LIVARNO home 384947 2107 User manual

LED BULB STRING LIGHTS
IAN 384947_2107
LED BULB STRING LIGHTS
Operation and safety notes

GB / IE / NI Operation and safety notes Page 5

2
1
43
5

5GB/IE/NI
List of pictograms used....................................................................................................Page 6
Introduction...............................................................................................................................Page 6
Proper use........................................................................................................................................Page 6
Parts description..............................................................................................................................Page 6
Technical data.................................................................................................................................Page 7
Included items .................................................................................................................................Page 7
Safety information..............................................................................................................Page 7
Before use...................................................................................................................................Page 8
Start-up .........................................................................................................................................Page 8
Timer function ..................................................................................................................................Page 8
Cleaning and care................................................................................................................Page 9
Disposal........................................................................................................................................Page 9
Warranty.....................................................................................................................................Page 9
Warranty claim procedure.............................................................................................................Page 9
Service .............................................................................................................................................Page 10
V3.0

6 GB/IE/NI
List of pictograms used
Observe caution and safety notes! This icon indicates that the product
is mains operated.
Alternating current / voltage Polarity of output terminal
Direct current / voltage This product is suitable for indoors
and outdoor use.
Never leave children unattended with
packaging materials or the product. Plugs for indoor use only.
Short-circuit-proof safety isolating
transformer Splashproof
Independent lamp control gear Non dimmable
Watt (Effective power) Safety class II
CE mark indicates conformity with
relevant EU directives applicable for
this product.
UKCA mark indicates conformity
with relevant Great Britain regula-
tions applicable for this product.
(The UKCA mark logo is valid in
Great Britain only.)
LED bulb string lights
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product. They
contain important information concerning safety,
use and disposal. Before using the product, please
familiarise yourself with all of the safety information
and instructions for use. Only use the product as
described and for the specified applications. If you
pass the product on to anyone else, please ensure
that you also pass on all the documentation with it.
Proper use
This product is suitable for use indoors
and outdoors. This product is intended
for use in private, domestic environment
only and not for commercial purposes or for use
in other applications.
Plugs for indoor use only.
Parts description
1Light chain
2Mains adapter
3Union nut
4Plug lead
5ON / OFF button

7GB/IE/NI
Technical data
Light chain + Mains adapter:
Total power
consumption: HG06008A-BS: 3.6W
HG06008B-BS: 4.7W
Light chain:
Operating voltage: 12V
HG06008A -BS : 2.4W,
HG06008B
-BS : 3.6 W
LEDs: 3 V
(LEDs are non-
replaceable) x 30
Protection system: IP44 (splashproof)
Mains adapter:
Nom. voltage, primary:
220–240V∼, 50/ 60Hz
Nom. voltage,
secondary:
12V
3.6 W for Model
HG06008B-BS,
2.4 W for Model
HG06008A-BS
Protection class: II /
Mains adapter (Model A (S024B120N2D)
Model B (S036B120N2D))
SELV: Safety extra low voltage
Ta: Maximum rated ambient
temperature
Tc:
Rated maximum operat-
ing temperature of the
case of a controlgear
Included items
1 LED bulb string lights
1 Mains adapter
1 Operating instructions
Safety information
YOU SHOULD STORE ALL SAFETY INFORMA-
TION AND INSTRUCTIONS IN A SAFE PLACE
IN CASE YOU NEED TO REFER TO THEM AG AIN
IN THE FUTURE!
Always keep children away from
the product.
This product is not a toy and should not be
played by children. Children are not able to
understand the dangers that can occur when
handling this product.
This product can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabili-
ties or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the product in a safe way
and understand the hazards involved. Children
shall not play with the product. Cleaning and
u
ser maintenance shall not be made by child ren
without supervision.
Ensure that the product is installed by suitably
experienced or qualified persons only.
CAUTION! RISK OF OVERHEATING!
Do not operate the product inside the packaging.
After use, keep the product in the packaging
to prevent unwanted damage.
Do not pull the light chain and make sure it is
laid down properly so that no one walks or
trips over it.
Do not attach any other objects to the product.
Avoid the danger of
death from electric shock!
Only use the mains adapter provided for the
light chain.
Before connecting the product to the mains
you should always check the product and the
mains adapter 2for any damage.
Never use the product if you discover that it is
damaged in any way.
This product’s external flexible wiring is non-
replaceable. Hence if it becomes damaged
you must dispose of the entire product.
Never open any of the electrical parts or insert
any kind of object into them.
Protect the light chain from sharp edges,
mechanical loads and hot surfaces.
Do not install with sharp fasteners or nails.
Always unplug the mains adapter 2from the
socket before installation, dismantling or cleaning.

