1. GENERAL CHARACTERISTICS
1.1 Presentation
Legrand PDUs are designed for supplying power to equipment in 19’’
enclosures.
They comprise:
- an aluminium casing
- socket modules
- additional functions
- a termination solution
- a mounting solution
Single-phase 230V – 50/60 Hz or three-phase 380 V – 50/60 Hz power
supply
The range features three main product families:
- PDUs designed for horizontal installation (10’’and 19’’PDUs)
- PDUs designed for vertical installation (Zero-U PDUs)
- Accessories
PDUs designed for horizontal installation (10’’and 19’’PDUs)
10’’PDUs to be installed on 10’’mounting uprights and 19’’PDUs to be
installed on 19’’mounting uprights. 1U height casing for compactness.
Integrated cable guide. Screwless snap-on fixing. End pieces with 180°
reversible metal brackets for vertical mounting capability.
PDUs designed for vertical installation (Zero-U PDUs)
For vertical installation on the rear of cabinets to save 19’’ space within
it.
Cable inlet can be rotated 330° to ensure perfect alignment of the
power cable.
Supplied with 2 sets of metal fixings: button for screwless fixing, or
standard screw-type brackets.
Accessories
- Replacement surge protection module to ensure continuity of service
- Locking caps for locking out the use of an outlet
See the detailed description of these accessories in the "Functions"
section.
Legrand's PDU offer is available as standard catalogue versions (see
the corresponding descriptions in the "Equipment and performance"
section) and as customized configurations.
1.2 Mechanical characteristics
- Casing: 6060 T5-R19 natural anodised aluminium
Dimensions in mm:
44.3
1U casing
23° view
CONTENTS Page
1. GENERAL CHARACTERISTICS .............1
2. EQUIPMENT AND PERFORMANCE ........3
3. FUNCTIONS..............................8
4. DIMENSIONS ...........................11
5. INSTALLATION ..........................12

2/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-05 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/19/
20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
51.
1
52
View from above
End viewSide viewEnd view
1U casing
Ze
ro-U casing
- Outlet modules:
PC/ABS
CW507L (CuZn 36) brass
- Fixing brackets:
DC01-A-m galvanised steel
1.3 Standards, regulations and tests
Depending on what equipment they comprise, the PDUs comply with
the current applicable standards below:
Application Standard
French/Belgian standard plugs/outlets
IEC/TR 60083
German standard plugs/outlets
UK standard plugs/outlets + electrical accessories
Italian standard outlets
Swiss standard outlets
C13 and C19 connectors for electrical equipment IEC 60320-2-2
Low voltage surge protection device IEC 6164-11
Switch IEC 60058-1
MCB IEC 60898-1
RCBO IEC 61008-1
Thermal circuit breaker IEC 60730-2-9
Industrial plug IEC 60309-1
Information-processing equipment IEC 60950-1
IP: IP40 for French/Belgian, German, Swiss, Italian and UK standards and
IP20 for electrical appliance connectors (C13 and C19)
IK07
Glow-wire flammability test: The various different standard outlets and
the other functions that equip the PDUs meet the requirements of their
respective standards relating to abnormal heat and fire resistance and
comply with the following thresholds:
- Plastic parts in contact with live parts: 750 °C
- Other plastic parts: 650 °C
Temperature rise: The PDUs are compliant with the standard
temperature rise limit of 45 °C for French/Belgian, German, Swiss and
Italian standards and electrical appliance connectors (C13 and C19) and
52 °C for the UK standard.
Final inspection: Compliant with European standard requirements and
Legrand's own manufacturing requirements, all products undergo
production tests, including:
- Electrical continuity to ensure the product is wired correctly
- Dielectric strength at 2000 V to ensure there is no leakage current
- Operating test
RoHS and REACH conformity: The PDUs comply with European
standards and therefore meet the requirements of the RoHS directive
(Restriction of Hazardous Substances) and REACH regulations
(Registration, Evaluation, Authorisation & restriction of CHemicals).

