Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 55 www.liko.com
Easy Strapper G7/G8, G77/G88
Monteringssats komplett lyftband G7/G8, G77/G88
Assembly Instruction
Monteringsanvisning
Prod. No. 20090069, 20090070
3SE640248-03
2011-03-30
© Copyright Liko AB www.liko.com
1. 2.
3.
4. Mount the spare part,
assemble in reverse order.
NOTE
- After changing lift strap the Limit Switch must be tested by lifting maximum load all the way up to the highest position
through the entire lifting range.
- With the emergency stop out, move the liftstrap all the way up against the Limit switch. Check that the motor does not
operate when touching the Limit switch.
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
20090069 Contains: Qty: Fits:
Easy strapper G7/G8 1 Golvo 7000
Golvo 7000 ES Classic
Golvo 8000 (all models)
20090070 Contains: Qty: Fits:
Easy strapper G77/G88 1 Golvo 7007 from S/N 7723630
Golvo 7007 ES Classic
Golvo 7007 LowBase
Golvo 8008 (all models)
Now with grey strap and
grey plastic details.
Tools required:
3mm
13mm
5.323-324

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 56 www.liko.com
Golvo 7007/8008 LowBase kit
Golvo 7007/8008 LowBase bensats
Assembly Instruction
Monteringsanvisning
Prod. No. 20090071
3SE640262-02
2010-05-10
© Copyright Liko AB www.liko.com
Tools required:
1. Remove rear wheel and leg. (left and right)
4 mm
5 mm
13 mm
17 mm
Contains: Qty:
Coverage list Lowrider 2
Leg alu right 1
Leg alu left 1
Leg adapter 2
Wheel housing Golvo LowR 2
Wheel axle 12x64 Golvo Lo 2
Leg LowRider 2
Wheel D50 Golvo LowRider 4
Leg clip 2
Bearing 10/12x10 2
Bearing Nylonit 10/12/12 2
Ball bearing 6000-2Z/C3 4
Locking nut M8 Nyloc fzb 8
Screw MC6S M8x30mm Ezloc 2
Stop screw S6SS M6x10 2
Tape 25x25 G7 4
Screw F6S M8x25 2
Retaining ring SGH26 4
Plastic cover IKPT 28 26 4
O-ring 9x1 2
Ball Class IV RB 6.35 LR 2
Fits:
Golvo 7007 (all models)
Golvo 8008 (all models)
5.330

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 57 www.liko.com
Golvo 7007/8008 LowBase kit
Golvo 7007/8008 LowBase bensats
Assembly Instruction
Monteringsanvisning
Prod. No. 20090071
© Copyright Liko AB www.liko.com
5.330
3. Assemble the rear wheels with stop screw.
2. Assemble the legs with screws, nuts, plastic covers and washers from the lift.
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 58 www.liko.com
Wireless Handcontrol HBL 20
Handkontroll IR HBL20
Assembly Instruction
Monteringsanvisning
Prod. No. 20490031
3SE640298-04
2011-03-03
© Copyright Liko AB www.liko.com
Tools required:
132 mm / 5 inch
2.
A. To activate IR control: Hold the hand
control IR about 20 cm/0.8 inch. from the
control unit’s IR receiver and press the
large UP and DOWN buttons on the hand
control simultaneously for about 2 seconds.
A signal is heard when the function is
activated. The lift is now ready to use with
Handcontrol IR.
B. Check to determine if other lifts in the
room are affected by your hand control. If
other lifts are affected by your hand control:
Use the large UP and DOWN buttons on
the operation panel of the lift that is to be
used. Press both buttons simultaneously
until a signal sounds. The lift has now been
assigned a unique communication code.
Now, activate IR control according to proce-
dure A, above.
4. 5.
Choice
1.
/
Contains: Qty:
Handcontrol HBL20 1
Clips with hook HBL20 1
Charge Cable Hook 2
Fits:
Golvo 8000 / 8008
Viking M Prod. No. 2040015
Viking L Prod. No. 2040014
Viking XL Prod. No. 2040013
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
50 mm / 2 inch
3. Golvo Viking M, Viking L, Viking XL
5.333

