LEGRAND 0 488 07 User manual

1/4
Technical data sheet: S000100487EN_2 Updated: 26/01/2023 Created: 18/05/2010
Catalogue Number(s): 0 488 07
PIR detector switch
128, av. du Maréchal-de-Lattre-de-Tassigny - 87045 LIMOGES Cedex
Tel : 0 ([phone] Fax : 0 ([phone]
www.legrand.com
1. USE
This device automatically controls a light source by detecting movement
in its supervision zone.
360° detection angle motion detector
Detection type: infra-red (PIR)
Mounting: ceiling
2. TECHNICAL CHARACTERISTICS
Voltage: 100-240 V~
Frequency: 50 / 60 Hz
No-load power consumption: 0,4W
Output by normally open contact connected to phase
Wiring: 2 x 2.5 mm2
Flush-mounting diameter: 65 mm without flush-mounting box,
68 mm with flush-mounting box
Weight: 114 g
Impact resistance: IK04
Penetration by solid bodies and liquids: IP41 installed product.
Operating temperature: -5°C to +45°C
Storage temperature: -20°C to +70°C
Cover removed
CONTENTS Page
1. Use .....................................1
2. Technical data ..........................1
3. Overall Dimensions .....................1
4. Connection .............................2
5. Installation .............................2
6. Disassembly ............................2
7. Settings ................................3
8. Performance............................4
9. Cleaning . . . . . . . . . . . . . . . . . . ............4
10. Standards. . . . . . . . . . . . . . . . . . . ...........4
3. OVERALL DIMENSIONS
Without protective cover
With protective cover
230 V~ 2000 W 8,5 A 2000 W 8,5 A 1000 VA 4,3 A 10x(2x36 W) 4,3 A 500 VA 2,1 A 1000 VA 4,3 A I max. ≤ 2A
110 V~ 1000 W 8,5 A 1000 W 8,5 A 500 VA 4,3 A 5x(2x36 W) 4,3 A 250 VA 2,1 A 500 VA 4,3 A

Incandescent lamp Compact fluorescent lamp with integrated ballast
Halogen lamp Compact fluorescent lamp with separate ferromagnetic or electronic ballast
Halogen lamp with separate ferromagnetic or electronic transformer Contactors
Fluorescent tubes
PIR Detector
Green detection
indicator light Green programming
indicator light
PIR transmission LED
(for configuration tool)
Protective shield
LEARN key
PIR reception LED
(for configuration tools
or remote control)
65 82
50 52
52
Ø : 102
Ø : 102

2/4
CONTENTS
Technical data sheet: S000100487EN_2 Updated: 26/01/2023 Created: 18/05/2010
Catalogue Number(s): 0 488 07
PIR detector switch
4. CONNECTION
Number of terminals: 4
Terminal type: automatic
Terminal capacity: 2 x 2.5 mm2
Stripping length: 8 mm
Cabling with auxiliary control : Manual on/Auto off
Pressing the auxiliary control allows the load to be switched on or off
manually. If no action is performed on the control, the detector will cut
off the related load at the end of the time delay or when the Daylight
setpoint is reached.
Cabling without auxiliary control: Auto on/Auto off
The load will be switched on and off automatically.
Option: Detector control using infra-red remote control.
Wiring
5. INSTALLATION