3/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
2. EQUIPMENT AND PERFORMANCE
2.1 Composition of each catalogue number
10" PDUs
6 468 98 6 468 00 6 468 01
Number of phases 1 1 1
Input voltage 230 V 230 V 230 V
Input current 16 A 16 A 16 A
Maximum power 3.7kW 3.7kW 3.7kW
Termination method Cord Cord
Cable length 1 m 1 m
Cable material PVC HO5VVF PVC HO5VVF
Cable cross-section 3G 1.5 3G 1.5
Plug type Schuko/UTE Schuko/UTE
Cable retention method Cableclamp + guide Cableclamp + guide
Number and type of outlets 4 French/Belgian 4 German
Outlets colour Black Black
Angle of outlets 55° 55°
Number of circuits per phase 1 1
Casing Zero-U aluminium 1U aluminium 1U aluminium
Fixings (included) 19’’reversible bracket + snap-on fixing 19’’reversible bracket + snap-on fixing 19’’reversible bracket + snap-on fixing
19" PDUs
6 468 05 6 468 06 6 468 07 6 468 09 6 468 10 6 468 11 6 468 12 6 468 13 6 468 14
Number of phases 1 1 1 1 1 1 1 1 1
Input voltage 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V
Input current 16 A 16 A 16 A 16 A 16 A 16 A 16 A 13 A 16 A
Maximum power 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3kW 3.7kW
Termination method Cord Cord Terminal
block**
Terminal
block**
Cord Cord Cord Cord Terminal
block**
Cable length 3 m 3 m 3 m 3 m 3 m 3 m
Cable material PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
Cable cross-section 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5
Plug type Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
BS 1363
Cable retention method Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Number and type of outlets* 6 French/
Belgian
6 German 6 C19 with
locking
6 C13 + 2
C19 with
locking
9 French/
Belgian
9 French/
Belgian
tamper-
proof
9 German 8 UK 10 C13
with
locking
Outlet colour Black Black Black Black Black Red Black Black Black
Angle of outlets 55° 55° 90° 90° 55° 55° 55° 90°
Number of circuits per phase 1 1 1 1 1 1 1 1 1
Additional functions
Casing 1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
Fixings (included) 19’’reversible bracket + snap-on fixing
* Outlets are equally distributed on each circuit
** Maximum capacity of terminal block 6 mm²

4/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
19" PDUs (continued)
6 468 15 6 468 18 6 468 19 6 468 20 6 468 21 6 468 22 6 468 23 6 468 24 6 468 30
Number of phases 1 1 1 1 1 1 1 1 1
Input voltage 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V
Input current 16 A 16 A 16 A 16 A 16 A 16 A 16 A 13 A 16 A
Maximum power 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3kW 3.7kW
Termination method Cord Cord Cord Cord Cord Cord Cord Cord Cord
Cable length 3 m 3 m 3 m 3 m 3 m 3 m 3 m 3 m 3 m
Cable material PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
Cable cross-section 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5
Plug type IEC 60309
16 A 2P+E
T23 SEV
1011
T23 SEV
1011
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
BS 1363 Schuko/
UTE
Cable retention method Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Number and type of outlets* 12 C13
with
locking
12 T13
Swiss
standard
12 T23
Swiss
standard
9 French/
Belgian
9 German 8 French/
Belgian
8 German 6 UK 6 French/
Belgian
Outlet colour Black Black Black Black Black Black Black Black Black
Angle of outlets 90° 90° 90° 55° 55° 55° 55° 55°
Number of circuits per phase 1 1 1 1 1 1 1 1 1
Additional functions Power
indicator
Power
indicator
Luminous
switch
Luminous
switch
Luminous
switch
1P MCB
C16 6 kA
Cat.No.
4 136 06
Casing 1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
Fixings (included) 19’’reversible bracket + snap-on fixing
* Outlets are equally distributed on each circuit