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 59 www.liko.com
Control Unit CBL, by S/N
Kontrollbox CBL S/N-styrd
Assembly Instruction
Monteringsanvisning
Prod. No. 20490039
3SE650270-03
2012-10-24
© Copyright Liko AB www.liko.com
Tools required:
2,5 mm
3 mm
Contains: Qty:
Control Unit CBL20 1 (pre-congured)
Cable cover 1
Screw cable cover 2
Screw M5x35 2 (Viking)
Screw M5x50 2 (Golvo)
Allen Key 2,5 mm 1
Fits: Prod. No.
Viking XL 2040013
Viking L 2040014
Viking M 2040015
Golvo 8008 LowBase 2000019
Golvo 8000 2000014
Golvo 8008 2000015
Golvo 8000 Classic 2000024
Golvo 8008 Classic 2000025
2. 3. 4.
5.
Before use!
Make sure the
S/N on the label
on Control
Unit CBL is the
same as on the
lift.
1.
50 mm
Centre laterally
Centrera i sidled
Controlbox CBL20
Prod.No 20490032
onlyfor use with:
VikingM
Prod.No 2040015
Etikettstorlek:52 X 21 mm
Layout?
Viking M:
The lower holes.
(no choice on the
Viking L & XL)
6. Viking: Golvo:
4 mm
5.336
ConformstoISO10535:2006withANSI/AAMIES60601-1:2005and
iscertifiedtoISO10535:2006withCSA-C22.2No.60601-1:08.
Int.Op:10/90Activetime2min.
?=;;;;æ;æ;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;æ;æ;:æ;:æ;:æ;:æ;:æ;„*„.æ;æ?=
?=;;;;Ó;Ó;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;Ó;Ó;:æ;:æ;:æ;:æ;:æ;„*„.Ó;Ó?=
7;;;;;;;330925;;;;;000001;;;<
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;æ;;;æ;–;;;;æ;ƒ;;;æ;ƒ=ƒ=;æ;ƒ;;;;;;;
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;æ;;;æ;–;;;;æ;ƒ;;;æ;ƒ=ƒ=;æ;ƒ;;;;;;;
;;;;;;8301209
24 V DC - 2.2 AhIP54 IEC 60601-1
TESTED
EAN-13Serial.no.
Y/M : 2012-3
Maxxxxkg/ xxx lbs
9801154
Productname
Prod. No.1234567
www.liko.com
Liko AB, Nedre vägen 100, 975 92 Luleå, Sweden
Conformsto ISO 10535:2006 with ANSI/AAMI ES60601-1:2005 and
iscertified to ISO 10535:2006 with CSA- C22.2 No. 60601-1:08.
Int.Op: 10/90 Active time 2 min.
?=;;;;æ;æ;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;æ;æ;:æ;:æ;:æ;:æ;:æ;„*„.æ;æ?=
?=;;;;Ó;Ó;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;Ó;Ó;:æ;:æ;:æ;:æ;:æ;„*„.Ó;Ó?=
7;;;;;;;330925;;;;;000001;;;<
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;æ;;;æ;–;;;;æ;ƒ;;;æ;ƒ=ƒ=;æ;ƒ;;;;;;;
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;æ;;;æ;–;;;;æ;ƒ;;;æ;ƒ=ƒ=;æ;ƒ;;;;;;;
;;;;;;8301209
24 V DC - 2.2 Ah IP54 IEC 60601-1
TESTED
EAN-13Serial.no.
Y/M : 2012-3
Max xxx kg / xxx lbs
9801154
Product name
Prod. No. 1234567
www.liko.com
Liko AB, Nedre vägen 100, 975 92 Luleå, Sweden
S/N:
!
TAGBORTTRANSPORTSTÖDMED
SKRUVARFÖREMONTERING.
BEFOREASSEMBLINGREMOVE
TRANSPORTSAFETYBRACKET.
VORDEMAUFSTELLENTRANSPORT-
SICHERUNGENTFERNEN.
AVANTASSEMBLAGE,DÉMONTER
LASÉCURITÉDETRANSPORT.
?=;;;;æ;æ;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;æ;æ;:æ;:æ;:æ;:æ;:æ;„*„.æ;æ?=
?=;;;;Ó;Ó;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;Ó;Ó;:æ;:æ;:æ;:æ;:æ;„*„.Ó;Ó?=
7;;;;;;;330925;;;;;000001;;;<
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;;æ;;æ;–;;;ƒ;;æ=;ƒ;ƒ=;æ;ƒ;;;;;;;
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;;æ;;æ;–;;;ƒ;;æ=;ƒ;ƒ=;æ;ƒ;;;;;;;
;;;;;;8301217
24 V DC - 2.2 AhIPX4 IEC 60601-1
TESTED
EAN-13
Serial.no.
Y/M : 2012-6
Maxxxxkg/xxx lbs
9801154
Productname
Prod. No.1234567
www.liko.com
Liko AB, Nedre vägen 100, 975 92 Luleå, Sweden
ConformstoISO10535:2006withANSI/AAMI
ES60601-1:2005andiscertifiedto
ISO10535:2006withCSA-C22.2No.60601-1:08.
Int.Op:10/90Activetime2min.
Viking Golvo
M5x35 M5x50

