Liko Sabina II EE User manual

Sabina II EE, EM
Service Manual
2005-09-12
Doc.no. 7SE155402-01
11:1

www.liko.com
Table of contents
Sabina II EE, EM
1.0
Position Ref.no.
Table of contents .......................................................................... 1.0
Care and maintenance ................................................................. 2.0
Technical Specications ............................................................... 3.0
Positions....................................................................................... 4.0
Spareparts with position. .............................................................. 5.0
Base ................................................................1 .......................... 4.1
Mast Sabina ...................................................2 .......................... 4.2
Attachment for control box .............................19 ......................... 4.19
Hand control ES, 6-button ..............................20 ......................... 4.20
Battery 2,9Ah/12V ..........................................21 ......................... 4.21
Cable for charging, EU ...................................22 ......................... 4.22
Cable for charging, UK ...................................23 ......................... 4.23
Cable for charging, US ...................................24 ......................... 4.24
Actuator for Base Widening............................43 ......................... 4.43
Hand control EM, 2-button .............................54 ......................... 4.54
Leg protector U1, Sa ......................................58 ......................... 4.58
Front wheel 75 mm.........................................60 ......................... 4.60
Rear wheel 75 mm .........................................61 ......................... 4.61
Lift arm plastic cover ......................................63 ......................... 4.63
Front wheel 100 mm.......................................64 ......................... 4.64
Rear wheel 100 mm .......................................65 ......................... 4.65
Foot tray complete..........................................67 ......................... 4.67
Control Box Sa ...............................................70 ......................... 4.70
Leg support ....................................................71 ......................... 4.71
Strap for leg support.......................................72 ......................... 4.72
Safety latch.....................................................87 ......................... 4.87
Extra Battery box, incl. Batteries ...................139 ........................ 4.139
Extension cable .............................................160 ........................ 4.160
Control box Sa II............................................188 ........................ 4.188
Actuator Sa II.................................................189 ........................ 4.189
Restoration set Manual Base.........................216..........................4.216
Restoration set Electrical Base......................217..........................4.217
Foot Tray cover .............................................230.........................4.230
Cable for charging, AU/NZ ............................248 ........................4.248
Troubleshooting............................................................................ 6.0
Drawing ........................................................................................ 7.0
Periodic Inspection ....................................................................... 8.0

www.liko.com
Innehållsförteckning
Sabina II EE, EM
Pos Bladnr.
Innehållsförteckning ...................................................................... 1.0
Tillsyn och underhåll...................................................................... 2.0
Teknisk data .................................................................................. 3.0
Positioner ...................................................................................... 4.0
Reservdelslista med positioner...................................................... 5.0
Chassie ............................................................... 1 ....................... 4.1
Pelare .................................................................. 2 ....................... 4.2
Monteringsbeslag kontrollbox............................. 19 ...................... 4.19
Handkontroll ES, 6-knapp .................................. 20 ...................... 4.20
Batteri 2,9Ah/12V ............................................... 21 ...................... 4.21
Laddningskabel, EU ........................................... 22 ...................... 4.22
Laddningskabel, UK ........................................... 23 ...................... 4.23
Laddningskabel, US ........................................... 24 ...................... 4.24
Ställdon LA 28 .................................................... 43 ...................... 4.43
Handkontroll EM, 2-knapp...................................54.......................4.54
Benskydd U1/Sa................................................. 58 ...................... 4.58
Framhjul 75 mm.................................................. 60 ...................... 4.60
Bakhjul 75 mm.................................................... 61 ...................... 4.61
Plastkåpa............................................................ 63 ...................... 4.63
Framhjul 100 mm ............................................... 64 ...................... 4.64
Bakhjul 100 mm.................................................. 65 ...................... 4.65
Fotstöd komplett Sa ........................................... 67 ...................... 4.67
Kontrollbox Sa .................................................... 70 ...................... 4.70
Underbensstöd till Sabina .................................. 71 ...................... 4.71
Vadband Sa ........................................................ 72 ...................... 4.72
Urkrokningsskydd ............................................... 87 ...................... 4.87
Batteribox inkl batterier...................................... 139 ..................... 4.139
Skarvkabel......................................................... 160 ..................... 4.160
Kontrollbox Sa II ................................................ 188 ..................... 4.188
Ställdon Sa II ..................................................... 189 ..................... 4.189
Renoveringssats Manuell breddning ................. 216 ..................... 4.216
Renoveringssats elektrisk breddning ................ 217 ..................... 4.217
Fotplatta Sa II .................................................... 230 ..................... 4.230
Laddningskabel, AU/NZ..................................... 248 ..................... 4.248
Enkel felsökning ............................................................................ 6.0
Ritningar ........................................................................................ 7.0
Periodisk Inspektion ...................................................................... 8.0
1.0

