Liko SlingGuard 450 User manual

SlingGuard™ sling bar
Instrucons for Use
SlingGuard™ 450 Prod. No. 3308020
SlingGuard™ 450 with Quick- Hook Mul Prod. No. 3308520
SlingGuard™ 670 Twin Prod. No. 3308040
SlingGuard™ 670 Twin with Quick- Hook Mul Prod. No. 3308540
7EN161113 Rev. 5
ENGLISH 2020
SlingGuard™ 670 Twin sling bar
SlingGuard™ 450 sling bar

www.hillrom.com
7EN161113 Rev. 5 • 2020 2
Table of Contents
Symbol Descripon ......................................................................................................................... 3
Product Descripon ........................................................................................................................ 4
Intended use .............................................................................................................................. 4
Safety Instrucons .......................................................................................................................... 5
SlingGuard™ 450 sling bar - Aach the sling suspension loops to the sling bar hooks. .............. 6
SlingGuard™ 670 Twin sling bar - Aach the sling suspension loops to the sling bar hooks. .... 7
Assembly .......................................................................................................................................... 8
Fixed assembly of SlingGuard™ sling bar to li .......................................................................... 8
Assembly of SlingGuard™ sling bar with Quick-Hook Mul ....................................................... 9
Dimensions ..................................................................................................................................... 9
SlingGuard™ 450 sling bars: ........................................................................................................ 9
SlingGuard™ 670 Twin sling bar ................................................................................................. 9
Cleaning and disinfecon .............................................................................................................. 10
Equipment ................................................................................................................................ 10
Cleaning instrucons ................................................................................................................ 10
Disinfecon Instrucons ........................................................................................................... 10
Use of cleaning and disinfecng agents on LikoGuard™ Overhead li .................................... 11
Care and maintenance ................................................................................................................... 12
Service ...................................................................................................................................... 12
Expected life me ..................................................................................................................... 12
Recycling Instrucons ............................................................................................................... 12
Product Changes ....................................................................................................................... 12
Design and Quality by Liko in Sweden ...................................................................................... 12
Noce to Users and/or Paents in EU ...................................................................................... 12

7EN161113 Rev. 5 • 2020 3www.hillrom.com
These symbols can be found in this document and/or on the product.
Symbol Descripon
Symbol Descripon
Warning; this situaon requires extra care and aenon.
CE mark
Legal manufacturer.
Read instrucons for use before use.
Date of manufacturing.
Important! Failure to follow the instrucons may lead to damage to the product.
Cauon! consult instrucons for use.
Read instrucons for use before use.
Product Idener.
Serial Number.
Medical device.
Recyclable.
(01) 0100887761997127
(11) Y Y M M DD
(21) 012345678910
GS1 Data Matrix Barcode that may contain following informaon.
(01) Global Trade Item Number
(11) Producon Date
(21) Serial Number

www.hillrom.com
7EN161113 Rev. 5 • 2020 4
Product Descripon
SlingGuard™ Sling bars are available in two versions of aachment to the li. Fixed aachment or the quick-aachment device
Quick- Hook Mul. SlingGuard™ Sling bars has latches to protect against involuntary unhooking of the slings suspension loops.
Medical Device Class I Product
Maximum load: 363 kg (800 Ibs.)
1. SlingGuard™ 450 sling bar
2. Aachment point to li
3. Latch
4. Sling bar hook
1
2
3
4