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 60 www.liko.com
Control Unit CBL, by S/N
Kontrollbox CBL S/N-styrd
Assembly Instruction
Monteringsanvisning
Prod. No. 20490039
© Copyright Liko AB www.liko.com
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
A. To activate IR control: Hold the hand control
IR about 20 cm/0.8 inch. from the control unit’s
IR receiver and press the large UP and DOWN
buttons on the hand control simultaneously for
about 2 seconds. A signal is heard when the
function is activated. The lift is now ready to
use with Hand control IR.
B. Check to determine if other lifts in the room
are affected by your hand control. If they are:
Use the large UP and DOWN buttons on the
operation panel of the lift that is to be used.
Press both buttons simultaneously until a
signal sounds. The lift has now been assigned
a unique communication code. Now, activate
IR control according to procedure A, above.
/
8.
5.336
- Charger cable; socket 1
- Lift motor cable; socket 2
- Base-motor cable; socket 3
1
3
”click”
7.
2

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 61 www.liko.com
Control Unit CBL, by S/N, Cable
Kontrollbox CBL S/N-styrd, kabel HK
Assembly Instruction
Monteringsanvisning
Prod. No. 20490054
3SE690227-02
2013-01-31
© Copyright Liko AB www.liko.com
Tools required:
5.336C
2,5 mm
(provided)
3 & 4mm
2. 3. 4.
5.
Before use!
Make sure the
S/N on the label
on Control
Unit CBL is the
same as on the
lift.
1.
Viking M:
The lower holes.
(no choice on the
Viking L & XL)
6. Viking: Golvo:
ConformstoISO10535:2006withANSI/AAMIES60601-1:2005and
iscertifiedtoISO10535:2006withCSA-C22.2No.60601-1:08.
Int.Op:10/90Activetime2min.
?=;;;;æ;æ;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;æ;æ;:æ;:æ;:æ;:æ;:æ;„*„.æ;æ?=
?=;;;;Ó;Ó;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;Ó;Ó;:æ;:æ;:æ;:æ;:æ;„*„.Ó;Ó?=
7;;;;;;;330925;;;;;000001;;;<
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;æ;;;æ;–;;;;æ;ƒ;;;æ;ƒ=ƒ=;æ;ƒ;;;;;;;
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;æ;;;æ;–;;;;æ;ƒ;;;æ;ƒ=ƒ=;æ;ƒ;;;;;;;
;;;;;;8301209
24VDC-2.2 Ah IP54IEC60601-1
TESTED
EAN-13Serial.no.
Y/M:2012-3
Maxxxxkg/ xxx lbs
9801154
Productname
Prod.No.1234567
www.liko.com
LikoAB,Nedrevägen100,97592Luleå, Sweden
Conformsto ISO 10535:2006 with ANSI/AAMI ES60601-1:2005 and
iscertified to ISO 10535:2006 with CSA- C22.2 No. 60601-1:08.
Int.Op: 10/90 Active time 2 min.