5/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
19" PDUs (continued)
6 468 31 6 468 32 6 468 33 6 468 35 6 468 36 6 468 40 6 468 41 6 468 42 6 468 43
Number of phases 1 1 1 1 1 1 1 1 1
Input voltage 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V
Input current 16 A 16 A 16 A 16 A 16 A 16 A 16 A 16 A 16 A
Maximum power 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW 3.7kW
Termination method Cord Cord Cord Cord Cord Cord Cord Cord Terminal
block**
Cable length 3 m 3 m 3 m 3 m 3 m 3 m 3 m 3 m
Cable material PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
PVC
HO5VVF
Cable cross-section 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5 3G 1.5
Plug type Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Schuko/
UTE
Cable retention method Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Cable
clamp +
guide
Number and type of outlets* 6 German 9 German 6 French/
Belgian
6 French/
Belgian
6 German 6 French/
Belgian
6 German 6 German/
Italian
6 C13 with
locking
Outlet colour Black Black Black Black Black Black Black Black Black
Angle of outlets 55° 55° 55° 55° 55° 55° 55° 90° 90°
Number of circuits per phase 1 1 1 1 1 1 1 1 1
Additional functions 1P MCB
C16 6 kA
Cat.No.
4 136 06
1P MCB
C16 6 kA
Cat.No.
4 136 06
1P RCBO
C16 6 kA
30 mA
AC type C
curve
Cat.No.
4 107 05
Surge
protection
module
Luminous
switch
Surge
protection
module
Luminous
switch
Ammeter Ammeter Ammeter Ammeter
Casing 1U
aluminium
2x1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
1U
aluminium
Fixings (included) 19’’reversible bracket + snap-on fixing
* Outlets are equally distributed on each vertical PDU circuit
** Maximum capacity of terminal block 6 mm²

6/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
19”PDUs (continued)
6 468 44 6 468 45 6 468 99
Number of phases 1 1 1
Input voltage 230 V 230 V 230 V
Input current 16 A 16 A 16 A
Maximum power 3.7kW 3.7kW 3.7kW
Termination method Terminal
block**
Terminal
block**
Cable length
Cable material
Cable cross-section
Plug type
Cable retention method Cable
clamp +
guide
Cable
clamp +
guide
Number and type of outlets* 6 C19 with
locking
6 C13 + 1
C19 with
locking
Outlet colour Black Black
Angle of outlets 90° 90°
Number of circuits per phase 1 1
Additional functions Ammeter Ammeter
Casing 1U
aluminium
1U
aluminium
Zero-U
aluminium
Fixings (included) 19’’reversible bracket + snap-on fixings
* Outlets are equally distributed on each vertical PDU circuit
** Maximum capacity of terminal block 6 mm²
Zero-U PDUs
646850 646851 646852 646853 646854 646856
Number of phases 1 1 1 1 1 1
Input voltage 230 V 230 V 230 V 230 V 230 V 230 V
Input current 32 A 32 A 32 A 32 A 32 A 32 A
Maximum power 7.4kW 7.4kW 7.4kW 7.4kW 7.4kW 7.4kW
Termination method Terminal block** Cord Terminal block** Cord Terminal block** Terminal block**
Cable length 3 m 3 m
Cable material Rubber HO7RNF Rubber HO7RNF
Cable cross-section 3G 4 3G 4
Plug type IEC 60309 32 A
2P+E
IEC 60309 32 A
2P+E
Cable retention method Cable clamp +
rotatative system
Cable clamp +
rotatative system
Cable clamp +
rotatative system
Cable clamp +
rotatative system
Cable clamp +
rotatative system
Cable clamp +
rotatative system
Number and type of outlets* 24 French/Belgian 24 French/Belgian 24 German 24 German 24 UK 24 C13 with
locking
Outlet colour Black Black Black Black Black Black
Angle of outlets 55° 55° 55° 55° 55° 90°
Number of circuits per phase 2 2 2 2 2 2
Identification of circuits (colour-code) Blue/Red Blue/Red Blue/Red Blue/Red Blue/Red Blue/Red
Additional functions 1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
Casing Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium
Fixings (included) 2 button + 2 standard brackets, 2 Minkels brackets + 2 screws
** Maximum capacity of terminal block 6 mm²

