Ltech AD-15-100-700-E1A1 User manual

Dimming interface: 0-10V (1-10V/10VPWM/RX), Push DIM.
T-PWM™ digital dimming.
Withsoft-onandfadeinfunction,visualmorecomfortable.
Automatic recognition of 0-10V, 1-10V input signal.
Dimming range: 0~100%, LED start at 0.01% possible.
0-100% flicker-free,High frequency exemption level.
Innovative thermal management technology, intelligent power life protection.
Multiple current & wide voltage, suitable for different power LED.
Non-load output voltage 0V to prevent damages to LED caused by poor contact.
Short circuit / Over-heat / Over load / Non-load protection, recover automatically.
Suitable for internal lights application forⅠ/Ⅱ/Ⅲ.
Up to 50,000-hour life time.
5 years warranty (Rubycon capacitor).
LED
Intelligent Driver
AD-15-100-700-E1A1 AD-25-150-900-E1A1 AD-36-200-1200-E1A1
10-54Vdc
58Vdc
1W~15W 1.5~25W 2W~36W
100-700mA 150-900mA 200-1200mA
±5%
≤2V
0Vdc
L-N: 1kV
<0.5mA/230Vac
83%
<0.15A <0.2A
84% 87%
<0.3A
≤3600Hz
OUTPUT
Model
INPUT
ENVIRONMENT
PROTECTION
SAFETY
&
EMC
OTHERS
Dimensions
Packing
Weight(G.W.)
167×41×32mm(L×W×H)
168×43×35mm(L×W×H)
165g±10g
Withstand Voltage
Isolation Resistance
Safety Standards
EMC Emission
EMC Immunity
I/P-O/P: 3750Vac
I/P-O/P: 100MΩ/500VDC/25°C/70%RH
EN61000-4-2,3,4,5,6,8,11 EN61547
Over-heat Protection
Short Circuit Protection
Max Output Voltage
Output Power
Leakage Current
Anti Surge
Inrush Current(typ.)
Efficiency(typ.)
Input Current
Frequency
Input Voltage Range
Dimming Interface
Ripple & Noise
Dimming Range
Working Temperature
Working Humidity
Storage Temp., Humidity
Temp. Coefficient
Vibration
Output Current
Output Voltage
Specification
Over Load Protection
Intelligently adjusting or turning off the output current if the PCB temperature≥110°C, , auto recovers
Non-load Protection Shut down the output if no load, auto recovers when load back to normal
Shut down automatically if short circuit occurs, auto recovers
Shut down the output when rated power≥102%, auto recovers
ta: 50°C tc: 90°C
20 ~ 95%RH, non-condensing
-40°C ~ 80°C, 10~95%RH
±0.03%/°C (0-50°C)
10~500Hz, 2G 12min/1cycle, period for 72min. each along X, Y, Z axes
Current Accuracy
PWM Frequency
0~100%, LED start at 0.01% possible
Non-load Output Voltage
0-10V (1-10V/PWM/RX), Push DIM
220-240Vac
50/60Hz
Power Factor PF>0.90/230Vac, at full load PF>0.93/230Vac, at full load PF>0.95/230Vac, at full load
THD ≤20% at 230Vac, at full load
Cold start 2.48A at 230Vac
(twidth=25.1μs measured at 50% Ipeak)
Cold start 2.28A at 230Vac
(twidth=36μs measured at 50% Ipeak)
Cold start 6.32A at 230Vac
(twidth=60.1μs measured at 50% Ipeak)
1www.ltech-led.com
IEEE 1789
Strobe Test Standard
Strobe Level Almost flicker-free / High frequency exemption level
0-10V
Push DIM
<2%
LF Current Ripple
GB19510.1, GB19510.14
EN61347-1, EN61347-2-13, EN62493
EN61347-1, EN61347-2-13, EN62384
AS61347-1, AS61347-2-13
EN61347-1, EN61347-2-13, EN62384
GB/T17743, GB17625.1
EN550515, EN61000-3-2, EN61000-3-3, EN61547
EN550515, EN61000-3-2, EN61000-3-3
CCC