?=;;;;æ;æ;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;æ;æ;:æ;:æ;:æ;:æ;:æ;„*„.æ;æ?=
?=;;;;Ó;Ó;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;Ó;Ó;:æ;:æ;:æ;:æ;:æ;„*„.Ó;Ó?=
7;;;;;;;330925;;;;;000001;;;<
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;æ;;;æ;–;;;;æ;ƒ;;;æ;ƒ=ƒ=;æ;ƒ;;;;;;;
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;æ;;;æ;–;;;;æ;ƒ;;;æ;ƒ=ƒ=;æ;ƒ;;;;;;;
;;;;;;8301209
24 V DC - 2.2 Ah IP54 IEC 60601-1
TESTED
EAN-13Serial.no.
Y/M : 2012-3
Max xxx kg / xxx lbs
9801154
Product name
Prod. No. 1234567
www.liko.com
Liko AB, Nedre vägen 100, 975 92 Luleå, Sweden
S/N:
!
TAGBORTTRANSPORTSTÖDMED
SKRUVARFÖREMONTERING.
BEFOREASSEMBLINGREMOVE
TRANSPORTSAFETYBRACKET.
VORDEMAUFSTELLENTRANSPORT-
SICHERUNGENTFERNEN.
AVANTASSEMBLAGE,DÉMONTER
LASÉCURITÉDETRANSPORT.
?=;;;;æ;æ;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;æ;æ;:æ;:æ;:æ;:æ;:æ;„*„.æ;æ?=
?=;;;;Ó;Ó;–;æ;æ?æ=ƒ;æ:æ;+÷+‹;:æ;Ó;Ó;:æ;:æ;:æ;:æ;:æ;„*„.Ó;Ó?=
7;;;;;;;330925;;;;;000001;;;<
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;;æ;;æ;–;;;ƒ;;æ=;ƒ;ƒ=;æ;ƒ;;;;;;;
;;;;;;;ƒ;æ;;;;æ;–;;æ;;ƒ;;ƒ;ƒ;;ƒ;;;æ;;æ;–;;;ƒ;;æ=;ƒ;ƒ=;æ;ƒ;;;;;;;
;;;;;;8301217
24VDC-2.2Ah IPX4 IEC60601-1
TESTED
EAN-13
Serial.no.
Y/M:2012-6
Maxxxxkg/xxx lbs
9801154
Productname
Prod.No.1234567
www.liko.com
LikoAB,Nedrevägen100,97592Luleå,Sweden
ConformstoISO10535:2006withANSI/AAMI
ES60601-1:2005andiscertifiedto
ISO10535:2006withCSA-C22.2No.60601-1:08.
Int.Op:10/90Activetime2min.
Viking Golvo
M5x35 M5x50
Contains: Qty:
Control Unit CBL20, cable 1 (pre-congured)
Cable cover 1
Screw, cable cover 2
Screw M5x35 2 (Viking)
Screw M5x50 2 (Golvo)
Allen Key 2,5 mm 1
Fits: Prod. No.
Viking XL 2040033
Viking L 2040034
Viking M 2040035
Golvo 8008 LowBase 2000039
Golvo 8000 2000034
Golvo 8008 2000035
Controlbox CBL20
Prod.No 20490032
onlyfor use with:
VikingM
Prod.No 2040015
Etikettstorlek:52 X 21 mm
Layout?

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 62 www.liko.com
© Copyright Liko AB www.liko.com
Control Unit CBL, by S/N, Cable
Kontrollbox CBL S/N-styrd, kabel HK
Assembly Instruction
Monteringsanvisning
Prod. No. 20490054
3SE690227-02
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
5.336C
- Charger cable; socket 1
- Lift motor cable; socket 2
- Base-motor cable; socket 3
9.
1
3
”click”
8.
2
Attach the locking ring.
Connect the Hand control. Make sure the rectangular tabs
at the locking ring are xed.
Battery
Prod. No. 2006107
Triangular tab
facing out.

