes in the same way as all
other house scene controllers programmed for the same
set (1-5 or 6-10).
To assign the controller for scenes 6-10, simultaneously
press and button B for 2 seconds.
To change the assignment back to scenes 1-5,
simultaneously press and button A for 2 seconds.
A = scenes 1-5 (default)
B = scenes 6-10
Power Fail Memory
After a power failure, all Miro devices automatically return to the state they
were in immediately prior to loss of power. All house binding and scene control
information is preserved.
Assigning the DRD5
for scene set 6-10

Lock House Configuration
The Lock Configuration function operates from a wireless Miro house scene
controller, and prevents the Miro wireless devices in the system from being
reprogrammed. Normal operations such as dimming, switching, scene recall and
scene light level modifications are not affected.
When the configuration is locked, if the rocker paddle on any Miro wireless
device is pressed and held (- -), the selected device’s LED flashes red, and the
command is ignored.
To lock the configuration:
Go to any house scene controller. Simultaneously press and buttons
Band Efor 2 seconds to toggle in and out of Lock Configuration mode.
 • Ifthemodechangesfromunlockedtolocked,theLEDflashesredfor2
seconds, indicating that configuration is now locked.
 • Ifthemodechangesfromlockedtounlocked,theLEDflashesgreenfor
2 seconds, indicating that configuration is now unlocked.
CLEANING
Clean using a cloth dampened only with water and a little mild detergent. Use of
solvents or hydrocarbon-based cleaners may cause permanent damage.
TROUBLESHOOTING
During Set House ID, the LED is not flashing on some Wireless Miro
devices.
• If LED is solid green before initiating House ID binding:
ThedevicealreadyhasanotherHouseID.Resetittothefactorydefaultso
thatitcanbeboundtothedesiredHouseID.Resettingtofactorydefaultsis
describedinthe“Ineedtostartover”issue.
• If LED is solid yellow after initiating House ID binding:
The device may be out of range of the initiating device. Add a MRR2G Wire-
less Miro Repeater to boost signal range.
I made a configuration mistake. I need to start over.
You can reset any wireless Miro device to factory default settings by press-
ing and holding until the LED changes to solid yellow (approximately 10
seconds). During the process, the LED flashes yellow and when complete,
it changes to solid yellow. The device can then be reconfigured, exactly like
any new device.

FCC Notice
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmenttoanoutletonacircuitdifferentfromthattowhichthe
receiver is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
WARRANTY INFORMATION
Manufacturer warranties its products to be free of defects in materials and
workmanship for a period of five (5) years. There are no obligations or liabilities
on the part of manufacturer for consequential damages arising out of, or
in connection with, the use or performance of this product or other indirect
damages with respect to loss of property, revenue or profit, or cost of removal,
installation or reinstallation.
Please
Recycle
Legrand Customers contact: Vantage Customers contact:
1061 South 800 East
Orem, UT 84097
Phone: [phone]
www.vantagecontrols.com
07478r39/2007
301 Fulling Mill Road Suite G
Middletown, PA 17057
Phone: [phone]
www.legrand.us/onq

Patents pending
DRD5 v2
Wireless House Scene Controller
Installation Instructions
Specifications
OperatingVoltage .....................120/277VAC,60Hz
Operating Temperature . . . . . . . . 32°F to 104°F (0°C to 40°C)