www.liko.com
2.0
For safe and troublefree operation, there are a few routine measures which should be perfor-
med every day the lift is used.
• Visually inspect the patient lift and check for external damage or wear.
• Check that the safety latches on the sling bar work properly.
• Check the hand control and the lift and width movements.
• Check the emergency lowering function.
• Charge the battery every night after use, or with the frequency needed.
If needed, clean the patient lift with warm water or ethanol. Warning! Do not use chemicals
containing Phenol or chlorine, since the nylon parts may be damaged.
CAUTION!
Use only authorized Liko service personnel and Liko spare parts.
Transportation and storage
During transportation, or when the patient lift is not to be used for some time, the emergency
button should be pushed in. Also, when storing, keep the patient lift at a temperature exceeding
freezing point and at a relative humidity no more than 60%.
We always try to improve our products. Naturally, this means changes from time to time.
Please contact our local representative or www.liko.com to recive the latest updates.
Care and Maintenance

www.liko.com
Tillsyn och underhåll
2.0
För problemfri användning bör vissa detaljer kontrolleras varje dag lyften används.
• Inspektera lyften och kontrollera att inga yttre skador har skett.
• Kontrollera skruv och låsmutter som fäster lyftbygeln.
• Kontrollera urkrokningsskyddets funktion.
• Kontrollera manövreringen av lyftrörelsen och breddinställningen.
• Kontrollera att nödsänkningen (både den elektriska och den manuella) fungerar.
• Ladda batterierna varje dag lyften använts och kontrollera då att laddaren fungerar.
Vid behov, rengör lyften med varmt vatten eller tvättsprit. OBS! Använd inte rengöringsmedel
som innehåller fenol eller klor, eftersom detta kan skada polyamidmaterialen.
Tillsyn och kontroll
Sabina skall genomgå kontroll minst en gång per år av förslitningdetaljer t ex leder, bultförband
mm. Utföres i enlighet med Likos serviceinstruktion och av auktoriserad personal.
VIKTIGT!
Reparation och underhåll får endast uföras av Liko auktoriserad personal och med original
reservdelar.
Transport och lagring
Under transport, eller då lyften inte skall användas under en längre tid, bör nödstoppen vara
intryckt. Lyften bör också förvaras frostfritt samt ej över normal luftfuktighet (ca 60%).
Serviceavtal
Liko erbjuder möjlighet att teckna serviceavtal för underhåll och återkommande provning av er
Sabina uppresningslyft.

www.liko.com
3.0
Technical Specications
Footrest: Removable.
Lower-leg Height and width adjustable.
support: Removable.
Intermittent Int. Op 10/90, active operation max 2 min.
operation: Out of a time of 100, active must be less
than 10, though not more than 2min.
IP class 43
Built for indoor operation.
Type B according to the degree of protection
against electric chock.
Class ll equipment.
Batteries: Two 12V 2.9 Ah valve-regulated leadacid
gel-type batteries. New batteries are
provided by the supplier.
Motor (mast): 24 V, 6 A, permanent magnetic motor with
mechanical safety mechanism and safety nut.
Motor (base): 24 V, 3.5 A, permanent magnetic motor.
Charger: Built-in charger, 100-230 V, 50-60 Hz,
max 400 mA.
Material: Painted steel with lacquer topcoat.
Emergency Mechanical and electrical.
lowering: and electrical.
Sabina II EE
Sabina II EM
* These measures depend on in which hole the mast is levelled and secured.
** 11 cm is standard setting. 15 cm is when using 100 mm wheel diameter.
Model Capacity L* A* B B1 C D E E1 F G** G1 H1 H2 Weight
Sabina II EE 200 172 81 110 100 106 86 69-105 53-90 21-30 65 30-40 11-15 5 60 35 44 19 118
Sabina II EM 200 172 81 110 100 106 86 69-105 53-90 21-30 65 30-40 11-15 5 60 35 44 19 118
Max Min Max Min (max) total del
Turning
diameter
* These measures depend on in which hole the mast is levelled and secured.
** 4 inches is standard setting. 6 inches is when using 100 mm wheel diameter.
Capacity and weight in lbs. Measurement in inches:
Capacity and weight in kg. Measurement in cm:
Model Capacity L* A* B B1 C D E E1 F G** G1 H1 H2 Weight
Sabina II EE 440 69 32 44 40 42 34 26-42 21-36 8-12 26 12-16 4-6 2 23.6 13.8 98 42.5 46
Sabina II EM 440 69 32 44 40 42 34 26-42 21-36 8-12 26 12-16 4-6 2 23.6 13.8 98 42.5 46
Max Min Max Min (max) total del
Turning
diameter