7EN161113 Rev. 5 • 2020 5www.hillrom.com
Safety informaon
A Liko™ li system is a combinaon of products. Each product has its own maximum load marking. The lowest specied
maximum load of the products that comprises the system sets the maximum load for the complete li system.
The li system can contain following products; li rails, a li motor, a sling bar, a sling or other recommended accessories.
Idenfy the maximum load for the complete li system by reading the maximum load marking on each product in the system.
Contact your Hill-Rom representave for support and advice.
Intended use
A SlingGuard™ sling bar is used as an aid in carrying out lis but does not come into contact with the paent, therefore we do
not go into dierent paent condions in the instricon for use. Surrounding (funconal) environment: Temp. +5 °C to +40 °C,
relave humidity 15% to 93% non-condensed. Barometric pressure range of 70 kPa to 106 kPa.
In the event of any queries regarding this product, contact your Hill-Rom representave.
For guidance and support in choosing the correct sling, visit www.hillrom.com or contact your Hill-Rom representave.
Note! Always read the instrucon for use that comes with Liko´s dierent sling models for correct and safe use of the sling.
The total maximum load for a li system is always determined by the product in the system with the lowest
specied maximum load.
Read and understand the Instrucon for use in its enrety before using the product.
Use of the product without a full understanding of the contents is subject to risk.
Read the instrucon for use for both the paent li and liing accessories before use. Liing and
transferring a person always involves a certain level of risk. It is important to completely understand the
contents of the instrucon for use. The equipment should only be used by trained personnel. Contact your
Hill-Rom representave in the event of any uncertaines or quesons.
Under no circumstances may the sling bar be modied. In the event of quesons, please contact Hill-Rom.

www.hillrom.com
7EN161113 Rev. 5 • 2020 6
Upper strap loops
Leg support loops
A
A
B
B
Sling with 4 suspension loops
SlingGuard™ 670 Twin sling bar
A
B
WRONG!
A
B
A
B
SlingGuard™ 450 sling bar - Aach the sling suspension loops to the sling bar hooks.
Note! For correct and safe use of a sling, always study the instrucon for use for the selected sling before liing.
Aach liing accessories correctly so that the sling bar hangs level and all sling bar hooks take all the
weight when liing!
Before liing always ensure that the sling’s strap loops are correctly connected to the sling bar hooks
when the sling straps are stretched, but before the paent is lied from the underlying surface.
The sling strap loops should be aached to the sling bar hooks so that the sling bar latches safely prevent
involuntary unhooking of the strap loops.

7EN161113 Rev. 5 • 2020 7www.hillrom.com
WRONG!
SlingGuard™ 670 Twin sling bar - Aach the sling suspension loops to the sling bar hooks.
Note! For correct and safe use of a sling, always study the instrucon for use for the selected sling before liing.
Sling with 4 suspension loops
Upper strap loops
Leg support loops
A
A
B
B
A
A
B
B
B
A
Sling with 6 suspension loops
A
A
C
C
B
B
Shoulder straps
Loop straps
Leg support loops
B
B
ABA
C
C
A
C

www.hillrom.com
7EN161113 Rev. 5 • 2020 8
Assembly
Fixed assembly of SlingGuard™ sling bar to li
Fits: LikoGuard™ L Overhead Li Prod. No. 3301030
LikoGuard™ XL Overhead Li Prod. No. 3301040
Torque: 1,25 ± 0,25 Nm (11 ± 2.2 in.Ibf)
1. 2. 3.
5.
4.
6.
7.
Tools required:
Torque Wrench: 0 - 10 Nm (88 in.Ibf)
Torx T25 X 2
Shall be assembled by personnel authorized by Hill-Rom!
Torx T25 X 1
Safety crical assembly!

7EN161113 Rev. 5 • 2020 9www.hillrom.com
Assembly of SlingGuard™ sling bar with Quick-Hook Mul
Fits: LikoGuard™ L Overhead Li Prod. No. 3301030
LikoGuard™ XL Overhead Li Prod. No. 3301040
Dimensions
SlingGuard™ 450 sling bars:
Prod. No. 3308020 (with xed aachment)
* Installaon dimensions: the distance between the sling bar hooks aachment point
(for sling etc.) to the sling bar’s central suspension point (CSP) to li.
model ABC H*
450 160 540 47 133
Weight: Approx. 1,8 kg / 4.0 Ibs.
Measurements in mm.
Measurements in Inch.
model ABC H*
450 6.3 21.3 1.8 5.2
g. b
* Installaon dimensions: the distance between the sling bar hooks aachment point
(for sling etc.) to the sling bar’s central suspension point (CSP) to li.
ABC H*
200 757 133 171
ABC H*
7.9 29.8 5.2 6.7
SlingGuard™ 670 Twin sling bar
Prod. No. 3308040 (with xed aachment)
Weight: Approx. 4.2 kg / 9.3 Ibs.
CSP (Central Suspension Point)
H*
B
C
A
CSP (Central Suspension Point)
A H*
C
B
Measurements in mm.
Measurements in Inch.
g. a
Mul-Link
Quick-Hook Mul
Open the Quick-Hook Mul with the green buon, see g.a and aach the Quick-Hook Mul to Mul-link at the li strap,
release the buon. The Quick-Hook Mul is now aached to the Mul-Link, see g.b.
Always check that the quick aachment device is correctly aached to the li strap aachment.