7/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
Zero-U PDUs (continued)
646857 646859 646860 646861 646865 646870
Number of phases 1 1 1 1 1 3
Input voltage 230 V 230 V 230 V 230 V 230 V 400 V
Input current 32 A 32 A 32 A 32 A 32 A 16 A
Maximum power 7.4kW 7.4kW 7.4kW 7.4kW 7.4kW 11kW
Connection method Cord Cord Terminal block** Cord Terminal block** Cord
Cable length 3 m 3 m 3 m 3 m
Cable material Rubber HO7RNF Rubber HO7RNF Rubber HO7RNF Rubber HO7RNF
Cable cross-section 3G 4 3G 4 3G 4 5G 2.5
Plug type IEC 60309 32 A
2P+E
IEC 60309 32 A
2P+E
IEC 60309 32 A
2P+E
IEC 60309 16 A
3P+N+E
Cable retention method Cable clamp +
rotative system
Cable clamp +
rotative system
Cable clamp +
rotative system
Cable clamp +
rotative system
Cable clamp +
rotative system
Cable clamp +
rotative system
Number and type of outlets* 24 C13 with
locking
24 German/Italian 20 C13 + 4 C19
with locking
20 C13 + 4 C19
with locking
20 C13 + 4 C19
with locking
18 C13 + 6 C19
with locking
Outlet colour Black Black Black Black Black Black
Angle of outlets 90° 90° 90° 90° 90° 90°
Number of circuits per phase 2 2 2 2 2 1
Identification of circuits (colour-code) Blue/Red Blue/Red Blue/Red Blue/Red Blue/Red
Additional functions 1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1P+N MCB C16
10 kA
Cat.No. 4 077 00
1 ammeter per
circuit
1P MCB C16 10 kA
Cat.No. 4 076 54
Casing Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium Zero-U aluminium
Fixings (included) 2 button + 2 standard brackets, 2 Minkels brackets + 2 screws
646875
Number of phases 3
Input voltage 400 V
Input current 16 A
Maximum power 11kW
Connection method Cord
Cable length 3 m
Cable material Rubber HO7RNF
Cable cross-section 5G 2.5
Plug type IEC 60309 16 A
3P+N+E
Cable retention method Cable clamp +
rotative system
Number and type of outlets* 18 C13 + 6 C19
with locking
Outlet colour Black
Angle of outlets 90°
Number of circuits per phase 1
Identification of circuits (colour-code)
Additional functions 1P MCB C16 10 kA
Cat.No. 4 076 54
1 ammeter per
circuit
Casing Zero-U aluminium
Fixings (included) 2 button + 2
standard brackets,
2 Minkels brackets
+ 2 screws
* Outlets are equally distributed on each circuit
** Maximum capacity of terminal block 6mm²