www.liko.com
Tekniska data
Fotplatta: Avtagbar
Underbensstöd: Justerbart i höjd och djup. Avtagbart.
Intermittent drift: Int. Op 10/90, aktiv drift max 2 min.
Av en tid på 100 får aktiv tid vara 10, dock max 2 min.
IP klass 43
Apparaten är avsedd för inomhusbruk
Typ B, enligt skyddsgrad mot elektrisk chock
Klass ll utrustning
Batterier: 2 st 12V 2.9 Ah ventilreglerade
slutna blyack. s.k gelbatterier. Nya
batterier tillhandahålles av leverantören
Ställdon (pelare): 24 V 9 A, permanent manetmotor med
mekanisk säkerhetsmekanism som
dragsäkring och säkerhetsmutter
Ställdon (u-rede): 24 V 3.5 A, permanent magnetmotor
Batteriladdare: Inbyggd laddare för 100-230 V,
50-60 Hz, max 400 mA
Material: Pulverlackat stål
Nödsänkning: Mekanisk och elektrisk.
3.0
Kapacitet och Vikt i kg. Mått i cm.
* Varierande mått beroende på monteringsalternativ.
** 11 cm är standard. 15 cm gäller vid 100 mm hjuldiameter.
Modell Kapacitet L* A* B B1 C D E E1 F G** G1 H1 H2 Vikt
Sabina II 200 172 81 110 100 106 86 69-105 53-90 21-30 65 30-40 11-15 5 60 35 44 19 118
200 172 81 110 100 106 86 69-105 53-90 21-30 65 30-40 11-15 5 60 35 44 19 118
Sabina II EE
Max Min Max Min (max) total del
Vänd-
diameter
Sabina
EM/ES
Sabina II EM

www.liko.com



















 

Positions Sabina II EE, EM
4.0
160
22 23 24

www.liko.com
5.0
Spare parts
PART. NO POS.NO PRODUCT UNIT
20190003 43 Actuator for Base Widening pce
20190042 60 Front Wheel 75 mm pce
20190046 64 Front Wheel 100 mm pce
20190043 61 Rear Wheel 75 mm pce
20190047 65 Rear Wheel 100 mm pce
20190029 58 Leg Protector U1,Sa pair
20290006 67 Foot Tray complete pce
20290026 230 Foot Tray cover pce
20290021 71 Leg Support pce
20290022 72 Strap for Leg support pce
2006106 139 Extra Battery box, incl. Batteries pce
20190049 216 Restoration set Manual Base set
20190050 217 Restoration set Electrical Base set
X 2

www.liko.com
5.0
Spare parts
PART. NO POS.NO PRODUCT UNIT
20090023 19 Attachment for Control Box pce
20090024 20 Hand Control ES 6-Button pce
20190016 54 Hand Control EM 2-Button
20090025 21 Battery 2,9 Ah/12V pair
20090026 22 Cable for Charging EU pce
20090027 23 Cable for Charging UK pce
20090028 24 Cable for Charging US pce
20090050 248 Cable for Charging AU/NZ pce
20190045 63 Lift Arm Plastic Cover set
21090001 160 Extension Cable pce
31190018 87 Safety Latch pair
20290024 188 Control Box Sa II pce
20290023 189 Actuator Sa II pce
X 2

