Liko LikoScale 400 User manual

* This user guide is a complement to the complete documentaon issued by the manufacturer of the scale.
The intenon with this document is to make it easier for our customers to use LikoScale in combinaon with Liko’s products.
For detailed informaon regarding the scale we refer you to the manufacturer’s Operang and Service Manual (aached).
LikoScale 400 accessory can be used with the following Liko lis:
LikoScale™ 400
Accessory
User Guide*
Prod. No. 3156226
7EN160276 Rev. 2
ENGLISH
Golvo™mobile li (all models)
Likorall™ overhead li (all models)
Mulrall™overhead li (all models)
Liko™ MasterLi overhead li (all models)
Viking™mobile li (S, M, L, XL)
- require Adapter 12 mm, Prod. No. 2016504.
Uno™ mobile li (all models)
- Uno models with serial numbers from 31825 require
Adapter 12 mm, Prod. No. 2016504.
- Uno models with serial numbers up to 31824 require
Adapter 8 mm, Prod. No. 2016502.
As the liing height is limited when LikoScale accessory is used in combinaon with LikoLight™ mobile li or Viking™ XS
mobile li, we do not recommend these alternaves.
LikoScale 400 is a convenient, easy-to-use scale that is intended for weighing paents in Liko mobile or staonary lis.
Together with Liko’s lis and liing accessories, LikoScale 400 enables safe and easy weighing.
The weight is shown on the scale’s digital display. By selecng unit mode the scale can display either kg or lbs.
The scale should only be used in combinaon with approved lis and accessories in accordance with the instrucons in this
guide.

2
LikoScale™ 400 accessory • 7EN160276 Rev 2 www.hill-rom.com I www.liko.com
Before assembly, make sure you have the following:
• Tool kit, 2 screws, 2 locking nuts • User Guide from Liko
•2 sleeves • Operang and Service Manual from manufacturer
• Baery • Declaraon of Calibraon
LikoScale 400 accessory is delivered with a 9 V baery with a baery life of about 3000 readings.
Installaon of baery:
1. Open the door on the back of the scale.
2. Install the baery.
3. Close the door.
When the baery needs to be replaced, a small baery symbol will appear
in the upper le corner of the display.
NOTE! Old baeries should be le at the nearest recycling staon.
Assembly Instrucons
Installing/replaceing the baery
LikoScale 400 accessory is delivered with two sleeves. The aachment type you have above and below the scale, and the
type of sling bar you have, determines if both sleeves must be used. Follow the assembly instrucons for the appropriate li,
aachment point, and sling bar.
Viking™ mobile li, Uno™ mobile li: Fixed assembly with adapter
1. Remove the liing accessory from the li.
2. Mount the appropriate adapter (see previous page) on to the li in accordance
with the assembly instrucon.
3. Aachment point under the scale:
Alternave 1 with Universal sling bar
Place one sleeve on the scale´s lower aachment point.
Mount the liing accessory under the scale, using bolt and locking nut provided.
Alternave 2 with Standard sling bar
Mount the liing accessory under the scale, using bolt and locking nut provided.
4. Place one sleeve on the scale´s upper aachment point. Mount the scale in its
upper aachment to the adapter, using bolt and locking nut provided.
When disassembling the scale, the adapter must be removed from the li before a liing accessory is reassembled on
to the li.
Viking™ mobile li, Uno™ mobile li: Quick-release assembly
Liko lis equipped with (Q-Link) quick fastener require the Adapter Kit LikoScale,
Prod. No. 3156232.
1. Remove the liing accessory from the li.
2. Place one sleeve on the scale´s upper aachment point.
3. Mount the Adapter Kit LikoScale in accordance with the assembly instrucon.
4. Mount the scale on to the li.
5. Mount the liing accessory under the scale.
Sleeve
Alt. 1
Alt. 2
Sleeve
Sleeve
Sleeve