8/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-05 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/19/
20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
2.2 Customized products
Legrand PDUs can be delivered with custom configurations to meet
specific customer requirements. Contact your local sales representative
to discuss your requirements.
Example:
19’’ PDU 1U with 2 x 2P+E French/Belgian standard outlets, 1 C19 socket
and 6 C13 sockets.
Supplied with 3 m cable and C20 plug
Example:
Zero-U PDU with 12 2P+E French/Belgian standard outlets.
Red strips for PDU identication purposes. Supplied with rotative
cable entry, 4.5 m cable and IEC 60309 16 A plug
CONFIGURATION EXAMPLES
3m
4.5 m
3. FUNCTIONS
3.1 Outlets
Legrand PDUs can be equipped with outlets of different standards.
C13 with cord locking system
2P+E 10 A
Outlet recess at 90° angle
Conforms to standard IEC 60320-2-2
C19 with cord locking system
2P+E 16 A
Socket recess at 90° angle
Conforms to standard IEC 60320-2-2
Cord locking system on C13/C19 sockets
The cord is locked mechanically into the outlet to prevent any
unintended disconnection (caused by maintenance, vibrations, etc.).
Pull-out force > 100 N
This universal solution is compatible with all standard cords available on
the market.
French-Belgian
2P+E 16 A
Terminals equipped with protective shutters
Outlet recess at 55° angle
Conforms to standard IEC 60320-2-2
German
2P+E 16 A
Terminals equipped with protective shutters
Outlet recess at 55° angle
Conforms to standard IEC 60320-2-2
UK
2P+E 13 A
Terminals equipped with protective shutters
Outlet recess at 90° angle
Conforms to standard IEC 60320-2-2
3.2 LED switch
The LED switch is used to control the PDU power supply.
A white LED is lit when the PDU sockets are supplied
with power.
16 A switch
Transparent switch
3.3 Power indicator
A white LED on the power indicator shows that the product is supplied
with power.
3.4 Ammeter
The ammeter is used to measure consumption for enhanced installation
management.
Operation: 230 VAC 50Hz
Measured value: current (0 to 32 A)
Operates by measuring the current using a shunt
3-digit display "XX.X"
Rotatable display for legible readout regardless of whether the PDU is
mounted vertically or horizontally
mA p
m
Ap
B
A
Amp
Amp

9/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-05 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/19/
20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
3.5 Surge protection and replacement module
Protection between Line and neutral of socket outlets connected
downstream against overloads generated by the electrical network
upstream of the surge protective device by creating a discharge current
on the network and/or earthing link.
To be used in combination with a voltage surge protector installed in
the panel..
PROTECTED
POWER
PROTECTED
POWER
PROTECTED
POWER
PROTECTED
POWER
B
A
ON
PROTECTED
POWER
PROTECTED
POWER
ON
6 468 97
ON
Operation
• Surge protective devices are designed to limit transient overvoltages
of atmospheric and industrial origin.
• They have a certain capacity to absorb energy and age with each
operation; it is therefore normal for them to be out-ot-order after a
certain number of operations. The imminent out-of-order status is
signalled and the draw-out module should be replaced.
• Surge protective devices are designed to be installed at use points and
are to be used in combination with the installation’s original modular
protection.
• They are not designed to provide sole protection for an installation
in a building likely to be hit by direct lightning strikes (e. g. buildings
equipped with lightning arresters). This would immediately put the
device out-of-order by exceeding its maximum discharge capacity.
• Overloads of atmospheric origin occur between the active wires and
the earth. They are highly charged and uncontrolled.
• Overloads of industrial origin occur between the active wires (L+N)
and are not so highly charged.
• The surge protective devices are equipped with an operation indicator
light (to be checked on a regular basis):
- Mains supply present and green indicator light on: operational
protection.
- Mains supply present and red indicator light on: change the module.
- Once the draw-out module is out-of-order the installation is no longer
protected but remains powered (including the withdrawn module).
Technical data
Number of poles 2
Neutral system TT - TNS
Mode of protection MCB C16 and/or MCBO
300mA
Maximum continuous operating voltage UCLN & N/PE 255V
L/PE 440V
Nominal sysem voltage U 230 VAC
Assigned current of load IL16A
Frequency F 50/60 Hz
Open cicuit voltage UOC 10 kV
Voltage protection level UPL/N 1kV
L/PE & N/PE 1,2kV
Temporary overvoltage test value UT441V
Nominal discharge current In 5kA
Maximum discharge current Imax 10 kA
Current factor k 1.6
Type Type 2 (T2) _ Type 3 (T3)
Location Indoor
Temperature and humidity range Normal range : -5°C : +40°C
Mechanical characteristics
IP 20
Cleaning
Without cleaning
Replaceable element: Cassette Reference 6 468 9
Conformity
In compliance with the standard NF EN 61643-11 : 2014