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 63 www.liko.com
Extension cable CBL20
Skarvkabel CBL20
Assembly Instruction
Monteringsanvisning
Prod. No. 21090018 Extension cable CBL20
21090019 Extension cable CBL20, US
3SE650216-05
2012-09-11
© Copyright Liko AB www.liko.com
Tools required:
Connect the Charging cable to the Extension cable and
the Extension cable to the wall socket (100-240 V AC).
The battery is fully charged after 5 hours.
After completed charging, place the cable on the
Charge cable hook.
2,5 mm
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
Contains: Qty:
Adapter cable charging 1
Extension Cable, US
Skarvkabel, US
Assembly Instruction
Monteringsanvisning
Prod. No. 21090011
3SE630218-03
2009-11-13
© Copyright Liko AB www.liko.com
5.263.1
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Liko and using original Liko spare parts.
Contains: Qty:
Extension cable US 1
Fits:
Golvo 7000ES/7007ES
Uno 100 EM/EE
Uno 102 EM/EE/ES
Sabina EM/EE
Sabina II EM/EE
Viking XL
Viking L
Viking M (prod. no. 2040005)
Length 26.5 cm/ 10.5 inch
Extension Cable, US
Skarvkabel, US
Assembly Instruction
Monteringsanvisning
Prod. No. 21090011
3SE630218-02
2007-10-29
© Copyright Liko AB www.liko.com
1.
3.
2.
5.263.1
Fits: Prod. No:
Golvo 8000/8008 (all models)
Viking XL 2040013 and 2040033
Viking L 2040014 and 2040034
Viking M 2040015 and 2040035
5.348-349

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 64 www.liko.com
Extra battery box
Extra batteribox
Assembly Instruction
Monteringsanvisning
Prod. No. 2006107
5.350
NOTE
- Before use, charge the batteries according to the instruction guide.
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
- Old batteries are to be left at the nearest recycling station.
“click”
NiMH
Contains: Qty:
Batteri BAL20 1
Fits: Prod. No.
Viking M 2040015
Viking M 2040035
Viking L 2040014
Viking L 2040034
Viking XL 2040013
Viking XL 2040033
Golvo 8000/8008 all models

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 65 www.liko.com
Beltclip HBL20
Bältesclips HBL20
Assembly Instruction
Monteringsanvisning
Prod. No. 21090020
3SE650217-04
2011-03-04
© Copyright Liko AB www.liko.com
Tools required:
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
Contains: Qty:
Belt Clips HBL20 1
Fits:
Wireless hand control HBL20 Prod. No. 21090020
5.351

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 66 www.liko.com
Clips with hook HBL20
Clips med krok HBL20
Assembly Instruction
Monteringsanvisning
Prod. No. 21090021
3SE650218-04
2011-03-04
© Copyright Liko AB www.liko.com
Tools required:
5.352
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
Contains: Qty:
Clips with hook 1
Fits:
Wireless hand control HBL20 Prod. No. 21090020

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 67 www.liko.com
Charge cable hook
Laddkabelkrok
Assembly Instruction
Monteringsanvisning
Prod. No. 21090022
3SE650219-06
2012-09-11
© Copyright Liko AB www.liko.com
Contains: Qty:
Charge cable hook 10
Fits: Prod. No.
Golvo 8000/8008 (all models)
Liko M220 2050010
Liko M230 2050015
Viking XL 2040013 and 2040033
Viking L 2040014 and 2040034
Viking M 2040015 and 2040035
NOTE
- Make sure the spare part is
mounted according to the
assembly instruction.
- Check all functions related to the
changed spare part.
- Repairs and maintenance may
only be performed by personnel
authorized by Hill-Rom/Liko and
using original Liko spare parts.
50 mm / 2 inch
245 mm / 9,6 inch
1:
132 mm / 5,2 inch 132 mm / 5,2 inch 132 mm / 5,2 inch
2: Viking XL Viking L Viking M
Golvo Liko M220 / M230
5.353

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 68 www.liko.com
HandControl hanger
Handkontrollupphängare
Assembly Instruction
Monteringsanvisning
Prod. No. 21090023
3SE650220-04
2011-03-04
© Copyright Liko AB www.liko.com
5.354
Contains: Qty:
HandControl hanger 10
132 mm / 5 inch
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
50 mm / 2 inch
Golvo Viking M, Viking L, Viking XL
Fits:
Golvo 8000 / 8008
Viking M Prod. No. 2040015
Viking L Prod. No. 2040014
Viking XL Prod. No. 2040013