3
LikoScale™ 400 accessory • 7EN160276 Rev 2 www.hill-rom.com I www.liko.com
The normal climate range for operaon of LikoScale 400 accessory is between +10o C (50o F) to +40o C (104o F) at a relave
humidity not exceeding 95%.
The scale must not be stored at temperatures below -20°C (-4°F ) or above +50°C (+122°F).
When the scale is stored for more than 6 months, the baery should be removed. Follow instrucons for Installing/replaceing
the Baery.
Before weighing, ensure the scale has been installed in accordance with the Assembly Instrucons on pages 2-3.
Before liing, check that the liing accessory is hanging vercally and can move freely.
Seng of unit mode (kg/lbs.)
Press the (kg/Ibs) - buon on the scale to display either kg or lbs.
Weighing with LikoScale 400 accessory
The scale can be reset to zero with or without the sling. If the scale is reset to zero without the sling aached to the sling bar,
the weight of the paent will include the weight of the sling. Therefore the weight of the sling must be
subtracted to obtain the correct weight of the paent.
Reseng the scale with the sling is described below:
1. Connect the sling to the sling bar.
2. Start the scale by pressing the ”OPERATE” buon.
3. Reset the scale by pressing the ”ZERO” buon.
When the scale is ready, the value ”0.0” will appear on the display.
4. Remove the sling from the sling bar and apply the sling to the paent in accordance with the instrucon guide for the sling
and li. Connect the sling to the sling bar.
5. Raise the sling bar so the paent rises slightly. Never li a paent higher than necessary.
6. When the liing moon has stabilized, press the ”OPERATE” buon. The paent’s weight can now be read on the display.
The scale turns o automacally aer about 60 seconds. For further readings, press the ”OPERATE” buon.
7. Lower the paent carefully and remove the sling from the sling bar.
Operaon
Sleeve
Sleeve
Alt. 1
Alt. 2
Likorall™ overhead li, MasterLi overhead li, Golvo™ mobile li: Fixed assembly
1. Remove the liing accessory from the li.
2. Aachment point under the scale:
Alternave 1 with Universal sling bar
Place one sleeve on the scale´s lower aachment point.
Mount the liing accessory under the scale, using bolt and locking nut provided.
Alternave 2 with Standard sling bar
Mount the liing accessory under the scale, using bolt and locking nut provided.
3. Mount the scale on to the li, using bolt and locking nut provided.
Mulrall™ overhead li, Likorall™ overhead li, MasterLi overhead li, Golvo™ mobile li: Quick-release assembly
Liko lis equipped with (Q-Link) quick fastener require the Adapter Kit LikoScale, Prod. No. 3156232.
1. Remove the liing accessory from the li
2. Place one sleeve on the scale´s upper aachment point.
3. Mount the Adapter Kit LikoScale in accordance with the assembly instrucon.
4. Mount the scale on to the li.
5. Mount the liing accessory under the scale.

Calibraon
For calibraon, see manufacturer’s Operang and Service Manual or contact Liko.
Technical Data
Display resoluon: 0.1 lb / 0.1 kg
Accuracy: 0.1 % +/- Digit of reading
Max. load: 400 kg (880 lbs.)
Min. load: 10 kg (22 lbs./1.57 st.)
Reset: One buon reset (“zero”)
Power supply: Baery 9 V
Display: Digital, liquid crystal (LCD)
Size: 76 x 76 x 102 mm (2.3 x 2.3 x 4 in.) (W x L x H)
Weight: 0.6 kg (1.3 lbs.)
Temperature range: +10o C to +40o C (+50o F to +104o F)
Humidity range: 0% - 95%
Distributor:
Liko AB
Nedre vägen 100
SE-975 92 Luleå, Sweden
Manufacturer:
SR Instruments, Inc
600 Young Street
Tonawanda, NY 14150, USA
www.hill-rom.com I www.liko.com
© Copyright Liko R&D AB 2015
