Analog Slider Stations
Analog Slider Stations
Leviton Lighting Control Division CP series
manual control panels are simple to operate
and to install. Lighting levels are easily adjusted
by moving the slide controller up or down to
the desired intensity. Control stations can
contain any number of slide or special function
controllers.
APPLICATION
Situations where analog control stations
are required.
FEATURES
• Simple to operate
• Easy to install
• Flexible design
• Screwless appearance
OPTIONS
• Control transfer
• Control join/separate
• Delux finishes

PRODUCT DATA
Leviton Manufacturing Co., Inc. Lighting Management Systems
20497 SW Teton Avenue, Portland, OR 97062
Telephone: [phone] • FAX: [phone] • Tech Line (6:00AM-4:00PM P.S.T. Monday-Friday): 1-800-959-6004
Leviton Manufacturing of Canada, Ltd.
165 Hymus Boulevard, Pointe Claire, Quebec H9R 1E9 • Telephone: [phone] • FAX: [phone]
Leviton S. de R.L. de C.V.
Lago Tana 43, Mexico DF, Mexico CP 11290 • Tel. [phone] • FAX: [phone] • www.leviton.com.mx
Visit our Website at: www.leviton.com/lms
© 2008 Leviton Manufacturing Co., Inc. All rights reserved. Subject to change without notice.
leviton specification submittal
JOB NAME: CATALOG NUMBERS:
JOB NUMBER:
cat. no. Description
APP-CP0OT-000 2 Button Remote Station. On/Take Control & Off.
APP-CP0SW-000 On/Off Switch. For use as remote on/off switch to master.
APP-CP10OT-000 10 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP10SW-000 10 Channel Output with On/Off Switch & Master.
APP-CP11OT-000 11 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP11SW-000 11 Channel Output with On/Off Switch & Master.
APP-CP12OT-000 12 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP12SW-000 2 Channel Output with On/Off Switch & Master.
APP-CP2OT-000 2 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP2SW-000 10 Channel Output with On/Off Switch & Master.
APP-CP3OT-000 3 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP3SW-000 3 Channel Output with On/Off Switch & Master.
APP-CP4OT-000 4 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP4SW-000 4 Channel Output with On/Off Switch & Master.
APP-CP5OT-000 5 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP5SW-000 5 Channel Output with On/Off Switch & Master.
APP-CP6OT-000 6 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP6SW-000 6 Channel Output with On/Off Switch & Master.
APP-CP7OT-000 7 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP7SW-000 7 Channel Output with On/Off Switch & Master.
APP-CP8OT-000 8 Channel Analog Output with On/Take Control Switch , Off Switch, & Master.
APP-CP8SW-000 8 Channel Output with On/Off Switch & Master.
APP-CP9OT-000 CP-9-OT Control Station
APP-CP9SW-000 9 Channel Output with On/Off Switch & Master.