www.liko.com
5.0
Reservdelslista
PRODUKT NR POS.NR PRODUKTBESKRIVNING ENHET
20190003 43 Ställdon LA 28 st
20190042 60 Framhjul 75 mm st
20190046 64 Framhjul 100 mm st
20190043 61 Bakhjul 75 mm st
20190047 65 Bakhjul 100 mm st
20190029 58 Benskydd U1,Sa par
20290006 67 Fotstöd kompl. Sa st
20290026 230 Fotplatta Sa II st
20290021 71 Underbensstöd t Sabina st
20290022 72 Vadband Sa st
2006106 139 Batteribox inkl batterier st
20190049 216 Renoveringssats manuell breddning set
20190050 217 Renov.sats elektr breddning set
X 2

www.liko.com
5.0
Reservdelslista
PRODUKT NR POS.NR PRODUKTBESKRIVNING ENHET
20090023 19 Monteringsbeslag kontrollbox st
20090024 20 Handkontroll ES 6-knapp st
20190016 54 Handkontroll EM 2-Knapp
20090025 21 Batteri 2,9 Ah/12V par
20090026 22 Laddningskabel EU st
20090027 23 Laddningskabel UK st
20090028 24 Laddningskabel US st
20090050 248 Laddningskabel AU/NZ st
20190045 63 Pelarkåpa set
21090001 160 Skarvkabel st
31190018 87 Urkrokningsskydd par
20290024 188 Kontrollbox Sa II st
20290023 189 Ställdon Sa II st
X 2

www.liko.com
Spareparts Specication
Reservdelslista
Serial no ................................ Version ................................ Release ................................
Details Detail.pos Detailnr. Unit.
Base leg Right Sabina/Uno100 1 90179103H 1
Base leg Left Sabina/Uno100 2 90179103V 1
Center Uno 100/Sa 5 901791023 1
Mounting plate 11 901969085 1
Wheel-set 75/75mm Uno 4/31 2014304 1
Turnable plate U102 EM 33 901969083 1
Ball coupling M10 32 930000004 4
Screw F6S M10*40 23 930000006 2
Screw MC6S M10*25 22 930000039 2
Domed locking nut M10 14 930000008 6
S6SS M8*10 24 930000050 2
Locking nut M10 15 930000010 2
Plastic cover IKP 30 26 G 35 900000002 2
Screw M6S M12*105 21 930000012 2
Covertube (gray) m 26 900000003 0,26
Locking handle 27/28 2107100 1
Decal Sabina II 900001109 2
All details according to drawingnr. R 3009134-7
Details Detail.pos Detailnr. Unit.
PSH M10*165 12 930000354 2
Distance (washer 8/18*5) 8 930000003 2
Uno EM handle (Base) 17 901969084 1
Plastic cover IK 22 19 G 34 900000004 1
M6S M8*75 20 930000030 2
Domed locking nut M8 13 930000014 3
Pin with snapping 29 930000021 1
M6S M8*50 19 930000022 1
Centercase 6 901969082 1
Top cover IKPT 2528G 36 900000007 1
Pressurespring 3*25*30 30 900000008 1
TBRB 8,4/16*3 3 930000023 1
Distance 8*12*30 Uno EM 7 900000037 4
Leg protector Uno 25 20190006 1
Decal ”Liko” 900000245 2
Washer NB 10*25*1,5 18 930000075 1
Foot frame 10 901791122 1
Foot plate 9 901791094 1
Locking nut M12 16 930000056 2
4.1
Base Sabina II EM
Underrede Sabina II EM Prod.no: 20190057
2003-09-10