www.hillrom.com
7EN161113 Rev. 5 • 2020 10
Disinfecon Instrucons
1. For the use of suitable disinfectants see chapter “Use of cleaning and disinfecng agents on LikoGuard™ Overhead li“.
2. Use the choice of disinfectant according to the manufacturer’s instrucons and repeat the work step as in ”Cleaning instrucons.
3. Remove traces of disinfectant aer disinfecon. Wipe o the enre sling bar with a cloth moistened with clean water starng
from the top and working down. The cloth shall not be so damp that it drips.
Cleaning and Disinfecon
Equipment
• Safety equipment (such as rubber gloves, protecve glasses, aprons, face masks/protecve masks and overshoes) according
to guidelines and rounes in your organizaon and the manufacturer’s instrucons.
• Clean buckets
• Cloths
• So brushes
• Warm water
• See chapter ”Use of cleaning and disinfecng agents on LikoGuard™ Overhead li” for choice of suitable cleaning and
disinfecng agents.
All parts must be kept clean in order to avoid the risk of infecon. Necessary precauons must be taken to eliminate all visible
stains and dirt. The cleaning and disinfecon methods described are specically aimed at the li and all accessories. It has
been designed to save me and contribute to eecvely ghng healthcare related infecons.
SlingGuard™450 sling bar
Li Strap
Latch
Cleaning instrucons
1. If the sling bar includes the Quick-hook Mul, remove the Sling bar by disconnecng the Quick-hook Mul from the lis
Mul-Link connector, see ”Assembly of SlingGuard™ Sling bar with Quick-Hook Mul”.
2. Clean the sling bar with a cloth moistened with warm water and a neutral cleaning agent approved by your organizaon.
A so brush may be used to remove stains and resistant dirt.
3. Wipe o the enre sling bar with a cloth moistened with clean water starng from the top and working down. The cloth
shall not be so damp that it drips.
IMPORTANT! The li strap or the Emergency stop cord shall not be exposed to following agents: CSI, Oxivir Tb, Dispatch,
Chlor-Clean, Dismozon Pur or the equivalent.
Cleaning and disinfecon must always be carried out in accordance with the recommended instrucons.

7EN161113 Rev. 5 • 2020 11 www.hillrom.com
Chemical class Acve ingredients pH Cleaning agents /
Disinfectant *) Manufacturer *) May not be used on
the following items:
Quaternary ammonium chloride Didecyl dimethyl ammonium chloride = 8.704%
Alkyl dimethyl benzyl ammonium chloride = 8.19%
9.0 – 10.0 when using
Virex II (256)
(or equivalent)
Johnson/Diversey
Quaternary ammonium chloride Alkyl dimethyl benzyl ammonium chloride = 13.238%
Alkyl dimethyl ethylbenzyl ammonium chloride = 13.238%
9.5 when using
HB Quat 25L
(or equivalent)
3M
Accelerated hydrogen peroxide Hydrogen Peroxide 0.1-1.5%
Benzyl Alcohol: 1-5% Hydrogen Peroxide 0.1-1.5% Benzyl Alcohol: 1-5%
3Oxivir Tb
(or equivalent)
Johnson/Diversey
Li strap, (LikoGuard™)
Emergency stop cord (LikoGuard™)
Phenolic Ortho-Phenylphenol = 3.40%
Ortho-Benzyl-para-Chlorophenol = 3.03
3.1 +/- 0.4 when using Wexcide
(or equivalent)
Wexford Labs
Bleach Sodium hypochlorite 12.2 Dispatch
(or equivalent)
Caltech
Li strap, (LikoGuard™)
Emergency stop cord (LikoGuard™)
Alcohol Isopropyl alcohol = 70% 5.0 – 7.0 Viraguard
(or equivalent)
Veridien
Quaternary ammonium n-Alkyl dimethyl benzyl ammonium chlorides = 0.105%
n-Alkyl dimethyl ethylbenzyl ammonium chlorides = 0.105%
11.5 - 12.5 CSI
(or equivalent)
Central Soluons Inc.
Li strap, (LikoGuard™)
Emergency stop cord (LikoGuard™)
Benzyl-C12-18- alkyldimethylammonium, chlorides
Benzyl-C12-18-alkyldimethylammonium, chlorides (22%) 2-Phenoxyethanol (20%) Tridecylpolyethylenglycolether (15%) Propan-2-ol (8%)
approx. 8.6 when using Terralin Protect
(or equivalent)
Shülke
Organic peroxide (type E, solid) Magnesium monoperoxyphtalate hexahydrate (50-100%)
Anionic surfactant (5-10%) Nonionic surfactant (1-5%)
5.3 when using Dismozon Pur
(or equivalent)
Bode
Li strap, (LikoGuard™)
Emergency stop cord (LikoGuard™)
Ethanol Hydrogen peroxide (2.5-10%)
Lauryldimethylamine oxide (0-2.5%) Ethanol (2.5-10%)
7Anioxy-Spray WS
(or equivalent)
Anios
Troclosene sodium Adipic acid 10-30%
Amorphous silica < 1% Sodium Toluene sulphonate 5-10% Troclosene sodium 10-30%
4-6 when using Chlor-Clean
(or equivalent)
Guest Medical Ltd
Li strap, (LikoGuard™)
Emergency stop cord (LikoGuard™)
*) or equivalent
Use of cleaning and disinfecng agents on LikoGuard™ Overhead li