UNIT DESCRIPTION
The Miro Decorator DRD5 Wireless House Scene Controller provides instant
recall of five user-recorded lighting scenes (or presets) across the entire
house.TheDRD5isawhole-housecontroller.Itisusedincombinationwithany
number of Miro Decorator wireless dimming or non-dimming devices.
The DRD5 can be differentiated from a Wireless Room Scene
Controller by the icon on its front, which resembles the outline of a
house exterior.
Typical locations for installing Miro Decorator wireless scene controllers are
inside the front door, the door from the garage, and the master bedroom. With
two or more controllers, you can control up to ten scenes in the house (see
OPERATIONsection).Youcaninstalladditionalhousescenecontrollersto
control those scenes from other locations in the house.
The Miro Decorator wireless house scene controller works as part of a Miro
Decoratorwirelesssystem.ItcancontrolavarietyofMiroDecoratorwireless
devices including dimmers, switches, appliance plugs and lamp plugs to create
up to five scenes. For example:
• Setthehousetosleep,turnlightsoffdownstairsbutleavelow-levelpathway
lighting for the kids to find the bathroom.
• Lightupthewholehouseforapartysetting.
• Createalightingtrailtogetyouthroughyourmorningandeveningroutines,
turning on the lights in dressing rooms, hallways and the kitchen, and perhaps
aTVorradiosoyoucanlistentothenews.
Note: To control a single room, use a Miro Decorator wireless room scene
controller (a wall mounted DRD6 or a handheld MRH6G remote).
Miro Wireless
Miro wireless devices use radio signals to communicate with each other to
control lighting and other types of electric loads in selected areas. Miro wireless
devicesusethe900MHzbandforhigh-speedcontrolcommunication.Usingthe
patented “frequency-agile” Top Dog™ technology, Miro wireless devices avoid
interferencewithother900MHzdevices,suchascordlessphonesandbaby
monitors.
Application Assistance
The Miro Installation Guide provides more information about configuring scenes
andpresets.Instructionsforinstallationanduseareincludedwiththerelevant
Miro wireless devices. Application support information and the Miro Installation
Guide are available on-line.

Wire Legend
Ground
Line
Neutral
GND
LINE
NEUT
SUPPLY
WIRES
INSTALLATION
For ease of installation, manufacturer recommends use of a deep
wall box. The device is equipped with flying leads to simplify installation,
however, if desired, they may be removed by loosening the screw terminals.
1. Disconnect power to circuit by turning circuit breaker OFF before installation.
2. Remove existing wall plate and switch.
3. Stripexistingwires1/2”.Iftwowireswillbeconnectedtothesameterminal
on a Miro device, both wires must be the same gauge (12AWG
or 14AWG).
4. WiretheLINE(black),NEUTRAL(white)andGNDsupplywirestothe
correspondingly marked screw terminals, according to the wiring diagram.
5. Attach the wall plate.
6. Switch the circuit breaker back ON.
INSTALL IN COMPLIANCE WITH ALL APPLICABLE
CODES & STANDARDS.
Failure to follow these instructions may cause
personal injury or equipment damage.
CAUTION
TURN THE POWER OFF AT THE CIRCUIT BREAKER
BEFORE INSTALLING THE DEVICE.

SET HOUSE ID
All Miro wireless devices installed in the same home must acquire the same
uniqueHouseIDbeforeuse.Thisprocessisknownashousebinding.EachMiro
wireless device is bound to all other Miro wireless devices in the house.
New Installation
1. Withalldevicesinstalledandenergized,makesurethateveryMirowireless
deviceLEDisyellow.IfanyLEDisoff,besurethecircuitbreakerisonandthe
device is correctly installed.
2. Press on any device paddle
until the LED flashes yellow (about
2 seconds). This indicates that it has
acquiredauniqueHouseID.
3. Make sure that all other Miro wireless
device LEDs are flashing green,
indicating that they have acquired the
sameHouseID.
4. Return to the device used in step 2, which is still flashing yellow. Press
until the LED changes to solid green (about 2 seconds). All device LEDs in the
house change to solid green, indicating house binding is complete.
Adding a Device to an Existing Installation
Ifyou’readdingorreplacingadeviceinaMirowirelessinstallationthatis
alreadyoperating,thenewdevicemustacquirethesameHouseIDastheother
Miro wireless devices in the house. After the new device is powered up, the LED
shouldbesolidyellow.ThisindicatesthatithasnotyetacquiredaHouseID.To
acquiretheHouseIDfortheexistingsystem:
1. Press on any previously bound device until the LED flashes yellow (about 2
seconds).
2. VerifythatthenewlyaddeddeviceLEDisflashinggreen,indicatingthatithas
acquiredtheHouseID.
3. Return to the same previously bound device used in step 1 and press until
the LED changes to solid green (about 2 seconds). All device LEDs should now
be solid green.
When you see
in the instructions,
firmly press and
hold both the top
and bottom of
the paddle until
the LED changes
(about 2 seconds).