www.liko.com
Spareparts Specication
Reservdelslista
Serial no ................................ Version ................................ Release ................................
Details Detail pos. Detail no. Unit
Base leg Right Sabina/Uno100 1 90179103H 1
Base leg Left Sabina/Uno100 2 90179103V 1
Center Sabina/Uno100 5 901791023 1
Motor-Actuator LA28 Gray 26 20190003 1
Wheel-set 75/75mm Uno 4/27 2014304 1
Foot frame 7 901791122 1
Foot plate ( V2 ) 8 901791094 1
Jointed arm Right 12 90129052H 1
Jointed arm Left 13 90129052V 1
Ball coupling M10 28 930000004 4
KC6S M10x25 19 930000039 3
Domed locking nut M10 11 930000008 6
S6SS M8x10 21 930000050 2
Locking nut M10 14 930000010 2
Cylindric bolt HCB 10x35 6 930000011 1
All details according to drawing no. R 3979115-6
4.1
Details Detail pos. Detail no. Unit
Screw M6S M12x105 18 930000012 2
Locking nut M12 15 930000056 2
Covertube black 23 900000051 0,12
Threaded pin bolt PSH M10x35 10 930000016 2
Split pin SP 2,5x16 16 930000017 1
Split pin SP 3,2x20 17 930000013 2
Washer Din433 10,5x18x1,6 3 930000019 1
Bearing 103-10-12 9 920000019 1
Screw F6S M10x40 20 930000006 2
Leg protector Sabina 22 900000285 2
Locking handle 24/25 2107101 1
Decal Sabina II 900001109 2
Decal ”Liko” 900000245 2
Tape- cushion 19x30 Uno 900000113 8
Base Sabina II EE
Underrede Sabina II EE Prod.no: 20290001
Doc. no: TI 20290001
2003-09-10
Fr. s/n 410001

www.liko.com
Assembly Instruction
Monteringsanvisning
4.1.1
2. When securing the mast to the base, the lift span can be
set at three different levels, as shown. Choose one of the
three holes to secure the mast to the base. The distance
between two holes is 5 cm (2 inches). Use the accompanying
locking handles to secure the mast to the base.
1. Lower the mast into the tube on the base.
Individual adjustment of lifting height
Patient’s height Pos.
< 170 cm (<67 inch.) 1
160-190 cm (63-75 inch.) 2
> 180 cm (>71 inch.) 3
3. A) Place the brace for the footrest into
the bracket on the mast, making sure the
frame is secure.
B) Press the footrest into the frame.
4. Insert the brace for the lower-leg
support into the mast’s lower-leg sup-
port mount.
Use knob A to adjust the depth, i.e.
the distance to the patient’s knees/
shins.
5. Mount lever for base-width adjustment
(Sabina II EM only):
• Press in the catch on the base with
one nger.
• Slide lever into place.
• Turn the lever until it clicks securely
in place on the base.
6. Connect the cables as follows:
• Mast motor cable to socket number 1
(see illustration above)
• Base motor cable to socket number 2
(not Sabina II EM).
• Handcontrol cable to socket number 3.
7. A) Connect the extension cable for the charging cable
to the control box.
B) Insert the extension cable in the tension clip under-
neath the control box.
C) Connect the charging cable to the extension cable.
Base Sabina
Underrede Sabina
Prod.no: 20290001
Doc. no: TI 20290001
2003-09-10

www.liko.com
Spareparts Specication
Reservdelslista
Serial no ................................ Version ................................ Release ................................
All details according to drawingnr. R 3979116-12
Details Detail pos. Detail no. Unit
Mast Sabina II 1 901791047 1
Arm Sabina 2 901991264 1
Motor-Actuator Sabina 7 20290023 1
Liftarm plastic cover 8 20190045 1
Control box Sabina II 4 20290024 1
Battery box 5 2006106 1
Leg support Sabina 16 20290021 1
Star wheel SR40 22 M8 15 14 930000191 1
Star wheel SR40 22 M8 15 23 930000344
Leg support cuvre 24 901979111 1
Attchment MBJ2 10 900000001 1
MC6S M5x8 low 10 930000001 4
Hand control ES 6 20090024 1
Lifthook Sabina 28 901791062 2
Safety Latch 30 31190018 2
Hookbushing Sabina 29 901973029 2
Details Detail pos. Detail no. Unit
Locking nut M10 12 930000010 3
Screw M6S M10x70 9 930000045 1
Top cover M10 gray 13 900000043 4
Washer plastic 36 900001372 2
K6S M6x20 31 930000244 2
Plastic cover RHS 60x40 37 900000049 1
IKP 30 26G 32 900000002 2
Bearing 10*12*6 34 920000017 1
Decal Sabina II 900001109 2
Decal trash can PB 900000553 1
Decal ETL U1-2/Sa 900000339 1
Top cover IKPT 15 12 G 900000292 1
Holder for charging cable 2107100 1
Mast Sabina ll EE
Pelare Sabina ll EE Prod.no: 20290025
2003-09-10
Fr. s/n 410001
4.2