Care and Maintenance
To ensure smooth operaon and use, some details should be checked before each use:
• Check that the screws and locking nuts at the sling bar and the li strap xings are ghtened
• Check that the latches are funconal and intact, missing or damaged latches must always be replaced with new ones.
• When using the Quick-release system, check that the Quick-release Hook is correctly aached to the li and sling bar, see
”Assembly of SlingGuard™ sling bar with Quick-Hook Mul”.
• Before liing, check that the liing accessory hangs vercally and can move freely.
Clean a SlingGuard™ Sling bar with a moist cloth, using warm water, as necessary.
For detailed informaon about cleaning and disinfecon of your Hill-Rom product we refer to chapter ”Cleaning and
disinfecng”.
Important! A SlingGuard™ sling bar shall not be exposed to running water.
Service
A periodic inspecon of the SlingGuard™ sling bar should be carried out at least once a year.
Expected life me
The product has an expected life me of 10 years when correctly handled, serviced and periodically inspected in accordance
with Liko product instrucons.
Recycling Instrucons
The product should be recycled as scrap metal.
Hill-Rom evaluates and provides guidance to its users on the safe handling and disposal of its devices to aid in the prevenon
of injury, including, but not limited to: cuts, punctures of the skin, abrasions, and any required cleaning and disinfecon of the
medical device aer use and prior to its disposal. Customers should adhere to all federal, state, regional, and/or local laws and
regulaons as it pertains to the safe disposal of medical devices and accessories.
If in doubt, the user of the device shall rst contact Hill-Rom Technical Support for guidance on safe disposal protocols.
Product Changes
Liko’s products undergo connuous development, which is why we reserve the right to make product changes without prior
noce. Contact your Hill-Rom representave for advice and informaon about product upgrades.
Design and Quality by Liko in Sweden
The management system for both manufacturing and development of the product is cered in accordance with ISO9001
and its equivalent for the medical device industry, ISO13485. The management system is also cered in accordance with the
environmental standard ISO14001.
Noce to Users and/or Paents in EU
Any serious incident that has occurred in relaon to the device, should be reported to the manufacturer and the competent
authority of the Member State in which the user and/or paent is established.
Periodic inspecon, repair and maintenance should be performed only in accordance with the Liko Service
Manual and by personnel trained by Hill-Rom and using original Liko spare parts.
The product should be used in accordance with the recommendaons for Expected Life Time.
© Copyright Liko R&D AB 2020. ALL RIGHTS RESERVED.
Liko AB
Nedre vägen 100
975 92 Luleå, Sweden
[phone]
www.hillrom.com
Liko AB is a subsidiary of Hill-Rom Holdings Inc.