OPERATION
Button and Paddle Functions
The rocker paddle has a house icon on it. Use it to begin and end binding and
scenerecordingfunctions.ItcanalsobeprogrammedasanON/OFFswitch,
using steps 1-3 of the Record a Whole-House Scene process described below.
Once programmed: Tap to switch or fade included devices to on (dimming
devices go to full bright). Tap to switch or fade included devices to off.
The smaller buttons, labeled A—E in the illustrations, are used to record and
recall scenes. Extra labels are provided so that you can relabel these buttons to
better suit your application.
Default Settings: InanewDRD5,whenyoutap or the E button, ALL Miro
Wirelessdevicesinthehouseturnoff.If,however,thenewDRD5isaddedtoan
existing house, it acquires the same scenes as any other DRD5 or MRH5G that is
assigned to the same set of scenes (see More Scenes).
Record a Whole-House Scene
1. Go to the DRD5 and press until the LED begins flashing (about 2 seconds).
Pressthedesiredscenebutton,ortaptheON/OFFpaddlethatyouwishto
program. The LEDs on all the Wireless Miro devices begin to flash. You now
have 10 minutes to complete this process.
2. To include or exclude a device in the scene press on the device until the
LED changes color. YellowflashingLED=Includedintheactivescene
Green flashing LED = NOT included in the active scene
 IfyougettoadeviceanditisNOTflashing,the10minutebindingprocess
timer may have expired. Go back to step 1 and repeat.
NOTE: You must include devices that are off in the house scene if you want
them to turn off when that scene is recalled.
3. Return to the DRD5 used in step 1. Press for 2 seconds — the status LED
stops flashing, then all the status LEDs in the house revert to green.
4. Go around the house and adjust light levels by pressing and holding or
on the devices that you want to adjust.
5. Go back to the DRD5 used in step 1 and press and hold the same scene button
until the LED flashes once (about 2 seconds). Scene recording for this button
is complete. Repeat this process for each scene button.
When you see
in the instructions,
touch the top of the
paddle as directed.
When you see in the
instructions, touch the
bottom of the paddle
as directed.

4-FOLD
•Print:2-sides
•InkColor:Black
•Paper:White16lb(60g/msq)
Uncoated, prefer recycled stock
•Finaltrimsize:16”(Wide)x6”(High).
•Four(4)fold.
•Finalfoldedsize:4”(Wide)x6”(High).
TITLE BOX PAGE ONLY.
DO NOT MAKE FILM • DO NOT PRINT
SANTA CLARA, CALIFORNIA
Title: DRD5 v2 Installation Instructions
IFYOUHAVEANYQUESTIONSREGARDINGSPECIFICATIONSORREQUIRE
ADDITIONALFILEFORMATTING,PLEASECONTACTMaryJoSowinski.
Phone: [phone]
Email: [email protected]
Drawing #:
07478
Orig. Drawing Date: 16 MAR 07 Rev. #:
3
Revision Date: 24 SEP 07
SOWINSKI
Scale: 1:1
All information in this drawing is the property of Watt Stopper/Legrand and cannot be copied or
used without the written approval of Watt Stopper/Legrand.
Drawn by
PLM
MarCom
Engineering
QA
TITLE BOX PG
REV DESCRIPTION INT: REV. DATE APPROVED
1 ECO#C01933 MJS 3/28/07 CG
2 EC0#C02227 MJS 4/23/07 CG
3 ECO#C02411 MJS