50
0.3 to 30 mm
Ø68 Ø65
6. DISASSEMBLY
8,5 A
max.
100 m max.
8,5 A
max.
CLIC

3/4
CONTENTS
Technical data sheet: S000100487EN_2 Updated: 26/01/2023 Created: 18/05/2010
Catalogue Number(s): 0 488 07
PIR detector switch
7. SETTINGS
- Parameters:
Time delay: Time for which light is switched on following detection.
Sensitivity: Detector range setting.
Daylight setpoint: Brightness value below which the light is switched
on and above which the light is switched off.
Auto on/Auto off mode:
The light is switched on automatically:
- When presence is detected, if the natural brightness is too low.
The light is switched off automatically:
- Where no presence is detected and at the end of the time delay set.
- Or if there is a sufficient level of natural light (activated setting).
Any new detection causes an automatic switch on if there is insufficient
light.
Walkthrough:
- If there is no presence detected in the 3 minutes following an initial
detection, the product will cut off after 3 minutes.
- If a new presence is detected in the 3 minutes following the initial
detection,
the device will cut off at the end of the time delay set.
Manual on/Auto off mode:
Comes on via a manual switch, automatic switch off:
- Where no presence is detected and at the end of the time delay set.
Following switch off, any new detection within a 30-second period will
cause the device to be switched on automatically.
After 30 seconds the device is switched on via a manual switch.
Initial detection: Light switched on from first detection.
Maintain: The load remains active if any new presence is detected.
7.SETTINGS (continued)
Retrigger: Function allowing automatic start of the product at the end
of 30seconds following the load being switched off.
Upon being switched off, any new detection within a 30-second period
will cause the device to be switched on automatically.
After 30 seconds the device must be switched on manually.
Calibration: The surrounding level of light measured with a luxmeter
will then have to be transmitted to the detector.
Light regulation: Light switched off automatically 10 minutes after
the Daylight setpoint has been exceeded. If the light level is below the
Daylight setpoint, the light is activated automatically after 20 seconds.
Provision of light: Quantity of additional lux provided when the light
is switched on.
- Modification of the parameters by the configuration tools
• 0 882 40: Configuration gateway and Legrand Close Up application.
The Close Up application is available on the Apple Store and the Play
Store
The detector functions are controlled by a number of parameters which
can be changed or programmed by an infrared configurator.
In combination with configuration tool 0 882 40, the Legrand Close Up
smartphone app can be used to view and modify all the detector
parameters with online help.
Point the infrared configuration tool at the detector and send the
necessary programming commands to the unit as indicated in the table
below.
For more information about setting parameters, refer to the data sheet
for the configuration gateway Cat. No. 0 882 40.
Google PlayApp Store
Sensor parameters Default value Modifiable parameters Configuration
tools
088230 088235
Time delay 15 mn 3,5,10,15,20 mins −
0 - 59 mins 59 secs −
Sensitivity PIR (very high) Low, medium, high, very
high
Daylight setpoint 500 lux
20, 100, 300, 500, 1000
lux −
0 - 1275 lux −
Modes
Auto on/Auto
off Inactive Enabled/Disabled
Walkthrough Active Enabled/Disabled
Manual on/
Auto off Inactive Enabled/Disabled
Detection
scheme
Initial PIR Non-modifiable −
Maintain PIR Non-modifiable −
Retrigger PIR PIR/Disabled −
Alert Inactive Enabled/Disabled −
Advanced
mode
Calibration −0 - 99995 lux −
Light regula-
tion Active Enabled/Disabled −
Provision of
light Auto Auto - 1275 lux −

4/4
CONTENTS
Technical data sheet: S000100487EN_2 Updated: 26/01/2023 Created: 18/05/2010
Catalogue Number(s): 0 488 07
PIR detector switch
8.PERFORMANCE continued7. SETTINGS continued
- Modifying the parameters using the configuration tools
(continued)
• 0 882 30: Configuration tool
When the sensor receives an IR command via a configuration tool,
itemits a beep confirming that the modification has been taken into
account.
For more information about setting parameters, refer to the data sheet
for the configuration tool Cat. No. 0 882 30.
- Restore to factory settings:
1st press: Short press on LEARN: the LED flashes slowly.
2nd press: Press and hold down LEARN for 10 seconds until the
LEDflashes quickly.
As from 01/01/2022, this
product ref. 0 882 30 is no
longer sold.
Height
Ø
Sensitivity
Low (25%)
Sensitivity
Medium (50%)
Ø (m) Surface area (m²) Ø (m) Surface area (m²)
Height (m)
2.5 4 15 6 25
35.5 25 6.5 35
46.5 35 7.5 45
56 30 10.5 90
64 15 5.5 25
Sensitivity
High (75%)
Sensitivity
Very-high (100%)
Ø (m) Surface area (m²) Ø (m) Surface area (m²)
Height (m)
2.5 6.5 30 8 50
38.5 60 11.5 100
412.5 125 14 155
512 115 16.5 215
68.5 60 12.5 125
8. PERFORMANCE 9. CLEANING
Ensure the lens remains clean.
Surface cleaning using a cloth.
Do not use: acetone, tar remover, trichloroethylene.
Resistant to the following products: - Hexane (EN 60669-1),
- Methylated spirit,
- Soapy water,
- Diluted ammonia
- Bleach diluted to 10%,
- Window cleaning products.
WARNING : Conduct preliminary tests before using any other
specific cleaning products.
10. STANDARDS
Directive: CE
Installation standards: NFC 15-100
Product standards: IEC 60669-2-1
Environmental standards:
- European Directive 2002/96/EC:
WEEE (Waste Electrical and Electronic Equipment).
- European Directive 2002/95/EC:
RoHS (Restriction of Hazardous Substances).
- Decrees and/or regulations: ERP (public buildings)
ERT (professional buildings)
IGH (high-rise buildings)