TUV
CE
RCM
ENEC
CCC
RCM
CE
China
Germany
European Union
Australia
Europe
China
Australia
European Union
UKCA
5 in 1 dimming
0-10V
1-10V
PWM
RX
Push DIM
Over-heat
Protection
Short Circuit
Protection
Multiple
Current
Over Load
Protection
PUSH DIM
0-10V
Certificate No. U6 17 07 01119 004
EMC Certificate No. BST1702498520001Y-1EC-1
LVD Certificate No. BST1709992470001Y-1SC-2
ENEC
CE
Certificate No. B 17 06 01119 001
TUV
RCM Equipment registration No: E2017013627 Ref: ESV170365
0.01-100%
Flicker-free
IEEE 1789
Super depth dimming technology
Flicker-free
IEEE 1789
Super depth
dimming
technology
Class 2
BS EN 61347-2-13:2014+A1:2017 BS EN 61347-1:2015+A1:2021
Britain
UKCA BS EN IEC 55015:2019/A11:2020, BS EN 61547:2009, BS EN IEC 61000-3-2:2019, BS EN 61000-3-3:2013/A1:2019
Britain

Push DIM
*
AD-15-100-700-E1A1
AD-25-150-900-E1A1
AD-36-200-1200-E1A1
ON
ON
ON
OFF
OFF
OFF
500mA180mA 600mA 700mA300mA 350mA 450mA100mA
1W-5.4W 1.8W-9.72W 3W-15W 3.5W-15.05W 4.5W-15.3W 5W-15W 6W-15W 7W-15.4W
10-54V 10-54V 10-50V 10-43V 10-34V 10-30V 10-25V 10-22V
150mA 250mA 300mA 350mA 500mA 600mA 700mA 900mA
10-54V 10-54V 10-54V 10-54V 10-50V 10-42V 10-36V 10-28V
1.5W-8.1W 2.5W-13.5W 3W-16.2W 3.5W-18.9W 5W-25W 6W-25.2W 7W-25.2W 9W-25.2W
200mA 350mA 500mA 600mA 700mA 900mA 1050mA 1200mA
10-54V 10-54V 10-54V 10-54V 10-52V 10-40V 10-35V 10-30V
2W-10.8W 3.5W-18.9W 5W-27W 6W-32.4W 7W-36.4W 9W-36W 10.5W-36.75W 12W-36W
On/off control: Short press.
Stepless dimming: Long press.
Dimming memory: Brightness will be the same as previously adjusted when turning off and on again.
With every other long press, the brightness goes to the opposite direction.
LED Current Selection
Quick options: DIP switch for 8 optional currents' quick selection ( s e e the table below ).
E.g. LED 3.2V/pcs: 10-54V can power 3-16pcs LEDs in series, 10-22V can power 3-6pcs LEDs, the max quantity of LEDs in series will be subject to the actual voltage of LED.
*After current setting by DIP switch, power off and then power on to make the new current effective.
Wiring Diagram
Reset Switch
N
L0-10V
3 3
N
L
0-10V Connection Push DIM Connection
Short press: on/off, long press: dimming.
0~100% dimming
4 in 1 dimming: 0-10V
1-10V
PWM
RX
Push DIM
0~100% dimming
The dimming interface priority: First 0-10V, next Push DIM.
Output Power
Output Power
Output Power
Output Voltage
Output Voltage
Output Voltage
Output Current
Output Current
Output Current
DIP Switch
DIP Switch
DIP Switch
0-10V
Push DIM
2www.ltech-led.com
Dimensions
Unit: mm
167
162
41
32
Wire diameter: 0.75-1.5 (20-16AWG)
Strip length: 8-9mm
Wire diameter: 0.5-1.5 (22-16AWG)
Strip length: 8-9mm

3
0.1%
1%
5%
30%
40%
70%
90%
100%
10%
20%
50%
60%
80%
Frequency(Hz)
Modulation(%)
1.00%
10.00%
100.00%
0.10%
110 100 1000 100003125
Modulation Area Diagram
High Frequency Exemption Area Diagram
Marks in the right chart weretestedresults of different current ranges.
Theoutputfrequenyis0Hzin100%brightnessanditscorresponding
modulation is0%, whichcould notbeshownintherightchart.