8 GB/IE/NI
Never touch the mains adapter 2plug or the
product itself with wet hands.
The product must not be electrically connected
to other light chains.
If the product is not in use for any length of
time (e.g. holidays), disconnect them from the
mains adapter.
If you have any questions about the product
or are unsure about any of its aspects, please
seek the advice of an electrical equipment
specialist.
Only use the product with the supplied mains
adapter 2all warranty claims will otherwise
expire.
The product is protected against splash water
(IP44). This protection type will only be main-
tained if the electrical socket used also comp lies
with at least this protection type.
This product is intended for use outdoors but
should be plugged into a socket which is
located in an indoor location (e.g. a shed,
garage or pouch).
The socket into which this product is plugged
must be protected by a residual current circuit
breaker (RCD) with a trip current not greater
than 30 mA.
Sockets positioned outdoors for use with this
product should be of a type which is adequately
water proof for an outdoor location and should
be located at least 2.5 m from the nearest body
of water or any location where water may collect.
Please note that the mains adapter 2will still
use some energy even when the light chain 1
have been switched off if the mains adapter 2
is still plugged in. To switch the product off
completely, unplug the mains adapter 2from
the socket.
The LEDs are non-replaceable.
If the LEDs have reached the end of their lives,
the entire product must be replaced.
Never attempt to install a separate bulb into
a E27 socket.
Never remove light bulbs and install them in
mains voltage sockets.
This lighting chain must not
be used without all gaskets being in place.
The LED driver can only be replaced by a
professional
Before use
Note: Please remove all packaging material from
the product.
Start-up
Insert the plug of the lead 4into the socket
of the mains adapter 2.
Tighten the union nut 3clockwise.
Plug the mains adapter 2into an easy to
access socket!
Please note that the mains adapter 2will still
use some energy even when the product has
been switched off if the mains adapter 2is
still plugged in. To switch the product off com-
pletely, unplug the mains adapter 2from the
socket.
Timer function
The ON/OFF button
5
has three functions:
1 x push of the button:
The product lights up continuously.
2 x push of the button:
The product lights up continuously for 6 hours
and then switches itself off for 18 hours. The
product will then switch on again for 6 hours
at the allocated time and then switch off for
18 hours.
Note: The ON /OFF button
5
lights up when
the timer function has been activated.
3 x push of the button:
The product is switched off.

9GB/IE/NI
Cleaning and care
CAUTION! DANGER OF ELECTRIC SHOCK!
First pull the mains adapter 2out of the mains
socket.
CAUTION! DANGER OF ELECTRIC SHOCK!
For reasons of electrical safety the mains adapter
2
must never be cleaned with water or other liquids
or immersed in water.
Do not use any solvents, petrol or similar items.
This would damage the product.
Only a dry, lint-free cloth should be used for
cleaning.
Disposal
The packaging is made entirely of recyclable
materials, which you may dispose of at local
recycling facilities.
b
a
Observe the marking of the packaging
materials for waste separation, which
are marked with abbreviations (a) and
numbers (b) with following meaning:
1–7: plastics/20–22: paper and fibre-
board / 80–98: composite materials.
The product and packaging materials
are recyclable, dispose of it separately
for better waste treatment. The Triman
logo is valid in France only.
Contact your local refuse disposal au-
thority for more details of how to dispose
of your worn-out product.
To help protect the environment, please
dispose of the product properly when it
has reached the end of its useful life and
not in the household waste. Information
on collection points and their opening
hours can be obtained from your local
authority.
Warranty
The product has been manufactured to strict qual-
ity guidelines and meticulously examined before
delivery. In the event of product defects you have
legal rights against the retailer of this product.
Your legal rights are not limited in any way by our
warranty detailed below.
The warranty for this product is 3 years from the
d
ate of purchase. The warranty period begins on
the date of purchase. Please keep the original
sales receipt in a safe location. This document is
required as your proof of purchase.
Should this product show any fault in materials or
manufacture within 3 years from the date of pur-
chase, we will repair or replace it – at our choice
– free of charge to you. This warranty becomes
void if the product has been damaged, or used or
maintained improperly.
The warranty applies to defects in material or man-
ufacture. This warranty does not cover product
parts subject to normal wear, thus possibly consid-
ered consumables (e.g. batteries) or for damage
to fragile parts, e.g. switches, rechargeable bat-
teries or glass parts.
Warranty claim procedure
To ensure quick processing of your case, please
observe the following instructions:
Please have the till receipt and the item number
(IAN 384947_2107) available as proof of pur-
chase.
You will find the item number on the rating plate,
an engraving on the front page of the instructions
for use (bottom left), or as a sticker on the rear or
bottom of the product.
If functional or other defects occur, please contact
the service department listed either by telephone
or by e-mail.
You can return a defective product to us free of
charge to the service address that will be provided

10 GB/IE/NI
to you. Ensure that you enclose the proof of pur-
chase (till receipt) and information about what the
defect is and when it occurred.
Service
Service Great Britain
Tel.: [phone]
E-Mail: [email protected]
Service Ireland
Tel.: [phone]
E-Mail: [email protected]
Service Northern Ireland
Tel.: [phone]
E-Mail: [email protected]
Plugs for indoor use only.

OWIM GmbH & Co. KG
Stiftsbergstraße 1
74167 Neckarsulm
GERMANY
Model-No.: HG06008A-BS / HG06008B-BS
Version: 03 / 2022
Last Information Update: 11 / 2021
Ident.-No.: HG06008A / B-BS112021-GB / IE
IAN 384947_2107