www.liko.com
Spareparts Specication
Reservdelslista
Serial no ................................ Version ................................ Release ................................
All details according to drawingnr. R 3039105-1
4.2
Details Detail pos. Detail no. Unit
Mast Sabina II 20 901791047 1
Arm Sabina 1 901991264 1
Motor-Actuator Sabina 33 20290023 1
Liftarm plastic cover 21 20190045 1
Control box Sabina II 5 20290024 1
Battery box 3 2006106 1
Leg support Sabina 17 20290021 1
Star wheel SR40 22 M8 15 29 930000191 1
Star wheel SR40 22 M6 15 28 930000344
Leg support cuvre 11 901979111 1
Attchment MBJ2 18 900000001 1
MC6S M5x8 low 18 930000001 4
Hand control EM 7 20090016 1
Lifthook Sabina 15 901791062 2
Safety Latch 35 31190018 1
Hookbushing Sabina 8 901973029 2
Details Detail pos. Detail no. Unit
Locking nut M10 16 930000010 3
Screw M6S M10x70 26 930000045 1
Top cover M10 gray 13 900000043 4
Washer plastic 4 900001372 2
K6S M6x20 23 930000244 2
Plastic cover RHS 60x40 38 900000049 1
IKP 30 26G 37 900000002 2
Bearing 10*12*6 6 920000017 1
Decal Sabina II 900001109 2
Decal trash can PB 900000553 1
Decal ETL U1-2/Sa 900000339 1
Top cover IKPT 15 12 G 900000292 1
Holder for charging cable 2107100 1
Mast Sabina ll EM
Pelare Sabina ll EM Prod.no: 20290027
2003-09-10

www.liko.com
Assembly Instruction
Monteringsanvisning
123
4.2.1
After assembling, check the following:
• Check that the lifting motion as well as the
width adjustment of the base coincides with
the indicators on the hand control.
• Check that the emergency lowering device
functions properly.
• Check the wheel brakes.
• Check the battery charge.
• Check that the LED lamps on the charger
lights when charging.
Before assembling Sabina, check that you
have the following parts and tools:
• Lift assembly and overhead beam.
• Base with motor for width adjustment.
• Hand control with cable.
• Tools: Wrench 17, (2)
• Connection cable for charging.
• Battery.
• Frame for the footrest and footrest.
• Kneepad.
Individual adjustment of lifting
height
Best position:
Patient's height Pos.
< 170 cm 1
160-190 cm 2
> 180 cm 3
2. When securing the mast to
the base, you have the option
of setting the liftspan in three
different levels.
Choose one of the three holes
to secure the mast to the base.
The distance between two
holes is 5 cm.
(2 inches)
Use locking handles or
screw M10x60 and locking-nut
M10. Tighten with tool if
you use screw and nut.
3. Place the removable battery-
pack into position on top of the
electronic power pack. Check
that the batterypack is locked
to the assembling part.
A "click" sound will be heard.
1. Lower the mast into the
pipe on the base as shown
in the picture.
4. Connect the cables as follows:
Hand control cable to socket no. 1
Motorcable mast to socket no. 2
Motorcable width adjustment to socket no. 3
5.Reset the emergency
brake by turning the button
in the direction shown by
the arrow on top of the
button.
Mast Sabina
Pelare Sabina Prod.no: 20290007
Doc. no: TI 20290007
2003-09-10

www.liko.com
Spareparts Specication
Reservdelslista
Serial no ................................ Version ................................ Release ................................
Details Detail pos. Detail no. Unit.
Attachment for controlbox MBJ2 10/22 900000001 1
MC6S M5*8 low 10/22 930000001 4
All details according to drawing no. R 3979116-12/ 3039105-1
4.19
x4
Attachment for Control Box
Monteringsbeslag kontrollbox Prod.no: 20090023
Doc. no: TI 20090023
2003-09-10

www.liko.com
Assembly Instruction
Monteringsanvisning
4.19.1
2. 3.
1.
4. 5.
Tools required:
3 mm
Attachment for Control Box
Monteringsbeslag kontrollbox Prod.no: 20090023
Doc. no: TI 20090023
2003-09-09