IEEE 1789
f
f
≤ 8Hz
≤ 10Hz
limit (%)
Exemption assessment
(High frequency exemption)
f
f
f
f
f
f
f
f
f
f
≤ 90Hz
≤ 90Hz
≤ 1250Hz
≤ 3125Hz
8Hz <
10Hz <
90Hz <
90Hz <
> 1250Hz
> 3125Hz
0.2
0.1
0.025 ×
0.01 ×
0.08 ×
(0.08/2.5) ×
limit (%)
Limit of Modulation in low risk area
Limit of Modulation in no effect area
Waveform frequency of Optical output
Waveform frequency of Optical output
Exemption assessment
Brightness
Flicker Test Form
www.ltech-led.com
0-10V
Push DIM
50%50%50%
1.0
0.9
30% 90
25% 85
85
20% 80
10% 65
70
60
0% 50
55
0.7
0.8
0.75
0.85
0.95
60%60%60% 70%70%70% 80%80%80% 90%90%90% 100%100%100%
PF
200 350 500 600 700 900
0
10
20
30
40
50
60
200mA
200mA200mA 350mA
350mA350mA 500mA
500mA500mA
900mA
900mA900mA 700mA
700mA700mA
1200mA
1200mA1200mA
600mA
600mA600mA
1050mA
1050mA1050mA
AD-15-100-700-E1A1
AD-25-150-900-E1A1
AD-36-200-1200-E1A1
50%50%50%
30%
25%
20%
10%
0% 50
60
55
70
65
80
75
85
0.7
0.75
0.8
0.85
0.9
0.95
60%60%60% 70%70%70% 80%80%80% 90%90%90% 100%100%100%
PF
100
0
10
20
30
40
50
60
180 300 350 450
100mA
100mA 100mA 180mA
180mA 180mA 300mA
300mA 300mA
500mA
500mA 500mA 450mA
450mA 450mA
700mA
700mA 700mA
350mA
350mA 350mA
600mA
600mA 600mA
1050 1200
500 600 700
50%50%50%
25%
15%
5%
20%
10%
0% 50
55
65
75
85
60
70
80
90
0.70
0.80
0.90
0.95
0.75
0.85
1
60%60%60% 70%70%70% 80%80%80% 90%90%90% 100%100%100%
PF
150
0
10
20
30
40
50
60
250 300 350 500 600 700
150mA
150mA
150mA 250mA
250mA
250mA 300mA
300mA
300mA
600mA
600mA
600mA 500mA
500mA
500mA
900mA
900mA
900mA
350mA
350mA
350mA
700mA
700mA
700mA
900
Relationship Diagrams
THD[%]THD[%]THD[%]
THD vs Load
Load [%] Load [%]
Load [%]
Load [%]
Load [%]
Load [%]
Load [%]
Load [%]
Load [%]
Efficiency[%]Efficiency[%]Efficiency[%]
VO[V]VO[V]VO[V]
IO[MA]
IO[MA]
IO[MA]
Efficiency vs Load
Power Factor Characteristic Current vs Voltage
Installation Precautions
≥15cm
≥15cm
≥15cm ≥15cm
≥15cm
Please do not stack the products. The distance between two products should be≥15cm so as not
to affect heat dissipation and the lifespan of the products.
Please not place the products on LED drivers. The distance between the product and the driver
should be ≥15cm so as not to affect heat dissipation and shorten the lifespan of the products.

4www.ltech-led.com
0-10V
Push DIM
Products shall be installed by qualified professionals.
LTECH products are non-waterproof (special models excepted). Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof enclosure.
Good heat dissipation will extend the working life of products. Please ensure good ventilation.
Please check if the working voltage used complies with the parameter requirements of products.
The diameter of wire used must be able to load the light fixtures you connect and ensure the firm wiring.
Before you power on products, please make sure all the wiring is correct in case of incorrect connection that causes damage to light fixtures.
If a fault occurs, please do not attempt to fix products by yourself. If you have any question, please contact your suppliers.
This manual is subject to changes without further notice. Product functions depend on the goods. Please feel free to contact our official distributors if you have any question.
Attentions
Warranty periods from the date of delivery: 5 years.
Free repair or replacement services for quality problems are provided within warranty periods.
Warranty Agreement
Warranty exclusions below:
Beyond warranty periods.
Any artificial damage caused by high voltage, overload, or improper operations.
Products with severe physical damage.
Damage caused by natural disasters and force majeure.
Warranty labels and barcodes have been damaged.
No any contract signed by LTECH.
1. Repair or replacement provided is the only remedy for customers. LTECH is not liable for any incidental or consequential damage unless it is within the law.
2. LTECH has the right to amend or adjust the terms of this warranty, and release in written form shall prevail
Update Log
Version Update Content
Updated Time
A5 Increase constant current test table; increase 50,000 hours of life
2020.03.30
Updated by
Liu Weili
A6 Increase the low-frequency current ripple; change the product silk screen
2021.12.10 Liu Weili