10/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-05 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/19/
20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
3.6 Protection devices
Protection devices are integrated in all standard catalogue PDUs and
customized PDUs.
- MCBs
For protecting equipment against short-circuits and overloads
407652 DX3 1P MCB 10 A 6000 A - 10 kA
407654 DX3 1P MCB 16 A 6000 A - 10 kA
409131 DX3 1P MCB 10 A 10000 A - 16k A
409133 DX3 1P MCB 16 A 10000 A - 16 kA
407698 DX3 1P+N MCB 10 A 6000 A - 10 kA
407700 DX3 1P+N MCB 16 A 6000 A - 10 kA
409150 DX3 1P+N MCB 10 A 10000 A - 16 kA
409152 DX3 1P+N MCB 16 A 10000 A - 16 kA
- RCBOs
For protecting equipment against short-circuits and overloads and
protecting people against leakage currents
410704 RCBO 10 A AC TYPE 4500 A - 6 kA - 30 mA
410705 RCBO 16 A AC TYPE 4500 A - 6 kA - 30 mA
410752 RCBO 10 A HPi AC TYPE 4500 A - 6 kA - 30 mA
410753 RCBO 16 A HPi AC TYPE 4500 A - 6 kA - 30 mA
See section 2 "Equipment and performance" to see which protection
device is integrated in the standard catalogue products.
MCBs and RCBOs are installed on a projecting DIN rail support to avoid
unintended breaking. This support can be equipped with a transparent
cover by special request.
1 or 2-module support depending on the catalogue number
1-module support 2-module support 1-module support
with cover
No coverWith transparent cover
3.7 Fuse (custom configured version)
For protecting equipment against short-circuits and overloads
Cartridge rating: 10 A and 16 A
To replace the cartridge, use a screwdriver to lever open the
compartment containing the fuse.
3.8 Thermal overload breaker (custom configured version)
For protecting equipment against short-circuits and overloads
Rating: 10 A and 16 A
Reset: The LED is lit during operation. When there is an overload, the
red button pops out of the module and the LED goes off. To reset the
breaker, press the red button until it clicks back into position; the LED
lights up again.
3.9 Colour-coding
The PDUs are colour-coded using coloured strips.
These strips clip onto the edge of the aluminium casing.
This solution is only compatible with Zero-U PDUs.
Extruded PVC plastic
Blue and red borders are available as standard, other colours are
available on request.
2 applications:
- For identifying circuits: one colour per circuit, to match the same
colour used on the circuit breaker
- For identifying the source: whole PDU in one colour identifies whether
it is the primary or interruptible power source when there are 2 PDUs in
the rack

11/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-05 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/19/
20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
3.10 Locking caps
For locking out the use of a socket.
Require a key to unlock access.
Products comprise a set of 6 locking caps + 1 key.
Cat.No 646890: For French/Belgian, German and Italian standard
sockets (P40)
Cat.No 646892: For UK standard sockets
Cat.No 646894: For C13 standard sockets
Cat.No 646895: For C19 standard sockets
ABS plastic
Light grey RAL 7035
Operating principle
1
23
456
4. DIMENSIONS
4.1 10’’ PDUS
52.5
44.3
214
237 237
52.5
214
52
180
All 10’’ catalogue numbers
excluding 6 468 98
To be equipped catalogue number
6 468 98
4.2 19’’ PDUS
442
52.5
465
465
52.5
442
52
405
44.3
All 19’’ catalogue numbers
excluding 6 468 99
To be equipped catalogue
number 6 468 99
4.3 ZEROU PDUS
Cat. No Height Width Depth Fixing centres
(min.-max.)
AB
(1) CDE(2) F(1)
1: Total height with standard bracket (screw-xing)
2: Total depth at circuit breaker slot
D
E
C
BFA
6468 50 1250 129452 52.5 87 1262-1292
6468 51 1250 129452 52.5 87 1262-1292
6468 52 1250 129452 52.5 87 1262-1292
6468 53 1250 129452 52.5 87 1262-1292
6468 54 1466 151052 52.5 87 1478-1508
6468 56 1034 107852 52.5 87 1046-1076
6468 57 1034 107852 52.5 87 1046-1076
6468 60 1070 111452 52.5 87 1082-1112
6468 61 1070 111452 52.5 87 1082-1112
6468 65 1160 120452 52.5 87 1172-1202
6468 70 1340 138452 52.5 87 1352-1382
6468 75 1475 151952 52.5 87 1487-1517