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 69 www.liko.com
Q-link
Assembly Instruction
Monteringsanvisning
Prod. No. 31590005
3SE640236-02
2010-05-10
Tools required
Contains: Qty:
Lift strap joint 1
Strap joint plastic cover 1
Lift strap safety pin 4 mm 1
Fits:
Extension belts
Golvo 7000/7007
Golvo 8000/8008
Likorall
Multirall 200
www.liko.com
© Copyright Liko AB
5.397
Important!
For safety reasons, it is essential that this component is correctly tted to the lift
according to these instructions.
1 X
1a. alt: 1b.
Disassemble:

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 70 www.liko.com
Q-link
Assembly Instruction
Monteringsanvisning
Prod. No. 31590005
NOTE
- After changing Q-link, the assembly must be tested by lifting maximum load all the way up to the highest position.
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
www.liko.com
© Copyright Liko AB
5.397
5.
6. 7.
3.
4.
2.
Assemble:

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 71 www.liko.com
Lift strap joint
Bandlås med hål
Assembly Instruction
Monteringsanvisning
Prod. No. 31590025
3SE640237-02
2010-05-10
Tools required
Contains: Qty:
Lift strap joint 1
Strap joint plastic cover 1
Lift strap safety pin 4mm 1
Fits:
Golvo 7000/7007
Golvo 8000/8008
Likorall
www.liko.com
© Copyright Liko AB
5.398
Important!
For safety reasons, it is essential that this component is correctly tted to the lift
according to these instructions.
1 X
1a. alt: 1b.
Disassemble:

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 72 www.liko.com
Lift strap joint
Bandlås med hål
Assembly Instruction
Monteringsanvisning
Prod. No. 31590025
NOTE
- After changing Lift strap joint, the assembly must be tested by lifting maximum load all the way up to the highest position.
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
www.liko.com
© Copyright Liko AB
5.398
5.
6. 7.
3.
4.
2.
Assemble:

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 73 www.liko.com
Friction plates 2.8-3.4 mm
Glidplattor 2.8-3.4 mm
Assembly Instruction
Monteringsanvisning
Prod. No. 20090072
3SE650254-02
2010-05-10
Fits:
Golvo 7000/7007 (all models)
Golvo 8000/8008 (all models)
www.liko.com
© Copyright Liko AB
5.404
Contains: Qty:
Friction plate 2.8 mm 20
Friction plate 3.0 mm 20
Friction plate 3.2 mm 20
Friction plate 3.4 mm 20
Tools required
Loctite 406 (Glue)
1
When changing Spare part 20090014
Actuator, replacement of Friction plate
(pos1) may be needed. Use the same
dimension as original or as instructions
below.
(Use glue)
Alternative Friction plates.
Friction plate 3,0 mm
Friction plate 3,4 mm
1
When changing Spare part 20090014 Actuator,
replacement of Friction plate (pos1) may be needed.
Use the same dimension as original or as instruc-
tions below. (Use glue)
Alternative Friction plates.
Friction plate 2.8 mm
Friction plate 3.0 mm
Friction plate 3.4 mm

Golvo™
ServiceManual Golvo™ mobile lift (3EN400404 Rev 3) 74 www.liko.com
Friction plates 2.8-3.4 mm
Glidplattor 2.8-3.4 mm
Assembly Instruction
Monteringsanvisning
Prod. No. 20090072
5.404
NOTE
- The actuator must be tested by lifting maximum load all the way up to the highest position/through the entire lifting range.
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
When changing Spare part 20090038 Gear Rack set, replace-
ment of Friction plates may be needed. Use the same dimension
as original or as instructions below.
(Use glue)
Short side in all Friction plates
facing the end of the beam.
Pos. Name: Pce.
1 Friction plate 2.8 mm 2
2 Friction plate 3.2 mm 2
3 Friction plate 3.0 mm 2
1
2
2
3
78
7007
80
82
84
86
88
90
92
94
96
98
100
102
104
76
1
3
2
2
Pos. Name: Pce.
4 Friction plate 3.0 mm 4
5 Friction plate 3.2 mm 4
6 Friction plate 3.4 mm 4
4
5
6