12/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
5. INSTALLATION
5.1 TERMINATION
Depending on the configuration, the PDUs can be connected in different ways.
1) Supplied with power cord
See section 2 "Equipment and performance" to see which standard catalogue products have an integrated cord.
2) Terminal block connection
Some products are supplied without a cable; they are designed to be wired on a terminal block.
See section 2 "Equipment and performance" to see which standard catalogue products have an integrated terminal block.
Example of terminal block connection for a Zero-U PDU with rotative cable entry
L2 L3
N
B
A
L2 L3
N
L2 L3
C
D
L2 L3
N
L2 L3
N
B
A
Cable ø7 min.
Cable ø15 max.
Cable ø13 min.
Cable ø20 max.
10 mm
120 mm
5G 2.5 mm2/5G 4 mm2
A
10 mm
120 mm
3G 2.5 mm2/3G 6 mm2
B
A
C
B
A
10
mm

13/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
3) Connection via fast connector or C20 connector (custom configured version)
Connectors mounted on the front panel of the PDU. The PDU is powered via a separate cable that plugs into these connectors.
C20 Wieland GST18 Wago
C20 Wieland GST18 Wago
Type Male Female Female
Nominal current 16 A 16 A 25 A
Voltage 250 VAC 250 VAC 250 VAC
IP 20 20 20
4) Explanation of 19’’ cable entry, rotative cable input, input with cable gland
The end piece on 19’’ PDUs integrates a cable guide.
Zero-U PDUs integrate a rotative cable input (330°).
330º

14/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
PDUs can be supplied with a cable input via cable gland by special request (input on front face or on the end).
5.2 MOUNTING SOLUTIONS
1)10’’ and 19’’
Horizontal mounting with snap-on fixing (for square holes 9.5 x 9.5).
Snap-on fixing system included
Snap-on xing
Vertical mounting possible by turning the fixing brackets round and positioning them on the rear of the unit.
Mounting bracket dimensions

15/15
CONTENTS
10’’ PDUs
19’’ PDUs
Zero-U PDUs
Data sheet: S000093176EN-04 Updated: 29/03/2018 Created: 25/10/2016
Cat. Nos: 6 468 00/01/05/06/07/09/10/11/12/13/14/15/18/1
9/20/21/22/23/24/30/31/32/33/35/36/40/41/42/43/44/
45/50/51/52/53/54/56/57/59/60/61/65/70/75/90/92/94/
95/97/98/99
2) Zero-U
Zero-U PDUs are designed for vertical installation and supplied with 2 sets of fixing accessories:
- 2 button: for screwless fixing. The height of the fixing centre can be set at any point along the full height of the PDU by sliding the button slots into
the groove on the rear of the PDU. Tightened using a 2.5 mm Allen key.
A
C
x2
B
A
B
2.5
Button dimensions
- 2 standard fixing brackets: for screw-fixing (screws not included)
x2
Standard xing bracket dimensions
- 2 Minkels brackets + 2 screws
x2
